Page 16 of 380
A WORD ABOUT YOUR KEYSYour vehicle uses a keyless ignition system.
This system consists of a Key Fob with Remote
Keyless Entry (RKE) transmitter and a Wireless
Ignition Node (WIN) with integral ignition
switch. You can insert the Key Fob into the
ignition switch with either side up.
Keyless Enter-N-Go Feature
This vehicle is equipped with the Keyless Enter-
N-Go feature, refer to “Starting Procedures” in
“Starting And Operating” for further informa-
tion.
Wireless Ignition Node (WIN)The Wireless Ignition Node (WIN) operates
similar to an ignition switch. It has four operat-
ing positions, three of which are detented and
one spring-loaded. The detented positions are
OFF, ACC, and ON/RUN. The START position is
a spring-loaded momentary contact position.
When released from the START position, the
switch automatically returns to the detented
ON/RUN position.NOTE:
With the Keyless Enter-N-Go feature, the
Electronic Vehicle Information Center (EVIC)
will display the ignition switch position
(OFF/ACC/RUN). Refer to “Electronic Ve-
hicle Information Center (EVIC)” in “Under-
standing Your Instrument Panel” for further
information.
Key FobThe Key Fob operates the ignition switch. Insert
the square end of the key fob into the ignition
switch located on the instrument panel and
rotate to the desired position. It also contains
the Remote Keyless Entry (RKE) transmitter
and an emergency key, which stores in the rear
of the Key Fob.
The emergency key allows for entry into the
vehicle on the driver’s side should the battery in
the vehicle or the RKE transmitter go dead. The
emergency key is also for locking the glove
box. You can keep the emergency key with you
when valet parking.
NOTE:
Entering a vehicle using the emergency key
with the theft alarm armed, will result in the
alarm sounding. Insert the Key Fob (even if
the Key Fob battery is dead) into the ignition
switch to disarm theft alarm.
To remove the emergency key, slide the me-
chanical latch at the top of the Key Fob side-
ways with your thumb and then pull the key out
with your other hand.
Wireless Ignition Node (WIN)
1 — OFF
2 — ACC (ACCESSORY)
3 — ON/RUN
4—START
12
Page 17 of 380
NOTE:
You can insert the double-sided emergency
key into the lock cylinders with either side
up.
Removing Key Fob From IgnitionPlace the shift lever in PARK. Turn the Key Fob
to the OFF position and then remove the Key
Fob.
With the Keyless Enter-N-Go feature, the EVIC
will display the ignition switch position “OFF/
ACC/RUN”. Refer to “Electronic Vehicle Infor-
mation Center (EVIC)” in “Understanding Your
Instrument Panel” for further information.NOTE:
•
If you try to remove the Key Fob before
you place the shift lever in PARK, it may
become trapped temporarily in the igni-
tion switch. If this occurs, place the shift
lever in PARK, rotate the key to the right
slightly, then remove the Key Fob as de-
scribed. If a malfunction occurs, the sys-
tem may trap the key in the ignition switch
to warn you that this safety feature is
inoperable. The engine can be started and
stopped, but the Key Fob cannot be re-
moved until you obtain service.
• The power window switches, radio, power
sunroof (if equipped), and power outlets
will remain active for up to 10 minutes
after the ignition switch is turned to the
OFF position. Opening either front door
will cancel this feature. The time for this
feature is programmable. Refer to “Elec-
tronic Vehicle Information Center (EVIC)/
Personal Settings (Customer-Program-
mable Features)” in “Understanding Your
Instrument Panel” for further information.
CAUTION!
•If your vehicle battery becomes low or
dead, your Key Fob will become locked in
the ignition.
• Do not attempt to remove the Key Fob
while in this condition, damage could occur
to the Key Fob or ignition module. Only
remove the emergency key for locking and
unlocking the doors.
• Leave the Key Fob in the ignition and
either:
• Jump Start the vehicle.
• Charge the battery.
WARNING!
•When leaving the vehicle, always remove
the key fob from the ignition and lock your
vehicle.
• Never leave children alone in a vehicle, or
with access to an unlocked vehicle.
(Continued)
Emergency Key Removal
13
Page 67 of 380
•ADAPTIVE CRUISE CONTROL (ACC) — IF EQUIPPED .... 117
• Adaptive Cruise Control (ACC) Operation .......... 118
• Activating Adaptive Cruise Control (ACC) ......... 119
• To Activate ............................ 119
• To Set A Desired ACC Speed ................. 119
• To Cancel ............................. 120
• ToTurnOff ............................ 120
• To Resume Speed ........................ 120
• To Vary The Speed Setting .................. 121
• Setting The Following Distance In ACC ........... 122
• Adaptive Cruise Control (ACC) Menu ............ 123
• Display Warnings And Maintenance ............. 124
• Precautions While Driving With ACC ............ 126
• Normal (Fixed Speed) Cruise Control Mode ........ 128
• Forward Collision Warning — If Equipped ......... 129
• PARKSENSE PARK ASSIST — IF EQUIPPED ......... 131
• ParkSense Sensors...................... 132
• ParkSense Warning Display ................. 132
• ParkSense Display...................... 132
• Enabling And Disabling ParkSense ............. 134
• Service The ParkSense Park Assist System........ 135
• Cleaning The ParkSense System.............. 135
63
Page 77 of 380
When RCP is on and the vehicle is in REVERSE,
the driver is alerted using both the visual and
audible alarms, including reducing the radio
volume.
WARNING!
RCP is not a Back Up Aid system. It is
intended to be used to help a driver detect an
oncoming vehicle in a parking lot situation.
Drivers must be careful when backing up,
even when using RCP. Always check carefully
behind your vehicle, look behind you, and be
sure to check for pedestrians, animals, other
vehicles, obstructions, and blind spots before
backing up. Failure to do so can result in
serious injury or death.
Modes Of OperationThree selectable modes of operation are avail-
able in the Electronic Vehicle Information Center
(EVIC). Refer to “Electronic Vehicle Information
Center (EVIC)/Personal Settings (Customer-
Programmable Features)” in “Understanding
Your Instrument Panel” for further information.
Blind Spot Alert
When operating in Blind Spot Alert mode, the
BSM system will provide a visual alert in the
appropriate side view mirror based on a de-
tected object. However, when the system is
operating in RCP, the system will respond with
both visual and audible alerts when a detected
object is present. Whenever an audible alert is
requested, the radio volume is reduced.
Blind Spot Alert Lights/Chime
When operating in Blind Spot Alert Lights/
Chime, the BSM system will provide a visual
alert in the appropriate side view mirror based
on a detected object. If the turn signal is then
activated, and it corresponds to an alert pres-
ent on that side of the vehicle, an audible chime
will also be sounded. Whenever a turn signal
and detected object are present on the same
side at the same time, both the visual and audio
alerts will be issued. In addition to the audible
alert the radio (if on) volume will be reduced.
NOTE:
•Whenever an audible alert is requested by
the BSM system, the radio volume is re-
duced. •
If the hazard flashers are on, the system
will request the appropriate visual alert
only.
When the system is in RCP, the system shall
respond with both visual and audible alerts
when a detected object is present. When-
ever an audible alert is requested, the radio
volume is reduced. Turn/hazard signal status
is ignored; the RCP state always requests
the chime.
Blind Spot Alert Off
When the BSM system is turned off there will be
no visual or audible alerts from either the BSM
or RCP systems.
NOTE:
The BSM system will store the current oper-
ating mode when the vehicle is shut off.
Each time the vehicle is started the previ-
ously stored mode will be recalled and used.
Astronomy Zone — System Temporarily
Unavailable
When the vehicle enters this zone the blind
spot system will become temporarily unavail-
able and the EVIC will display the message “
Blind spot system unavailable-Astronomy 73
Page 79 of 380
the radio volume control knob or from the
steering wheel radio control, if so equipped.
The radio display will be used for visual
prompts from the Uconnect™ Phone such as
CELL or caller ID on certain radios.
Compatible Phones* The Uconnect™ Phone requires a mobile
phone equipped with the Bluetooth
“Hands-Free Profile”, version 1.0 or higher.
See Uconnect™ website for supported
phones.
• www.chrysler.com/uconnect
• www.dodge.com/uconnect
• www.jeep.com/uconnect
To find the list of compatible phones navigate
through the following menus:
• Select model year for the vehicle
• Select type of the vehicle
• In the getting started tab, select compatible
phones
OperationVoice commands can be used to operate the
Uconnect™ Phone and to navigate through the
Uconnect™ Phone menu structure. Voice com-
mands are required after most Uconnect™
Phone prompts. You will be prompted for a
specific command and then guided through
the available options.
•Prior to giving a voice command, one must
wait for the beep, which follows the “Ready”
prompt or another prompt.
• For certain operations, compound com-
mands can be used. For example, instead of
saying “Setup” and then “Phone Pairing”, the
following compound command can be said:
“Setup Phone Pairing”.
• For each feature explanation in this section,
only the compound form of the voice com-
mand is given. You can also break the com-
mands into parts and say each part of the
command when you are asked for it. For
example, you can use the compound form
voice command “Phonebook New Entry”, or
you can break the compound form com-
mand into two voice commands: “Phone- book” and “New Entry”. Please remember,
the Uconnect™ Phone works best when you
talk in a normal conversational tone, as if
speaking to someone sitting a few feet/
meters away from you.
Voice Command Tree
Refer to “Voice Tree.”
Help Command
If you need assistance at any prompt, or if you
want to know your options at any prompt, say
“Help” following the beep. The Uconnect™
Phone will play all the options at any prompt if
you ask for help.
To activate the Uconnect™ Phone from idle,
simply press the
button and follow the
audible prompts for directions. All Uconnect™
Phone sessions begin with a press of the
button on the radio control head.
Cancel Command
At any prompt, after the beep, you can say
“Cancel” and you will be returned to the main
menu. However, in a few instances the system
will take you back to the previous menu.
75
Page 80 of 380
Pair (Link) Uconnect™ Phone To A Mobile
Phone
To begin using your Uconnect™ Phone, you
must pair your compatible Bluetoothenabled
mobile phone (refer to “Compatible Phones”
section to learn about the phone type).
To complete the pairing process, you will need
to reference your mobile phone owner’s
manual. The Uconnect™ website may also
provide detailed instructions for pairing.
The following are general phone to Uconnect™
Phone pairing instructions:
• Press the
button to begin.
• After the “Ready” prompt and the following
beep, say “Setup Phone Pairing”.
• When prompted, after the beep, say “Pair a
Phone” and follow the audible prompts.
• You will be asked to say a four-digit Personal
Identification Number (PIN), which you will
later need to enter into your mobile phone.
You can enter any four-digit PIN. You will not
need to remember this PIN after the initial
pairing process. •
For identification purposes, you will be
prompted to give the Uconnect™ Phone a
name for your mobile phone. Each mobile
phone that is paired should be given a
unique phone name.
• You will then be asked to give your mobile
phone a priority level between 1 and 7, with
1 being the highest priority. You can pair up
to seven mobile phones to your Uconnect™
Phone. However, at any given time, only one
mobile phone can be in use, connected to
your Uconnect™ System. The priority allows
the Uconnect™ Phone to know which mobile
phone to use if multiple mobile phones are in
the vehicle at the same time. For example, if
priority 3 and priority 5 phones are present in
the vehicle, the Uconnect™ Phone will use
the priority 3 mobile phone when you make a
call. You can select to use a lower priority
mobile phone at any time (refer to “Ad-
vanced Phone Connectivity”).
Dial By Saying A Number
• Press the
button to begin.
• After the “Ready” prompt and the following
beep, say “Dial.” •
The system will prompt you to say the num-
ber you want to call.
• For example, you can say “151-1234-5555.”
• The Uconnect™ Phone will confirm the
phone number and then dial. The number
will appear in the display of certain radios.
Call By Saying A Name
• Press the
button to begin.
• After the “Ready” prompt and the following
beep, say “Call.”
• The system will prompt you to say the name
of the person you want to call.
• After the “Ready” prompt and the following
beep, say the name of the person you want
to call. For example, you can say “John
Doe”, where John Doe is a previously stored
name entry in the Uconnect™ Phonebook or
downloaded phonebook. To learn how to
store a name in the phonebook , refer to
“Add Names to Your Uconnect™ Phone-
book”.
76
Page 81 of 380
•The Uconnect™ Phone will confirm the name
and then dial the corresponding phone num-
ber, which may appear in the display of
certain radios.
Add Names To Your Uconnect™
Phonebook
NOTE:
Adding names to the Uconnect™ Phone-
book is recommended when the vehicle is
not in motion.
• Press the
button to begin.
• After the “Ready” prompt and the following
beep, say “Phonebook New Entry”.
• When prompted, say the name of the new
entry. Use of long names helps the Voice
Command and it is recommended. For ex-
ample, say “Robert Smith” or “Robert” in-
stead of “Bob”.
• When prompted, enter the number designa-
tion (e.g., “Home”, “Work”, “Mobile”, or
“Other”). This will allow you to store multiple
numbers for each phonebook entry, if de-
sired. •
When prompted, recite the phone number
for the phonebook entry that you are adding.
After you are finished adding an entry into the
phonebook, you will be given the opportunity to
add more phone numbers to the current entry
or to return to the main menu.
The Uconnect™ Phone will allow you to enter
up to 32 names in the phonebook with each
name having up to four associated phone
numbers and designations. Each language has
a separate 32-name phonebook accessible
only in that language. In addition, if equipped
and supported by your phone, Uconnect™
Phone automatically downloads your mobile
phone’s phonebook.
Phonebook Download — Automatic
Phonebook Transfer From Mobile Phone
If equipped and specifically supported by your
phone, Uconnect™ Phone automatically down-
loads names (text names) and number entries
from your mobile phone’s phonebook. Specific
Bluetooth Phones with Phone Book Access
Profile may support this feature. See
Uconnect™ website for supported phones. •
To call a name from downloaded (or
Uconnect™) Phonebook, follow the proce-
dure in “Call by Saying a Name” section.
• Automatic download and update, if sup-
ported, begins as soon as the phone
Bluetooth wireless connection is made to
the Uconnect™ Phone. For example, after
you start the vehicle.
• Maximum of 1000 entries per phone will be
downloaded and updated every time a
phone is connected to the Uconnect™
Phone.
• Depending on the maximum number of en-
tries downloaded, there may be a short
delay before the latest downloaded names
can be used. Until then, if available, the
previously downloaded phonebook is avail-
able for use.
• Only the phonebook of the currently con-
nected mobile phone is accessible.
• Only the mobile phone’s phonebook is
downloaded. SIM card phonebook is not
part of the mobile phonebook.
77
Page 86 of 380
You can use your Uconnect™ Phone to access
a voice mail system or an automated service,
such as a paging service or automated cus-
tomer service. Some services require immedi-
ate response selection. In some instances, that
may be too quick for use of the Uconnect™
Phone.
When calling a number with your Uconnect™
Phone that normally requires you to enter in a
touch-tone sequence on your mobile phone
keypad, you can press the
button and
say the sequence you wish to enter followed by
the word “Send”. For example, if required to
enter your PIN followed with a hash, (3746#),
you can press the
button and say, “3 7 4
6 # Send”. Saying a number, or sequence of
numbers, followed by “Send”, is also to be
used for navigating through an automated cus-
tomer service center menu structure, and to
leave a number on a pager.
You can also send stored Uconnect™ Phone-
book entries as tones for fast and easy access
to voice mail and pager entries. To use this
feature, dial the number you wish to call and
then press the
button and say “Send.”
The system will prompt you to enter the name or number and say the name of the phonebook
entry you wish to send. The Uconnect™ Phone
will then send the corresponding phone num-
ber associated with the phonebook entry, as
tones over the phone.
NOTE:
•
You may not hear all of the tones due to
mobile phone network configurations;
this is normal.
• Some paging and voice mail systems
have system time out settings that are too
short and may not allow the use of this
feature.
Barge In — Overriding Prompts
The “Voice Command” button can be used
when you wish to skip part of a prompt and
issue your voice command immediately. For
example, if a prompt is asking “Would you like
to pair a phone, clear a,” you could press the
button and say, “Pair a Phone” to select
that option without having to listen to the rest of
the voice prompt.
Turning Confirmation Prompts On/Off
Turning confirmation prompts off will stop the
system from confirming your choices (e.g., the Uconnect™ Phone will not repeat a phone
number before you dial it).
•
Press the
button to begin.
• After the “Ready” prompt and the following
beep, say:
“Setup Confirmations Prompts On”
“Setup Confirmations Prompts Off”
Phone And Network Status Indicators
If available on the radio and/or on a premium
display such as the instrument panel cluster,
and supported by your mobile phone, the
Uconnect™ Phone will provide notification to
inform you of your phone and network status
when you are attempting to make a phone call
using Uconnect™ Phone. The status is given
for network signal strength, phone battery
strength, etc.
Dialing Using The Mobile Phone Keypad
You can dial a phone number with your mobile
phone keypad and still use the Uconnect™
Phone (while dialing via the mobile phone
keypad, the user must exercise caution and
take precautionary safety measures). By dial-
ing a number with your paired Bluetooth mo-
82
Page 107 of 380
12. Repeat the above steps to set the next
memory position, using the other numbered
memory button, or to link another RKE transmit-
ter to memory.
Memory Position Recall
NOTE:
The vehicle must be in PARK to recall
memory positions. If a recall is attempted
when the vehicle is not in PARK, a message
will be displayed in the Electronic Vehicle
Information Center (EVIC).
To recall the memory settings for driver one,
press MEMORY button number 1 on the driv-
er’s door, or the UNLOCK button on the RKE
transmitter linked to memory position 1.
To recall the memory setting for driver two,
press MEMORY button number 2 on the driv-
er’s door, or the UNLOCK button on the RKE
transmitter linked to memory position 2.
A recall can be cancelled by pressing any of
the MEMORY buttons on the drivers door dur-
ing a recall (S, 1, or 2). When a recall is
cancelled, the driver’s seat, driver’s mirror andthe pedals stop moving. A delay of one second
will occur before another recall can be se-
lected.
To Disable A RKE Transmitter
Linked To Memory
1. Turn the ignition switch to the LOCK posi-
tion, and remove the key.
2. Press and release MEMORY button number
1. The system will recall any memory settings
stored in position 1. Wait for the system to
complete the memory recall before continuing
to Step 3.
3. Press and release the memory S (SET) but-
ton located on the driver’s door.
4. Within five seconds, press and release
MEMORY button 1 on the driver’s door.
5. Within five seconds, press and release the
UNLOCK button on the RKE transmitter.
To disable another RKE transmitter linked to
either memory position, repeat steps 1 through
5 for each RKE transmitter.
NOTE:
Once programmed, all RKE transmitters
linked to memory can be easily enabled or
disabled at one time. Refer to “Electronic
Vehicle Information Center (EVIC)/Customer-
Programmable Features” in “Understanding
Your Instrument Panel” for further informa-
tion.
Easy Entry/Exit SeatThis feature provides automatic driver’s seat
positioning which will enhance driver mobility
out of and into the vehicle.
There are two possible Easy Entry/Exit adjust-
ments available:
•
The seat cushion will move rearward ap-
proximately 2.5 in (60 mm), if the starting
position of the seat is greater than or equal to
2.67 in (68 mm) forward of the rear seat stop
when the key is removed from the ignition
switch. The seat will then move forward
approximately 2.5 in (60 mm) when the key is
placed into the ignition and turned out of the
LOCK position.
103
Page 123 of 380
NOTE:
Any chassis/suspension modifications to
the vehicle will effect the performance of the
Adaptive Cruise Control.
Activating Adaptive Cruise Control
(ACC)
You can only activate ACC if the vehicle speed
is above 18 mph (30 km/h).
When the system is turned on and in the
READY state, the Electronic Vehicle Information
Center (EVIC) displays “Adaptive Cruise
Ready.”
When the system is OFF, the EVIC displays
“Adaptive Cruise Control Off.”
NOTE:
You cannot enable ACC under the following
conditions:
•When in Four-Wheel Drive Low.
• When you apply the brakes.
• When the parking brake is set.
• When the automatic transmission is in
PARK, REVERSE or NEUTRAL. •
When pushing the RES + button without a
previously set speed in memory.
To ActivatePush and release the ON/OFF button. The ACC
menu in the EVIC displays “Adaptive Cruise
Ready.”
To turn the system OFF, push and release the
ON/OFF button again. At this time, the system
will turn off and the EVIC will display “Adaptive
Cruise Control Off.”
WARNING!
Leaving the Adaptive Cruise Control (ACC)
system on when not in use is dangerous. You
could accidentally set the system or cause it
to go faster than you want. You could lose
control and have a collision. Always leave the
system off when you are not using it.
To Set A Desired ACC SpeedWhen the vehicle reaches the speed desired,
push the SET -button and release. The EVIC
will display the set speed.
Adaptive Cruise Control Ready
ACC Set
11 9
