STRUCTURE AND OPERATIONTM-35
< SYSTEM DESCRIPTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Rear planetary gear
Mid planetary gear
“D6” and “M6” Positions
Name Rear sun gear Rear carrier Rear internal gear
Condition — input/Output —
Direction of rotation Clockwise revolution Clockwise revolution Clockwise revolution
Number of revolutions Same number of revolution as the
rear carrier Same number of revolution as the
input shaft Same number of revolution as the
rear carrier
Name Mid sun gear Mid carrier Mid internal gear
Condition — Output Input
Direction of rotation Clockwise revolution Clockwise revolution Clockwise revolution
Number of revolutions Same number of revolution as the
mid internal gear Same number of revolution as the
mid internal gear Same number of revolution as the
input shaft
Revision: 2010 May2011 QX56

STRUCTURE AND OPERATIONTM-37
< SYSTEM DESCRIPTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Front planetary gear
Rear planetary gear
Mid planetary gear
“D7” and “M7” Positions
Name Front sun gear Front carrier Front internal gear
Condition Fixed Output Input
Direction of rotation — Clockwise revolution Clockwise revolution
Number of revolutions — Deceleration from front internal
gear Same number of revolution as the
input shaft
Name Rear sun gear Rear carrier Rear internal gear
Condition — Input/Output Input
Direction of rotation Clockwise revolution Clockwise revolution Clockwise revolution
Number of revolutions Acceleration from rear carrier Same number of revolution as the
input shaft Same number of revolution as the
front carrier
Name Mid sun gear Mid carrier Mid internal gear
Condition — Output Input
Direction of rotation Clockwise revolution Clockwise revolution Clockwise revolution
Number of revolutions Acceleration from mid internal gear Acceleration from mid internal gear Same number of revolution as the
input shaft
Revision: 2010 May2011 QX56

STRUCTURE AND OPERATIONTM-39
< SYSTEM DESCRIPTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Front planetary gear
Under drive planetary gear
Rear planetary gear
Mid planetary gear
“R” Position
Name Front sun gear Front carrier Front internal gear
Condition — Output Input
Direction of rotation Counterclockwise revolution Clockwise revolution Clockwise revolution
Number of revolutions Deceleration from front internal
gear Deceleration from front internal
gear Same number of revolution as the
input shaft
Name Under drive sun gear Under drive carrier Under drive internal gear
Condition — Fixed Input/Output
Direction of rotation Counterclockwi se revolution — Clockwise revolution
Number of revolutions Acceleration from under drive inter-
nal gear —
Same number of revolution as the
front carrier
Name Rear sun gear Rear carrier Rear internal gear
Condition — Input/Output Input
Direction of rotation Clockwise revolution Clockwise revolution Clockwise revolution
Number of revolutions Acceleration from rear carrier Same number of revolution as the
input shaft Same number of revolution as the
under drive internal gear
Name Mid sun gear Mid carrier Mid internal gear
Condition — Output Input
Direction of rotation Clockwise revolution Clockwise revolution Clockwise revolution
Number of revolutions Acceleration from mid internal gear Acceleration from mid internal gear Same number of revolution as the
input shaft
Revision: 2010 May2011 QX56

TM-40
< SYSTEM DESCRIPTION >[7AT: RE7R01B]
STRUCTURE AND OPERATION
 The 1st one-way clutch and the front brake regulate c
ounterclockwise rotation of the under drive carrier.
NOTE:
The front brake operates at the fixed speed or less.
 The rear carrier and the mid internal gear are fixed by the reverse brake.
 The mid sun gear rotates at the same speed as the rear sun gear by operation of the 2nd one-way clutch
and the high and low reverse clutch.
NOTE:
The high and low reverse clutch operates at the fixed speed or less.
JSDIA0875GB
Revision: 2010 May2011 QX56

STRUCTURE AND OPERATIONTM-41
< SYSTEM DESCRIPTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
 Each planetary gear enters the state described below.
Front planetary gear
Under drive planetary gear
Rear planetary gear
Mid planetary gear
TRANSMISSION : Component DescriptionINFOID:0000000006226765
FLUID COOLER & FLUID WARMER SYSTEM
FLUID COOLER & FLUID WARMER SYSTEM : System DescriptionINFOID:0000000006226766
The A/T fluid temperature is controlled to an appropriate level by the A/T fluid cooler and A/T fluid warmer.
Name Front sun gear Front carrier Front internal gear
Condition — Output Input
Direction of rotation Counterclockwise revolution Clockwise revolution Clockwise revolution
Number of revolutions Deceleration from front internal
gear Deceleration from front internal
gear Same number of revolution as the
input shaft
Name Under drive sun gear Under drive carrier Under drive internal gear
Condition — Fixed Input/Output
Direction of rotation Counterclockwi se revolution — Clockwise revolution
Number of revolutions Acceleration from under drive inter-
nal gear —Same number of revolution as the
front carrier
Name Rear sun gear Rear carrier Rear internal gear
Condition Output Fixed Input
Direction of rotation Counterclockwi se revolution — Clockwise revolution
Number of revolutions Acceleration from rear internal
gear —Same number of revolution as the
under drive internal gear
Name Mid sun gear Mid carrier Mid internal gear
Condition Input Output Fixed
Direction of rotation Counterclockwise revolution Counterclockwise revolution —
Number of revolutions Same number of revolution as the
rear sun gear Deceleration from mid sun gear —
Name of the Part (Abbreviation) Function
Front brake (FR/B) Fastens the under drive carrier.
Input clutch (I/C) Connects the input shaft, the mid internal gear and the rear carrier.
Direct clutch (D/C) Connects the rear carrier and the rear sun gear.
High and low reverse clutch (HLR/C) Connects the rear sun gear and the mid sun gear.
Reverse brake (R/B) Fastens the rear carrier.
Low brake (L/B) Fastens the mid sun gear.
2346 brake (2346/B) Fastens the under drive sun gear.
1st one-way clutch (1st OWC) Allows the under drive carrier to turn freely in the forward direction but fastens it for reverse
rotation.
2nd one-way clutch (2nd OWC) Allows the rear sun gear to turn freely in the forward direction but fastens it for reverse ro-
tation.
Torque converter Amplifies driving force the engine, and transmits it to transmission input shaft.
Oil pump Driven by the engine, oil pump supplies oil to torque converter, control valve assembly, and
each lubricating system.
Revision: 2010 May2011 QX56

TM-206
< UNIT REMOVAL AND INSTALLATION >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
8. Remove exhaust front tube (RH and LH) and main muffler. Refer to
EX-5, "Exploded View".
9. Separate propeller shaft assembly. Refer to DLN-144, "
Removal and Installation".
NOTE:
Cap or plug opening to prevent fluid from spilling.
10. Remove front under cover with a power tool. Refer to EXT-25, "
Removal and Installation".
11. Remove protector A and B. Refer to SCS-32, "
FRONT TUBE ASSEMBLY : Exploded View".
12. Remove front suspension rear cross member.
13. Remove crankshaft position sensor (POS) from A/T assembly. Refer to EM-106, "
Exploded View".
CAUTION:
 Never subject it to impact by dropping or hitting it.
 Never disassemble.
 Never allow metal filings, etc. to ge t on the sensor's front edge magnetic area.
 Never place in an area affected by magnetism.
14. Remove rear plate cover. Refer to EM-54, "
Exploded View".
15. Turn crankshaft, and remove the four tight ening bolts for drive plate and torque converter.
CAUTION:
When turning the crankshaft, turn it clockw ise as viewed from the front of the engine.
16. Remove A/T fluid cooler tube A and D. Refer to TM-202, "
Exploded View".
NOTE:
Cap or plug openings to prevent fluid from spilling.
17. Remove bolts fixing A/T assembly to engine with a power tool.
18. Disconnect connector from A/T assembly.
19. Remove harness and brackets from A/T assembly.
20. Remove A/T assembly from the vehicle. CAUTION:
 Secure torque converter to prevent it from dropping.
 Secure A/T assembly to a transmission jack.
21. Remove air breather hose and bracket. Refer to TM-199, "
2WD
: Exploded View".
22. Remove manual lever from A/T assembly. Refer to TM-178,
"Exploded View".
INSTALLATION
Note the following, and Install in the reverse order of removal.
 Check fitting of dowel pin ( ).
ATA0025D
JSDIA1597ZZ
Revision: 2010 May2011 QX56

TRANSMISSION ASSEMBLYTM-207
< UNIT REMOVAL AND INSTALLATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
 When installing A/T assembly to the engine, be sure to check dimension “A” to ensure it is within the reference value limit.
 When installing A/T assembly to the engine, attach the fixing bolts in accordance with the following standard.
*: Tightening the bolt with bracket (and washer). Refer to TM-199, "2WD : Exploded View".
 Align the positions of tightening bolts for drive plate with those of the torque converter, and temporarily
tighten the bolts. Then, tighten the bolts with the specified torque.
CAUTION:
 When turning crankshaft, turn it clockwise as viewed from the front of the engine.
 When tightening the tightening bolts for the torq ue converter after fixing the crankshaft pulley
bolts, be sure to confirm the tightening torque of the crankshaft pulley mounting bolts. Refer to
EM-62, "
Removal and Installation".
 Rotate crankshaft several turns and check to be sure that A/T rotates freely without binding after
converter is installed to drive plate.
2WD : Inspection and AdjustmentINFOID:0000000006233265
INSPECTION AFTER INSTALLATION
 Check A/T fluid leakage. Refer to TM-175, "Inspection".
 Check A/T position after adjusting A/T position. Refer to TM-101, "
Inspection".
ADJUSTMENT AFTER INSTALLATION
 Adjust A/T fluid level. Refer to TM-95, "Adjustment".
 Adjust A/T position. Refer to TM-101, "
Adjustment".
 Perform decel G sensor calibration when replacing A/T assembly. Refer to TM-91, "
Special Repair Require-
ment".
4WD
B: Scale
C : Straightedge
Dimension “A” : Refer to TM-297, "Torque Convert-
er".
JPDIA0042ZZ
Bolt symbol A
Insertion direction A/T assembly to engine
Number of bolts 9
Bolt length “L”
mm (in) 70 (2.76)
Tightening torque
N·m (kg-m, ft-lb) 113 (12, 83)
JSDIA1598ZZ
Revision: 2010 May2011 QX56

TRANSMISSION ASSEMBLYTM-209
< UNIT REMOVAL AND INSTALLATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
12. Remove crankshaft position sensor (POS) from A/T assembly. Refer to EM-106, "Exploded View".
CAUTION:
 Never subject it to impact by dropping or hitting it.
 Never disassemble.
 Never allow metal filings, etc. to get on the sensor's front edge magnetic area.
 Never place in an area affected by magnetism.
13. Remove rear plate cover. Refer to EM-54, "
Exploded View".
14. Turn crankshaft, and remove the four tightening bolts for drive plate and torque converter. CAUTION:
When turning the crankshaft, turn it clock wise as viewed from the front of the engine.
15. Remove A/T fluid cooler tube A and D. Refer to TM-202, "
Exploded View".
NOTE:
Cap or plug openings to prevent fluid from spilling.
16. Support transfer assembly with a transmission jack.
17. Remove bolts fixing A/T assembly to engine with a power tool.
18. Disconnect connectors from A/T assembly and transfer assembly.
19. Remove harness and brackets from A/T assembly and transfer assembly.
20. Remove A/T assembly with transfer assembly from the vehicle. CAUTION:
 Secure torque converter to prevent it from dropping.
 Secure A/T assembly to a transmission jack.
21. Remove air breather hoses and bracket. Refer to TM-200, "
4WD
: Exploded View" (for A/T) and DLN-121, "Removal and Installa-
tion" (for transfer).
22. Remove manual lever from A/T assembly. Refer to TM-178,
"Exploded View".
23. Remove transfer assembly from A/T assembly with power tool. Refer to DLN-121, "
Removal and Installation".
NOTE:
Cap or plug opening to prevent fluid from spilling.
INSTALLATION
Note the following, and Install in the reverse order of removal.
 Check fitting of dowel pin ( ).
 When installing A/T assembly to the engine, be sure to check dimension “A” to ensure it is within the reference value limit.
SCIA2203E
JSDIA1597ZZ
B: Scale
C : Straightedge
Dimension “A” : Refer to TM-297, "Torque Convert-
er".
JPDIA0042ZZ
Revision: 2010 May2011 QX56

TM-210
< UNIT REMOVAL AND INSTALLATION >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
 When installing A/T assembly to the engine, attach the fixing bolts
in accordance with the following standard.
*: Tightening the bolt with bracket (and washer). Refer to TM-200, "4WD : Exploded View".
 Align the positions of tightening bolts for drive plate with those of the torque converter, and temporarily
tighten the bolts. Then, tighten the bolts with the specified torque.
CAUTION:
 When turning crankshaft, turn it clockwi se as viewed from the front of the engine.
 When tightening the tightening bolts for the torque converter after fixing the crankshaft pulley
bolts, be sure to confirm the tightening torque of the crankshaft pulley mounting bolts. Refer to
EM-62, "
Removal and Installation".
 Rotate crankshaft several turns and check to be sure that A/T rotates freely without binding after
converter is installed to drive plate.
4WD : Inspection and AdjustmentINFOID:0000000006226912
INSPECTION AFTER INSTALLATION
 Check A/T fluid leakage.
 Check A/T position after adjusting A/T position. Refer to TM-101, "
Inspection".
ADJUSTMENT AFTER INSTALLATION
 Adjust A/T fluid level. Refer to TM-95, "Adjustment".
 Adjust A/T position. Refer to TM-101, "
Inspection".
 Perform decel G sensor calibration w hen replacing A/T assembly. Refer to TM-91, "
Special Repair Require-
ment".
Bolt symbol A
Insertion direction A/T assembly to engine
Number of bolts 9
Bolt length “L”
mm (in) 70 (2.76)
Tightening torque
N·m (kg-m, ft-lb) 113 (12, 83)
JSDIA1598ZZ
Revision: 2010 May2011 QX56

TM-268
< UNIT DISASSEMBLY AND ASSEMBLY >[7AT: RE7R01B]
TRANSMISSION ASSEMBLY
Check torque converter one-way clutch using a check tool as shown
at figure.
1. Insert a check tool into the groove of bearing support built into
one-way clutch outer race.
2. When fixing bearing support with a check tool, rotate one-way clutch spline using a screwdriver.
3. Make sure that inner race rotates clockwise only. If not, replace
torque converter assembly.
1st One-way Clutch
Check operation of 1st one-way clutch.
1. Install 1st one-way clutch (1) to front brake hub (with under drivecarrier).
2. Hold 1st one-way clutch.
3. Check front brake hub for correct locking and unlocking direc- tions. If necessary, replace 1st one-way clutch.
Under Drive Sun Gear
Check for deformation, fatigue or damage. If necessary, replace the under drive sun gear.
Mid Carrier Assembly
Check for deformation, fatigue or damage. If necessary, replace the mid carrier assembly.
Rear Carrier Assembly
Check for deformation, fatigue or damage. If necessary, replace the rear carrier assembly.
Reverse Brake Drive Plates
Check facing for burns, cracks or damage. If necessary, replace the plate.
Reverse Brake Retaining Plate, Driven Plates and Dish Plates
Check facing for burns, cracks or damage. If necessary, replace the plate.
Each Snap Ring
Check for deformation, fatigue or damage. If necessary, replace the snap ring.
Parking Actuator Support and Parking Pawl
SCIA3171E
: Unlocked
: Locked
JSDIA1713ZZ
Revision: 2010 May2011 QX56
