* S U SPEN SIO N U NIF O RM IN SPEC TIO N G UID ELIN ES *
1 988 J e ep C hero ke e
GENERAL INFORMATION
Steering, Suspension, Wheel Alignment, Wheels and Tires
Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
Motorist Assurance Program (MAP)
OVERVIEW
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Steering and Suspension
AIR RIDE SUSPENSION
AIR RIDE SUSPENSION - AIR SHOCKS AND AIR STRUTS
AIR RIDE SUSPENSION - AIR SPRING VALVES
AIR RIDE SUSPENSION - AIR SPRINGS
AIR RIDE SUSPENSION - COMPRESSORS
AIR RIDE SUSPENSION - HEIGHT SENSORS
AIR RIDE SUSPENSION - MODULES
AIR RIDE SUSPENSION - RELAYS (COMPRESSOR)
AIR RIDE SUSPENSION - SWITCHES (ON/OFF)
AIR RIDE SUSPENSION - TORSION SPRINGS (COUNTER BALANCING)
AIR RIDE SUSPENSION - TUBING
AIR RIDE SUSPENSION - WARNING LAMPS
AIR RIDE SUSPENSION - WIRING HARNESSES
BALL JOINTS
BUSHINGS
CENTER LINKS
CONTROL ARM SHAFTS
CONTROL ARMS
DRAG LINKS
ELECTRONIC RIDE CONTROL SHOCKS AND STRUTS
IDLER ARMS
KING PINS
PITMAN ARMS
POWER STEERING HOSES
POWER STEERING (HYDRAULIC) PUMPS
RADIUS ARMS
RELAY RODS
SHOCK ABSORBERS, STRUT CARTRIDGES AND STRUT ASSEMBLIES
SPINDLES
SPRINGS - COIL, LEAF AND TORSION BAR
STEEL POWER STEERING LINES
STEERING ARMS
STEERING DAMPERS
STEERING GEARS (EXCEPT RACK AND PINION)
STEERING GEARS - RACK AND PINION
STEERING KNUCKLES
STRIKE OUT BUMPERS
STRUT RODS
STRUT UPPER BEARING PLATE ASSEMBLIES
SWAY BAR LINKS
SWAY BARS
Page 1132 of 1378
TIE ROD ENDS (INNER AND OUTER)
TRACK BARS
TRAILING ARMS
WHEEL BEARINGS, RACES AND SEALS
Wheel Alignment
WHEEL ALIGNMENT
Wheels and Tires
TIRES
VALVE STEMS
WHEEL ATTACHMENT HARDWARE
WHEELS (RIMS)
MOTORIST ASSURANCE PROGRAM (MAP)
OVERVIEW
The Motorist Assurance Program is the consumer outreach
effort of the Automotive Maintenance and Repair Association, Inc.
(AMRA). Participation in the Motorist Assurance Program is drawn from
retailers, suppliers, independent repair facilities, vehicle
manufacturers and industry associations.
Our organization's mission is to strengthen the relationship
between the consumer and the auto repair industry. We produce
materials that give motorists the information and encouragement to
take greater responsibility for their vehicles-through proper,
manufacturer-recommended, maintenance. We encourage participating
service and repair shops (including franchisees and dealers) to adopt
1) a Pledge of Assurance to their Customers and 2) the Motorist
Assurance Program Standards of Service. All participating service
providers have agreed to subscribe to this Pledge and to adhere to the
promulgated Standards of Service demonstrating to their customers that
they are serious about customer satisfaction.
These Standards of Service require that an inspection of the
vehicle's (problem) system be made and the results communicated to the\
customer according to industry standards. Given that the industry did
not have such standards, the Motorist Assurance Program successfully
promulgated industry inspection communication standards in 1994-95 for
the following systems: Exhaust, Brakes, ABS, Steering and Suspension,
Engine Maintenance and Performance, HVAC, and Electrical Systems.
Further, revisions to all of these inspection communication standards
are continually re-published. In addition to these, standards for
Drive Train and Transmissions have recently been promulgated.
Participating shops utilize these Uniform Inspection & Communication
Standards as part of the inspection process and for communicating
their findings to their customers.
The Motorist Assurance Program continues to work
cooperatively and proactively with government agencies and consumer
groups toward solutions that both benefit the customer and are
mutually acceptable to both regulators and industry. We maintain the
belief that industry must retain control over how we conduct our
business, and we must be viewed as part of the solution and not part
of the problem. Meetings with state and other government officials
(and their representatives), concerned with auto repair and/or
consumer protection, are conducted. Feedback from these sessions is
brought back to the association, and the program adjusted as needed.
To assure auto repair customers recourse if they were not
satisfied with a repair transaction, the Motorist Assurance Program
offers mediation and arbitration through MAP/BBB-CARE and other non-
Page 1133 of 1378
profit organizations. MAP conducted pilot programs in twelve states
before announcing the program nationally in October, 1998. During the
pilots, participating repair shops demonstrated their adherence to the
Pledge and Standards and agreed to follow the UICS in communicating
the results of their inspection to their customers. To put some
"teeth" in the program, an accreditation requirement for shops was
initiated. The requirements are stringent, and a self-policing method
has been incorporated which includes the "mystery shopping" of
outlets.
We welcome you to join us as we continue our outreach... with
your support, both the automotive repair industry and your customers
will reap the benefits. Please visit MAP at our Internet site www.
motorist.org or contact us at:
1444 I Street, NW Suite 700
Washington, DC 20005
Phone (202) 712-9042 Fax (202) 216-9646
January 1999
MAP UNIFORM INSPECTION GENERAL GUIDELINES
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
It is MAP policy that all exhaust, brake, steering,
suspension, wheel alignment, drive-line, engine performance and
maintenance, and heating, ventilation and air conditioning, and
electrical services be offered and performed under the standards and
procedures specified in these sections.
Before any service is performed on a vehicle, an inspection
of the appropriate system must be performed. The results of this
inspection must be explained to the customer and documented on an
inspection form. The condition of the vehicle and its components will
indicate what services/part replacements may be "Required" or
"Suggested". In addition, suggestions may be made to satisfy the
requests expressed by the customer.
When a component is suggested or required to be repaired or
replaced, the decision to repair or replace must be made in the
customer's best interest, and at his or her choice given the options
available.
This section lists the various parts and conditions that
indicate a required or suggested service or part replacement.
Although this list is extensive, it is not fully inclusive. In
addition to this list, a technician may make a suggestion. However,
any suggestions must be based on substantial and informed experience,
or the vehicle manufacturer's recommended service interval and must be
documented.
Some conditions indicate that service or part replacement is
required because the part in question is no longer providing the
function for which it is intended, does not meet a vehicle
manufacturer's design specification or is missing.
Example:
An exhaust pipe has corroded severely and has a hole in it
through which exhaust gases are leaking. Replacement of the
exhaust pipe in this case is required due to functional
failure.
Example:
A brake rotor has been worn to the point where it measures
less than the vehicle manufacturer's discard specifications.
Replacement of the rotor is required because it does not meet
design specifications.
Page 1134 of 1378
Some conditions indicate that a service or part replacement
is suggested because the part is close to the end of its useful life
or addresses a customer's need, convenience or request. If a
customer's vehicle has one of these conditions, the procedure may be
only to suggest service.
Example:
An exhaust pipe is rusted, corroded or weak, but no leaks are
present. In this case, the exhaust pipe has not failed.
However, there is evidence that the pipe may need replacement
in the near future. Replacement of the pipe may be suggested
for the customer's convenience in avoiding a future problem.
Example:
The customer desires improved ride and/or handling, but the
vehicle's shocks or struts have not failed. In this case,
replacement may be suggested to satisfy the customer's
wishes. In this case, replacement of the shocks or struts may
not be sold as a requirement.
A customer, of course, has the choice of whether or not a
shop will service his or her vehicle. He or she may decide not to
follow some of your suggestions. When a repair is required, a MAP shop
must refuse partial service on that system if, in the judgment of the
service provider, proceeding with the work could create or continue an
unsafe condition. When a procedure states that required or suggested
repair or replacement is recommended, the customer must be informed of
the generally acceptable repair/replacement options whether or not
performed by the shop.
When presenting suggested repairs to the customer, you must
present the facts, allowing the customer to draw their own conclusions
and make an informed decision about how to proceed.
The following reasons may be used for required and suggested
services. These codes are shown in the "Code" column of the MAP
Uniform Inspection & Communications Standards that follow:
Reasons to Require Repair or Replacement
A - Part no longer performs intended purpose
B - Part does not meet a design specification (regardless of
performance)
C - Part is missing
NOTE: When a repair is required, the shop must refuse partial
service to the system in question, if the repair creates
or continues an unsafe condition.
Reasons to Suggest Repair or Replacement
1 - Part is close to the end of its useful life (just above
discard specifications, or weak; failure likely to occur
soon, etc.)
2 - To address a customer need, convenience, or request (to
stiffen ride, enhance performance, eliminate noise,
etc.)
3 - To comply with maintenance recommended by the vehicle's
Original Equipment Manufacturer (OEM)
4 - Technician's recommendation based on substantial and
informed experience
NOTE: Suggested services are always optional. When presenting
suggested repairs to the customer, you must present
Page 1135 of 1378
the facts, allowing the customer to draw their own
conclusions and make an informed decision about how to
proceed.
STEERING AND SUSPENSION
SERVICE PROCEDURES REQUIRED AND SUGGESTED FOR PROPER VEHICLE
OPERATION
Steering and suspension are complex systems made up of a
variety of interdependent components. For proper vehicle handling,
ride, and tire wear, a thorough inspection is required whenever
suspension work is being performed.
Conditions listed assume that the problem has been isolated
to the specific component by proper testing procedures.
NOTE: When replacing steering and/or suspension components which
may affect an alignment angle, you are required to check
and adjust alignment as needed. Refer to the OEM
specifications.
CAUTION: DO NOT use ride height altering or load compensating
components, such as variable rate springs and coil over
shocks, on vehicles with height or load sensing
proportioning valve-equipped braking systems, unless
these components are original equipment.
AIR RIDE SUSPENSION
NOTE: Depending on the air suspension design, there are some
aftermarket products available to eliminate the air ride
suspension on certain vehicles. If the system has been
eliminated with one of these products, then no service is
suggested or required.
AIR RIDE SUSPENSION - AIR SHOCKS AND AIR STRUTS
NOTE: This section covers the air spring portion of the
air shock or strut. For damping portion of shock
or strut conditions and procedures, refer to the
SHOCK ABSORBERS, STRUT CARTRIDGES AND STRUT ASSEMBLIES
section.
AIR RIDE SUSPENSION - AIR SHOCK AND AIR STRUT INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Inner fabric of air bag
damaged ................ A ............ Require replacement.
Leaking ................. A .. Require repair or replacement.
Outer covering of air bag
is cracked to the extent
that inner fabric of air
bag is visible ......... 1 ............ Suggest replacement.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - AIR SPRING VALVES
AIR RIDE SUSPENSION - AIR SPRING VALVE INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Page 1136 of 1378
Attaching hardware
incorrect .............. A .......... Require replacement of
incorrect part.
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Blocked ................. A .. Require repair or replacement.
Connector bent .......... A .. Require repair or replacement.
Connector broken ........ A ............ Require replacement.
Connector loose ......... A .. Require repair or replacement.
Inoperative ............. A .. Require repair or replacement.
Leaking ................. A .. Require repair or replacement.
Restricted .............. A .. Require repair or replacement.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - AIR SPRINGS
AIR RIDE SUSPENSION - AIR SPRING INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
broken ................. A ... Require replacement of broken
part.
Attaching hardware
incorrect .............. A .......... Require replacement of
incorrect part.
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Collar cracked .......... A ............ Require replacement.
End cap cracked ......... A ............ Require replacement.
Inner fabric of bag
damaged ................ A ............ Require replacement.
Leaking ................. A .. Require repair or replacement.
Outer covering of air bag
is cracked to the extent
that inner fabric of air
bag is visible ......... 1 ............ Suggest replacement.
Piston cracked .......... A ............ Require replacement.
\
\
\
\
\
\
\
Page 1137 of 1378
![JEEP CHEROKEE 1988 Service Repair Manual AIR RIDE SUSPENSION - COMPRESSORS
AIR RIDE SUSPENSION - COMPRESSOR INSPECTION \
\
\
\
\](/img/16/57037/w960_57037-1136.png "JEEP CHEROKEE 1988 Service Repair Manual AIR RIDE SUSPENSION - COMPRESSORS
AIR RIDE SUSPENSION - COMPRESSOR INSPECTION \
\
\
\
\")
AIR RIDE SUSPENSION - COMPRESSORS
AIR RIDE SUSPENSION - COMPRESSOR INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware bent . B ... Require repair or replacement
of bent part.
Attaching hardware
broken ................. A ... Require replacement of broken
part.
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Connector bent .......... A .. Require repair or replacement.
Connector broken ........ A ............ Require replacement.
Connector loose ......... A .. Require repair or replacement.
Does not build pressure . A .......... ( 1) Further inspection
required.
Excessive run time ...... B .......... ( 2) Further inspection
required.
Inoperative ............. A ............ Require replacement.
Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.
( 1) - If failure to build pressure is traced to the
compressor, require replacement.
( 2) - If excessive run time is traced to the compressor,
require replacement.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - HEIGHT SENSORS
AIR RIDE SUSPENSION - HEIGHT SENSOR INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware bent . B ... Require repair or replacement
of bent part.
Attaching hardware
broken ................. A ... Require replacement of broken
part.
Attaching hardware
corroded, affecting
structural integrity .... A .......... Require replacement of
corroded part.
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Attaching hardware
Page 1138 of 1378
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Dust boot missing ....... 2 ........ (1) Suggest replacement.
Dust boot split ......... 2 ........ ( 1) Suggest replacement.
Dust boot torn .......... 2 ........ ( 1) Suggest replacement.
Housing cracked ......... A ............ Require replacement.
Lead routing incorrect .. B .. Require rerouting according to
vehicle manufacturer's
specifications.
Loose ................... B ... Require adjustment to vehicle
manufacturer's specifications.
Missing ................. C ............ Require replacement.
Output signal incorrect . A .. Require repair or replacement.
Wire lead damaged ....... A .. Require repair or replacement.
( 1) - This condition can lead to damage of the sliding magnet,
which, in turn, causes premature sensor failure.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - MODULES
AIR RIDE SUSPENSION - MODULE INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Housing cracked ......... 2 .. Suggest repair or replacement.
Inoperative ............. A ............ Require replacement.
Missing ................. C ............ Require replacement.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - RELAYS (COMPRESSOR)
AIR RIDE SUSPENSION - RELAY (COMPRESSOR) INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Housing cracked ......... 2 ........ ( 1) Suggest replacement.
Intermittent ............ A ............ Require replacement.
Missing ................. C ............ Require replacement.
Output signal incorrect . A ............ Require replacement.
( 1) - If moisture enters the relay, it can reduce life
expectancy or impair function.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - SWITCHES (ON/OFF)
Page 1139 of 1378
![JEEP CHEROKEE 1988 Service Repair Manual AIR RIDE SUSPENSION - SWITCH (ON/OFF) INSPECTION \
\
\
\
\
\
\
Conditio](/img/16/57037/w960_57037-1138.png "JEEP CHEROKEE 1988 Service Repair Manual AIR RIDE SUSPENSION - SWITCH (ON/OFF) INSPECTION \
\
\
\
\
\
\
Conditio")
AIR RIDE SUSPENSION - SWITCH (ON/OFF) INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Broken .................. A ............ Require replacement.
Missing ................. C ............ Require replacement.
Output signal incorrect . A ............ Require replacement.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - TORSION SPRINGS (COUNTER BALANCING)
AIR RIDE SUSPENSION - TORSION SPRING (COUNTER BALANCING) INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware bent . B ... Require repair or replacement
of bent part.
Attaching hardware
broken ................. A ... Require replacement of broken
part.
Attaching hardware
incorrect .............. A .......... Require replacement of
incorrect part.
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Broken .................. A ............ Require replacement.
Missing ................. C ............ Require replacement.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - TUBING
AIR RIDE SUSPENSION - TUBING INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
incorrect .............. A .......... Require replacement of
incorrect part.
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Blocked ................. A .. Require repair or replacement.
Fitting incorrect ....... B ............ Require replacement.
Leaking ................. A .. Require repair or replacement.
Line type incorrect ..... B ............ Require replacement.
Missing ................. C ............ Require replacement.
Restricted .............. A .. Require repair or replacement.
Routed incorrectly ...... B ..... Require routing correction.
Page 1140 of 1378
![JEEP CHEROKEE 1988 Service Repair Manual \
\
\
\
\
\
\
AIR RIDE SUSPENSION - WARNING LAMPS
AIR RIDE SU](/img/16/57037/w960_57037-1139.png "JEEP CHEROKEE 1988 Service Repair Manual \
\
\
\
\
\
\
AIR RIDE SUSPENSION - WARNING LAMPS
AIR RIDE SU")
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - WARNING LAMPS
AIR RIDE SUSPENSION - WARNING LAMP INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Bulb burned out ......... A ............ Require replacement.
Warning light does
not come on during
bulb check ............. .. . Further inspection required to
determine cause.
Warning light flashes ... .. . Further inspection required to
determine cause.
Warning light is
intermittent ........... .. . Further inspection required to
determine cause.
Warning light stays
on after initial
bulb check ............. .. . Further inspection required to
determine cause.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - WIRING HARNESSES
AIR RIDE SUSPENSION - WIRING HARNESS INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Connector bent .......... A .. Require repair or replacement.
Connector broken ........ A .. Require repair or replacement.
Connector loose ......... A .. Require repair or replacement.
Damaged (cut, burned, or
chafed) ................ A .. Require repair or replacement.
Excessive resistance .... B .. Require repair or replacement.
Fuse blown .............. A ............ Require replacement.
Fusible link blown ...... A ............ Require replacement.
Open .................... A .. Require repair or replacement.
Poor ground ............. A .. Require repair or replacement.
Routed incorrectly ...... B .. Require rerouting according to
vehicle manufacturer's
specifications.
Shorted ................. A .. Require repair or replacement.
Terminal bent ........... A .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal corroded ....... A .. Require repair or replacement.
Terminal loose .......... A .. Require repair or replacement.
\
\
\
\
\
\
\
BALL JOINTS
Before requiring or suggesting ball joint replacement, the
approved OEM procedure must be used to measure ball joint wear. The
measurement(s) obtained, along with the vehicle manufacturer's
specifications, must be noted on the inspection report. Some states
require that these measurements also appear on the invoice.
NOTE: The term "perceptible movement," defined as any visible
movement in any direction, has been the industry standard
for determining the need for replacement of follower ball
joints. Some vehicle manufacturers are now publishing
specifications for follower ball joints that were
