JEEP LIBERTY 2008 KK / 2.G Owners Manual

A control switch for the outlet is located in the lower
switch bank below the climate controls.
Press and release the switch once to turn on the power
outlet. A status indicator in the switch will illuminate in
approximately one second to indicate that power isavailable at the outlet. Press and release the switch again
to turn off the power outlet. The status indicator will also
turn off.
NOTE:Due to built-in overload protection, the power
outlet will shut down if the 115 Volt AC (150 Watt
maximum) power rating is exceeded.
WARNING!
To Avoid Serious Injury or Death:
²Do not use a 3-Prong Adaptor.
²Do not insert any objects into the receptacles.
²Do not touch with wet hands.
²Close the lid when not in use.
²If this outlet is mishandled, it may cause an
electric shock and failure.
115VAC (150W) Power Outlet Control Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171
3

CUP HOLDERS
Front and rear cup holders are located in the center
console.
Front Cup Holders
Rear Cup Holders
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

STORAGE
Front Storage Compartment
The front storage compartment (located on the left side of
the instrument panel) can hold cell phones, PDA's, and
other small items.
Console Storage Compartment
To open, press the latch and lift the cover.
Front Storage Compartment
Center Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173
3

The center console has a removable storage tray, which
can hold cell phones, PDA's, and other small items.CARGO AREA FEATURES
Cargo Load Floor
The cargo load floor system has a load capacity of 400 lbs
(181 kg). The load floor has a built-in storage bin that can
hold a variety of items. The underside of the storage bin
cover also contains a plastic lined tray. The cover can be
installed with either side facing up for added utility.
To provide additional storage area, each rear seat can be
folded flat. This allows for extended cargo space and still
maintains some rear seating room. Refer to ªSeatsº in this
Section for additional information on the 60/40 Split
Folding Rear Seat with Fold Flat feature.
Accessing the Storage Bin
NOTE: The spring-loaded latches that retain the
storage bin cover to the cargo load floor should not be
used as cargo tie-downs.
1. Flip the spring-loaded latch pull-loops up.
Removable Storage Tray
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Pull the loops upward and twist them1¤4turn so that
they are parallel to the slots in the storage bin cover.
3. Lift the cover upward over the loops.
4. When done, reinstall the cover with the handle recess
facing toward you.NOTE:You can install the cover with either side facing
upward.
5. With the cover seated in the floor, pull upward on
loops and twist them
1¤4turn so that they are no longer
parallel to the slots in the cover.
6. Flip the loops down.
WARNING!
A loose storage bin cover thrown forward in a colli-
sion or hard stop could endanger the occupants of the
vehicle. Always latch the storage bin cover to the
cargo load floor with the spring-loaded latches when
not accessing the storage bin.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175
3

Cargo Tie-Down Hooks & Loops
The tie-downs located on cargo area floor should be used
to secure loads safely when the vehicle is moving.NOTE: The spring-loaded latches that retain the
storage bin cover to the cargo load floor should not be
used as cargo tie-downs.
Cargo tie-down loops are located on the trim panels.
Cargo Tie-Down Hooks
Cargo Tie-Down Loops
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
²Cargo tie-downs are not safe anchors for a child
seat tether strap. In a sudden stop or collision, a
tie-down could pull loose and allow the child seat
to come loose. A child could be badly injured. Use
only the anchors provided for child seat tethers.
²The weight and position of cargo and passengers
can change the vehicle center of gravity and ve-
hicle handling. To avoid loss of control resulting
in personal injury, follow these guidelines for
loading your vehicle:
²Do not carry loads that exceed the load limits de-
scribed on the label attached to the left door or left
door center pillar.
²Always place cargo evenly on the cargo floor. Put
heavier objects as low and as far forward as possible.
²Place as much cargo as possible in front of the rear
axle. Too much weight or improperly placed weight
over or behind the rear axle can cause the vehicle to
sway.
²Do not pile luggage or cargo higher than the top of the
seatback. This could impair visibility or become a
dangerous projectile in a sudden stop or collision.
WARNING!
To help protect against personal injury, passengers
should not be seated in the rear cargo area. The rear
cargo space is intended for load carrying purposes
only, not for passengers, who should sit in seats and
use seat belts.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177
3

Retractable Cargo Area Cover Ð If Equipped
NOTE:The purpose of this cover is for privacy, not to
secure loads. It will not prevent cargo from shifting or
protect passengers from loose cargo.
The removable retractable cargo area cover mounts in the
cargo area behind the top of the rear seats.
The cover, when extended, covers the cargo area to keep
items out of sight. Notches in the trim panels near the
liftgate opening secure the extended cover in place.
The cover rolls away neatly inside its housing when not
in use. You can also remove the cover from the vehicle to
make more room in the cargo area.
To install the cover, position it in the vehicle so that the
flat side of the housing faces upward. Then, insert either
the left or the right spring-loaded post (located on the
ends of the cover housing) into either of the left or the
right attachment points shown.Then, insert the spring-loaded post on the opposite end
of the cover housing into the attachment point on the
opposite side of the vehicle.
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Next, grab the cover handle and pull the cover toward
you. As the cover nears the liftgate opening, guide the
rear attachment posts (on both ends of the cover) into the
notches in the trim panels. Then, lower the cover to
position the posts into the bottom of the notches and
release the handle.WARNING!
In an accident, a cargo cover loose in the vehicle
could cause injury. It could fly around in a sudden
stop and strike someone in the vehicle. Do not store
the cargo cover on the cargo floor or in the passenger
compartment. Remove the cover from the vehicle
when taken from its mounting. Do not store in the
vehicle.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179
3

REAR WINDOW FEATURES
Rear Window Wiper/Washer Ð If Equipped
The Rear Window Wiper / Washer Control is
located on the right side of the steering column.The rotary ring switch on the lever controls rear wiper
and washer operation. Rotate the switch upward to the
first detent to activate the rear wiper. Rotate the switch
upward to the second detent to activate the rear washer.
The washer will continue to operate until you release the
switch. Once released, the wiper will cycle three times,
return to the park position, and then resume normal
operation.
NOTE:The rear wiper will automatically return to the
ªParkº position if you turn off the ignition switch while
it is operating. The rear wiper will resume operation
when you turn the ignition switch to the ON position
again.
Rear Window Wiper / Washer Control
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
