connector JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual

C300 (LHD) - GRAY (LEFT BODY SIDE)
CAV CIRCUIT
A P130 16DG/WT (HEATED SEATS)
B Q13 16DB
C B40 14LB
D F9 14RD/BK (EXCEPT BASE))
E P144 16BK/VT (HEATED SEATS)
F A141 16DG/BK (EXCEPT DIESEL)
G-
H-
J-
K-
L Q23 16RD/WT
M-
1 D25 20YL/VT
2 V13 18BR/LG
3 V22 18BR/YL
4 P112 20YL/WT
5 P114 20YL/RD
6 P35 18OR/VT
7 P36 18PK/VT
8 L50 18WT/TN
9 B1 18YL/DB
10 B2 18YL
11 B3 18LG/DB
12 B4 18LG
13 -
14 -
15 -
16 P29 20BR/WT (HEATED SEATS)
17 P86 18PK/BK (HEATED SEATS)
18 E21 20OR/RD
19 K4 20BK/LB
20 K226 20LB/YL
21 L62 18BR/RD
22 L95 18DG/YL (BUILT-UP-EXPORT)
23 -
24 L1 18VT/BK
25 -
26 -
27 -
28 -
29 -
30 -
31 -
32 -
8W - 80 - 44 8W-80 CONNECTOR PIN-OUTWJ

C300 (LHD) - GRAY (LEFT BODY SIDE)
CAV CIRCUIT
33 -
34 -
35 -
36 -
37 X75 20GY/LG (BUILT-UP-EXPORT)
38 -
39 -
40 -
41 K106 20WT/DG (EXCEPT
BUILT-UP-EXPORT)
42 K107 20OR/YL (EXCEPT
BUILT-UP-EXPORT)
43 K125 18OR/DG (EXCEPT
BUILT-UP-EXPORT)
44 -
45 -
46 -
47 -
48 -
49 -
50 -
51 -
52 -
53 X91 18WT/DG (PREMIUM)
53 X57 18WT/DG (BASE)
54 X51 18DG/WT (BASE)
54 X93 18DG/WT (PREMIUM)
55 -
56 -
57 Z155 18BK/OR (EXCEPT BASE)
58 -
59 -
60 -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 45

C301 (RHD) - BLACK (LEFT BODY SIDE)
CAV CIRCUIT
A Q13 16DB
B Q23 16RD/WT
C F9 14RD/BK
D F60 16RD/WT
E Z9 16BK
F Z5 16BK/VT
G C15 12BK/WT
H A148 16LG/RD
J-
K-
L Q30 16TN
M P130 16DG/WT
1 L50 18W/TTN
2 F70 18PK
3 M2 18YL
4 M20 18YL/BK
5 P35 18 OR/VT
6 P36 18PK/VT
7 F30 14RD/TN
8 L7 18BK/YL
9 L95 18DG/YL
10 L63 18DG/RD
11 G80 20VT/YL
12 X80 18LB/BK
13 X82 18LB/RD
14 X85 18LG/DG
15 X87 18LG/RD
16 X93 18DG/WT
17 X91 18WT/DG
18 X84 18OR/GY
19 L62 20BR/RD
20 X86 18OR/RD
21 X81 18YL/BK
22 X83 18YL/RD
23 X56 18DB/PK
24 X51 18WT/DG
25 X57 18DG/WT
26 X52 18DB/WT
27 X58 18DB/OR
28 X54 18VT
29 X55 18BR/RD
30 X53 18DG/OR
31 X64 18BR/WT
32 D25 20YL/VT
8W - 80 - 46 8W-80 CONNECTOR PIN-OUTWJ

C301 (RHD) - BLACK (LEFT BODY SIDE)
CAV CIRCUIT
33 -
34 G78 20TN/BK
35 -
36 -
37 E21 20OR/RD
38 G77 20TN/OR
39 G76 20TN/YL
40 L1 18VT/BK
41 G5 20DB/WT
42 P86 20PK/BK
43 P29 20BR/WT
44 G73 20LG/OR
45 C235 18WT/LB (CD)
46 X160 20YL (CD)
47 X40 20RD/WT (CD)
48 -
49 X112 20RD (CD)
50 X41 20RD/BK (CD)
51 Z4 20WT/BK (CD)
52 Z17 20BK (CD)
53 -
54 -
55 -
56 -
57 -
58 -
59 -
60 -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 47

C301 (RHD) - BLACK (RIGHT BODY SIDE)
CAV CIRCUIT
A Q13 16DB
B Q23 16RD/WT
C F9 14RD/BK
D F60 16RD/WT
E Z9 16BK
F Z5 16BK/VT
G C15 12BK/WT
H A148 16LG/RD
J-
K-
L Q30 16TN
M P130 16DG/WT
1 L50 18WT/TN
2 F70 18PK
3 M2 18YL
4 M20 18YL/BK
5 P35 18OR/VT
6 P36 18PK/VT
7 F30 16RD/TN
8 L7 18BK/YL
9 L95 18DG/YL
10 L63 18DG/RD
11 G80 20VT/YL
12 X80 18LB/BK
13 X82 18LB/RD
14 X85 18LG/DG
15 X87 18LG/RD
16 X93 18DG/WT
17 X91 18WT/DG
18 X84 18OR/GY
19 L62 18BR/RD
20 X86 18OR/RD
21 X81 18YL/BK
22 X83 18YL/RD
23 X56 18DB/BK
24 X51 18WT/DG
25 X57 18DG/WT
26 X52 18DB/WT
27 X58 18DB/OR
28 X54 18VT
29 X55 18BR/RD
30 X53 18DG/OR
31 X64 18BR/WT
32 D25 20YL/VT
33 F22 20WT/PK
34 G78 20TN/BK
35 M1 18PK/RD
36 -
37 E21 20OR/RD
38 G77 20TN/OR
39 G76 20TN/YL
40 L1 18VT/BK
41 G5 20DB/WT
42 P86 20PK/BK
43 P29 20BR/WT
8W - 80 - 48 8W-80 CONNECTOR PIN-OUTWJ

C301 (RHD) - BLACK (RIGHT BODY SIDE)
CAV CIRCUIT
44 G73 20LG/OR
45 C235 20WT/LB (CD)
46 X160 20YL (CD)
47 X40 20WT/RD (CD)
48 -
49 X112 20RD (CD)
50 X41 20WT/DG (CD)
51 Z4 20WT/BK (CD)
52 Z17 20BK (CD)
53 -
54 -
55 -
56 -
57 -
58 -
59 -
60 -
C302 - BLACK (BODY SIDE)
CAV CIRCUIT
1 P112 20YL/WT
2 P114 20YL/RD
3 D25 20YL/VT
4 Z243 12BK (RHD)
4 Z28 12BK (LHD)
5 E21 20OR/RD
6 Q13 16DB
7 Q23 16RD/WT
8 A146 12OR/WT
9 X55 18BR/RD (LHD BASE)
9 X85 18LG/DG (LHD PREMIUM)
9 X80 18LB/BK (RHD PREMIUM)
10 X82 18LB/RD (RHD PREMIUM)
10 X53 18DG/OR (LHD BASE)
10 X87 18LG/RD (LHD PREMIUM)
11 M1 18PK/RD (JAPAN)
12 -
13 -
14 -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 49

C302 - BLACK (FRONT DRIVER DOOR SIDE)
CAV CIRCUIT
1 P112 20YL/WT
2 P114 20YL/RD
3 D25 20YL/VT
4 Z1 12BK
5 E21 20OR/RD
6 Q13 16DB
7 Q23 16RD/WT
8 A146 12OR/WT
9 X85 18LG/DG (LHD PREMIUM)
9 X80 18LG/DG (RHD PREMIUM)
9 X55 18LG/DG (BASE)
10 X53 18LG/RD (BASE)
10 X82 18LG/RD (RHD PREMIUM)
10 X87 18LG/RD (LHD PREMIUM)
11 M1 18PK (JAPAN)
12 -
13 -
14 -
C303 - WHITE (RIGHT BODY SIDE)
CAV CIRCUIT
1 X58 18DB/OR (BASE AUDIO)
1 X92 18TN/DG (PREMIUM AUDIO)
2 X52 18DB/WT (BASE AUDIO)
2 X90 18WT/VT (PREMIUM AUDIO)
3 E21 20OR/DB (RHD)
3 E20 20OR/DB (LHD)
4 P35 18OR/VT
5 P36 18PK/VT
6-
7-
8 Q13 16DB (RHD)
8 Q14 16GY (LHD)
9 Q24 16DG (LHD)
9 Q23 16RD/WT (RHD)
10 Z151 16BK (RHD)
10 Z28 16BK (LHD)
11 G76 18TN/YL (LHD)
11 G76 20TN/YL (RHD)
8W - 80 - 50 8W-80 CONNECTOR PIN-OUTWJ

C303 - WHITE (REAR DOOR SIDE)
CAV CIRCUIT
1 X58 18TN/DG (BASE)
1 X55
1 X92 18TN/DG (PREMIUM)
2 X52 18WT/VT (BASE)
2 X90 18WT/VT (PREMIUM)
3 E21 20OR/RD
4 P35 18OR/VT
5 P36 18PK/VT
6-
7-
8 Q14 16GY
9 Q24 16DG
10 Z1 16BK
11 G76 18TN/YL
C304 - BLACK (BODY SIDE)
CAV CIRCUIT
1 P86 20PK/BK (RHD)
1 P86 18PK/BK (LHD)
2 P130 16DG/WT
3 D25 20YL/VT
4 F37 16RD/LB (RHD)
4 F37 16RD (LHD)
5 Z238 16BK (RHD)
5 Z243 16BK (LHD)
6 P29 20BR/WT
7 Z155 18BK/OR (RHD)
7 Z155 20BK/OR (LHD)
8 Z5 16BK/VT (RHD)
8 P144 16BK/VT (LHD)
9-
10 -
C304 - BLACK (POWER SEAT SIDE)
CAV CIRCUIT
1 P86 20DG/YL (HEATED SEATS)
2 P130 16DG/WT (HEATED SEATS)
3 D25 20VT/YL (PREMIUM POWER
SEATS)
4 F35 16RD
5 Z1 16BK
6 P29 20BR/WT (HEATED SEATS)
7 Z2 20BK/OR (PREMIUM POWER SEATS)
8 Z5 16BK/VT (HEATED SEATS)
9-
10 -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 51

C306 - BLACK (BODY SIDE)
CAV CIRCUIT
1 P130 16DG/WT
2 Z238 16BK
3 F37 16RD/LB
4 P86 20PK/BK
5 P29 20BR/WT
6 P144 16BK/LG
C306 - BLACK (POWER SEAT SIDE)
CAV CIRCUIT
1 P130 16DG/WT (HEATED SEATS)
2 Z1 16BK
3 F37 16RD/LB
4 P86 20DG/YL (HEATED SEATS)
5 P29 20BR/WT (HEATED SEATS)
6 Z5 16BK/VT (HEATED SEATS)
C307 - WHITE (BODY SIDE)
CAV CIRCUIT
1 X93 18DG/WT (RHD)
1 X91 18WT/DG (LHD)
2 X93 18DG/WT (LHD)
2 X91 18WT/DG (RHD)
3 E20 20OR/DB (RHD)
3 E21 20OR/RD (LHD)
4 P35 18OR/VT
5 P36 18PK/VT
6-
7-
8 Q13 16DB (LHD)
8 Q14 16GY (RHD)
9 Q24 16DG (RHD)
9 Q23 16RD/TN (LHD)
10 Z243 16BK
11 G77 20TN/OR
C307 - WHITE (REAR DOOR SIDE)
CAV CIRCUIT
1 X57 18TN/DG (BASE)
1 X93 18TN/DG (PREMIUM)
2 X51 18WT/VT (BASE)
2 X91 18WT/VT (PREMIUM)
3 E21 20OR/RD
4 P35 18OR/VT
5 P36 18PK/VT
6-
7-
8 Q14 16GY
9 Q24 16DG
10 Z1 16BK
11 G76 18TN/YL
8W - 80 - 52 8W-80 CONNECTOR PIN-OUTWJ

C308 - WHITE (LEFT BODY SIDE)
CAV CIRCUIT
1 G78 20TN/BK
2 P35 18PK/VT (RHD)
2 P35 18OR/VT (LHD)
3 P36 18OR/VT (RHD)
3 P36 18PK/VT (LHD)
4 V13 18BR/LG
5 V22 18BR/YL
6 F70 18PK
7 L50 18WT/TN
8 Z309 12BK
9 G80 20VT/YL
10 C15 12BK/WT
11 L7 18BK/YL
C308 - WHITE (LIFTGATE SIDE)
CAV CIRCUIT
1 G78 20TN/BK
2 P35 18OR/VT
3 P36 18PK/VT
4 V13 18BR/LG
5 V22 18BR/YL
6 F70 18PK
7 L50 18WT/TN
8 Z1 12BK
9 G80 18VT/YL
10 C15 12BK/WT
11 L7 18BK/YL
C309 - WHITE (OVERHEAD SIDE)
CAV CIRCUIT
1 D25 20YL/VT
2 M20 20YL/BK
3 M2 20YL/DG
4 P112 20BK/WT
5 P114 20BK/YL
6 L1 20BK/VT
7 G5 20DB/WT
8 X75 20GY/LG (ALARM)
9-
10 F70 20PK
11 Q30 20BK/LB (AUTOWIPE)
11 Q30 16TN (SUNROOF)
12 Z150 20BK (EXCEPT SUNROOF)
12 Z150 16BK (SUNROOF)
13 -
14 Z155 20BK/OR
15 G73 20LG/OR
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 53
