JEEP LIBERTY 2008 KK / 2.G Owners Manual

TO OPEN AND CLOSE THE HOOD
Two latches must be released to open the hood. First, pull
the hood release lever located under the left side of the
instrument panel.Next, locate the safety latch lever between the grille and
hood opening (left of center when facing hood). Push the
safety latch lever to the right and then raise the hood.
Hood Release
Underhood Safety Latch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131
3

Use the hood prop rod to secure the hood in the open
position. Place the upper end of the prop rod in the hole
on the underside of the hood.To prevent possible damage:
²Before closing hood, make sure the hood prop rod is
fully seated into its storage retaining clips.
²Do not slam the hood to close it. Use a firm downward
push at the center front edge of the hood to ensure that
both latches engage. Never drive your vehicle unless
the hood is fully closed, with both latches engaged.
WARNING!
If the hood is not fully latched, it could fly up when
the vehicle is moving and block your forward vision.
Be sure all hood latches are fully latched before
driving.
Hood Prop Rod Hole Location
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

LIGHTS
Exterior & Interior Lighting Control
The Multi-Function Control Lever on the left side
of the steering column controls the operation of
the headlights, parking lights, turn signal lights,
instrument panel lights, instrument panel light dimming,
interior lights, and fog lights (if equipped).
Headlights & Parking Lights
Turn the end of the Multi-Function Control Lever to the
first detent for parking light operation. Turn the end of
the lever to the second detent for headlight operation.
Headlight Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133
3

Automatic Headlights Ð If Equipped
This system automatically turns the headlights ON or
OFF according to ambient light levels. To turn the system
ON, turn the end of the Multi-Function Control Lever to
the (A) AUTO position (third detent). When the system is
ON, the Headlight Time Delay feature is also ON. This
means the headlights will stay ON for up to 90 seconds
after you turn the ignition switch to the LOCK position.
To turn the Automatic System OFF, turn the end of the
Multi-Function Control Lever out of the (A) position.
NOTE:The engine must be running before the head-
lights will turn ON in the Automatic mode.
Headlights with Wipers (Available with Auto
Headlights Only)
When this feature is active, the headlights will turn ON
approximately 10 seconds after the wipers are turned on
if the Multi-Function Control Lever is placed in the (A)AUTO position. In addition, the headlights will turn OFF
when the wipers are turned off if they were turned on by
this feature.
The Headlights with Wipers feature can be turned on or
off through the Electronic Vehicle Information Center
(EVIC) Ð if equipped. For details, refer to ºHeadlights
On with Wipers,º under ªPersonal Settings (Customer
Programmable Features),º under ªElectronic Vehicle In-
formation Centerº in Section 4 of this manual.
Headlight Time Delay Ð If Equipped
This feature is particularly useful when exiting your
vehicle in an unlit area. It provides the safety of headlight
illumination for about 90 seconds after turning the igni-
tion switch to the LOCK position.
To activate the delay, turn the ignition switch to the
LOCK position while the headlights are still on. Then,
turn off the headlights within 45 seconds. The delay
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

interval begins when you turn off the headlights. Only
the headlights will illuminate during this time.
If you turn the headlights, or parking lights, or ignition
switch on again, the system will cancel the delay.
If you turn the headlights off before the ignition, they will
turn off in the normal manner.
The Headlight delay time is programmable on vehicles
equipped with the Electronic Vehicle Information Center
(EVIC). For details, refer to ªDelay Turning Headlights
Off,º under ªPersonal Settings (Customer Programmable
Features),º under ªElectronic Vehicle Information Center
(EVIC)º in Section 4 of this manual.Daytime Running Lights (DRL) Ð If Equipped
The high beam headlights will turn on as Daytime
Running Lights (DRL) and operate at DRL (lower) inten-
sity, whenever the ignition is on, the engine is running,
the headlight switch is off, the parking brake is off, the
turn signal is off, and the selector lever is in any position
except ªPº (Park).
NOTE:The Daytime Running Lights will turn off
automatically when the turn signal is in operation and
turn on again when the turn signal is not operating.
Lights-On Reminder
If the headlights or parking lights are on after the ignition
is turned to the LOCK position, a chime will sound to
alert the driver when the driver's door is opened.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135
3

Fog Lights Ð If Equipped
To activate the front fog lights, turn on the parking
lights or the low beam headlights and pull out on
the end of the Multi-Function Control Lever.
NOTE:The front fog lights will only operate with the
headlights on low beam. Selecting high beam headlights
will turn off the front fog lights.
Turn Signals
Move the Multi-Function Lever upward or downward
and the corresponding turn signal indicator on the in-
strument panel will flash to show proper operation of the
front and rear turn signal lights.
Front Fog Light Control
Turn Signal Control
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

You can signal a lane change by moving the lever upward
or downward partially without moving beyond the de-
tent.
If either turn signal indicator has a very fast flash rate,
check for a defective outside light bulb. If an indicator
fails to light when the lever is moved, see your autho-
rized dealer for service.
Highbeam/Lowbeam Select Switch
Push the Multi-Function Control Lever away from you to
switch the headlights to HIGH beam. Pull the Lever
toward you, to switch the headlights back to LOW beam.
Flash to Pass
You can signal another vehicle with your headlights by
lightly pulling the Multi-Function Control Lever toward
you. This will cause the headlights to turn on at high
beam and remain on until the lever is released.
Highbeam Functions
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137
3

NOTE:If the Multi-Function Control Lever is held in
the Flash to Pass position for more than 15 seconds, the
high beams will shut off. If this occurs, wait 30 seconds
before activating the Flash to Pass function again.
Interior Lights
Map/Reading Lights
These lights are mounted between the sun visors on the
overhead console and above the rear doors by the grab
handles. Each light is turned ON by pressing the lens.
Press the lens a second time to turn OFF the light. These
lights also turn on when a door is opened, or when the
Unlock button on the Remote Keyless Entry (RKE) trans-
mitter is pressed, or when the Dimmer Control is turned
completely upward to the second detent.
Cargo Light
The cargo light is mounted in the headliner above the
rear cargo area. This light will turn on when you open the
liftgate or any door, or if you press the Unlock button on
the Remote Keyless Entry (RKE) transmitter, or rotate the
Dimmer Control on the Multi-Function Control Lever
completely upward to the second detent.
Battery Saver Feature
To protect the battery, the interior lights will turn off
automatically 10 minutes after the ignition switch is
moved to the LOCK position. This will occur if the
interior lights were switched on manually or are on
because a door is open.
Dimmer Control
The Dimmer Control is part of the Multi-Function Con-
trol Lever. It controls the operation of the interior lights
and the brightness of the instrument panel lights.
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Instrument Panel Dimming
With the parking lights or headlights on, rotate the
Dimmer Control upward or downward to change the
brightness of the instrument panel lights.
Parade Mode (Daytime Brightness Feature)
Rotate the Dimmer Control to the first detent to brighten
the odometer and radio display when the parking lights
or headlights are on during daylight conditions.
Interior Light ON
Rotate the Dimmer Control completely upward to the
second detent to turn on the interior lights. The interior
lights will remain on when the dimmer control is in this
position.
Interior Light Defeat OFF
Rotate the Dimmer Control completely downward to the
(O) OFF position. The interior lights will remain off when
the doors are open.
Dimmer Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139
3

WINDSHIELD WIPERS AND WASHERS
The Windshield Wiper / Washer Control Lever is
located on the right side of the steering column.Rotate the end of the lever to the first detent past the
intermittent settings for Low-speed wiper operation, or
to the second detent past the intermittent settings for
High-speed wiper operation.
NOTE:The wipers will automatically return to the
ªParkº position if you turn off the ignition switch while
they are operating. The wipers will resume operation
when you turn the ignition switch to the ON position
again.
Windshield Wiper/Washer Lever
