JEEP GRAND CHEROKEE 2004 WK / 3.G Owners Manual

²PERFORM SERVICE
²DOOR OPEN (one or more, with graphic)
²LIFTGATE OPEN (with graphic)
²LIFTGLASS OPEN (with graphic)
²WASHER FLUID LOW (with graphic)
²MEMORY SEAT DISABLED
²MEMORY #1 POSITIONS SET
²MEMORY #2 POSITIONS SET
²PEDAL ADJUST DISABLED
²LEFT FRONT LOW PRESSURE
²LEFT FRONT HIGH PRESSURE
²RIGHT FRONT LOW PRESSURE
²RIGHT FRONT HIGH PRESSURE
²LEFT REAR LOW PRESSURE
²LEFT REAR HIGH PRESSURE
²RIGHT REAR LOW PRESSURE
²RIGHT REAR HIGH PRESSURE
²SPARE LOW PRESSURE (5 Tire TPM System Only)
²SPARE HIGH PRESSURE (5 Tire TPM System Only)
²TIRE PRESSURE UNAVAILABLE
²TIRE PRESSURE NOW AVAILABLE
²TIRE SENSOR BAD/MISSING
²SPARE SWAP DETECTED (5 Tire TPM System Only)
²REMOVE MAGNET FROM SPARE (5 Tire TPM Sys-
tem Only)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91
3

Tire Pressure Monitor System Ð If Equipped
The Tire Pressure Monitor (TPM) system uses wireless
technology to monitor tire pressure levels. Sensors,
mounted to each wheel as part of the valve stem transmit
tire pressure readings to a receiver located in the over-
head console.The tire pressure is shown in the Electronic Vehicle
Information Center (EVIC) display. The TPM system
remains active even if it is not displayed in the EVIC.
CAUTION!
The TPM system is designed to monitor your tire
pressure and will not function as a tire pressure
gauge while adjusting the pressure in your tires.
There will be a delay between the instant you adjust
the air pressure in a tire and when the system
updates the display.
NOTE:The TPM system can inform you about a low or
high tire pressure condition, but it does not replace
normal tire maintenance.
The TPM system is not intended to provide you with
notification of rapid pressure loss.
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

1. If any tire pressure has exceeded the low or high
pressure (refer to STARTING AND OPERATING Ð
TIRES AND WHEELS), the TPM system will display a
message in the EVIC and sound a chime. It will then go
into the tire pressure display screen and flash the pres-
sure value of the tire that is low or high. This will be
displayed for the rest of the ignition cycle, or until either
the C/T, MENU, STEP, or RESET button is pressed.
NOTE:This display will return 60 seconds after either
the C/T, MENU, STEP, or RESET button is pressed. If a
tire is low or high, you should correct your tire inflation
pressure as soon as possible and inspect all of your tires.
Refer to STARTING AND OPERATING Ð TIRES AND
WHEELS for more details.
Once the low or high tire pressure message has occurred,
it will continue to blink until the tire pressure is cor-
rected.2. If the spare tire pressure has exceeded the low or high
pressure allowed, the TPM system will display a message
in the EVIC for 60 seconds and sound a chime per every
ignition cycle (5 Tire TPM System Only).
NOTE:This message will return every ignition cycle,
until the tire pressures are corrected.
3. When the vehicle is moving and the EVIC cannot
receive a valid sensor signal from the tire pressure
sensors, the TIRE PRESSURE UNAVAILABLE message
will be displayed for 5 seconds along with a chime. The
display will then shift to the individual tire pressure
display screen and display dashes for the tire or tires that
are affected. Once the TIRE PRESSURE UNAVAILABLE
message has been displayed, and valid sensor signals are
received, the EVIC will display the TIRE PRESSURE
NOW AVAILABLE message for 5 seconds along with a
chime. This is meant to inform you when the TPM system
has returned to it's normal operation. This will occur
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93
3

when valid tire pressure sensor messages have been
received from all 4 road tires. TPM system function is
temporarily unavailable due to external electromagnetic
interference, such as electronic devices or nearby radio or
TV towers.
4. In addition to monitoring the vehicle tires, the TPM
system monitors faults within the system. When any
fault has been set, the TPM system will display TIRE
SENSOR BAD/MISSING. Be sure to inspect your tires for
proper inflation pressure. After you determine that your
tires are properly inflated, see your authorized dealer for
service to diagnose the problem with the TPM system.5. With the 5 Tire TPM System, if a road tire is replaced
by the spare, the TPM system will automatically detect
that the tires have been switched (after the ignition has
been cycled) and display SPARE SWAP DETECTED
along with a chime. This could take up to 10 minutes
with vehicle speed above 25 mph (40 km/h).
6. With the 4 Tire TPM System, if a road tire is replaced
by the spare, the TPM system will display TIRE SENSOR
BAD/MISSING. This is due to the spare tire not being
equipped with a tire pressure sensor. Once the road tire is
repaired and/or installed back on the vehicle with the
proper tire pressure the message will be removed. This
could take up to 10 minutes with vehicle speed above 25
mph (40 km/h).
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

General Information
This device complies with FCC rules part 15 and with
RSS-210 of Industry Canada. Operation is subject to the
following conditions:
1. This device may not cause harmful interference
2. This device must accept any interference that may be
received, including interference that may cause undes-
ired operation
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the device.
For further assistance, questions, or comments about the
TPM system, please call1±877±774±8473.
Customer Programmable Features
Press the MENU button until one of the display choices
following appears:
Language?
When in this display you may select one of five lan-
guages for all display nomenclature, including the trip
computer functions. Press the STEP button while in this
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95
3

display selects English, Francais, Deutsch, Italiana, or
Espanol. As you continue the displayed information will
be shown in the selected language.
Display U.S. or Metric?
Pressing the STEP button when in this display selects US
or Metric. The overhead console and instrument panel
displays will be in the selected units.
Auto Door Locks?
When this feature is selected, all doors and the liftgate
lock automatically when the speed of the vehicle reaches
15 mph (25 km/h). Pressing the STEP button when in this
display will select ªYesº or ªNo.º
Auto Unlock On Exit? (Available Only When the
AUTO DOOR LOCKS Feature is Turned On )
When this feature is selected all the vehicle's doors will
unlock when the driver's door is opened if the vehicle is
stopped and the transmission is in P (Park) or N (Neu-
tral) position. Pressing the STEP button when in this
display will select ªYesº or ªNo.º
Remote Unlock Driver's Door 1st?
When this feature is selected only the driver's door will
unlock on the first press of the remote keyless entry
unlock button and require a second press to unlock the
remaining locked doors and liftgate. WhenREMOTE
UNLOCK ALL DOORSis selected all of the doors and
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

the liftgate will unlock at the first press of the remote
keyless entry unlock button. Pressing the STEP button
when in this display will select DRIVER'S DOOR 1ST or
ALL DOORS.
Remote Linked To Memory? (Available with
Memory Seat Only)
When this feature is selected the memory seat, mirror,
and radio settings will return to the memory set position
when the remote keyless entry ªUnlockº button is
pressed. If this feature is not selected then the memory
seat, mirror, and radio settings can only return to the
memory set position using the door mounted switch.
Pressing the STEP button when in this display will select
ªYesº or ªNo.º
Sound Horn On Lock?
When this feature is selected a short horn sound will
occur when the remote keyless entry ªLockº button is
pressed. This feature may be selected with or without theflash lights on lock/unlock feature. Pressing the STEP
button when in this display will select ªYesº or ªNo.º
Flash Lights On Lock/Unlock?
When this feature is selected, the front and rear turn
signals will flash when the doors are locked or unlocked
using the remote keyless entry transmitter. This feature
may be selected with or without the sound horn on lock
feature selected. Pressing the STEP button when in this
display will select ªYesº or ªNo.º
Headlamp Delay
When this feature is selected the driver can choose, when
exiting the vehicle, to have the headlamps remain on for
30, 60, or 90 seconds, or not remain on. Pressing the STEP
button when in this display will select 30, 60, 90, or OFF.
Headlamp On With Wipers? (Available with Auto
Headlights Only)
When this feature is selected and the headlight switch
has at least once been moved to the AUTO position, the
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97
3

headlights will turn on when the wipers are turned on.
The headlights will also turn off when the wipers are
turned off if they were turned on in this way. Pressing the
STEP button when in this display will select ªYesº or
ªNo.º
NOTE:Turning the headlights on during the daytime
causes the instrument panel lights to dim. To increase the
brightness, refer to ªLightsº in this section.
Service Interval
When this feature is selected a service interval between
2,000 (3 200 km) and 6,000 miles (10 000 km) in 500 mile
(800 km) increments may be selected. Pressing the STEP
button when in this display will select distances between
2,000 (3 200 km) and 6,000 miles (10 000 km) in 500 mile
(800 km) increments.
Reset Service Distance (Displays Only if Service
Interval was Changed)
When this feature is selected the current accumulated
service distance can be reset to the newly selected service
interval. Pressing the STEP button when in this display
will select ªYesº or ªNo.º
Low Fuel Chime?
When this feature is selected a chime will sound when
the ªLow Fuel Indicator Lightº is displayed in the
instrument panel cluster. Pressing the STEP button when
in this display will select ªYesº or ªNo.º
Easy Exit Seat? (Available with Memory Seat Only)
When this feature is selected, the driver's seat moves
rearward 2 inches (5 cm) or to the farthest rearward
position if this distance is less than 2 inches (5 cm) when
the key is removed from the ignition switch so that the
driver can more easily exit the vehicle. The seat will
return to the memorized seat location (if REMOTE LINK
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

TO MEMORY is set to YES) when the remote keyless
entry transmitter is used to unlock the door. Pressing the
STEP button when in this display will select ªYesº or
ªNo.º
Retrain Tire Sensors? (Available with TPM System
Only)
When this feature is selected, the TPM system will start
the retraining procedure (Refer to Training Procedure
below). Pressing the STEP button when in this display
will select ªYesº or ªNo.º Then, press the MENU button
to enter selection.
WARNING!
Death or serious injury can occur if magnetically
sensitive devices are exposed to this magnet. Mag-
nets can affect pacemakers.
NOTE:The tire pressure sensors must be retrained after
rotating the tires or replacing one or more sensors. If a
wheel rotation is not followed by the retrain procedure,
the system will not properly inform you of the correct
vehicle location for a low or high pressure tire.
The following describes how to use this feature:
1. Locate the training magnet under the spare tire
(shaped like a doughnut).
2. Press the MENU button until RETRAIN TIRE SEN-
SORS is displayed.
3. Press the STEP button to select YES to retrain TPM
sensor.
4. Press the MENU button to enter selection.
5. Display will read TRAIN LEFT FRONT TIRE.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99
3

NOTE:There is a 60 second timer for training the first
tire and a 30 second timer between training the remain-
ing tires. If either of these timers expire, the EVIC will
abort the training procedure.
6. Starting at the left front tire, place the training magnet
over the valve stem until the horn chirps (This takes
approximately 5 seconds).7. Repeat step 6 working clockwise around the vehicle
(Left Front, Right Front, Right Rear, Left Rear, Spare) until
all five TPM sensor positions are trained.
NOTE:The spare tire is only trained with the 5 Tire
TPM System.
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
