Fuel IconsWhat It Means
Diesel fuel containing up to7%(V/V) Fatty Acid Methyl Esters (FAME)EN590compliant fuel
Diesel fuel containing up to 10 % (V/V) Fatty Acid Methyl Esters (FAME)EN16734compliant fuel
289

NON-SRT FLUID
CAPACITIES
U.S. Metric
Fuel (Approximate)
All Engines24.6 Gallons 93.1 Liters
AdBlue
®Fluid Tank8 Gallons 30.3 Liters
Engine Oil with Filter
3.6L Engine (API Certified SAE 0W-20, FCA Material Standard 9.55535-CR1 or
MS-6395)6 Quarts 5.6 Liters
5.7L Engine (API Certified SAE 5W-20, FCA Material Standard 9.55535-CR1 or
MS-6395)7 Quarts 6.6 Liters
3.0L Diesel Engine (API Certified SAE 5W-40, ACEA A3/B4, API CJ-4/SM, FCA
Material Standard 9.55535-D3 or MS-10902)8 Quarts 7.7 Liters
Cooling System *
3.6L Engine (OAT FCA Material Standard MS.90032) 10.4 Quarts 9.9 Liters
5.7 Liter Engine (OAT FCA Material Standard MS.90032) – Without Trailer Tow
Package15.4 Quarts 14.6 Liters
5.7 Liter Engine (OAT FCA Material Standard MS.90032) – With Trailer Tow
Package16 Quarts 15.2 Liters
3.0L Diesel Engine (OAT FCA Material Standard MS.90032) 12 Quarts 11.4 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
TECHNICAL SPECIFICATIONS
290

SRT FLUID CAPACITIES
U.S. Metric
Fuel (Approximate)
24.6 Gallons 93.1 Liters
Engine Oil With Filter
6.2 Liter Engine (SAE 0W-40, Synthetic API Certified, MS-12633 or ACEA A1/B1) 8.3 Quarts 7.8 Liters
6.4 Liter Engine (SAE 0W-40, Synthetic API Certified, MS-12633 or ACEA A1/B1) 7 Quarts 6.6 Liters
Cooling System*
6.2L Engine (OAT FCA Material Standard MS.90032) 14.7 Quarts 13.9 Liters
6.2L Engine Intercooler (OAT FCA Material Standard MS.90032)) 4.0 Quarts 3.9 Liters
6.4 Liter Engine (OAT FCA Material Standard MS.90032) 16 Quarts 15.5 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
FLUIDS AND LUBRICANTS
NON-SRT
Engine
Your vehicle is equipped with an engine oil
that has been thoroughly developed and
tested in order to meet the requirements of
the Scheduled Servicing Plan. Constant use
of the prescribed lubricants guarantees the
fuel consumption and emission specifica-
tions. Lubricant quality is crucial for engine
operation and duration. If lubricants con-
forming to the specific request are not avail-able, products that meet the indicated speci-
fications can be used to top up, in this case
optimal performance of the engine is not
guaranteed.
291

Component Fluid, Lubricant, or Genuine Part
Engine Coolant We recommend you use PARAFLUUPFormula OAT (Organic Additive Technology) or equivalent
meeting the requirements of FCA Material Standard MS.90032.
Engine Oil – 3.6L Engine We recommend you use SELENIA K POWER 0W-20, or equivalent, API Certified 0W-20 Engine
Oil, meeting the requirements of FCA Material Standard 9.55535-CR1 or MS-6395. Refer to
your engine oil filler cap for correct SAE grade.
Engine Oil – 5.7L Engine We recommend you use SELENIA K POWER 5W-20, or equivalent, API Certified 5W-20 Engine
Oil, meeting the requirements of FCA Material Standard 9.55535-CR1 or MS-6395. Refer to
your engine oil filler cap for correct SAE grade.
Engine Oil – 3.0L Diesel Engine We recommend you use 5W-40 synthetic engine oil such as Mopar that meets FCA Material
Standard MS-10902 or FCA 9.55535-D3 and the ACEA A3/B4 or API CJ-4/SM engine oil cat-
egory is required.
SELENIA SPORT SAE 5W-40 synthetic engine oil, or equivalent, that meets FCA Material Stan-
dard 9.55535-Z2 and the ACEA A3/B4 should be used when recommended oil is not available
Engine Oil Filter We recommend you use Mopar Engine Oil Filters or equivalent.
Spark Plugs We recommend you use Mopar Spark Plugs or equivalent.
Fuel Selection – 3.6L Engine Minimum 91 Octane (EN228)
Fuel Selection – 5.7L Engine Minimum 91 Octane Acceptable - 95 Octane Recommended (EN228)
Fuel Selection – 3.0L Diesel Engine 50 Cetane or higher (Less than 10 ppm Sulfur)(EN 590)
Additive For Diesel Emissions (UREA) AdBlue
®(Urea-Water Solution) (DEF) According to DIN 70 070 and ISO 22241-1
TECHNICAL SPECIFICATIONS
292

CAUTION!
• Mixing of engine coolant (antifreeze)
other than specified Organic Additive
Technology (OAT) engine coolant (anti-
freeze), may result in engine damage
and may decrease corrosion protection.
Organic Additive Technology (OAT) en-
gine coolant is different and should not
be mixed with Hybrid Organic Additive
Technology (HOAT) engine coolant (anti-
freeze) or any “globally compatible”
coolant (antifreeze). If a non-OAT engine
coolant (antifreeze) is introduced into
the cooling system in an emergency, the
cooling system will need to be drained,
flushed, and refilled with fresh OAT cool-
ant (conforming to MS.90032), by an
authorized dealer as soon as possible.
• Do not use water alone or alcohol-based
engine coolant (antifreeze) products. Do
not use additional rust inhibitors or an-
tirust products, as they may not be com-
patible with the radiator engine coolant
and may plug the radiator.
CAUTION!
• This vehicle has not been designed for
use with propylene glycol-based engine
coolant (antifreeze). Use of propylene
glycol-based engine coolant (antifreeze)
is not recommended.
• The use of products with different speci-
fications than those indicated above
could cause damage to the engine that is
not covered by the warranty.
• Use AdBlue
®only according to DIN
70 070 and ISO 22241-1. Other fluids
may cause damage to the system: also
exhaust emissions would no longer com-
ply with the law.
• The distribution companies are respon-
sible for the compliance of their prod-
uct. Observe the precautions of storage
and servicing, in order to preserve the
initial qualities. The manufacturer of the
vehicle does not recognize any guaran-
tee in case of malfunctions and damage
caused to the vehicle due to the use of
AdBlue
®not in accordance with
regulations.
293

Chassis
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission We recommended you use TUTELA TRANSMISSION AS8 Fluid, or equivalent, meeting require-
ments of FCA Material Standard 9.55550-AV5 or MS.90030-A5. Failure to use the correct fluid
may affect the function or performance of your transmission.
Transfer Case – Single-Speed (Quadra-Trac I) We recommended you use TUTELA TRANSMISSION POWERGEAR 4 Fluid, or equivalent, meet-
ing requirements of FCA Material Standard MS-10216.
Transfer Case – Two-Speed (Quadra-Trac II) We recommended you use TUTELA TRANSMISSION FORCE 4 Fluid, or equivalent, meeting re-
quirements of FCA Material Standard 9.55550-AV4 or MS-9602 (ATF+4).
Axle Differential (Front) We recommend you use TUTELA TRANSMISSION MULTIAXLE or equivalent, SAE 75W-85 (API-
GL5).
Axle Differential (Rear) – With Electronic
Limited-Slip Differential (ELSD)We recommend you use TRANSMISSION AXLE-DRIVE with friction modifier, or equivalent, SAE
75W-85 (API-GL5).
Axle Differential (Rear) – Without Electronic
Limited-Slip Differential (ELSD)We recommend you use TUTELA TRANSMISSION MULTIAXLE or equivalent, SAE 75W-85 (API-
GL5).
Brake Master Cylinder We recommend you use DOT 3, SAE J1703 brake fluid. If DOT 3 brake fluid is not available
then TUTELA TOP4/S, FMVSS no. 116 DOT 4, ISO 4925 SAE J1704, or equivalent, is accept-
able.
DOT 4 Brake fluid must be replaced every 24 months regardless of mileage.
TECHNICAL SPECIFICATIONS
294

FLUIDS AND LUBRICANTS —
SRT
Engine
Your vehicle is equipped with an engine oil
that has been thoroughly developed and
tested in order to meet the requirements of
the Scheduled Servicing Plan. Constant use
of the prescribed lubricants guarantees thefuel consumption and emission specifica-
tions. Lubricant quality is crucial for engine
operation and duration. If lubricants con-
forming to the specific request are not avail-
able, products that meet the indicated speci-
fications can be used to top up, in this case
optimal performance of the engine is not
guaranteed.
Component Fluid, Lubricant, or Genuine Part
Engine Coolant We recommend you use PARAFLUUPFormula OAT (Organic Additive Technology) or equivalent
meeting the requirements of FCA Material Standard MS.90032.
Engine Oil We recommend you use SELENIA DIGITEK 0W-40, or equivalent API Certified SAE 0W-40 syn-
thetic engine oil, meeting the requirements of FCA MS-12633 or ACEA A1/B1.
Engine Oil Filter We recommend you use Mopar Engine Oil Filters or equivalent.
Spark Plugs We recommend you use Mopar Spark Plugs or equivalent.
Fuel Selection We recommend you use 98 Research Octane Number (RON) or Higher (EN228).
295

CAUTION!
• Mixing of engine coolant (antifreeze)
other than specified Organic Additive
Technology (OAT) engine coolant (anti-
freeze), may result in engine damage
and may decrease corrosion protection.
Organic Additive Technology (OAT) en-
gine coolant is different and should not
be mixed with Hybrid Organic Additive
Technology (HOAT) engine coolant (an-
tifreeze) or any “globally compatible”
coolant (antifreeze). If a non-OAT engine
coolant (antifreeze) is introduced into
the cooling system in an emergency, the
cooling system will need to be drained,
flushed, and refilled with fresh OAT
coolant (conforming to MS.90032), by
an authorized dealer as soon as possible.
• Do not use water alone or alcohol-based
engine coolant (antifreeze) products. Do
not use additional rust inhibitors or an-
tirust products, as they may not be com-
patible with the radiator engine coolant
and may plug the radiator.
CAUTION!
• This vehicle has not been designed for
use with propylene glycol-based engine
coolant (antifreeze). Use of propylene
glycol-based engine coolant (antifreeze)
is not recommended.
• The use of products with different speci-
fications than those indicated above
could cause damage to the engine that
is not covered by the warranty.
• Use AdBlue
®only according to DIN
70 070 and ISO 22241-1. Other fluids
may cause damage to the system: also
exhaust emissions would no longer com-
ply with the law.
• The distribution companies are respon-
sible for the compliance of their prod-
uct. Observe the precautions of storage
and servicing, in order to preserve the
initial qualities. The manufacturer of the
vehicle does not recognize any guaran-
tee in case of malfunctions and damage
caused to the vehicle due to the use of
AdBlue
®not in accordance with
regulations.
TECHNICAL SPECIFICATIONS
296

Chassis
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission We recommended you use TUTELA TRANSMISSION AS8 Fluid, or equivalent, meeting require-
ments of FCA Material Standard 9.55550-AV5 or MS.90030-A5. Failure to use the correct fluid
may affect the function or performance of your transmission.
Transfer Case – Single-Speed (Selec-Track) We recommended you use TUTELA TRANSMISSION FORCE 4 Fluid, or equivalent, meeting
requirements of FCA Material Standard 9.55550-AV4 or MS-9602 (ATF+4).
Axle Differential (Front) We recommend you use TUTELA TRANSMISSION MULTIAXLE or equivalent, SAE 75W-85
(API-GL5).
Axle Differential (Rear) – With Electronic
Limited-Slip Differential (ELSD)We recommend you use TRANSMISSION AXLE-DRIVE with friction modifier, or equivalent, SAE
75W-85 (API-GL5).
Brake Master Cylinder We recommend you use DOT 3, SAE J1703 brake fluid. If DOT 3 brake fluid is not available then
TUTELA TOP4/S, FMVSS no. 116 DOT 4, ISO 4925 SAE J1704, or equivalent, is acceptable
If using DOT 4 brake fluid, the fluid must be changed every 24 months. This interval is time based
only, mileage intervals do not apply.
297

FUEL CONSUMPTION AND
CO
2EMISSIONS
The fuel consumption and CO2emission fig-
ures declared by the manufacturer are deter-
mined on the basis of the type-approval tests
laid down by the applicable standards in the
country where the vehicle is registered.
The type of route, traffic conditions, weather
conditions, driving style, general condition of
the vehicle, trim level/equipment/ accesso-
ries, use of the climate control system, ve-
hicle load, presence of roof racks and other
situations that adversely affect the aerody-
namics or wind resistance lead to different
fuel consumption values than those mea-
sured.The fuel consumption will only become more
regular after driving the first 1,864 miles
(3000 km).
To find the specific fuel consumption and
CO
2emission figures for this vehicle, please
refer to the data in the Certificate of Confor-
mity (if equipped), and the related documen-
tation that accompanies the vehicle (if
equipped).
MOPAR ACCESSORIES
Authentic Accessories By Mopar
In choosing Authentic Accessories you gain
far more than expressive style, premium pro-
tection, or extreme entertainment, you also
benefit from enhancing your vehicle with
accessories that have been thoroughly tested
and factory-approved.
The following highlights just some of the
many Authentic Jeep Accessories by Mopar
featuring a fit, finish, and functionality spe-
cifically for your Jeep Grand Cherokee.
TECHNICAL SPECIFICATIONS
298
