JEEP WRANGLER 2004 TJ / 2.G Owners Manual

Miles 93,000 96,000 99,000 102,000 105,000
(Kilometers) (149 000) (154 000) (158 000) (163 000) (168 000)
Change the engine oil and engine oil filter. X X X X X
Inspect the engine air filter element, replace if
necessary.X
Lubricate the steering linkage tie rod ends. X X X X X
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid³ X
Inspect the drive belt and replace as needed. Not
required if belt was previously replaced.X
Flush and replace the engine coolant. X
SCHEDULE ªBº 271
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (173 000) (178 000) (182 000) (187 000) (192 000)
Change the engine oil and engine oil filter. X X X X X
Inspect the engine air filter element, replace if
necessary.X
Inspect the PCV Valve, and replace if necessary.LX
Replace the spark plugs.X
Inspect the ignition cables, and replace if neces-
sary (2.4L Only).X
Lubricate the steering linkage tie rod ends. X X X X X
Lubricate the steering and suspension ball joints. X X X
Inspect the brake linings. X X
Drain and refill the front and rear axle fluid³ X X
Drain and refill the automatic transmission fluid,
and replace main sump filter.X
Inspect the drive belt and replace as needed. Not
required if belt was previously replaced.X
Drain and refill the transfer case fluid. X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.LThis maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty.
272 SCHEDULE ªBº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

³Off-highway operation, trailer towing, taxi, limousine,
bus, snow plowing, or other types of commercial service
or prolonged operation with heavy loading, especially inhot weather, require front and rear axle service indicated
witha³inSchedule ªBº. Perform these services if the
vehicle is usually operated under these conditions.
SCHEDULE ªBº 273
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule ªAº
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (19 000) (29 000) (38 000) (48 000)
[Months] [6] [12] [18] [24] [30]
Change the engine oil and engine oil filter. X X X X X
Inspect the engine air filter element, and replace
if necessary.X
Replace the spark plugs.X
Lubricate the steering linkage joints and outer tie
rod ends.X X XXX
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Inspect the transfer case fluid.X
274 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54, 000
(Kilometers) (58 000) (67 000) (77 000) (86 000)
[Months] [36] [42] [48] [54]
Change the engine oil and engine oil filter. X X X X
Lubricate the steering and suspension ball joints. X X
Lubricate the steering linkage joints and outer tie rod
ends.XXXX
Inspect the brake linings. X X
SCHEDULE ªAº 275
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 60,000 66,000 72,000 78,000
(Kilometers) (96 000) (106 000) (115 000) (125 000)
[Months] [60] [66] [72] [78]
Change the engine oil and engine oil filter. X X X X
Inspect the engine air filter element, and replace if nec-
essary.X
Inspect the PCV Valve, and replace if necessary.LX
Replace the ignition cables (2.4L Only).X
Replace the spark plugs.X
Lubricate the steering linkage joints and outer tie rod
ends.XXXX
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Inspect the drive belt, and replace as needed. X
Inspect the drive belt, and replace as needed. Not re-
quired if belt was previously replaced.X
Flush and replace the engine coolant at 60 months, re-
gardless of mileage.X
Inspect transfer case fluid. X
276 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 84,000 90,000 96,000 102, 000
(Kilometers) (134 000) (144 000) (154 000) (163 000)
[Months] [84] [90] [96] [102]
Change the engine oil and engine oil filter. X X X X
Inspect the engine air filter element, and replace if nec-
essary.X
Inspect the PCV Valve, and replace if necessary.LX
Replace the spark plugs.X
Lubricate the steering linkage joints and outer tie rod
ends.XXXX
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Inspect the drive belt, and replace as needed. Not re-
quired if previously replaced.XX
Flush and replace the engine coolant if not done at 60
months.X
Inspect the transfer case fluid. X
SCHEDULE ªAº 277
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 114,000 120,000
(Kilometers) (173 000) (182 000) (192 000)
[Months] [108] [114] [120]
Change the engine oil and engine oil filter. X X X
Inspect the engine air filter element, and replace if necessary.X
Replace the ignition cables (2.4L Only).X
Inspect the PCV Valve, and replace if necessary.LX
Replace the spark plugs.X
Lubricate the steering linkage joints and outer tie rod ends. X X X
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Replace the timing belt (2.4L Only). X
Inspect the drive belt, and replace as needed. Not required if pre-
viously replaced.X
Drain and refill the transfer case fluid. X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.LThis maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty.
278 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS
mSuggestions For Obtaining Service For Your
Vehicle
..............................280
NPrepare For The Appointment............280
NPrepare A List........................280
NBe Reasonable With Requests.............280
mIf You Need Assistance..................280
mWarranty Information...................283
mMopartParts.........................284
mReporting Safety Defects.................284
NIn Canada..........................284
mPublication Order Forms.................285
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you're having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle's
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle's problems or the
specific work you want done. If you've had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at aminimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Your selling dealer is best equipped and most anxious to
provide prompt resolution for any warranty issue or
related matter that you may experience. The manufactur-
er's dealers have the facilities, factory-trained techni-
cians, special tools, and the latest information to assure
your vehicle is fixed correctly and in a timely manner.
The manufacturer has empowered its dealers to make
warranty and repair decisions that ensure you are not
inconvenienced. There is no need for you to wait for a
decision from the manufacturer. If a special circumstance
occurs that requires information from the manufacturer,
we have asked the dealer's service management to make
the contact on your behalf.
280 IF YOU NEED CONSUMER ASSISTANCE
