(4) Remove the screw that secures the lower
anchor to the bracket on the outboard side of the
front seat cushion frame.
(5) Unsnap and lift the trim cover to access the
nut that secures the front seat belt turning loop to
the height adjuster on the upper B-pillar (Fig. 20).
(6) Remove the nut that secures the seat belt turn-
ing loop to the height adjuster stud on the upper
B-pillar.
(7) Remove the seat belt turning loop from the
height adjuster stud.
(8) Remove the upper and lower trim from the
inside of the B-pillar. (Refer to 23 - BODY/INTERI-
OR/B-PILLAR UPPER TRIM - REMOVAL) and
(Refer to 23 - BODY/INTERIOR/B-PILLAR LOWER
TRIM - REMOVAL).
(9) On the driver side only, disconnect the seat belt
tensioner pigtail wire connector from the body wire
harness connector.
(10) Remove the screw that secures the lower
retractor bracket to the lower B-pillar.
(11) Disengage the engagement tab on the upper
retractor bracket/seat belt web guide from the
engagement slot in the lower B-pillar.
(12) Remove the front seat belt and retractor from
the B-pillar as a unit.INSTALLATION
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
WARNING: DURING AND FOLLOWING ANY SEAT
BELT SERVICE, CAREFULLY INSPECT ALL SEAT
BELTS, BUCKLES, MOUNTING HARDWARE, AND
RETRACTORS FOR PROPER INSTALLATION,
OPERATION, OR DAMAGE. REPLACE ANY BELT
THAT IS CUT, FRAYED, OR TORN. STRAIGHTEN
ANY BELT THAT IS TWISTED. TIGHTEN ANY
LOOSE FASTENERS. REPLACE ANY BELT THAT
HAS A DAMAGED OR INOPERATIVE BUCKLE OR
RETRACTOR. REPLACE ANY BELT THAT HAS A
BENT OR DAMAGED LATCH PLATE OR ANCHOR
PLATE. NEVER ATTEMPT TO REPAIR A SEAT BELT
COMPONENT. ALWAYS REPLACE DAMAGED OR
FAULTY SEAT BELT COMPONENTS WITH THE COR-
RECT, NEW AND UNUSED REPLACEMENT PARTS
LISTED IN THE MOPAR PARTS CATALOG.
(1) Position the front seat belt and retractor to the
B-pillar as a unit (Fig. 20). Be certain to engage the
engagement tab on the upper retractor bracket/seat
belt web guide into the engagement slot in the lower
B-pillar.
(2) Install and tighten the screw that secures the
lower retractor bracket to the lower B-pillar. Tighten
the screw to 43 N´m (32 ft. lbs.).
(3) On the driver side only, reconnect the seat belt
tensioner pigtail wire connector to the body wire har-
ness connector.
(4) Reinstall the upper and lower trim onto the
inside of the B-pillar. (Refer to 23 - BODY/INTERI-
OR/B-PILLAR UPPER TRIM - INSTALLATION) and
(Refer to 23 - BODY/INTERIOR/B-PILLAR LOWER
TRIM - INSTALLATION).
(5) Position the seat belt turning loop onto the
height adjuster stud on the upper B-pillar.
Fig. 20 Front Seat Belt Retractor Remove/Install
1 - ADJUSTER
2 - B-PILLAR
3 - RETRACTOR
4 - B-PILLAR TRIM
5 - CONNECTOR (DRIVER SIDE ONLY)
6 - LOWER ANCHOR
7 - NUT
8 - TURNING LOOP
9 - COVER
8O - 24 RESTRAINTSKJ
FRONT SEAT BELT & RETRACTOR (Continued)

(6) Install and tighten the nut that secures the
seat belt turning loop to the height adjuster stud.
Tighten the nut to 34 N´m (25 ft. lbs.).
(7) Fold and snap the trim cover back into place to
conceal the nut that secures the front seat belt turn-
ing loop to the height adjuster on the upper B-pillar.
(8) Position the front seat belt lower anchor to the
bracket on the outboard side of the front seat cushion
frame (Fig. 19).
(9) Install and tighten the screw that secures the
lower anchor to the bracket on the outboard side of
the front seat cushion frame. Tighten the screw to 43
N´m (32 ft. lbs.).
(10) Align the plug that covers the front seat belt
lower anchor screw with the hole near the rear of the
outboard seat side shield. Using hand pressure, press
firmly and evenly on the plug until it snaps into
place.
(11) Do not reconnect the battery negative cable at
this time. The airbag system verification test proce-
dure should be performed following service of any
supplemental restraint system component. (Refer to
8 - ELECTRICAL/RESTRAINTS - STANDARD PRO-
CEDURE - VERIFICATION TEST).
FRONT SEAT BELT BUCKLE
REMOVAL
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.WARNING: DURING AND FOLLOWING ANY SEAT
BELT SERVICE, CAREFULLY INSPECT ALL SEAT
BELTS, BUCKLES, MOUNTING HARDWARE, AND
RETRACTORS FOR PROPER INSTALLATION,
OPERATION, OR DAMAGE. REPLACE ANY BELT
THAT IS CUT, FRAYED, OR TORN. STRAIGHTEN
ANY BELT THAT IS TWISTED. TIGHTEN ANY
LOOSE FASTENERS. REPLACE ANY BELT THAT
HAS A DAMAGED OR INOPERATIVE BUCKLE OR
RETRACTOR. REPLACE ANY BELT THAT HAS A
BENT OR DAMAGED LATCH PLATE OR ANCHOR
PLATE. NEVER ATTEMPT TO REPAIR A SEAT BELT
COMPONENT. ALWAYS REPLACE DAMAGED OR
FAULTY SEAT BELT COMPONENTS WITH THE COR-
RECT, NEW AND UNUSED REPLACEMENT PARTS
LISTED IN THE MOPAR PARTS CATALOG.
(1) Disconnect and isolate the battery negative
cable. Wait two minutes for the system capacitor to
discharge before further service.
(2) Remove the front seat and seat track from the
floor panel as a unit. (Refer to 23 - BODY/SEATS/
SEAT - FRONT - REMOVAL).
(3) Disconnect the seat belt switch pigtail wire
connector from the seat wire harness connector on
the seat cushion frame bracket located under the
rear edge of the seat cushion near the inboard side of
the seat (Fig. 21).
Fig. 21 Seat Belt Switch Connector
1 - PIGTAIL WIRE
2 - SEAT WIRE HARNESS
3 - SEAT CUSHION FRAME BRACKET
4 - BODY WIRE HARNESS
5 - INBOARD SEAT TRACK
KJRESTRAINTS 8O - 25
FRONT SEAT BELT & RETRACTOR (Continued)

(4) Remove the screw that secures the front seat
belt buckle anchor to the bracket near the rear of the
inboard seat track (Fig. 22).
(5) Remove the two screws that secure the inboard
seat cushion side shield to the seat cushion frame.
(6) Remove the two screws that secure the inboard
seat track to the rear inboard corner of the seat cush-
ion frame.
(7) Disconnect the seat belt switch pigtail wire
routing clip from the locating hole in the seat cushion
frame.
(8) Remove the seat belt switch pigtail wire from
between the seat cushion frame and the seat track by
gently prying the inboard seat track away from the
inboard rear corner of the seat cushion frame far
enough to slide the pigtail wire from between them.
(9) Remove the front seat belt buckle from the
inboard seat cushion side shield.
INSTALLATION
WARNING: ON VEHICLES EQUIPPED WITH AIRBAGS,
DISABLE THE SUPPLEMENTAL RESTRAINT SYSTEM
BEFORE ATTEMPTING ANY STEERING WHEEL,
STEERING COLUMN, DRIVER AIRBAG, PASSENGER
AIRBAG, SEAT BELT TENSIONER, FRONT IMPACT
SENSORS, SIDE CURTAIN AIRBAG, OR INSTRUMENT
PANEL COMPONENT DIAGNOSIS OR SERVICE. DIS-
CONNECT AND ISOLATE THE BATTERY NEGATIVE
(GROUND) CABLE, THEN WAIT TWO MINUTES FOR
THE SYSTEM CAPACITOR TO DISCHARGE BEFORE
PERFORMING FURTHER DIAGNOSIS OR SERVICE.
THIS IS THE ONLY SURE WAY TO DISABLE THE SUP-
PLEMENTAL RESTRAINT SYSTEM. FAILURE TO TAKE
THE PROPER PRECAUTIONS COULD RESULT INACCIDENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
WARNING: DURING AND FOLLOWING ANY SEAT
BELT SERVICE, CAREFULLY INSPECT ALL SEAT
BELTS, BUCKLES, MOUNTING HARDWARE, AND
RETRACTORS FOR PROPER INSTALLATION,
OPERATION, OR DAMAGE. REPLACE ANY BELT
THAT IS CUT, FRAYED, OR TORN. STRAIGHTEN
ANY BELT THAT IS TWISTED. TIGHTEN ANY
LOOSE FASTENERS. REPLACE ANY BELT THAT
HAS A DAMAGED OR INOPERATIVE BUCKLE OR
RETRACTOR. REPLACE ANY BELT THAT HAS A
BENT OR DAMAGED LATCH PLATE OR ANCHOR
PLATE. NEVER ATTEMPT TO REPAIR A SEAT BELT
COMPONENT. ALWAYS REPLACE DAMAGED OR
FAULTY SEAT BELT COMPONENTS WITH THE COR-
RECT, NEW AND UNUSED REPLACEMENT PARTS
LISTED IN THE MOPAR PARTS CATALOG.
(1) Position the front seat belt buckle to the
inboard seat cushion side shield (Fig. 22).
(2)
Position the seat belt switch pigtail wire between
the seat cushion frame and the seat track by gently pry-
ing the inboard seat track away from the inboard rear
corner of the seat cushion frame far enough to slide the
pigtail wire into position between them.
(3) Engage the seat belt switch pigtail wire routing
clip into the locating hole in the seat cushion frame.
(4) Install and tighten the two screws that secure
the inboard seat track to the rear inboard corner of
the seat cushion frame. Tighten the screws to 28 N´m
(21 ft. lbs.).
(5) Position the inboard seat cushion side shield to
the seat cushion frame.
(6) Install and tighten the two screws that secure
the inboard seat cushion side shield to the seat cush-
ion frame. Tighten the screws to 1 N´m (9 in. lbs.).
(7) Position the front seat belt buckle anchor to
the bracket on the inboard side of the seat track.
(8) Install and tighten the screw that secures the
front seat belt buckle anchor to the bracket on the
inboard side of the seat track. Tighten the screw to
43 N´m (32 ft. lbs.).
(9)
Reconnect the seat belt switch pigtail wire connec-
tor to the seat wire harness connector on the seat cush-
ion frame bracket located under the rear edge of the seat
cushion near the inboard side of the seat (Fig. 21).
(10) Reinstall the front seat and seat track to the
floor panel as a unit. (Refer to 23 - BODY/SEATS/
SEAT - FRONT - INSTALLATION).
(11) Do not reconnect the battery negative cable at
this time. The airbag system verification test proce-
dure should be performed following service of any
supplemental restraint system component. (Refer to
8 - ELECTRICAL/RESTRAINTS - STANDARD PRO-
CEDURE - VERIFICATION TEST).
Fig. 22 Front Seat Belt Buckle Remove/Install
1 - FRONT SEAT BELT BUCKLE
2 - INBOARD SIDE SHIELD
3 - SCREW
4 - PIGTAIL WIRE
8O - 26 RESTRAINTSKJ
FRONT SEAT BELT BUCKLE (Continued)

PASSENGER AIRBAG
DESCRIPTION
The rearward facing surface of the injection
molded, thermoplastic passenger airbag door is the
most visible part of the passenger airbag (Fig. 23).
The passenger airbag door is located above the glove
box opening in front of the front seat passenger seat-
ing position on the instrument panel. The integral
upper mounting flange is secured with five screws
and the lower mounting flange with six screws to the
instrument panel structural support. The passenger
airbag door includes an integral air conditioning
panel outlet housing and an integral side window
demister outlet. An integral stamped metal bracket
that reinforces the upper airbag door mounting
flange is secured to the back of the door unit with
heat stakes. The upper airbag door fasteners and
mounting flange are concealed beneath the instru-
ment panel top cover, while the lower fasteners and
mounting flange are concealed beneath a bezel on the
instrument panel above the glove box opening.
Located behind the passenger airbag door within
the instrument panel is the passenger airbag unit
(Fig. 24). The passenger airbag unit used in this
model is a multistage, Next Generation-type that
complies with revised federal airbag standards to
deploy with less force than those used in some prior
models. The passenger airbag unit consists of a
molded, glass-filled nylon plastic housing, a molded
plastic inner airbag cushion cover, the airbag cush-
ion, and the airbag inflator. The airbag housing con-tains the airbag inflator, while the inner cover
contains the folded airbag cushion. The inner cover
completely encloses the airbag cushion and is perma-
nently retained to the housing. The passenger airbag
unit is secured by two screws on each side to two
stamped metal mounting brackets that are fastened
with screws to the instrument panel structural sup-
port. The airbag cushion is constructed of a coated
nylon fabric. The airbag inflator is a dual-initiator,
hybrid-type unit that is secured to and sealed within
the airbag housing. A short four-wire pigtail harness
with a keyed, yellow connector insulator connects the
two inflator initiators to the vehicle electrical system
through a dedicated take out and connector of the
instrument panel wire harness.
The passenger airbag cannot be repaired, and must
be replaced if deployed, faulty, or in any way dam-
aged. The passenger airbag door and the passenger
airbag mounting brackets are available for separate
service replacement.
OPERATION
The multistage passenger airbag is deployed by
electrical signals generated by the Airbag Control
Module (ACM) through the passenger airbag squib 1
and squib 2 circuits to the two initiators in the air-
bag inflator. By using two initiators, the airbag can
be deployed at multiple levels of force. The force level
is controlled by the ACM to suit the monitored
impact conditions by providing one of three delay
intervals between the electrical signals provided to
the two initiators. The longer the delay between
these signals, the less forcefully the airbag will
deploy.
Fig. 23 Passenger Airbag Door
1 - PASSENGER AIRBAG DOOR
2 - DEMISTER OUTLET
3 - PANEL OUTLET
4 - BEZEL
5 - GLOVE BOX
Fig. 24 Passenger Airbag Unit
1 - PIGTAIL WIRE CONNECTOR
2 - RETAINER
3 - HOUSING
4 - INNER COVER
KJRESTRAINTS 8O - 27

The hybrid-type inflator assembly includes a small
canister of highly compressed gas. When the ACM
sends the proper electrical signal to the airbag infla-
tor, the initiator converts the electrical energy into
chemical energy. This chemical energy opens up a
burst disk to allow the inert gas to flow into the air-
bag cushion. The inflator is sealed to the airbag
cushion so that all of the released inert gas is
directed into the airbag cushion, causing the cushion
to inflate. As the cushion inflates, the passenger air-
bag door will split at predetermined tear seam lines
on the inside surface of the door and the door will
pivot downwards out of the way. Following a passen-
ger airbag deployment, the airbag cushion quickly
deflates by venting the inert gas through vent holes
within the fabric used to construct the sides of the
airbag cushion.
Typically, both initiators are used during an airbag
deployment event. However, it is possible for only one
initiator to be used during a deployment due to an
airbag system fault; therefore, it is necessary to
always confirm that both initiators have been used in
order to avoid the improper disposal of potentially
live pyrotechnic materials. (Refer to 8 - ELECTRI-
CAL/RESTRAINTS - STANDARD PROCEDURE -
SERVICE AFTER A SUPPLEMENTAL RESTRAINT
DEPLOYMENT).
REMOVAL
The following procedure is for replacement of a
faulty or damaged passenger airbag. If the passenger
airbag has been deployed, review the recommended
procedures for service after a supplemental restraint
deployment before removing the airbag from the
vehicle. (Refer to 8 - ELECTRICAL/RESTRAINTS -
STANDARD PROCEDURE - SERVICE AFTER A
SUPPLEMENTAL RESTRAINT DEPLOYMENT).
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.WARNING: WHEN REMOVING A DEPLOYED AIR-
BAG, RUBBER GLOVES, EYE PROTECTION, AND A
LONG-SLEEVED SHIRT SHOULD BE WORN. THERE
MAY BE DEPOSITS ON THE AIRBAG UNIT AND
OTHER INTERIOR SURFACES. IN LARGE DOSES,
THESE DEPOSITS MAY CAUSE IRRITATION TO THE
SKIN AND EYES.
(1) Disconnect and isolate the battery negative
cable. Wait two minutes for the system capacitor to
discharge before further service.
(2) Remove the passenger airbag door from the
instrument panel. (Refer to 8 - ELECTRICAL/RE-
STRAINTS/PASSENGER AIRBAG DOOR - REMOV-
AL).
(3) Remove the two screws on each side of the pas-
senger airbag that secure the passenger airbag to the
metal brackets on the instrument panel support
structure (Fig. 25).
(4) Disengage the passenger airbag wire harness
connector from the retainer securing the connector to
the metal bracket on the instrument panel support
structure above the airbag by sliding both halves of
the connector to the left.
(5) Disconnect the passenger airbag pigtail wire
connector from the instrument panel wire harness
connector for the airbag. To disconnect the connector:
(a) Slide the red Connector Position Assurance
(CPA) lock on the top of the connector toward the
side of the connector.
(b) Depress the connector latch tab and pull the
two halves of the connector straight away from
each other.
Fig. 25 Passenger Airbag Remove/Install
1 - PASSENGER AIRBAG
2 - WIRE HARNESS CONNECTOR
3 - SCREW (4)
4 - GLOVE BOX LATCH STRIKER
8O - 28 RESTRAINTSKJ
PASSENGER AIRBAG (Continued)

(6) Remove the passenger airbag from the instru-
ment panel as a unit.
(7) If the passenger airbag has been deployed, both
passenger airbag mounting brackets on the instru-
ment panel must be replaced. (Refer to 8 - ELECTRI-
CAL/RESTRAINTS/PASSENGER AIRBAG
MOUNTING BRACKET - REMOVAL).
INSTALLATION
The following procedure is for replacement of a
faulty or damaged passenger airbag. If the passenger
airbag has been deployed, both passenger airbag
mounting brackets on the instrument panel must
also be replaced. (Refer to 8 - ELECTRICAL/RE-
STRAINTS/PASSENGER AIRBAG MOUNTING
BRACKET - INSTALLATION).
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
WARNING: WHEN REMOVING A DEPLOYED AIR-
BAG, RUBBER GLOVES, EYE PROTECTION, AND A
LONG-SLEEVED SHIRT SHOULD BE WORN. THERE
MAY BE DEPOSITS ON THE AIRBAG UNIT AND
OTHER INTERIOR SURFACES. IN LARGE DOSES,
THESE DEPOSITS MAY CAUSE IRRITATION TO THE
SKIN AND EYES.
WARNING: USE EXTREME CARE TO PREVENT ANY
FOREIGN MATERIAL FROM ENTERING THE PAS-
SENGER AIRBAG, OR BECOMING ENTRAPPED
BETWEEN THE PASSENGER AIRBAG CUSHION
AND THE PASSENGER AIRBAG DOOR. FAILURE TO
OBSERVE THIS WARNING COULD RESULT IN
OCCUPANT INJURIES UPON AIRBAG DEPLOY-
MENT.
(1) Position the passenger airbag unit into the
instrument panel (Fig. 25).(2) Reconnect the passenger airbag pigtail wire
connector to the instrument panel wire harness con-
nector for the airbag. Be certain that the latch on the
connector and the red Connector Position Assurance
(CPA) lock are each fully engaged.
(3) Engage the passenger airbag wire harness con-
nector onto the retainer that secures the connector to
the metal bracket on the instrument panel support
structure above the airbag by aligning the right end
of the connector slot with the left end of the retainer
and sliding both halves of the connector to the right.
(4) Carefully position the passenger airbag unit
onto the two metal brackets on the instrument panel
support structure, being certain that the alignment
pin features on each side of the airbag are engaged
in the alignment holes in the metal brackets.
(5) Install and tighten the two screws on each side
of the passenger airbag that secure the passenger
airbag to the metal brackets on the instrument panel
support structure. Tighten the screws to 6 N´m (55
in. lbs.).
(6) Reinstall the passenger airbag door onto the
instrument panel. (Refer to 8 - ELECTRICAL/RE-
STRAINTS/PASSENGER AIRBAG DOOR - INSTAL-
LATION).
(7) Do not reconnect the battery negative cable at
this time. The airbag system verification test proce-
dure should be performed following service of any
supplemental restraint system component. (Refer to
8 - ELECTRICAL/RESTRAINTS - STANDARD PRO-
CEDURE - VERIFICATION TEST).
PASSENGER AIRBAG DOOR
REMOVAL
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
KJRESTRAINTS 8O - 29
PASSENGER AIRBAG (Continued)

WARNING: WHEN REMOVING A DEPLOYED AIR-
BAG, RUBBER GLOVES, EYE PROTECTION, AND A
LONG-SLEEVED SHIRT SHOULD BE WORN. THERE
MAY BE DEPOSITS ON THE AIRBAG UNIT AND
OTHER INTERIOR SURFACES. IN LARGE DOSES,
THESE DEPOSITS MAY CAUSE IRRITATION TO THE
SKIN AND EYES.
(1) Disconnect and isolate the battery negative
cable. Wait two minutes for the system capacitor to
discharge before further service.
(2) Remove the top cover from the instrument
panel. (Refer to 23 - BODY/INSTRUMENT PANEL/
INSTRUMENT PANEL TOP COVER - REMOVAL).
(3) Remove the passenger side bezel from the
upper glove box opening of the instrument panel.
(Refer to 23 - BODY/INSTRUMENT PANEL/IP PAS-
SENGER SIDE BEZEL - REMOVAL).
(4) Remove the three small screws that secure the
passenger airbag door to the glove box opening upper
reinforcement (Fig. 26).
(5) Remove the three large screws that secure the
passenger airbag door to the glove box opening upper
reinforcement.
(6) Remove the one small screw that secures the
passenger airbag door to the top of the instrument
panel.
(7) Remove the four large screws that secure the
passenger airbag door to the top of the instrument
panel.
(8) Remove the passenger airbag door from the
instrument panel.INSTALLATION
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
WARNING: THE PASSENGER AIRBAG DOOR MUST
NEVER BE PAINTED. REPLACEMENT PASSENGER
AIRBAG DOORS ARE SERVICED IN THE ORIGINAL
COLORS. PAINT MAY CHANGE THE WAY IN WHICH
THE MATERIAL OF THE AIRBAG DOOR RESPONDS
TO AN AIRBAG DEPLOYMENT. FAILURE TO OBSERVE
THIS WARNING COULD RESULT IN OCCUPANT INJU-
RIES UPON AIRBAG DEPLOYMENT.
(1) Position the passenger airbag door onto the
instrument panel (Fig. 26).
(2) Install and tighten the four large screws that
secure the passenger airbag door to the top of the
instrument panel. Tighten the screws to 4 N´m (35
in. lbs.).
(3) Install and tighten the one small screw that
secures the passenger airbag door to the top of the
instrument panel. Tighten the screw to 2 N´m (20 in.
lbs.).
(4) Install and tighten the three large screws that
secure the passenger airbag door to the glove box
opening upper reinforcement. Tighten the screws to 4
N´m (35 in. lbs.).
(5) Install and tighten the three small screws that
secure the passenger airbag door to the glove box
opening upper reinforcement. Tighten the screws to 2
N´m (20 in. lbs.).
(6) Reinstall the passenger side bezel onto the
upper glove box opening of the instrument panel.
(Refer to 23 - BODY/INSTRUMENT PANEL/IP PAS-
SENGER SIDE BEZEL - INSTALLATION).
(7) Reinstall the top cover onto the instrument
panel. (Refer to 23 - BODY/INSTRUMENT PANEL/
INSTRUMENT PANEL TOP COVER - INSTALLA-
TION).
(8) Reconnect the battery negative cable.
Fig. 26 Passenger Airbag Door Remove/Install
1 - PASSENGER AIRBAG DOOR
2 - LARGE SCREW (7)
3 - SMALL SCREW (4)
8O - 30 RESTRAINTSKJ
PASSENGER AIRBAG DOOR (Continued)

PASSENGER AIRBAG
MOUNTING BRACKET
REMOVAL
The passenger airbag mounting brackets cannot be
repaired. They must be replaced if faulty or dam-
aged, or if the passenger airbag has been deployed.
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Remove the passenger airbag from the instru-
ment panel. (Refer to 8 - ELECTRICAL/RE-
STRAINTS/PASSENGER AIRBAG - REMOVAL).
(2) Remove the two screws that secure the inboard
and/or outboard passenger airbag mounting brack-
et(s) to the instrument panel support structure (Fig.
27).
(3) Remove the inboard and/or outboard passenger
airbag mounting bracket(s) from the instrument
panel support structure.
INSTALLATION
The passenger airbag mounting brackets cannot be
repaired. They must be replaced if faulty or dam-
aged, or if the passenger airbag has been deployed.
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Position the inboard and/or outboard passenger
airbag mounting bracket(s) to the instrument panel
support structure (Fig. 27).
(2) Install and tighten the two screws that secure
the inboard and/or outboard passenger airbag mount-
ing bracket(s) to the instrument panel support struc-
ture. Tighten the screws to 2 N´m (20 in. lbs.).
(3) Reinstall the passenger airbag to the instru-
ment panel. (Refer to 8 - ELECTRICAL/RE-
STRAINTS/PASSENGER AIRBAG -
INSTALLATION).
Fig. 27 Passenger Airbag Mounting Brackets
Remove/Install
1 - INBOARD BRACKET
2 - I/P SUPPORT STRUCTURE
3 - OUTBOARD BRACKET
4 - SCREW (2)
5 - SCREW (2)
KJRESTRAINTS 8O - 31

REAR CENTER SEAT BELT &
RETRACTOR
REMOVAL
WARNING: DURING AND FOLLOWING ANY SEAT
BELT SERVICE, CAREFULLY INSPECT ALL SEAT
BELTS, BUCKLES, MOUNTING HARDWARE, AND
RETRACTORS FOR PROPER INSTALLATION,
OPERATION, OR DAMAGE. REPLACE ANY BELT
THAT IS CUT, FRAYED, OR TORN. STRAIGHTEN
ANY BELT THAT IS TWISTED. TIGHTEN ANY
LOOSE FASTENERS. REPLACE ANY BELT THAT
HAS A DAMAGED OR INOPERATIVE BUCKLE OR
RETRACTOR. REPLACE ANY BELT THAT HAS A
BENT OR DAMAGED LATCH PLATE OR ANCHOR
PLATE. NEVER ATTEMPT TO REPAIR A SEAT BELT
COMPONENT. ALWAYS REPLACE DAMAGED OR
FAULTY SEAT BELT COMPONENTS WITH THE COR-
RECT, NEW AND UNUSED REPLACEMENT PARTS
LISTED IN THE MOPAR PARTS CATALOG.
(1) Remove the right center seat belt buckle unit
from the floor panel. (Refer to 8 - ELECTRICAL/RE-
STRAINTS/REAR SEAT BELT BUCKLE - REMOV-
AL).
(2) Unlatch and fold the right rear seat back for-
ward and separate the cargo area carpet from the
base of the seat back panel.
(3) Reach between the base of the right rear seat
back and the forward edge of the rear cargo floor to
access and remove the screw that secures the rear
center seat belt lower anchor to the floor panel (Fig.
28).
(4) Lift the rear center seat belt lower anchor off of
the stud on the rear floor panel.
(5) Remove the two screws that secure the belt
web guide to the top of the right rear seat back
panel.
(6) Remove the right rear seat back panel from the
vehicle. (Refer to 23 - BODY/SEATS/SEAT BACK -
REAR - REMOVAL).
(7) Remove the two screws that secure the belt
web guide to the top of the right rear seat back
panel.
(8) Remove the trim from the right rear seat back.
(Refer to 23 - BODY/SEATS/SEAT BACK COVER -
REAR - REMOVAL).
(9) Route the rear seat belt lower anchor and belt
web guide through the top of the seat back panel.
(10) Disengage the seat back latch cable fitting
from the cable support on the retractor, which is a
light snap fit (Fig. 29).
Fig. 28 Rear Center Seat Belt Anchor Plate
Remove/Install
1 - SCREW (2)
2 - BUCKLE UNIT
3 - REAR SEAT BACK
4 - REAR FLOOR PANEL
5 - STUD (1)
6 - ANCHOR PLATE
Fig. 29 Seat Back Latch Cable Disengage/Engage
1 - LEVER
2 - PLUNGER
3 - LATCH CABLE FITTING
4 - REAR CENTER RETRACTOR
5 - SUPPORT
8O - 32 RESTRAINTSKJ

(11) Remove the screw that secures the retractor
to the rear seat back panel (Fig. 30).
(12) Remove the rear center seat belt and retractor
unit from the seat back panel.
INSTALLATION
WARNING: DURING AND FOLLOWING ANY SEAT
BELT SERVICE, CAREFULLY INSPECT ALL SEAT
BELTS, BUCKLES, MOUNTING HARDWARE, AND
RETRACTORS FOR PROPER INSTALLATION,
OPERATION, OR DAMAGE. REPLACE ANY BELT
THAT IS CUT, FRAYED, OR TORN. STRAIGHTEN
ANY BELT THAT IS TWISTED. TIGHTEN ANY
LOOSE FASTENERS. REPLACE ANY BELT THAT
HAS A DAMAGED OR INOPERATIVE BUCKLE OR
RETRACTOR. REPLACE ANY BELT THAT HAS A
BENT OR DAMAGED LATCH PLATE OR ANCHOR
PLATE. NEVER ATTEMPT TO REPAIR A SEAT BELT
COMPONENT. ALWAYS REPLACE DAMAGED OR
FAULTY SEAT BELT COMPONENTS WITH THE COR-
RECT, NEW AND UNUSED REPLACEMENT PARTS
LISTED IN THE MOPAR PARTS CATALOG.
(1) Position the rear center seat belt and retractor
unit onto the seat back panel.
(2) Install and tighten the screw that secures the
retractor to the rear seat back panel (Fig. 30).
Tighten the screw to 27 N´m (20 ft. lbs.).
(3) Position the seat back latch cable plunger
against the retractor latch lever, then engage the
cable fitting into the cable support on the retractor,
which is a light snap fit (Fig. 29).
(4) Route the rear seat belt lower anchor and belt
web guide through the top of the seat back panel.(5) Reinstall the trim onto the right rear seat
back. (Refer to 23 - BODY/SEATS/SEAT BACK
COVER - REAR - INSTALLATION).
(6) Install and tighten the two screws that secure
the belt web guide to the top of the right rear seat
back panel. Tighten the screws to 2 N´m (20 in. lbs.).
(7) Reinstall the right rear seat back panel into
the vehicle. (Refer to 23 - BODY/SEATS/SEAT BACK
- REAR - INSTALLATION).
(8) Position the rear center seat belt lower anchor
off of the stud on the rear floor panel (Fig. 28).
(9) Reach between the base of the right rear seat
back and the forward edge of the rear cargo floor to
install and tighten the screw that secures the rear
center seat belt lower anchor to the floor panel.
Tighten the screw to 43 N´m (32 ft. lbs.).
(10) Restore the cargo area carpet to the base of
the seat back panel and unfold the right rear seat
back to its upright position.
(11) Reinstall the right center seat belt buckle unit
onto the floor panel. (Refer to 8 - ELECTRICAL/RE-
STRAINTS/SEAT BELT BUCKLE - INSTALLA-
TION).
REAR OUTBOARD SEAT BELT
& RETRACTOR
REMOVAL
WARNING: DURING AND FOLLOWING ANY SEAT
BELT SERVICE, CAREFULLY INSPECT ALL SEAT
BELTS, BUCKLES, MOUNTING HARDWARE, AND
RETRACTORS FOR PROPER INSTALLATION,
OPERATION, OR DAMAGE. REPLACE ANY BELT
THAT IS CUT, FRAYED, OR TORN. STRAIGHTEN
ANY BELT THAT IS TWISTED. TIGHTEN ANY
LOOSE FASTENERS. REPLACE ANY BELT THAT
HAS A DAMAGED OR INOPERATIVE BUCKLE OR
RETRACTOR. REPLACE ANY BELT THAT HAS A
BENT OR DAMAGED LATCH PLATE OR ANCHOR
PLATE. NEVER ATTEMPT TO REPAIR A SEAT BELT
COMPONENT. ALWAYS REPLACE DAMAGED OR
FAULTY SEAT BELT COMPONENTS WITH THE COR-
RECT, NEW AND UNUSED REPLACEMENT PARTS
LISTED IN THE MOPAR PARTS CATALOG.
(1) Unsnap and lift the trim cover to access the
screw that secures the rear outboard seat belt turn-
ing loop to the upper C-pillar (Fig. 31).
(2) Remove the screw that secures the seat belt
turning loop to the upper C-pillar.
(3) Remove the screw that secures the lower seat
belt anchor to the bracket on the outboard side of the
rear seat cushion frame.
Fig. 30 Rear Center Retractor Remove/Install
1 - REAR SEAT BACK PANEL
2 - SCREW (1)
KJRESTRAINTS 8O - 33
REAR CENTER SEAT BELT & RETRACTOR (Continued)
