C109 - BLACK (TRANSFER CASE JUMPER SIDE)
CAV CIRCUIT
1 K77 18LG/BK
2 K4 18BK/LB
C110 (DIESEL) - GRAY (LEFT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
1 K154 10GY
2 K254 10GY/YL
C110 (DIESEL) - GRAY (GLOW PLUG SIDE)
CAV CIRCUIT
1 K154 10GY
2 K254 10GY/YL
C111 - BLACK (LEFT FRONT LIGHTING MODULE
SIDE)
CAV CIRCUIT
1 L33 18RD
2 L43 18VT
3 L61 20TN/LG
4 L7 20BK/YL
5 L114 18BR/YL (BUILT-UP-EXPORT)
6 Z141 18BK
C111 - BLACK (LEFT HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 L33 18LG/BR (DIESEL)
1 L33 18RD (GAS)
2 L43 18VT
3 L61 20LG (DIESEL)
3 L61 20TN/LG (GAS)
4 L7 18BK/YL (DIESEL)
4 L7 20BK/YL (GAS)
5 L13 18BR/YL (BUILT-UP-EXPORT)
6 Z141 18BK
8W - 80 - 34 8W-80 CONNECTOR PIN-OUTWJ

C112 - BLACK (RIGHT HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 L34 18RD/OR
2 L44 18VT/RD
3 L60 20TN
4 L7 20BK/YL
5 L13 18BR/YL (BUILT-UP-EXPORT)
6 Z142 18BK
C112 - BLACK (RIGHT FRONT LIGHTING
MODULE SIDE)
CAV CIRCUIT
1 L34 18RD/OR
2 L44 18VT/RD
3 L60 20TN
4 L7 20BK/YL
5 L13 18BR/YL (BUILT-UP-EXPORT)
6 Z142 18BK
C113 (DIESEL) - LT. GRAY (ENGINE SIDE)
CAV CIRCUIT
1 D51 16WT
2 D52 16DG/WT
C113 (DIESEL) - LT. GRAY (TRANSMISSION
SIDE)
CAV CIRCUIT
1 D52 18LG/WT
2 D51 18DG/WT
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 35

C200 - GRAY/LHD BLACK/RHD (LEFT BODY
SIDE)
CAV CIRCUIT
A-
B-
C A1 12RD
D-
E-
F-
G A2 12PK/BK
H C1 12DG
J-
K-
M-
L-
1 X56 18DB/PK (BASE)
1 X84 18OR/GY (EXCEPT BASE)
2 X86 18OR/RD (EXCEPT BASE)
2 X54 18VT (BASE)
3 X81 18YL/BK (EXCEPT BASE)
3 X55 18BR/RD (BASE)
4 X53 18DG/OR (BASE)
4 X83 18YL/RD (EXCEPT BASE)
5 X53 18DG/OR
6 X55 18BR/RD
7 X54 18VT
8 X56 18DB/PK
9 Y152 20LG/OR (EXCEPT
BUILT-UP-EXPORT)
10 D20 20LG (GAS)
11 Y151 20LG/BR (EXCEPT
BUILT-UP-EXPORT)
12 Y153 20DB/RD (EXCEPT
BUILT-UP-EXPORT)
13 X40 20RD/WT (CD)
14 D25 20YL/VT
15 D25 20YL/VT
16 D32 20LG/DG (GAS)
17 T41 18BK/WT
18 Z4 20WT/BK (CD)
19 X41 20WT/DG (CD)
20 T6 18OR/BK (GAS)
21 D21 20PK (GAS)
22 K29 18WT/PK
23 X160 20YL (CD)
24 X112 20RD (CD)
25 -
26 -
27 G70 20BR/TN (BUILT-UP-EXPORT)
28 R47 20DB/LB
29 Z17 20BK (CD)
30 R49 20LB
31 G76 20TN/YL (RHD)
31 G76 18TN/YL (LHD)
32 T2 18TN/BK (DIESEL)
33 -
34 -
8W - 80 - 36 8W-80 CONNECTOR PIN-OUTWJ

C200 - GRAY/LHD BLACK/RHD (LEFT BODY
SIDE)
CAV CIRCUIT
35 X51 18WT/DG
36 X57 18DG/WT
37 L7 18BK/YL (BUILT-UP-EXPORT)
38 L13 18BR/YL (BUILT-UP-EXPORT)
39 V10 22BR (LHD)
39 V10 20BR (RHD)
40 X52 18DB/WT
41 X58 18DB/OR
42 -
43 V13 18BR/LG
44 V14 22RD/VT
45 -
46 V20 20BK/WT (RHD)
46 V20 18BK/WT (LHD)
47 V22 18BR/YL
48 R46 20BR/LB (RHD)
48 R46 18BK/LB (LHD)
49 X64 18BR/WT
50 Z305 20BK/OR
51 Z306 20BK/LG
52 R48 20TN
53 G32 20BK/LG (LHD)
53 G32 20DB/OR (RHD)
54 G31 20VT/LG
55 Z9 16BK
56 V11 20BK/TN
57 G18 20PK/BK
58 V37 22RD/LG (LHD)
58 V37 20RD/LG (RHD)
59 K4 20BK/LB
60 -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 37

C200 - GRAY/LHD BLACK/RHD (INSTRUMENT
PANEL SIDE)
CAV CIRCUIT
A-
B-
C A1 12RD
D-
E-
F-
G A2 12PK/BK
H C1 12DG
J-
K-
L-
M-
1 X84 18OR/BK
2 X86 18OR/RD
3 X81 18YL/BK
4 X83 18YL/RD
5 X53 18DG/OR
6 X55 18BR/RD
7 X54 18VT
8 X56 18DB/PK
9 Y152 20LG/BR (EXCEPT
BUILT-UP-EXPORT)
10 D20 20LG
11 Y151 20LG/BR (EXCEPT
BUILT-UP-EXPORT)
12 Y153 20DB/RD (EXCEPT
BUILT-UP-EXPORT)
13 X40 20WT/RD
14 D25 20YL/VT/GY
15 D25 20YL/VT/BR
16 D32 20LG/DG
17 T41 18BK/WT (DIESEL)
18 Z4 20WT/BK
19 X41 20WT/DG
20 T6 18OR/WT (GAS)
21 D21 20PK
22 K29 18WT/PK
23 X160 20YL
24 X112 20RD
25 -
26 -
27 G70 20BR/TN (BUILT-UP-EXPORT)
28 R47 20DB/LB
29 Z17 20BK
30 R49 20LB
31 G76 18TN/YL
32 T2 20TN/BK (DIESEL)
33 -
34 -
35 X51 18WT/DG
36 X57 18DG/WT
37 L7 18BK/YL (BUILT-UP-EXPORT)
38 L13 20BR/YL (BUILT-UP-EXPORT)
39 V10 20BR
40 X52 18DB/WT
8W - 80 - 38 8W-80 CONNECTOR PIN-OUTWJ

C200 - GRAY/LHD BLACK/RHD (INSTRUMENT
PANEL SIDE)
CAV CIRCUIT
41 X58 18DB/OR
42 -
43 V13 18BR/LG
44 V14 20RD/VT
45 -
46 V20 18BK/WT
47 V22 18BR/YL
48 R46 20BR/LB
49 X64 18BR/WT
50 Z305 20BK/OR
51 Z306 20BK/LG
52 R48 20TN
53 G32 20BK/LB
54 G31 20VT/LG
55 Z9 16BK
56 V11 20BK/TN
57 G18 20PK/BK
58 V37 20RD/LG
59 K4 20BK/LB
60 -
C201 (DIESEL) - WHITE (INSTRUMENT PANEL
SIDE)
CAV CIRCUIT
1-
2 Z300 18BK
3 E2 20OR
4 K29 18WT/PK
5 D25 20YL/VT
6 D19 20VT/OR
7 D21 20PK
8 F12 20DB/WT
9 T2 20TN/BK
10 Z234 18BK
11 T41 18BK/WT
12 F991 18OR/DB
C201 (DIESEL) - WHITE (SHIFTER ASSEMBLY SIDE)
CAV CIRCUIT
1-
2-
3-
4 K2 20WT/PK
5 D25 20RD
6-
7 D21 20PK
8 F12 20DB/WT
9 T2 20TN/BK
10 Z234 20WT
11 T41 20BK/WT
12 F991 20OR/DB
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 39

C202 (AZC) - WHITE (INSTRUMENT PANEL SIDE)
CAV CIRCUIT
1 C100 20YL/DB (RHD)
1 C32 20GY/DB (LHD)
2 C100 20YL/DB (LHD)
2 C32 20GY/DB (RHD)
3 C96 20WT/DB (RHD)
3 C33 20DB/RD (LHD)
4 C94 20WT/DG (RHD)
4 C95 20WT/BK (LHD)
5 C95 20WT/BK (RHD)
5 C94 20WT/DG (LHD)
6 C33 20DB/RD (RHD)
6 C96 20WT/DB (LHD)
7 C35 20DG/YL (RHD)
7 C102 20TN/BK (LHD)
8 C35 20DG/YL (LHD)
8 C102 20TN/BK (RHD)
9 C56 20RD/LG
10 -
11 C201 20LB/YL
12 G32 20BK/LB
C202 (AZC) - WHITE (A/C SIDE)
CAV CIRCUIT
1 C100 20YL/DB (RHD)
1 C32 20GY/DB (LHD)
2 C100 20YL/DB (LHD)
2 C32 20GY/DB (RHD)
3 C96 20WT/DB (RHD)
3 C33 20DB/RD (LHD)
4 C94 20WT/DG (RHD)
4 C95 20WT/BK (LHD)
5 C95 20WT/BK (RHD)
5 C94 20WT/DG (LHD)
6 C33 20DB/RD (RHD)
6 C96 20WT/DB (LHD)
7 C35 20DG/YL (RHD)
7 C102 20TN/BK (LHD)
8 C35 20DG/YL (LHD)
8 C102 20TN/BK (RHD)
9 C56 20RD/LG
10 -
11 C201 20LB/YL
12 G32 20BK/LB
8W - 80 - 40 8W-80 CONNECTOR PIN-OUTWJ

C202 (MTC) - WHITE (INSTRUMENT PANEL SIDE)
CAV CIRCUIT
1-
2 C201 20LB/YL
3 G32 20BK/LB
4-
5 C67 20RD/LB
6-
7-
8-
9-
10 C6 14LB
11 Z132 20BK/OR
12 F22 20WT/PK
13 C7 12BK/TN
14 C1 12DG
15 C4 16TN
16 C5 16LG
C202 (MTC) - WHITE (A/C SIDE)
CAV CIRCUIT
1-
2 C101 20LB/YL
3 G32 20BK/LB
4-
5 C67 20RD/LB
6-
7-
8-
9-
10 C6 14LB
11 Z132 20BK/OR
12 F22 20WT/PK
13 C7 12BK/TN
14 C1 12DG
15 C4 16TN
16 C5 16LG
C203 (AZC) - WHITE (INSTRUMENT PANEL SIDE)
CAV CIRCUIT
1 Z118 12BK
2 C1 12DG
C203 (AZC) - WHITE (A/C SIDE)
CAV CIRCUIT
1 Z118 12BK
2 C1 12DG
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 41

C300 (LHD) - GRAY (RIGHT BODY SIDE)
CAV CIRCUIT
A P130 16DG/WT (EXCEPT BASE)
B Q13 16DB
C B40 12LB
D F9 14RD/BK (EXCEPT
BUILT-UP-EXPORT)
E P144 16BK/LG (EXCEPT BASE)
F A141 16DG/BK (GAS)
G-
H-
J-
K-
L Q23 16RD/WT
M-
1 D25 20YL/VT
2 V13 18BR/LG
3 V22 18BR/YL
4 P112 20YL/WT
5 P114 20YL/RD
6 P35 18OR/VT
7 P36 18PK/VT
8 L50 18WT/TN
9 B1 18YL/DB
10 B2 18YL
11 B3 18LG/DB
12 B4 18LG
13 -
14 -
15 -
16 P29 20BR/WT (EXCEPT BASE)
17 P86 20PK/BK (EXCEPT BASE)
18 E21 20OR/RD
19 K4 20BK/LB
20 K226 18LB/YL (DIESEL)
20 K226 20LB/YL (GAS)
21 L62 18BR/RD
22 L95 18DG/YL (BUILT-UP-EXPORT)
23 -
24 L1 18VT/BK
25 -
26 -
27 -
28 -
29 -
30 -
31 -
8W - 80 - 42 8W-80 CONNECTOR PIN-OUTWJ

C300 (LHD) - GRAY (RIGHT BODY SIDE)
CAV CIRCUIT
32 -
33 -
34 -
35 -
36 -
37 X75 20GY/LG (BUILT-UP-EXPORT)
38 -
39 -
40 -
41 K106 20WT/DG (EXCEPT
BUILT-UP-EXPORT)
42 K107 20OR/YL (EXCEPT
BUILT-UP-EXPORT)
43 K125 18WT/DB (EXCEPT
BUILT-UP-EXPORT)
44 -
45 -
46 -
47 -
48 -
49 -
50 -
51 -
52 -
53 X57 18DG/WT (BASE)
53 X91 18WT/DG (EXCEPT BASE)
54 X51 18WT/DG (BASE)
54 X93 18DG/WT (EXCEPT BASE)
55 -
56 -
57 Z155 18BK/OR
58 -
59 -
60 -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 43
