NOTE:
To improve the vehicle’s traction when driv-
ing with snow chains, or starting off in deep
snow, sand, or gravel, it may be desirable to
switch to the “Partial Off” mode by pressing
the “ESC OFF” switch. Once the situation
requiring ESC to be switched to the “Partial
Off” mode is overcome, turn ESC back on by
momentarily pressing the “ESC OFF”
switch. This may be done while the vehicle
is in motion.
WARNING!
•When in "Partial Off" mode, the TCS func-
tionality of ESC, (except for the limited slip
feature described in the TCS section), has
been disabled and the "ESC Off Indicator
Light" will be illuminated. When in "Partial
Off" mode, the engine power reduction
feature of TCS is disabled, and the en-
hanced vehicle stability offered by the ESC
system is reduced.
• Trailer Sway control (TSC) is disabled
when the ESC system is in the "Partial Off"
mode.
4WD Low Range
Partial Off
This is the normal operating mode for ESC in
4WD LOW range. Whenever the vehicle is
started in 4WD LOW range, or the transfer case
(if equipped) is shifted from 4WD HIGH range or
NEUTRAL to 4WD LOW range, the ESC sys-
tem will be in the “Partial Off” mode.Trailer Sway Control (TSC)TSC uses sensors in the vehicle to recognize
an excessively swaying trailer and will take the
appropriate actions to attempt to stop the sway.
The system may reduce engine power and
apply the brake of the appropriate wheel(s) to
counteract the sway of the trailer. TSC will
become active automatically once an exces-
sively swaying trailer is recognized. No driver
action is required. Note that TSC cannot stop all
trailers from swaying. Always use caution when
towing a trailer and follow the trailer tongue
weight recommendations. Refer to “Trailer Tow-
ing” in “Starting and Operating” for further infor-
mation. When TSC is functioning, the “ESC
Activation/Malfunction Indicator Light” will flash,
the engine power may be reduced and you may
feel the brakes being applied to individual
wheels to attempt to stop the trailer from sway-
ing. TSC is disabled when the ESC system is in
the “Partial Off” mode.
ESC OFF Switch
255

WARNING!(Continued)
•Never use a tire with a smaller load index
or capacity, other than what was originally
equipped on your vehicle. Using a tire with
a smaller load index could result in tire
overloading and failure. You could lose
control and have a collision.
• Failure to equip your vehicle with tires
having adequate speed capability can re-
sult in sudden tire failure and loss of ve-
hicle control.
CAUTION!
Replacing original tires with tires of a differ-
ent size may result in false speedometer and
odometer readings.
TIRE CHAINS (TRACTION
DEVICES)
Use of traction devices require sufficient tire-to-
body clearance. Follow these recommenda-
tions to guard against damage.
• Traction device must be of proper size for the
tire, as recommended by the traction device
manufacturer.
• Install on Rear Tires Only
• Due to limited clearance, use reduced size
snow chains or traction devices with a maxi-
mum projection of 6 mm beyond the tire
profile.
WARNING!
Using tires of different size and type (M+S,
Snow) between front and rear axles can cause
unpredictable handling. You could lose control
and have a collision.
CAUTION!
To avoid damage to your vehicle or tires,
observe the following precautions:
•Because of restricted traction device clear-
ance between tires and other suspension
components, it is important that only trac-
tion devices in good condition are used.
Broken devices can cause serious dam-
age. Stop the vehicle immediately if noise
occurs that could indicate device break-
age. Remove the damaged parts of the
device before further use.
• Install device as tightly as possible and
then retighten after driving about ½ mile
(0.8 km).
• Do not exceed 30 mph (48 km/h).
• Drive cautiously and avoid severe turns
and large bumps, especially with a loaded
vehicle.
• Do not drive for prolonged period on dry
pavement.
(Continued)
265

The Tire Pressure Monitoring Telltale Light will
flash on and off for 75 seconds, and remain on
solid when a system fault is detected. In addi-
tion, a “SERVICE TPM SYSTEM” message
may be displayed for approximately 5 seconds
when a system fault is detected, and a chime
will sound. If the ignition switch is cycled, this
sequence will repeat, providing the system fault
still exists. The Tire Pressure Monitoring Telltale
Light will turn off when the fault condition no
longer exists. A system fault can occur by any of
the following:
1. Jamming due to electronic devices or driving
next to facilities emitting the same Radio Fre-
quencies as the TPM sensors.
2. Installing some form of aftermarket window
tinting that affects radio wave signals.
3. Lots of snow or ice around the wheels or
wheel housings.
4. Using tire chains on the vehicle.
5. Using wheels/tires not equipped with TPM
sensors.NOTE:There is no tire pressure monitoring sensor in
the spare tire. The TPMS will not be able to
monitor the tire pressure. If you install the
spare tire, in place of a road tire, that has a
pressure below the low-pressure warning
limit, upon the next ignition switch cycle, a
chime will sound, a “LOW TIRE PRESSURE”
message will be displayed in the instrument
cluster for a minimum of five seconds, an
Inflate to XXX
message will be displayed and
the Tire Pressure Monitoring Telltale Light will
turn ON. After driving the vehicle for up to 20
minutes above 15 mph (24 km/h), the Tire
Pressure Monitoring Telltale Light will flash on
and off for 75 seconds and then remain on
solid. In addition, a “SERVICE TPM SYSTEM”
message will be displayed for a minimum of
five seconds. For each subsequent ignition
switch cycle, a chime will sound, a “SERVICE
TPM SYSTEM” message will be displayed for
a minimum of five seconds, and the Tire Pres-
sure Monitoring Telltale Light will flash on and
off for 75 seconds and then remain on solid. Once you repair or replace the original road
tire, and reinstall it on the vehicle in place of
the spare tire, the TPMS will update automati-
cally and the Tire Pressure Monitoring Telltale
Light will turn OFF, as long as no tire pressure
is below the low-pressure warning limit in any
of the four active road tires. The vehicle may
need to be driven for up to 20 minutes above
15 mph (24 km/h) in order for the TPMS to
receive this information.
Premium System – If EquippedThe Tire Pressure Monitor System (TPMS)
uses wireless technology with wheel rim-
mounted electronic sensors to monitor tire pres-
sure levels. Sensors, mounted to each wheel as
part of the valve stem, transmit tire pressure
readings to the Receiver Module.
NOTE:
It is particularly important, for you to regu-
larly check the tire pressure in all of your
tires and to maintain the proper pressure.
269

If the ignition switch is cycled, this sequence will
repeat, providing the system fault still exists. If
the system fault no longer exists, the Tire Pres-
sure Monitoring Telltale Light will no longer
flash, the"SERVICE TPM SYSTEM" message
will not be present, and a pressure value will be
displayed instead of dashes. A system fault can
occur by any of the following:
1. Jamming due to electronic devices or driving
next to facilities emitting the same Radio Fre-
quencies as the TPM sensors.
2. Installing some form of aftermarket window
tinting that affects radio wave signals. 3. Lots of snow or ice around the wheels or
wheel housings.
4. Using tire chains on the vehicle.
5. Using wheels/tires not equipped with TPM
sensors.
The EVIC will also display a
"SERVICE TPM
SYSTEM" message for a minimum of five sec-
onds when a system fault is detected possibly
related to an incorrect sensor location fault. In
this case, the "SERVICE TPM SYSTEM" mes-
sage is then followed by a graphic display, with
pressure values still shown. This indicates the
pressure values are still being received from the
TPM Sensors but they may not be located in the
correct vehicle position. However, the system
still needs to be serviced as long as the "SER-
VICE TPM SYSTEM" message exists.
NOTE:
There is no tire pressure monitoring sensor
in the spare tire. The TPMS will not be able to
monitor the tire pressure. If you install the
spare tire in place of a road tire that has a
pressure below the low-pressure warning limit, upon the next ignition switch cycle, the
Tire Pressure Monitoring Telltale Light will
remain ON, a chime will sound, and the EVIC
will still display a “flashing” pressure value
in the graphic display and an
Inflate to
XXX kPa message will be displayed. After
driving the vehicle for up to 20 minutes
above 15 mph (24 km/h), the Tire Pressure
Monitoring Telltale Light will flash on and off
for 75 seconds and then remain on solid. In
addition, the EVIC will display a “SERVICE
TPM SYSTEM message for five seconds
and then display dashes (- -) in place of the
pressure value. For each subsequent igni-
tion switch cycle, a chime will sound, the
Tire Pressure Monitoring Telltale Light will
flash on and off for 75 seconds and then
remain on solid, and the EVIC will display a
SERVICE TPM SYSTEM message for five
seconds and then display dashes (- -) in
place of the pressure value. Once you repair
or replace the original road tire, and reinstall
it on the vehicle in place of the spare tire, the
TPMS will update automatically.
271

Refrigerant................. .317
Reminder, Seat Belt ..............40
Remote Keyless Entry (RKE) .........19
Remote Sound System (Radio) Controls . .207
Replacement Bulbs .............336
Replacement Keys ...............15
Replacement Parts ..............312
Replacement Tires ..............264
Resetting Oil Change Indicator .......177
Restraints, Child ................50
Restraints, Occupant .............31
Retractable Cargo Area Cover .......152
Roll Over Warning ................4
Rotation, Tires ................266
Safety Checks Inside Vehicle .........60
Safety Checks Outside Vehicle ........61
Safety, Exhaust Gas ...........30, 60
Safety Tips ...................59
Schedule, Maintenance ........344, 359
Seat Belt Maintenance ............331
Seat Belt Reminder ..............40
Seat Belts .................33, 60
Adjustable Upper Shoulder
Anchorage .................36
And Pregnant Women ..........41
Child Restraint ............50, 56 Front Seat
.................33
Inspection .................60
Pretensioners ...............37
Reminder ................ .165
Shoulder Belt Anchorage .........36
Untwisting Procedure ...........35
Seats ......................94
Easy Entry ................104
Memory ................. .102
Power ...................95
Rear Folding ...............100
Security Alarm (Theft Alarm) ......16, 167
Selec-Terrain ................ .240
Selection of Oil ................314
Sentry Key (Immobilizer) ...........15
Sentry Key Programming ...........16
Sentry Key Replacement ...........15
Service Assistance ..............372
Service Engine Soon

Light
(Malfunction Indicator) ..........162
Settings, Personal ..............184
Shifting ....................225
Automatic Transmission .........225
Shift Lever Override .............304
Shoulder Belts .................33
Side Airbag ...................46
Signals, Turn .........61, 163, 337, 338 SmartBeams
.................107
Snow Chains (Tire Chains) .........265
Snow Tires ................. .261
Sound Systems ................188
Sound Systems (Radio) ...........188
Spare Tire ................262, 295
Specifications Fuel (Gasoline) .............273
Oil .................... .314
Speed Control (Cruise Control) ....117,119
Speedometer .................166
Starting ....................220
Automatic Transmission .........220
Cold Weather ..............222
Engine Fails to Start ..........222
Starting and Operating ............220
Starting Procedures .............220
Steering Power ................248, 250
Tilt Column .............115,116
Wheel, Heated ..............116
Wheel Lock ................14
Wheel, Tilt .............115,116
Steering Wheel Audio Controls .......207
Steering Wheel Mounted Sound System Controls ................. .207
Storage ....................335
400

Storage, Vehicle............213, 335
Storing Your Vehicle .............335
Sunglasses Storage .............141
Sun Roof ................142, 144
Sun Visor Extension ..............72
Supplemental Restraint System - Airbag. . .41
Suspension, Air ................241
Sway Control, Trailer .............255
Synthetic Engine Oil .............315
Tachometer ................. .162
Telescoping Steering Column .....115,116
Temperature Control, Automatic (ATC) . . .209
Temperature Gauge, Engine Coolant . . . .167
Tether Anchor, Child Restraint ........54
Theft Alarm (Security Alarm) .........16
Theft System (Security Alarm) ........16
Tie Down Hooks, Cargo ...........153
Tilt Steering Column ..........115,116
Tires ....................61, 259
Aging (Life of Tires) ...........264
Air Pressure ...............259
Chains ................. .265
Compact Spare .............262
General Information ...........259
High Speed ...............260
Inflation Pressures ............260 Life of Tires
...............264
Pressure Monitor System (TPMS) . . .266
Pressure Warning Light .........164
Radial ...................261
Replacement ...............264
Rotation ................ .266
Safety ...................259
Snow Tires ................261
Spare Tire ................295
Spinning ................ .263
Tread Wear Indicators ..........263
Tongue Weight/Trailer Weight ........281
Tow/Haul Indicator Light ...........163
Towing ................. .278, 304
Disabled V

ehicle.............304
Guide ...................281
Recreational ...............287
Weight ................. .281
Towing Eyes ................ .303
Traction Control ................252
Trailer Sway Control (TSC) .........255
Trailer Towing ................ .278
Cooling System Tips ..........285
Hitches ................. .286
Minimum Requirements .........282
Trailer and Tongue Weight .......281
Wiring ...................284 Trailer Towing Guide
.............281
Trailer Weight .................281
Transfer Case ................326
Maintenance ...............326
Transmission Automatic ...........226, 231, 326
Maintenance ...............326
Shifting ................. .225
Transmitter Battery Service (Remote Keyless Entry) ..........20
Transmitter Programming (Remote Keyless Entry) ..........19
Transmitter, Remote Keyless Entry (RKE) . .19
Transporting Pets ...............58
Tread Wear Indicators ............263
Turn Signals ............163, 337, 338
UCI Connector ................189
Uconnect® (Hands-Free Phone) .......72
Universal Consumer Interface (UCI) Connector .................189
Untwisting Procedure, Seat Belt .......35
Vanity Mirrors .................72
Variance, Compass ..............182
Vehicle Identification Number (VIN) ......8
Vehicle Modifications/Alterations ........8
401
