ROOF LUGGAGE RACK
External racks do not increase the total load carrying
capacity of the vehicle. Be sure that the total occupant
and luggage load inside the vehicle, plus the load on the
luggage rack, do not exceed the rated vehicle capacity.
This vehicle is not equipped with roof rack cross rails as
built, unless ordered as optional equipment. Cross rails
must be installed prior to carrying loads on the roof rack.
If not equipped, your authorized dealer can order and
install Mopartcross rails built specifically for this roof
rack system or a number of after market rails that are
tailored to your life-style or activities.CAUTION!
²To prevent damage to the roof of your vehicle, DO
NOT carry any loads on the roof rack without cross
rails installed. The load should be secured and
placed on top of the cross rails, not directly on the
roof. If it is necessary to place the load on the roof,
place a blanket or some other protection between the
load and the roof surface.
²To avoid damage to the roof rack and vehicle, do not
exceed the rated load capacity of your cross rail system
or the roof rack system maximum load capacity of 150
lbs (68 kg). Always distribute heavy loads as evenly as
possible and secure the load appropriately.
²Long loads which extend over the windshield, such
as wood panels or surfboards, should be secured to
both the front and rear of the vehicle.
²Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof rack.
Wind forces, due to natural causes or nearby truck
traffic, can add sudden upward loads. This is espe-
cially true on large flat loads and may result in
damage to the cargo or your vehicle.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121
3

WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in
personal injury or property damage. Follow the roof
rack ªCautionsº when carrying cargo on your roof
rack.
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
mInstrument Panel And Interior Controls.......126
mInstrument Cluster......................127
NInstrument Cluster Ð If Equipped.........128
mInstrument Cluster Description.............129
mElectronic Digital Clock..................135
NClock Setting Procedure.................135
mRadio General Information................135
NRadio Broadcast Signals.................135
NTwo Types Of Signals..................135NElectrical Disturbances..................136
NAM Reception.......................136
NFM Reception........................136
mSales Code RBKÐAM/ FM Stereo Radio With
CD Player And CD Changer Controls........136
NRadio Operation......................136
NCD Player Operation...................139
NCD Changer Control Capability Ð If
Equipped...........................140
NRadio Display Messages................1424

mSales Code RBPÐAM & FM Stereo Radio With
Cassette Tape Player, CD Player, And Optional
CD/DVD Changer Controls...............143
NRadio Operation......................143
NTape Player Operation..................147
NCD Player Operation...................149
NCD/DVD Changer Operation Ð If
Equipped...........................150
mSales Code RB1ÐAM/FM Stereo Radio With
DVD/GPS Navigation System..............152
mSatellite Radio Ð If Equipped..............152
NSystem Activation.....................152
NElectronic Serial Number/Sirius Identification
Number (ENS/SID)....................153NSelecting Satellite Mode In RBB And RBK
Radios.............................153
NSelecting Satellite Mode In RBP, RBU, RAZ,
And RBQ Radios.....................154
NSelecting a Channel....................154
NStoring And Selecting Pre-Set Channels......155
NUsing The PTY (Program Type) Button
(If Equipped)........................155
NPTY Button9Scan9.....................155
NPTY Button9Seek9.....................155
NSatellite Antenna......................155
NReception Quality.....................156
m10±Disc Remote CD Changer..............156
NLoading The CD Changer...............156
124 UNDERSTANDING YOUR INSTRUMENT PANEL

mRemote Sound System Controls Ð If Equipped . . 160
NRadio Operation......................161
NTape Player.........................161
NCD Player Ð Single Disc In Radio.........162
NCD Player Ð 10 Disc In Cargo Area........162
mCassette Tape And Player Maintenance.......162
mCD/DVD Disc Maintenance...............163
mRadio Operation And Cellular Phones........164
mClimate Controls.......................164
NAir Conditioning.....................164NBlower Control.......................165
NTemperature Control...................165
NMode Selection.......................166
NInfrared Dual-Zone Climate Control Ð If
Equipped...........................167
NWindow Fogging.....................170
mRear Window Features...................170
NRear Window Wiper/Washer.............170
NRear Window Defroster.................171
UNDERSTANDING YOUR INSTRUMENT PANEL 125
4

INSTRUMENT PANEL AND INTERIOR CONTROLS
126 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER
UNDERSTANDING YOUR INSTRUMENT PANEL 127
4

INSTRUMENT CLUSTER Ð IF EQUIPPED
128 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER DESCRIPTION
1. Voltmeter
Indicates available battery voltage and charging
system operation. The lower red zone shows that
the battery charge may be too low to start the engine.
With the engine running, the normal operating range is
between 11 and 15 volts. Prolonged gage readings be-
tween 9-11 (undercharge) or above 15 (overcharge) indi-
cate possible malfunction of the generator, voltage regu-
lator or battery. See your dealer if such signs occur.
2. Turn Signal Indicator Light
The arrows will flash in unison with the exterior
turn signals, when using the multi-function control
lever. When the hazard warning system is activated, both
the indicator lights will flash simultaneously.
3. Tachometer
Indicates the engine speed in revolutions per minute.
CAUTION!
Do not operate the engine with the tachometer
pointer in the red area. Engine damage will occur.
4. High Beam Indicator Light
This light shows that the headlights are on high
beam. Pull the multi-function control lever to-
wards the steering wheel to switch the headlights from
high to low beam.
5. Airbag Warning Light
This indicator lights and remains lit for 6 to 8
seconds when the ignition is first turned on. If the
bulb does not come on during starting, have it serviced.
If the light stays on or comes on while driving, have the
airbag system checked by an authorized dealer.
6. Speedometer
Indicates vehicle speed.
UNDERSTANDING YOUR INSTRUMENT PANEL 129
4

7. Oil Pressure Gage
Indicates the engine oil pressure. This gage does
not measure oil level. Pressure varies with engine
speed, temperature, and oil viscosity. Normal oil pressure
will be midway between the lowest and highest limit
marks.
8. Sentry Key Indicator Light Ð If Equipped
Refer to ªSentry Key Immobilizer Systemº in
Section 2 of this manual for more information.
9. Malfunction Indicator Light
This light is part of an onboard diagnostic system
called OBD II which monitors engine and auto-
matic transmission control systems. This light
will illuminate when the ignition is in the ON position
before engine start. If the bulb does not come on when
turning the ignition key from OFF to ON, have the
condition checked promptly.Certain conditions such has a loose or missing gas cap,
poor fuel quality, etc. may illuminate the light after
engine start. The vehicle should be serviced if the light
stays on through several typical driving cycles. In most
situations, the vehicle will drive normally and will not
require towing.
When the engine is running, the ªMalfunction Indicator
Lightº may flash to alert of serious conditions that could
lead to immediate loss of power or severe catalytic
converter damage. The vehicle should be serviced as
soon as possible if this occurs.
10. Cruise Indicator Light
This indicator lights when the electronic speed
control system is turned ON.
11. Check Gages Warning Light
This light illuminates when the voltmeter, oil
pressure, or temperature gages indicate a reading
130 UNDERSTANDING YOUR INSTRUMENT PANEL
