LAND ROVER DISCOVERY 1999 Workshop Manual

CHASSIS AND BODY DIMENSIONS
77-1-10 BODY DIMENSIONS
Front end/side information
I.D Description Length
A Distance between bonnet hinge fixing top hole and
windscreen side finisher top fixing slot1553.5 (61.161)
B Distance between windscreen side finisher top fixing
slots1430 (56.299)
C Distance between front door top hinge fixing hole and
rear door top hinge fixing hole998.5 (39.311)
D Distance between front door top hinge fixing hole and
rear door bottom hinge fixing hole1067.7 (42.035)
E Distance between front door bottom hinge fixing hole
and rear door top hinge fixing hole1072.5 (42.224)
F Distance between front door bottom hinge fixing hole
and rear door bottom hinge fixing hole998.5 (39.311)
G Distance between 'B/C' post top jig location hole and 'D'
post top door striker fixing hole767 (30.196)
H Distance between 'B/C' post bottom jig location hole and
'D' post top door striker fixing hole849.1 (33.429)
M77 1754
A
B
C
D
G
E
F
H

CHASSIS AND BODY DIMENSIONS
BODY DIMENSIONS 77-1-11
Internal information
I.D Description Length
A Distance between seat belt anchorage top fixing and
seat belt reel lower fixing1814.5 (71.437)
B Distance between seat belt anchorage lower fixings on
wheel arch inner1430.2 (56.307)
M77 1760
A
B

CHASSIS AND BODY DIMENSIONS
77-1-12 BODY DIMENSIONS
Rear end information
I.D Description Length
A Distance between taildoor setting block, jig location hole
and taildoor bottom hinge, middle fixing hole1364.4 (53.716)
B Distance between taildoor setting block, jig location hole
and taildoor top hinge, middle fixing hole1319.8 (51.960)
C Distance between crossmember outer rear panel, jig
location hole and rear headrest fixing hole 1413 (55.629)
M77 1758A
A
B
C

CHASSIS AND BODY DIMENSIONS
BODY DIMENSIONS 77-1-13
Gaps and profiles
Figures shown outside brackets are metric measurements (millimetres) and those inside brackets are imperial
measurements (inches).
Front end information
Gaps
The tolerance for the above figures is ± 1.0 (0.039).
Section Gap Description Dimension
A-A a Headlamp to grille 9.5 (0.374)
B-B b Headlamp to bonnet 14.0 (0.551)
C-C c Headlamp to indicator lamp 6.0 (0.236)
D-D d Headlamp to headlamp surround panel 9.5 (0.374)

CHASSIS AND BODY DIMENSIONS
77-1-14 BODY DIMENSIONS
Front end/side information
Gaps
The tolerance for gap 'e' is ± 1.0 (0.039), and for gap 'x' is ± 0.5 (0.019).
Profile
Section Gap Description Dimension
E-E e Bonnet to wing 6.0 (0.236)
x Fuel filler lid to body side panel 3.0 (0.118)
Section Description Dimension
E-E Profile of bonnet to wing +1.0 (0.039) -0.0

CHASSIS AND BODY DIMENSIONS
BODY DIMENSIONS 77-1-15
Side information
Gaps
The tolerance for gap 'f', 'g' and 'h' is ± 1.0 (0.039), and for gap 'j' is ± 2.0 (0.078).
Profiles
Section Gap Description Dimension
F-F f Wing to front door 6.0 (0.236)
G-G g Front door to rear door 6.0 (0.236)
H-H h Rear door to panel body side 6.0 (0.236)
J-J j Panel body side to roof 3.0 (0.118)
Section Description Dimension
F-F Profile of wing to front door +1.0 (0.039) -0.0
G-G Profile of front door to rear door +1.0 (0.039) -0.0
H-H Profile of rear door to panel body side +1.0 (0.039) -0.0

CHASSIS AND BODY DIMENSIONS
77-1-16 BODY DIMENSIONS
Rear end information
Gaps
The tolerance for gap 'k' and 'l' is ± 1.0 (0.039), and for gap 'm' is ± 2.0 (0.078).
Section Gap Description Dimension
K-K k Taildoor to body side panel 7.0 (0.275)
L-L l Taildoor to body side panel 7.0 (0.275)
M-M m Taildoor to roof 23.0 (0.905)

PANEL REPAIRS
REPLACEMENT PANELS 77-2-1
PANEL REPAIRS REPLACE ME NT PA NELS
Replacement panels
Front end outer panels
1Bonnet assembly
2Front wing3Wing support bracket

PANEL REPAIRS
77-2-2 REPLACEMENT PANELS
Front end inner panels
1Bonnet locking platform
2Headlamp mounting panels3Front crossmember
4Front bulkhead assembly

PANEL REPAIRS
REPLACEMENT PANELS 77-2-3
Valance panels
1Reinforcement valance outer
2Valance upper assembly3Headlamp closing panel
4Front valance assembly
