connector JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual

C102 (DIESEL) - BLACK (LEFT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
1 D21 18PK
2 D25 18VT/YL
3 K226 18DB/WT
4 D52 18LG/VT
5 D51 18DG/WT
6 B22 18DG/YL
7 F991 20OR/DB
8 T752 18DG/OR
9 K236 18GY/PK
10 K132 18BR/PK
11 A82 18PK/LG
12 K152 18WT
13 L50 18WT/TN
14 K29 18WT/PK
C102 (DIESEL) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 D21 20PK
2 D25 20VT/YL
3 K226 20DB/WT
4 D52 16DG/WT
5 D51 16WT
6 B22 20DG/YL
7 F991 20RD/DB
8 T752 20DG/RD
9 K236 20GY/PK
10 K132 20BR/PK
11 A82 16PK/DG
12 K152 20WT
13 L50 20WT/DB
14 K29 20WT/PK
C102 (GAS RHD) - BLACK (RIGHT HEADLAMP
AND DASH SIDE)
CAV CIRCUIT
1 A30 14RD/WT (4.7L)
2 F991 20OR/DB
3 K173 18LG
4 F42 18DG/LG
5 A7 14RD/BK
6 L1 18VT/BK
7 Z306 20BK/LG
8 T41 18BK/WT
9-
10 K4 20BK/LB
11 K200 18VT/OR (4.7L)
12 C2 18DB/YL
13 -
14 A142 14DG/OR
8W - 80 - 14 8W-80 CONNECTOR PIN-OUTWJ

C102 (GAS RHD) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 A30 14RD/WT (4.7L)
2 F991 18OR/DB
3 K173 18LG
4 F42 18DG/LG
5 A7 14RD/BK
6 L1 18VT/BK
7 Z306 20BK/LG
8 T41 18BK/WT
9-
10 K4 18BK/LB
11 K200 18VT/OR (4.7L)
12 C2 18DB/YL
13 -
14 A142 14DG/OR
C103 (DIESEL) - GRAY (LEFT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
1 T41 18BK/WT
2 K173 18LG
3 C2 18DB/PK
4-
5 F142 14OR/DG
6 K51 18DB/YL
7 K25 18VT/LG
8 Y42 18OR/DB
9 C18 18DB
10 K4 20BK/LB
11 K6 18VT/WT
12 -
13 T40 12BR
14 F15 18DB/WT
C103 (DIESEL) - GRAY (ENGINE SIDE)
CAV CIRCUIT
1 T41 20BK/WT
2 K173 20GY
3 C3 14DB/BK
4-
5 F142 16RD/DG
6 K51 20DB/YL
7 K25 20VT/DG
8 Y42 20RD/DB
9 C18 20DB
10 K4 16BK/LB
11 K6 16VT/WT
12 -
13 T40 12DG
14 F15 20DB/WT
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 15

C103 (GAS) - GRAY (RIGHT HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 F22 20WT/PK (EXCEPT 4.7L RHD)
1 F22 18WT/TN (4.7L RHD)
2 T6 18OR/WT (4.7L LHD)
2 C18 20DB (4.0L LHD BUILT-UP-EXPORT)
2 C18 18DB (4.0L EXCEPT BUILT-UP-EXPORT)
3 D20 20LG (4.7L LHD)
3 D20 18LG (4.7L RHD)
4 D21 20PK (4.7L LHD)
4 K299 18BR/WT (4.0L LHD)
4 D21 18PK (4.7L RHD)
5 B22 18DG/YL (LHD)
6 K20 18DG
7 K30 20PK (4.0L RHD)
7 K30 18PK/YL (4.7L RHD)
7 K30 20PK/YL (LHD)
8 A142 14DG/OR (4.0L LHD)
8 T10 18DG/LG (4.7L LHD)
9 T16 14RD (4.7L LHD)
10 D25 18VT/YL (4.7L RHD)
10 D25 18VT/YL (4.7L EXCEPT BUILT-UP-EXPORT)
10 D25 20VT/YL (4.7L LHD BUILT-UP-EXPORT)
11 Z305 20BK/OR
12 F45 18YL/RD (4.7L RHD)
12 T15 18YL/BR (4.0L)
12 F45 18YL/RD (4.7L EXCEPT BUILT-UP-EXPORT)
12 F45 20YL/RD (4.7L LHD BUILT-UP-EXPORT)
13 K6 18VT/BK (4.0L LHD)
14 F142 18OR/DG
C103 (GAS) - GRAY (ENGINE SIDE)
CAV CIRCUIT
1 F22 18WT/PK
2 C18 18DB (4.0L LHD)
2 K200 18VT/OR (4.7L RHD)
3 K99 18BR/OR (4.0L LHD)
3 D20 18LG (4.7L RHD)
4 K299 18BR/WT (4.0L BUILT-UP-EXPORT)
4 D21 18PK (4.7L RHD)
5 B22 18DG/YL (4.0L LHD)
6 K20 18DG
7 K30 18PK/YL
8 A142 14DG/OR (4.0L LHD)
9 T16 14RD (4.7L)
10 D25 18WT/VT (4.7L)
11 Z305 20BK/OR
12 T15 18LG (4.0L LHD)
12 F45 18YL/RD (4.7L)
13 K6 18VT/BK (4.0L LHD)
13 K199 18DB/WT (4.7L LHD)
14 F142 18OR/DG
8W - 80 - 16 8W-80 CONNECTOR PIN-OUTWJ

C104 - LT. GRAY (RIGHT HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 K200 18VT/OR (4.0L EXCEPT BUILT-UP-EXPORT)
1 K4 18BK/LB (4.7L HIGH OUTPUT)
2 K99 18BR/OR (4.7L)
2 F991 20OR/DB (4.0L)
3 K173 18LG (4.0L)
4 F42 18DG/LG (4.0L)
5 A7 14RD/BK (4.0L)
5 K4 18BK/LB (4.7L HIGH OUTPUT)
6 L1 18VT/BK (4.0L)
6 K142 18GY/BK (4.7L HIGH OUTPUT)
7 Z306 20BK/LG (4.0L)
7 K299 18BR/WT (4.7L)
8 C18 18DB (4.7L)
8 T41 18BK/WT (4.0L)
9 K6 18VT/BK (4.7L)
9 C2 18DB/YL (4.0L)
10 K4 18BK/LB (4.0L)
10 K42 18DB/LG (4.7L HIGH OUTPUT)
C104 - LT. GRAY (ENGINE SIDE)
CAV CIRCUIT
1 K200 18VT/OR (EXCEPT 4.0L BUILT-UP-EXPORT)
2 F991 18OR/DB
3 K173 18LG
4 F42 18DG/LG
5 A7 14RD/BK
6 L1 18VT/BK
7 Z306 20BK/LG
8 T41 18BK/WT
9 C2 18DB/YL
10 K4 18BK/LB
C105 (DIESEL) - GRAY (LEFT HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 C13 18DB/OR
2 F300 18RD/BK
3 V37 18RD/LG
4 Z305 20BK/OR
5 Z306 20BK/LG
6 L1 18VT/BK
7-
8-
9-
10 -
11 -
12 -
13 -
14 -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 17

C105 (DIESEL) - GRAY (ENGINE SIDE)
CAV CIRCUIT
1 C13 20DB/RD
2 F300 20RD/BK
3 V37 20RD/DG
4 Z305 18BK/DB
5 Z306 18BK/DB
6-
7-
8-
9-
10 -
11 -
12 -
13 -
14 -
C106 (DIESEL) - GRAY (BODY SIDE)
CAV CIRCUIT
A B10 14BR/WT (LHD)
B-
C-
D-
E-
F-
G-
H-
J-
K-
L-
M B29 14DG/OR
1 F15 20DB/WT
2-
3 G31 20VT/LG
4 G32 20DB/OR (RHD)
4 G32 20BK/LB (LHD)
5 G18 20PK/BK
6-
7-
8 F12 20DB/WT (LHD)
9-
10 Z231 18BK (RHD)
11 K4 20BK/LB (LHD)
11 G9 18GY/BK (RHD)
12 K6 18VT/WT (LHD)
13 -
14 -
15 -
16 K173 18LG
17 -
18 X2 18DG/RD
19 C18 18DB (LHD)
20 Y42 18OR/DB
21 -
8W - 80 - 18 8W-80 CONNECTOR PIN-OUTWJ

C106 (DIESEL) - GRAY (BODY SIDE)
CAV CIRCUIT
22 -
23 -
24 -
25 B7 18WT
26 B6 18WT/DB
27 -
28 -
29 -
30 -
31 -
32 -
33 -
34 -
35 -
36 -
37 -
38 L13 18BR/YL (BUILT-UP-EXPORT)
39 -
40 -
41 -
42 R46 20BR/LB
43 R48 20TN
44 -
45 -
46 -
47 -
48 -
49 -
50 -
51 -
52 -
53 L7 20BK/YL
54 L60 20TN
55 -
56 -
57 L39 20LB
58 -
59 L44 18VT/RD
60 L34 18RD/OR
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 19

C106 (DIESEL) - GRAY (RIGHT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
A-
B-
C-
D-
E-
F-
G-
H-
J-
K-
L-
M-
1 F15 18DB/WT
2-
3 G31 20VT/LG
4 G32 20BK/LB
5 G18 20PK/BK
6-
7-
8-
9-
10 Z231 18BK (RHD)
11 K4 18BK/LB (LHD)
11 G9 18GY/BK (RHD)
12 K6 18VT/WT (LHD)
13 -
14 -
15 -
16 K173 18LG
17 -
18 X2 18DG/RD
19 C18 18DB (LHD)
20 Y42 18OR/DB
21 -
22 -
23 -
24 -
25 B7 18WT
26 B6 18WT/DB
27 -
28 -
29 -
30 -
31 -
8W - 80 - 20 8W-80 CONNECTOR PIN-OUTWJ

C106 (DIESEL) - GRAY (RIGHT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
32 -
33 -
34 -
35 -
36 -
37 -
38 L13 18BR/YL
39 -
40 -
41 -
42 R46 18BR/LB
43 R47 18TN
44 -
45 -
46 -
47 -
48 -
49 -
50 -
51 -
52 -
53 L7 20BK/YL
54 L60 20TN
55 -
56 -
57 L39 20LB
58 -
59 L44 18VT/RD
60 L34 18RD/OR
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 21

C106 (GAS) - GRAY/RHD BLACK/LHD (BODY SIDE)
CAV CIRCUIT
A A149 12RD/TN
B A148 16LG/RD
C C1 12DG
D-
E A10 12RD/DG (LHD)
E A10 10RD/DG (RHD)
F A1 12RD
G A145 10WT/RD
H A146 10OR/WT
J A147 10RD/GY
K A148 10PK/WT
L A2 12PK/BK
M A20 14RD/DB
1 A141 16DG/BK
2 G18 20PK/BK (LHD)
2 F42 18DG/LG (RHD)
3 V3 16BR/WT
4 V4 16RD/YL
5 V55 16TN/RD
6 V6 16DB
7 F22 18WT/TN (RHD)
7 F22 20WT/PK (LHD)
8 F12 20DB/WT
9 K52 20PK/BK (LHD)
10 K29 20WT/PK (LHD)
10 Z231 18BK (RHD)
11 K512 18LB (RHD)
11 K226 20LB/YL (LHD)
12 K107 20OR/YL (LHD)
13 K251 18LB (RHD)
13 K106 20WT/DG (LHD)
14 T41 18BK/WT (LHD)
14 C13 20DB/OR (RHD)
15 V35 20LG/RD (RHD)
16 V36 20TN/RD (RHD)
17 G9 18GY/BK (RHD)
18 K25 18VT/LG (RHD)
19 K51 20DB/YL (RHD)
20 K125 18WT/DB (LHD)
21 K125 18WT/DB (RHD)
22 K31 18BR (RHD)
23 -
24 -
25 B7 18WT
26 B6 18WT/DB
27 X3 22GY/OR (LHD)
27 X3 22BK/RD (RHD)
28 G32 20BK/LB (LHD)
28 G32 20DB/OR (RHD)
29 -
30 G31 20VT/LG
31 -
32 V32 22OR/DG (LHD)
33 V30 22DB/RD
34 V16 22VT
8W - 80 - 22 8W-80 CONNECTOR PIN-OUTWJ

C106 (GAS) - GRAY/RHD BLACK/LHD (BODY SIDE)
CAV CIRCUIT
35 V14 22RD/VT
36 -
37 F45 20YL/RD
38 L13 18BR/YL (BUILT-UP-EXPORT)
39 -
40 Z306 20BK/LG
41 Z305 20BK/OR
42 R46 20BR/LB
43 R48 20TN
44 F991 20OR/DB
45 B22 18DG/YL (LHD)
46 -
47 -
48 D25 18YL/VT
49 D21 20PK
50 D20 20LG
51 D32 20LG/DG (LHD)
52 T41 18BK/WT (RHD)
52 T6 18OR/BK (LHD)
53 L7 20BK/YL
54 L60 20TN
55 G18 20PK/BK (RHD)
55 V37 22RD/LG (LHD)
56 L1 18VT/BK
57 L39 20LB
58 K4 18BK/LB (LHD)
58 K4 20BK/LB (RHD)
59 L44 18VT/RD
60 L34 18RD/OR
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 23
