ISUZU TF SERIES 2004 Workshop Manual

MANUAL TRANSMISSION 7B1-117

4. OIL LEAKAGE

Checkpoint Trouble Cause Countermeasure

Gear oilReplace the gear oilImproper gear oil
Drain plug and/or filler plugTighten the plug(s) and
replenish the oil
Drain the oil to the correct
level
Loose plug(s)
Oil level too high
OKNG NG NG
OK OKOil level
Rear cover oil seal
Air breather
Replace the oil seal
Install the air breather
Replace the air breather
Worn or scratched oil seal
Air breather not installed
Air breather clogged
Front cover oil sealReplace the oil seal
Replace the gasket(s)
Worn or scratched oil seal
Defective or improperly
installed gasket(s)
OK
NG NG NG NG
OK OKGaskets

7B1-118 MANUAL TRANSMISSION

Special Tools (4





4)

ILLUSTRATION TOOL NO.
TOOL NAME ILLUSTRATION TOOL NO.
TOOL NAME
5-8840-2158-0
Mainshaft collar remover 5-8840-2159-0
Mainshaft end bearing
installer
5-8840-2027-0
Puller 5-8840-0015-0
Bearing
remover/installer
5-8840-2160-0
Holding fixture 5-8840-2797-0
Rear case oil seal
installer
5-8840-0003-0
Holding fixture base 5-8840-0026-0
Front cover oil seal
installer
5-8840-2156-0
Wrench 9-8522-1165-0
Mainshaft collar remover
5-8840-0047-0
Tork bit wrench
(T–45) 5-8840-0007-0
Driver handle

No. TFMUA-WE-0431

WORKSHOP MANUAL

TF SERIES




SECURITY






SECTION 11

IMMOBILIZER SYSTEM 11A-1

SECTION 11A
IMMOBILIZER SYSTEM
CONTENTS

Service Precaution.................................................
11A-2
General Description...............................................
11A-3
What happens without proper transponder
operation? ..........................................................
11A-6
No proper transponder is available, what
should be done for the system? ......................
11A-6
Caution to the operation.....................................
11A-6
Summary of operation........................................
11A-6
What your organization should provide for
your customer ....................................................
11A-6
Car Pass .............................................................
11A-6
Security code management ..............................
11A-6
Essential tool (Scan tool : Tech-2) ..................
11A-6
Circuit Diagram .................................................
11A-7
Parts Location.........................................................
11A-10
Immobilizer control unit (ICU); For Electronic
Control Engine (6VE1, C24SE, 4JH1-TC,
4JA1-TC) .......................................................... 11A-11
Pin-outs; For Electronic Control Engine
(6VE1, C24SE, 4JH1-TC, 4JA1-TC)...............
11A-12
Immobilizer control unit (ICU); Mechanical
Control Engine (4JA1-T) .................................. 11A-13
Immobilizer coil (Antenna) ...................................
11A-15
Transponder (Key) ............................................ 11A-15
Immobilizer warning lamp ................................. 11A-15
Engine control module (ECM) .......................... 11A-15
Car Pass Card .................................................. 11A-16
Loss of car pass card.........................................
11A-16
Instructions on Filling Out the form "Data
request, car pass" .............................................
11A-16
Important Instructions ........................................
11A-17
lmportant information on Programming .............
11A-19
Security code ......................................................
11A-19
Entering a code ..................................................
11A-19
Transponder (Key) .............................................
11A-19
Important .............................................................
11A-19
Tech-2 Scan Tool ..................................................
11A-20
Tech-2 Features .................................................
11A-21
Getting Started ...................................................
11A-21
Operating Procedure .........................................
11A-22
Menu ....................................................................
11A-23
DTC ......................................................................
11A-23
Clear DTC Information .......................................
11A-23
Tech-2 Data Display ...........................................
11A-23
Check Vehicle Identification Number (VIN) ....
11A-23
Reset Immobilizer (Reset Immobilizer
Control Unit) .......................................................
11A-23
Reset Engine Control Module (Reset ECM) ...
11A-24
Erase transponder key .......................................
11A-24
Programming Immobilizer Function .................
11A-25
Programming ICU ...............................................
11A-26
Programming ECM .............................................
11A-27
Programming ICU and ECM .............................
11A-28
Transponder program ........................................
11A-28
Data List ...............................................................
11A-30
Diagnostic procedure ............................................
11A-31
Clearing Diagnostic Trouble Codes ....................
11A-31
Verifying Vehicle Repair ........................................
11A-31
Diagnostic Aids ......................................................
11A-31
Check the condition for system parts ..............
11A-31
Check the Electro-Magnetic Interference
(EMI) ....................................................................
11A-31
Check the other items ........................................
11A-31
Check the operation ...........................................
11A-31
Diagnostic Trouble Code (DTC) list ....................
11A-32
IMMOBILIZER SYSTEM CHECK ........................
11A-33
NO IMMOBILIZER WARNING LAMP .................
11A-36
IMMOBILIZER WARNING LAMP ON STEADY 11A-37
B0001 REPLACE ELECTRONIC CONTROL
UNIT (ECU) (IMMOBILIZER FAULT) ................
11A-38
B0002 IMMOBILIZER NOT PROGRAMMED ....
11A-39
B0003 TRANSPONDER KEY PROBLEM ..........
11A-40
B0004 IMMOBILIZER COIL CIRCUIT
(ANTENNA COIL FAULT) ...................................
11A-42
B0005 COMMUNICATION LINE W VOLTAGE
LOW .......................................................................
11A-43
B0006 COMMUNICATION LINE W VOLTAGE
HIGH .......................................................................
11A-44
B0007 NO ENGINE REQUEST RECEIVED ......
11A-45
B0008 WRONG TRANSPONDER KEY .............
11A-47
B0009 NO TRANSPONDER KEY
PROGRAMMED ...................................................
11A-48

11A-2 IMMOBILIZER SYSTEM

B0010 UNKNOWN TRANSPONDER KEY .......
11A-49
B0011 TRANSPONDER KEY PROBLEM
(Only 4JA1-T Engine) ...................................... 11A-50
B0012 WRONG TRANSPONDER KEY
(Only 4JA1-T Engine) ...................................... 11A-52
B0013 IMMOBILIZER NOT PROGRAMMED
(Only 4JA1-T Engine) ...................................... 11A-53
B0014 NO TRANSPONDER KEY
PROGRAMMED (Only 4JA1-T Engine) ........... 11A-54
B0015 VEHICLE SPEED SIGNAL LOW
(Only 4JA1-T Engine) ....................................... 11A-55
B0016 VEHICLE SPEED SIGNAL HIGH
(Only 4JA1-T Engine) ...................................... 11A-56
B0023 IMMOBILIZER COIL CIRCUIT
(ANTENNA COIL FAULT)
(Only 4JA1-T Engine) ...................................... 11A-57
B0024 WRONG TRANSPONDER KEY
(Only 4JA1-T Engne) ....................................... 11A-58
B0055 EEPROM ERROR ................................. 11A-59
Special Tool ............................................................
11A-60

Service Precaution
WARNING: THIS VEHICLE HAS A SUPPLEMENTAL
RESTRAINT SYSTEM (SRS). REFER TO THE SRS
COMPONENT AND WIRING LOCATION VIEW IN
ORDER TO DETERMINE WHETHER YOU ARE
PERFORMING SERVICE ON OR NEAR THE SRS
COMPONENTS OR THE SRS WIRING. WHEN YOU
ARE PERFORMING SERVICE ON OR NEAR THE
SRS COMPONENTS OR THE SRS WIRING, REFE
R
TO THE SRS SERVICE INFORMATION. FAILURE TO
FOLLOW WARNINGS COULD RESULT IN
POSSIBLE AIR BAG DEPLOYMENT, PERSONAL
INJURY, OR OTHERWISE UNNEEDED SRS SYSTEM
REPAIRS.



CAUTION: Always use the correct fastener in the
proper location. When you replace a fastener, use
ONLY the exact part number for that application.
ISUZU will call out those fasteners that require a
replacement after removal. ISUZU will also call out
the fasteners that require thread lockers or thread
sealant. UNLESS OTHERWISE SPECIFIED, do not
use supplemental coatings (Paints, greases, o
r
other corrosion inhibitors) on threaded fasteners o
r
fastener joint interfaces. Generally, such coatings
adversely affect the fastener torque and the joint
clamping force, and may damage the fastener.
When you install fasteners, use the correct
tightening sequence and specifications. Following
these instructions can help you avoid damage to
parts and systems.

IMMOBILIZER SYSTEM 11A-3

General Description
The immobilizer system consists of the four major
components which are Engine Control Module (ECM),
Immobilizer Control Unit (lCU), transponder, and scan
tool (Tech-2).
This system can be activated by a correctly programmed
transponder and starter switch is set to OFF.
This system can be deactivated by a correctl
y
programmed transponder key connected with a correctly
programmed ECM and a correctly programmed lCU.
While the system is on :
The starter cut off relay deactivates function of starter,
and the fuel injector power source is deactivated also.


Check Engine lamp is flashing.


Warning buzzer is operating.
(With antitheft system)






Gasoline Engine (6VE1, C24SE)

LTW3BALF000101

11A-4 IMMOBILIZER SYSTEM

Diesel Engine With ECM (4JH1-TC/4JA1-TC)

LTW3BALF000201
