JEEP WRANGLER 2017 JK / 3.G Owners Manual

The power inverter is designed with built-in overload
protection. If the power rating of 150 Watts is exceeded, the
power inverter will automatically shut down. Once the
electrical device has been removed from the outlet the
inverter should automatically reset. If the power rating
exceeds approximately 170 Watts, the power inverter may
have to be reset manually. To reset the inverter manuallypush the power inverter button OFF and ON. To avoid
overloading the circuit, check the power ratings on electri-
cal devices prior to using the inverter.
The power inverter switch is located on
the instrument panel below the climate
controls. To turn on the power outlet,
push the switch once. The indicator light
will illuminate. Push the switch a sec-
ond time to turn the power inverter
outlet off.
NOTE: When the power inverter switch is pushed, there
will be a delay of approximately one second before the
inverter indicator light turns ON.
WARNING!
To avoid serious injury or death:
• Do not insert any objects into the receptacles.
• Do not touch with wet hands.
• Close the lid when not in use.
• If this outlet is mishandled, it may cause an electric
shock and failure.
Power Inverter
3
GETTING TO KNOW YOUR VEHICLE 179

GETTING TO KNOW YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT CLUSTER ..................182
▫ Instrument Cluster Descriptions ............183
 INSTRUMENT CLUSTER DISPLAY —
IF EQUIPPED .......................... .185
▫ Instrument Cluster Display Location
And Controls ........................ .185
▫ Instrument Cluster Display Menu Items .......187
 WARNING/INDICATOR LIGHTS AND
MESSAGES ........................... .195
▫ Red Telltale Indicator Lights ...............196
▫ Yellow Telltale Indicator Lights .............202▫
Green Telltale Indicator Lights ..............208
▫ White Telltale Indicator Lights ..............209
▫ Blue Telltale Indicator Lights ...............210
 ONBOARD DIAGNOSTIC SYSTEM —
OBDII .............................. .210
▫ Onboard Diagnostic System (OBD II)
Cybersecurity ..........................211
▫ Loose Fuel Filler Cap Message .............211
 EMISSIONS INSPECTION AND
MAINTENANCE PROGRAMS ..............2114

INSTRUMENT CLUSTER
Instrument Cluster
182 GETTING TO KNOW YOUR INSTRUMENT PANEL

Instrument Cluster Descriptions
1.Fuel Gauge
• The pointer shows the level of fuel in the fuel tank
when the ignition switch is in the ON/RUN position.
•
The fuel pump symbol points to the side of the
vehicle where the fuel filler door is located.
2. Speedometer
• Indicates vehicle speed.
3. Tachometer
• Indicates the engine speed in revolutions per minute
(RPM x 1000).
CAUTION!
Do not operate the engine with the tachometer pointer
in the red area. Engine damage will occur.
4. Temperature Gauge
• The temperature gauge shows engine coolant tem-
perature. Any reading within the normal range indi-
cates that the engine cooling system is operating
satisfactorily. •
The gauge pointer will likely indicate a higher tem-
perature when driving in hot weather, up mountain
grades, or when towing a trailer. It should not be
allowed to exceed the upper limits of the normal
operating range.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call an authorized dealer for
service if your vehicle overheats.
CAUTION!
Driving with a hot engine cooling system could dam-
age your vehicle. If the temperature gauge reads “H”
pull over and stop the vehicle. Idle the vehicle with the
air conditioner turned off until the pointer drops back
into the normal range. If the pointer remains on the
“H”, turn the engine off immediately and call an
authorized dealer for service.
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 183

5.Odometer / Trip Odometer Display Area
• The odometer display shows the total distance the
vehicle has been driven. The trip odometer shows
individual trip mileage. Refer to “Odometer/Trip
Odometer/ECO (Fuel Saver Indicator) Button” for
further information.
• U.S. Federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser
the correct mileage that the vehicle has been driven. If
your odometer needs to be repaired or serviced, the
repair technician should leave the odometer reading
the same as it was before the repair or service. If they
cannot do so, then the odometer must be set at zero,
and a sticker must be placed in the door jamb stating
what the mileage was before the repair or service. It is
a good idea for you to make a record of the odometer
reading before the repair/service, so that you can be
sure that it is properly reset, or that the door jamb
sticker is accurate if the odometer must be reset at zero.
Vehicle Odometer Messages
All messages will display in the instrument cluster display,
if equipped. Refer to “Instrument Cluster Display— If
Equipped” in this section for further information. When the appropriate conditions exist, the following
odometer messages will display:
•ECO — Fuel Saver Indicator
• door — Door Open
• gATE — Swing Gate Open
• LoW tirE — Low Tire Pressure
• HOTOIL — Oil Temperature Above Normal Limits
• gASCAP — Fuel Cap Fault
• noFUSE — Fuse Fault
• CHAngE OIL — Oil Change Required
6. Software Telltales
• Hard and Soft Telltales (Symbols) appear based on
specific behaviors.
7.
Instrument Cluster Display / Compass Mini-Trip Com-
puter Display — If Equipped
• When the appropriate conditions exist, this display
shows the instrument cluster display messages. Refer
to “Instrument Cluster Display” in “Getting To Know
Your Instrument Panel” for further information.
•
When the appropriate conditions exist, this display
shows the Mini-Trip Computer messages. Refer to “Mini-
Trip Computer” in “Getting To Know Your Instrument
Panel” for further information.
184 GETTING TO KNOW YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER DISPLAY — IF EQUIPPED
Your vehicle may be equipped with an instrument cluster
display, which offers useful information to the driver. With
the ignition in the STOP/OFF position, opening/closing of
a door will activate the display for viewing, and display
the total miles, or kilometers, in the odometer. Your instru-
ment cluster display is designed to display important
information about your vehicle’s systems and features.
Using a driver interactive display located on the instru-
ment panel, your instrument cluster display can show you
how systems are working and give you warnings when
they aren’t. The steering wheel mounted controls allow
you to scroll through and enter the main menus and
submenus. You can access the specific information you
want and make selections and adjustments.
Instrument Cluster Display Location And Controls
The instrument cluster display features a driver-interactive
display that is located in the instrument cluster.
Instrument Cluster Display
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 185

This system conveniently allows the driver to select a
variety of useful information by pushing the switches
mounted on the steering wheel. The instrument cluster
display consists of the following:
•Compass Heading (N, S, E, W, NE, NW, SE, SW)
• Outside Temperature (°F or °C)
• ECO Display
• Digital Speedometer
• Average Fuel Economy
• Distance To Empty
• Tire Pressure Monitor System — If Equipped
• Elapsed Time
• Vehicle Info
• Units Selection
• System Status and Warnings (Door Open, etc.)
• Personal Settings (Customer-Programmable Features) The system allows the driver to select information by
pushing the following buttons mounted on the steering
wheel:
Instrument Cluster Display Control Buttons
1 — MENU Button
3 — Down Arrow Button
2 — Right Arrow Button 4 — Compass Button
186 GETTING TO KNOW YOUR INSTRUMENT PANEL

•MENU Button
Push and release the MENUbutton to advance the display
to each of the instrument cluster display Main Menu
features or to return to the Main Menu from a submenu.
Upon reaching the last item in the Main Menu the instru-
ment cluster display will advance to the first item in the
Main Menu with the next MENUbutton push and release.
• Compass Button
Push and release the compassbutton to return to the
Compass/Outside Temperature/Audio Information/ECO
screen whenever the current display is not the Compass/
Outside Temperature/Audio Information/ECO screen.
• Right Arrow Button
Push and release the rightarrow button when prompted
by the instrument cluster display to Reset Main Menu
features with a reset capability or to change Personal
Settings.
• Down Arrow Button
Push and release the downarrow button when prompted
by the instrument cluster display to step through Vehicle
Info submenu, stored system warning messages, or Per-
sonal Settings features.Instrument Cluster Display Menu Items
NOTE: The instrument cluster display menu items display
in the center of the instrument cluster. Menu items may
vary depending on your vehicle features.
Average Fuel Economy
Shows the average fuel economy since the last reset.
Average fuel economy can be reset by pushing and holding
the right arrow button (as prompted in the instrument
cluster display). Upon reset, the history information will be
erased, and the averaging will continue from the last fuel
average reading before the reset.
Compass, Outside Temperature Display / ECO (Fuel
Saver Mode) — If Equipped
The compass readings indicate the direction the vehicle is
facing. Push and release the compassbutton to display one
of eight compass headings, the outside temperature/ECO
if the instrument cluster display is not already displaying
this screen.
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 187

NOTE:The system will display the last known outside
temperature when starting the vehicle and may need to be
driven several minutes before the updated temperature is
displayed. Engine temperature can also affect the dis-
played temperature; therefore, temperature readings are
not updated when the vehicle is not moving.
ECO (Fuel Saver Mode) — If Equipped
The ECO message will display below the outside tempera-
ture in the instrument cluster display (if the audio system
is on the ECO indicator will override the audio information
display line if the Display Fuel Saver personal setting is
ON — see Personal Settings section). This message will
appear whenever you are driving in a fuel efficient manner.
This feature allows you to monitor when you are driving in
a fuel efficient manner, and it can be used to modify
driving habits in order to increase fuel economy.
Automatic Compass Calibration
This compass is self-calibrating, which eliminates the need
to set the compass manually. When the vehicle is new, the
compass may appear erratic, and the instrument cluster
display will display “CAL” until the compass is calibrated.
You may also calibrate the compass by completing one or
more 360–degree turns (in an area free from large metal or metallic objects) until the “CAL” message displayed in the
instrument cluster display turns off. The compass will now
function normally.
NOTE:
A good calibration requires a level surface and an
environment free from large metallic objects such as build-
ings, bridges, underground cables, railroad tracks, etc.
Manual Compass Calibration
If the compass appears erratic and the “CAL” indicator
does not appear in the instrument cluster display, you must
put the compass into the Calibration Mode manually as
follows:
1. Start the engine. Leave the gear selector in PARK in order to enter the instrument cluster display Program-
ming Menus.
2. Push the MENUbutton until Personal Settings
(Customer-Programmable Features) displays in the in-
strument cluster display.
3. Push the downarrow button until “Calibrate Compass”
displays in the instrument cluster display.
4. Push and release the rightarrow button to start the
calibration. The “CAL” indicator will display in the
instrument cluster display.
188 GETTING TO KNOW YOUR INSTRUMENT PANEL
