220CARE AND MAINTENANCE
SPRAY NOZZLES
Windscreen washer fig. 7
If the jet of fluid is inadequate, firstly check that there is
fluid in the reservoir: see “Checking fluid levels” in this
section).
Then check that the nozzle holes are not clogged, if nec-
essary use a needle.
The windscreen jets are directed by adjusting the angle
of the nozzles.
Fluid jets should be directed at about 1/3 height from
the window upper edge.
IMPORTANT In versions with a sunroof, make sure that
the sunroof is closed before operating the front jets.
fig. 7L0E0099m
Rear window wiper fig. 8
Rear window washer jets are fixed.
The nozzle holder is on the rear window.
fig. 8 L0E0100m

CARE AND MAINTENANCE221
5
BODYWORK
PROTECTION FROM ATMOSPHERIC AGENTS
The main causes of corrosion are the following:
atmospheric pollution;
salty air and humidity (coastal areas, or hot humid cli-
mates);
seasonal environment conditions.
The abrasive action of wind-borne atmospheric dust and
sand, as well as mud and gravel raised by other cars is
also not to be underestimated.
On your car, Lancia has implemented the best manufac-
turing technologies to effectively protect the bodywork
against corrosion.These include:
painting products and systems which give the car par-
ticular resistance to corrosion and abrasion;
use of galvanised (or pre-treated) steel sheets, with high
resistance to corrosion;
spraying the underbody, engine compartment, wheel-
house internal parts and other parts with highly pro-
tective wax products;
spraying of plastic parts, with a protective function, in
the most exposed points: underdoor, inner wing parts,
edges, etc.;
use of “open” boxed sections to prevent condensation
and pockets of moisture from triggering rust inside.
BODY AND UNDERBODY WARRANTY
Your car is covered by warranty against perforation due
to rust of any original element of the structure or body.
For the general terms of this warranty, refer to the War-
ranty Booklet.

222CARE AND MAINTENANCE
To wash the car correctly, proceed as follows:
remove the aerial from the roof to prevent damage to
it if the car is washed in an automatic system;
in washing stations keep the steam jet/high pressure
washing nozzles at least 40 cm away from the body-
work to prevent damage. Remember that in the long-
term puddles of water can damage the car;
wash the body using a low pressure jet of water;
wipe a sponge with a slightly soapy solution over the
bodywork, frequently rinsing the sponge;
rinse well with water and dry with a jet of air or leather
pad.
When drying take care to dry the least exposed parts where
the water could collect most easily. It is a good idea to leave
the car in the open for a while after washing it to give time
for the water to evaporate.
Do not wash the car after it has been parked in the sun
or when the engine is bonnet is hot: this could take the
shine off the paint. ADVICE FOR PRESERVING THE BODYWORK
Paint
Paintwork does not only serve an aesthetic purpose, but
also protects the underlying sheet metal.
Touch up abrasions and scratches immediately to prevent
the formation of rust. Only use genuine spare paint prod-
ucts for touch-ups (see “Bodywork paint identification
plate” in the “Technical Specifications” section).
Normal maintenance of paintwork consists in washing the
car: the frequency depends on the conditions and envi-
ronment where the car is used. For example, it is advis-
able to wash the car more often in areas with a high en-
vironmental pollution or on roads sprinkled with salt.

CARE AND MAINTENANCE223
5
Exterior plastic parts must be cleaned in the same way
as the rest of the car.
Where possible, do not park under trees; the resinous sub-
stance many species release give the paint a dull appearance
and increase the possibility of triggering rust processes.
IMPORTANT Bird droppings must be washed off imme-
diately and thoroughly as the acid they contain is partic-
ularly aggressive.
Detergents cause water pollution. The car
should be washed in areas equipped for col-
lecting and purifying the liquid used in the
washing process.
Windows
Use specific window cleaner products.
Use also clean cloths to avoid scratching the glass or dam-
aging the transparency.
IMPORTANT Wipe the rear window inside gently with a
cloth in the direction of the filaments to avoid damaging
the heating device.
Engine compartment
At the end of each winter, thoroughly wash the engine
compartment, taking care to avoid directly hitting with
the water jet the electronic control units and the relay/fuse
control unit on the left side of the engine compartment
(running direction). Have this operation performed at a
specialised workshop.
IMPORTANT Perform this operation on a cold engine and
with the key at STOP. After the washing operation, make
sure that the various protections (e.g. rubber caps and
guards) have not been removed or damaged.
Front headlights
IMPORTANT Never use aromatic substances (e.g.: petrol)
or ketenes (e.g.: acetone) for cleaning front headlight plas-
tic lens.
To keep intact the aesthetic properties of the
paintwork do not use abrasive and/or pol-
ish products for cleaning the car bodywork.

224CARE AND MAINTENANCE
INTERIOR
Periodically check that water is not trapped under the mats
(due to water dripping off shoes, umbrellas, etc.) which
could cause oxidisation of the sheet metal.
Never use flammable products, such as petrol
ether or rectified petrol to clean inside the car.
The electrostatic charges which are generat-
ed by rubbing during the cleaning operation may
cause a fire.
Don’t keep aerosol cans in the vehicle: risk of
explosion. Aerosol cans must not be exposed
to a temperature exceeding 50°C. When the
vehicle is exposed to sunlight, inner temperature can
greatly exceed this value.
CLEANING SEATS AND FABRIC PARTS
Remove dust with a soft brush or a vacuum cleaner. It is
advisable to use a moist brush on velvet upholstery.
Rub the seats with a sponge moistened with a solution of
water and neutral detergent.
INTERIOR PLASTIC PARTS
It is advisable to clean interior plastic parts with a moist
cloth and a solution of water and mild soap. Use specific
products for cleaning plastic, without solvents and specif-
ically designed to prevent damage to the appearance and
colour of the treated parts to remove grease and tough
stains.
IMPORTANT Never use spirit or petroleum to clean the
instrument panel.

TECHNICAL DATA225
6
Identification data ............................................................... 226
Engine codes - bodywork versions........................................ 228
Engine ................................................................................ 229
Fuel system .........................................................................231
Transmission ....................................................................... 232
Brakes.................................................................................. 232
Suspension .......................................................................... 233
Steering ............................................................................... 233
Wheels ................................................................................ 234
Dimensions ......................................................................... 238
Performance ........................................................................ 239
Weight ................................................................................ 240
Consumables ....................................................................... 242
Fluids and lubricants ........................................................... 244
Fuel consumption ................................................................ 246
CO
2 emissions ..................................................................... 248

226TECHNICAL DATA
IDENTIFICATION DATA
The vehicle identification details are fig. 1:
A Identification plate (located in the engine compartment,
next to the upper attachment for the right-hand shock
absorber);
B Bodywork label (located on the passenger compartment
floor panel, next to the front passenger seat);
C Body paintwork identification label (located on the in-
side the tailgate);
D Engine label (located in the rear left-hand part, gear-
box-side).IDENTIFICATION PLATE fig. 2
This plate is applied to the engine compartment front
beam and shows the following identification data:
B Homologation number.
C Vehicle type code.
D Chassis manufacturing serial number.
E Maximum vehicle weight fully loaded.
F Maximum vehicle weight fully loaded with trailer.
G Maximum vehicle weight on front axle.
H Maximum vehicle weight on rear axle.
I Engine type.
L Body version code.
M Spare part code.
N Smoke opacity index (for diesel engines).
fig. 1L0E0116mfig. 2L0E0117m

TECHNICAL DATA227
6
CHASSIS MARKING fig. 3
This is printed on the passenger compartment floor pan-
el near the front right seat. Move flap A forwards to ac-
cess it.
The chassis marking includes:
vehicle type (ZAR 844000);
chassis manufacturing serial number.BODYWORK PAINT IDENTIFICATION PLATE
fig. 4
This plate is applied inside the bonnet and shows the fol-
lowing data:
A Paint manufacturer.
B Colour name.
C Lancia colour code.
D Respray and touch up code.
ENGINE MARKING
The engine marking is stamped on the cylinder block and
includes the model and the chassis number.
fig. 3L0E0118mfig. 4L0E0119m

228TECHNICAL DATA
198A4000
198A1000
198A2000
955A4000 (
)
844A1000
198A5000
844A2000 (
)
844AXA1A 00
844AXA1A 00B (*)
844AXB1A 01
844AXB1A 01B (*)
844AXC1A 02C
844AXC1A 02D (*)
844AXF1A 06C (
)
844AXF1A 06D (*)
844AXE1A 04C
844AXE1A 04D (*)
844AXD1A 03C
844AXD1A 03D (*)
844AXG1A 08 (
)
844AXG1A 08B
ENGINE CODES - BODYWORK VERSIONS
(*) Versions with 18” wheels
(
) For versions/markets where applicable
(
) Without DPF version
ENGINE CODE BODYWORK VERSION
1.4 Turbo Jet 120 HP
1.4 Turbo Jet 150 HP
1.6 Multijet
1.9 Twin Turbo Multijet
2.0 Multijet

198A1000
Otto
4 in line
72 x 84
1368
9,8
± 0,2
110
150
5500
206 (*)
21
2250/3000 (*)
NGK IKR9F8
Unleaded petrol
95 RON (Specification EN228)
198A4000
Otto
4 in line
72 x 84
1368
9,8
± 0,2
88
120
5000
206
21
1750
NGK IKR9F8
Unleaded petrol
95 RON (Specification EN228)
TECHNICAL DATA229
6
ENGINE
INTRODUCTION 1.4 Turbo Jet 120 HP 1.4 Turbo Jet 150 HP
Engine code
Cycle
Number and layout of cylinders
Piston bore and stroke mm
Total displacement cm3
Compression ratio
Maximum power (EEC) kW
HP
corresponding ratio rpm
Maximum torque (EEC) Nm
kgm
corresponding ratio rpm
Spark plugs
Fuel
(*) With SPORT function activated (where required)
