VEHICLE CONTROL AND DISPLAY SYMBOLS
JINTRODUCTION7

SPECIFICATIONS
SPECIFICATION NOTATIONS
All torque specifications listed in this service man-
ual are in both metric system and SAE/English sys-
tem.
WARNING: THE USE OF INCORRECT ATTACHING
HARDWARE CAN RESULT IN COMPONENT DAM-
AGE AND/OR PERSONAL INJURY.
During all procedures, it is important to retain the
original attaching hardware. If the hardware is not
reusable, replace new hardware with equivalent
specifications.
METRIC SYSTEM NOTATION
The following conversion chart will assist in con-
verting SAE/English units to equivalent metric
units.
TORQUE SPECIFICATIONS
TORQUE CHARTS
If applicable, torque chart(s) for screws, bolts and
nuts is/are provided at the end of each service infor-
mation group. Refer to the Standard Torque Specifi-
cations chart and the bolt grade/class identification
illustrations (Figs. 7 and 8).
It is important to be aware that the torque values
listed in the chart are based on clean and dry bolt
threads. Reduce the applicable listed torque value by
10 percent when the bolt threads are lubricated with
engine oil and by 20 percent if new, plated bolts are
being tightened.Various sizes of (Torx) head fasteners are used
as attaching hardware for numerous compo-
nents in Jeeptvehicles.
BOLT THREAD AND GRADE/CLASS
IDENTIFICATION
THREAD IDENTIFICATION
SAE and metric bolt/nut threads are different. The
difference is described in the Thread Notation chart.
GRADE/CLASS IDENTIFICATION
The SAE bolt strength grades range from grade 2
to grade 8. The higher the grade number, the greater
the bolt strength. The grade identification is deter-
mined by the line marks on the top of each bolt head
(Fig. 7). The actual bolt strength grade corresponds
to the number of line marks plus 2. For example:
²a grade 2 bolt has no line marks on top of the bolt
head;
²a grade 5 bolt has 3 line marks on top of the bolt
head;
²a grade 7 bolt has 5 line marks on top of the bolt
head; and
²a grade 8 bolt has 6 line marks on top of the bolt
head.
The most commonly used metric bolt strength
classes are 9.8 and 12.9. The metric strength class
identification number is imprinted on the head of the
bolt (Fig. 8). The higher the class number, the
greater the bolt strength. Some metric-dimension
nuts are also imprinted with a single-digit strength
class identification number on the nut face.
CONVERSION FORMULAS AND EQUIVALENT VALUES
8 INTRODUCTIONJ

STANDARD TORQUE VALUES
THREAD NOTATIONÐSAE AND METRIC
Fig. 7 SAE Bolt Grade Identification
Fig. 8 Metric Bolt Class Identification
JINTRODUCTION9

TORQUE CONVERSION
10 INTRODUCTIONJ
