C309 - WHITE (LEFT BODY SIDE)
CAV CIRCUIT
1 D25 20YL/VT
2 M20 18YL/BK (RHD)
2 M20 20YL/BK (LHD)
3 M2 18YL (RHD)
3 M2 20YL/DG (LHD)
4 P112 20YL/WT
5 P114 20YL/RD
6 L1 20VT/BK
7 G5 20DB/WT
8 X75 20GY/LG (BUILT-UP-EXPORT)
9-
10 F70 20PK (LHD)
10 F70 18PK (RHD)
11 Q30 16TN
12 Z150 16BK
13 -
14 Z155 20BK/OR (EXCEPT LHD BASE)
14 Z155 18BK/OR (RHD/LHD BASE)
15 G73 20LG/OR
C310 (BUILT-UP-EXPORT) - LT.GRAY (TRAILER TOW SIDE)
CAV CIRCUIT
1 F9 14RD/BK
2 L62 20BR/RD
3 L1 18VT/BK
4 F30 14RD/TN
5 L7 18BK/YL
6 Z150 14RD/BK
7 B40 14LB
8 Z150 14BK
9 L50 18WT/TN
10 L63 20DG/RD
11 Z1 14BK
12 -
13 -
14 -
C310 (BUILT-UP-EXPORT) - LT.GRAY (BODY SIDE)
CAV CIRCUIT
1 F9 14RD/BK
2 L62 18BR/RD (LHD)
2 L62 20BR/RD (RHD)
3 L1 18VT/BK
4 F30 14RD/TN
5 L7 18BK/YL
6 L95 18DG/YL
7 B40 14LB
8 Z150 14BK
9 L50 16WT/TN (RHD)
9 L50 18WT/TN (LHD)
10 L63 20DG/RD
11 Z150 14BK
12 -
13 -
14 -
8W - 80 - 54 8W-80 CONNECTOR PIN-OUTWJ

C310 (EXCEPT BUILT-UP-EXPORT) - LT. GREEN
(TRAILER TOW SIDE)
CAV CIRCUIT
1 F9 14RD/BK
2 L62 20BR/RD
3 L1 18VT/BK
4 F30 14RD/TN
5 L7 18BK/YL
6 Z150 14RD/BK
7 B40 14LB
8 Z150 14BK
9 L50 18WT/TN
10 L63 20DG/RD
C310 (EXCEPT BUILT-UP-EXPORT) - LT. GREEN
(LEFT BODY SIDE)
CAV CIRCUIT
1 F9 14RD/BK
2 L62 18BR/RD
3 L1 18VT/BK
4 F30 14RD/TN
5 L7 18BK/YL
6 Z150 14BK
7 B40 14LB
8 Z150 14BK
9 L50 18WT/TN
10 L63 20DG/RD
C311 - WHITE (LIFTGATE SIDE)
CAV CIRCUIT
1 L50 18WT/TN
2 Z1 18BK
C311 - WHITE (CHMSL SIDE)
CAV CIRCUIT
1 L50 18WT/TN
2 Z1 18BK
C312 - WHTE (LIFTGATE SIDE)
CAV CIRCUIT
1 Z1 18BK
2 L7 18BK/YL
3 P101 18OR/PK
4 F70 18PK
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 55

C312 - WHITE (LICENSE PLATE LAMP SIDE)
CAV CIRCUIT
1 Z1 18BK
2 L7 18BK/YL
3 P101 18OR/PK
4 F70 18PK
C313 - WHITE (FRONT DRIVER DOOR SIDE)
CAV CIRCUIT
1 P112 20YL/WT
2 P114 20YL/RD
C313 - WHITE (MUX JUMPER SIDE)
CAV CIRCUIT
1 P112 20YL/WT
2 P114 20YL/RD
C314 - LT. GRAY (BODY SIDE)
CAV CIRCUIT
1 D25 20YL/VT
2 A146 12OR/WT
3 P35 18OR/VT
4 P36 18PK/VT
5 Z28 12BK (LHD)
5 Z243 12BK (RHD)
6 Q14 16GY
7 Q24 16DG
8 E20 20OR/DB
9 X56 18DB/PK (BASE LHD)
9 X80 18LB/BK (PREMIUM LHD)
9 X85 18LG/DG (RHD)
10 X54 18VT (BASE)
10 X87 18LG/RD (RHD)
10 X82 18LB/RD (PREMIUM)
11 -
12 -
13 -
14 -
8W - 80 - 56 8W-80 CONNECTOR PIN-OUTWJ

C314 - LT. GRAY (FRONT PASSENGER DOOR
SIDE)
CAV CIRCUIT
1 D25 20YL/VT
2 A146 12OR/WT
3 P35 18OR/VT
4 P36 18PK/VT
5 Z1 12BK
6 Q14 16GY
7 Q24 16DG
8 E20 20OR/DB
9 X80 18LB/BK (LHD PREMIUM)
9 X85 18LB/BK (RHD PREMIUM)
9 X56 18LB/BK (BASE)
10 X54 18LB/RD (BASE)
10 X87 18LB/RD (RHD PREMIUM)
10 X82 18LB/RD (LHD PREMIUM)
11 -
12 -
13 -
14 -
C315 - (OVERHEAD SIDE)
CAV CIRCUIT
1 Q30 16TN
2-
3 Q43 20VT
4 Q41 20WT
5-
6-
7 Z150 16BK
8-
C315 - (SUN ROOF MODULE SIDE)
CAV CIRCUIT
1 Q30 16DB
2-
3 Q43 20VT
4 Q41 20WT
5-
6-
7 Z150 16BK
8-
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 57

C316 (EXCEPT BUILT-UP-EXPORT) - (PEDAL
SIDE)
CAV CIRCUIT
1 Y153 16DB/RD
2 L1 18WT/BR
3 F72 16RD/YL
4 D25 20VT/YL
5 Y151 20LG/BR
6 Z155 20BK/OR
7 Y152 20LG/OR
8 Z151 16BK
C316 (EXCEPT BUILT-UP-EXPORT) - (BODY
SIDE)
CAV CIRCUIT
1 Y153 20DB/RD
2 L1 18VT/BK
3 F72 16RD/YL
4 D25 20YL/VT
5 Y151 20LG/BR
6 Z155 18BK/OR
7 Y152 20LG/OR
8 Z151 18BK
C317 - (OVERHEAD SIDE)
CAV CIRCUIT
1 Z155 20BK/OR
2-
3 X75 20GY/LG
4-
5 D25 20YL/VT
6 F70 20PK
C317 - (INTRUSION TRANSCEIVER MODULE
SIDE)
CAV CIRCUIT
1 Z155 20BK
2-
3 X75 20GY/LG
4-
5 D25 20YL/VT
6 F70 20PK
C318 - (LEFT BODY SIDE (LHD)/ RIGHT BODY
SIDE (RHD))
CAV CIRCUIT
1 R73 20LB/BR
2 R75 20LB/OR
8W - 80 - 58 8W-80 CONNECTOR PIN-OUTWJ

C318 - (OVERLAY SIDE)
CAV CIRCUIT
1 R72 20LB/WT (RHD)
1 R73 20LB/BR (LHD)
2 R74 20LB/YL (RHD)
2 R75 20LB/OR (LHD)
C319 - (RIGHT BODY SIDE (LHD)/ LEFT BODY
SIDE (RHD))
CAV CIRCUIT
1 R72 20LB/WT (LHD)
2 R74 20LB/YL (LHD)
C319 - (OVERLAY SIDE)
CAV CIRCUIT
1 R73 20LB/BR (RHD)
1 R72 20LB/WT (LHD)
2 R75 20LB/OR (RHD)
2 R74 20LB/YL (LHD)
CAMSHAFT POSITION SENSOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K944 20BR/DG CAMSHAFT POSITION SENSOR GROUND
2 K44 20YL/GY CAMSHAFT POSITION SENSOR SIGNAL
3 F15 18RD/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
CAMSHAFT POSITION SENSOR (GAS) - GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 K44 18TN/YL CAMSHAFT POSITION SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
CAPACITOR (4.0L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A142 16DG/OR (RHD) AUTO SHUT DOWN RELAY OUTPUT
1 A142 14DG/OR (LHD) AUTO SHUT DOWN RELAY OUTPUT
2- -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 59

CAPACITOR NO. 1 (4.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
2- -
CAPACITOR NO. 2 (4.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
2- -
CARGO LAMP - WHITE 3 WAY
CAV CIRCUIT FUNCTION
1 F70 20PK FUSED B(+)
2 G73 20LG/OR LIFTGATE COURTESY DISABLE
3 M2 20YL/DG COURTESY LAMP DRIVER
CENTER HIGH MOUNTED STOP LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L50 18WT/TN PRIMARY BRAKE SWITCH SIGNAL
2 Z309 18BK GROUND
CIGAR LIGHTER - RED 3 WAY
CAV CIRCUIT FUNCTION
1 F30 16RD FUSED CIGAR LIGHTER RELAY OUTPUT
2- -
3 Z300 16BK GROUND
8W - 80 - 60 8W-80 CONNECTOR PIN-OUTWJ

CLOCKSPRING C1 - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 X3 20GY/OR HORN RELAY CONTROL
2 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
3 K4 20BK/LB SENSOR GROUND
4- -
CLOCKSPRING C2-4WAY
CAV CIRCUIT FUNCTION
1 R63 20TN/LB DRIVER SQUIB 2 LINE 2
2 R61 20OR/LB DRIVER SQUIB 2 LINE 1
3 R43 20BK/LB DRIVER SQUIB 1 LINE 1
4 R45 20DG/LB DRIVER SQUIB 1 LINE 2
CLOCKSPRING C3 - GRAY 6 WAY
CAV CIRCUIT FUNCTION
1 X20 20RD/YL RADIO CONTROL MUX
2 X10 20RD/BK RADIO CONTROL MUX RETURN
3 X3 20GY/OR HORN RELAY CONTROL
4 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
5 K4 20BK/LB SENSOR GROUND
6- -
CLOCKSPRING C4 - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X20 20RD/YL RADIO CONTROL MUX
2 X10 20RD/BK RADIO CONTROL MUX RETURN
COIL ON PLUG NO. 1 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K91 14TN/RD COIL DRIVER NO. 1
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 61

COIL ON PLUG NO. 2 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K92 14TN/PK COIL DRIVER NO. 2
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL ON PLUG NO. 3 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K93 14TN/OR COIL DRIVER NO. 3
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL ON PLUG NO. 4 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K94 14TN/LG COIL DRIVER NO. 4
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL ON PLUG NO. 5 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K95 14TN/DG COIL DRIVER NO. 5
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL ON PLUG NO. 6 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K96 14TN/LB COIL DRIVER NO. 6
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
8W - 80 - 62 8W-80 CONNECTOR PIN-OUTWJ

COIL ON PLUG NO. 7 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K97 14BR COIL DRIVER NO. 7
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL ON PLUG NO. 8 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K98 14LB/RD COIL DRIVER NO. 8
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL RAIL (4.0L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K91 14TN/RD COIL DRIVER NO. 1
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3 K92 14TN/PK COIL DRIVER NO. 2
4 K93 14TN/OR COIL DRIVER NO. 3
COMPACT DISC CHANGER (PREMIUM RADIO) - BLACK 8 WAY
CAV CIRCUIT FUNCTION
1 X40 20WT/RD AUDIO OUT RIGHT
2 C235 20WT/LB SHIELD
3 D25 20YL/VT PCI BUS
4 X112 20RD IGNITION SWITCH OUTPUT (RUN-ACC)
5 X41 20WT/DG AUDIO OUT LEFT
6 Z4 20WT/BK GROUND
7 Z17 20BK GROUND
8 X160 20YL B(+)
