JEEP GRAND CHEROKEE 2004 WK / 3.G Owners Manual

Gate Operator/Canadian Programming
Canadian radio-frequency laws require transmitter sig-
nals to9time-out9(or quit) after several seconds of
transmission - which may not be long enough for
HomeLink to pick up the signal during programming.
Similar to this Canadian law, some U.S. gate operators are
designed to9time-out9in the same manner.
If you live in Canada or you are having difficulties
programming a gate operator by using the9Program-
ming HomeLink9procedures (regardless of where you
live), replace step two with the following:
NOTE:If programming a garage door opener or gate
operator, it is advised to unplug the device during the
9cycling9process to prevent possible overheating.
Press and hold the HomeLink button while you press
and release - every two seconds ((cycle() your hand-heldtransmitter button until the radio signal has success-
fully been accepted by HomeLink. (The message
TRAINED will appear on the HomeLink display.)
Proceed with the remaining steps under9Programming
HomeLink9to complete.
Using HomeLink
To operate, simply press and release the programmed
HomeLink button. Activation will now occur for the
trained device (i.e. garage door opener, gate operator,
security system, entry door lock, home/office lighting,
etc.). For convenience, the hand-held transmitter of the
device may also be used at any time. In the event that
there are still programming difficulties or questions,
contact HomeLink at:www.homelink.comor1-800-355-
3515.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111
3

POWER SUNROOF Ð IF EQUIPPED
The sunroof is electrically operated from a switch located
in the overhead console. To operate the sunroof, the
ignition switch must be in the ON or ACC position. The
sunroof has ªManualº and ªExpress Openº modes of
operation when opening.
Express Open Mode
To open the sunroof in the Express Open mode, press the
switch rearward for less than one second. This causes the
sunroof glass to automatically retract and stop at the full
open position. This glass position provides the largest
possible opening while minimizing low-speed wind buf-
feting. If wind buffeting does occur, adjusting the sunroof
glass position may reduce the intensity of the buffeting.
Manual Open Mode
The sunroof can also be opened by pressing and holding
the switch rearward. Once the switch is held rearward for
more than one second, releasing the switch at any time
during travel will cause the sunroof to stop at the current
position.
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Closing Operation
To close the sunroof from an open position, press the
switch forward and hold it until the sunroof glass comes
to a complete stop. Releasing the switch at any time in
this mode will cause the sunroof to stop at the current
position.
Vent Operation
Opening the glass panel to the vent position will improve
interior ventilation. To open the sunroof to the vent
position from the closed position, press the switch for-
ward and hold. Releasing the switch at any time during
travel will cause the sunroof to stop at the current vent
position. To reach the fully vented position, continue to
hold the switch forward until vent motion stops. To close
the sunroof from the vent position, press and hold the
switch rearward until the glass comes to a complete stop.
Ignition Off Operation
The sunroof will also operate up to 45 seconds after the
ignition has been turned off. The sunroof operation will
be canceled if either of the front doors are opened during
the 45 second time period.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113
3

Sunshade Operation
The sunshade covering the glass in the panel will open
with the sunroof and must be closed manually. It can also
be opened and closed manually without activating the
sunroof. This will allow you to enjoy the warmth of the
sun during the winter months.WARNING!
In an accident, there is greater risk of being thrown
from a vehicle with an open sunroof. You could be
seriously injured or killed. Always fasten your seat
belt properly and be sure all passengers are properly
secured too.
Maintenance
Care should be taken in cleaning the inside of the glass.
Use only nonabrasive cleaners and a soft cloth.
WARNING!
Do not allow small children to operate the sunroof,
and never allow objects to project through the sun-
roof opening. Injury may result.
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

POWER OUTLET
To the right of the convenience tray (lower center of
instrument panel) is an outlet for electrically powered
accessories. Pull lightly on the tab of the plastic cover to
access the outlet.
There is a rear power outlet located in the right rear cargo
area rearward of the storage bin/CD changer (if equipped).
The power outlets are a direct feed from the battery so
they receive power whether the ignition is in the ON or
OFF position.
All accessories connected to this outlet should be re-
moved or turned off when the vehicle is not in use to
protect the battery against discharge.
Rear Power Outlet
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115
3

CAUTION!
Electrical Outlet Use With Engine Off
²Many accessories that can be plugged in draw
power from the vehicle's battery, even when not
in use (i.e., cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle's battery will
discharge sufficiently to degrade battery life
and/or prevent engine starting.
²Accessories that draw higher power (i.e., coolers,
vacuum cleaners, lights, etc.) will degrade the
battery even more quickly. Only use these inter-
mittently and with greater caution.
²After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle's battery.
GLOVE COMPARTMENT
The glove compartment light will remain on if the glove
box door is not securely closed, causing an unnecessary
drain on the battery.
CUP HOLDERS
In the center console there are two cup holders for the
front seat passengers.
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:The cup holder insert is removable, from the
console, for cleaning. It can be reinstalled with the larger
cup depression towards the passenger seat, but the top
surface will not be flush with the console surface.The rear passengers have access to two cup holders that
pull out from the rear of the center console.
Front Cup Holders
Rear Cup Holders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117
3

CARGO AREA FEATURES
Cargo Light
The cargo area light is activated by opening the liftgate,
opening any door, or by rotating the dimmer control on
the multi-function control lever to the extreme top posi-
tion. If all doors are closed and only the liftgate is open,
pushing on the cargo light lens surface will turn off all
interior lamps. Push on the lens surface a second time to
restore the interior lights to normal operation.
Retractable Cargo Area Cover Ð If Equipped
To cover the cargo area:
1. Grasp the cover at the center handle. Pull it over the
cargo area.
2. Insert the pins on the ends of the cover into the slots in
the pillar trim cover.
3. The liftgate may be opened with the cargo cover in
place.
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
In an accident a cargo cover loose in the vehicle
could cause injury. It could fly around in a sudden
stop and strike someone in the vehicle. Do not store
the cargo cover on the cargo floor or in the passenger
compartment. Remove the cover from the vehicle
when taken from its mounting. Do not store in the
vehicle.
Cargo Tie-Down Hooks
The tie-downs located on cargo area floor should be used
to safely secure loads when vehicle is moving.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119
3

WARNING!
²Cargo tie-down hooks are not safe anchors for a
child seat tether strap. In a sudden stop or colli-
sion a hook could pull loose and allow the child
seat to come loose. A child could be badly injured.
Use only the anchors provided for child seat
tethers.
²The weight and position of cargo and passengers
can change the vehicle center of gravity and
vehicle handling. To avoid loss of control result-
ing in personal injury, follow these guidelines for
loading your vehicle:
²Do not carry loads which exceed the load limits
described on the label attached to the left door or left
door center pillar. Refer to ªVehicle Loadingº in Sec-
tion 5 for additional information on cargo weights.
²Always place cargo evenly on the cargo floor. Put
heavier objects as low and as far forward as possible.
²Place as much cargo as possible in front of the rear
axle. Too much weight or improperly placed weight
over or behind the rear axle can cause the rear of the
vehicle to sway.
²Do not pile luggage or cargo higher than the top of the
seatback. This could impair visibility or become a
dangerous projectile in a sudden stop or collision.
WARNING!
To help protect against personal injury, passengers
should not be seated in the rear cargo area. The rear
cargo space is intended for load carrying purposes
only, not for passengers, who should sit in seats and
use seat belts.
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
