GENERAL INFORMATION
03-12
Self-locking bolts and screws
Self-locking bolts and screws, i.e. nylon patched or
trilobular thread can be re-used providing resistance
can be felt when the locking portion enters the female
thread.
Nylon patched bolts and screws have a locking agent
pre-applied to the threads. They are identified by the
presence of a coloured section of thread which
extends for up to 180
° around the thread.
Trilobular bolts (i.e. Powerlok) have a special thread
form which creates a slight interference with the
thread of the hole or nut into which it is screwed.
DO NOT re-use self-locking fasteners in critical
locations (e.g. engine bearings, flywheel). Always
use the correct replacement self-locking nut, bolt or
screw.
DO NOT fit non self-locking fasteners in applications
where a self-locking nut, bolt or screw is specified.Nut identification
A nut with an ISO metric thread is marked on one
face or on one of the flats of the hexagon with the
strength grade symbol 8, 12, or 14. Some nuts with a
strength grade 4, 5 or 6 are also marked and some
have the metric symbol M on the flat opposite the
strength grade marking.
A clock face system is sometimes used as an
alternative method of indicating the strength grade.
The external chamfers or a face of the nut is marked
in a position relative to the appropriate hour mark on
a clock face to indicate the strength grade.
A dot is used to locate the 12 o'clock position and a
dash to indicate the strength grade. If the grade is
above 12, two dots identify the 12 o'clock position.
When tightening a slotted or castellated nut, never
loosen it to insert a split pin except where
recommended as part of an adjustment. If difficulty is
experienced, alternative washers or nuts should be
selected, or the washer thickness reduced.
Where bearing pre-load is involved, nuts should be
tightened in accordance with special instructions.

TORQUE WRENCH SETTINGS
06-2
Engine Td5
TORQUE DESCRIPTION METRIC IMPERIAL
ACE pump bolts25 Nm (18 lbf.ft)
A/C compressor bolts 25 Nm (18 lbf.ft)
Alternator support bracket to cylinder head bolts 25 Nm (18 lbf.ft)
Alternator/vacuum pump oil feed pipe union 10 Nm (7 lbf.ft)
Camshaft cover to camshaft carrier bolts 10 Nm (7 lbf.ft)
Camshaft sprocket to camshaft bolts 37 Nm (27 lbf.ft)
Centrifuge cover bolts 10 Nm (7 lbf.ft)
Centrifuge oil drain pipe to sump bolts (or nuts) 10 Nm (7 lbf.ft)
Centrifuge to oil drain pipe bolts 10 Nm (7 lbf.ft)
Centrifuge to oil cooler housing bolts 25 Nm (18 lbf.ft)
CKP sensor bolt10 Nm (7 lbf.ft)
Coolant pipe bolt50 Nm (37 lbf.ft)
Connecting rod bolts, then a further 80°20 Nm (15 lbf.ft)
Crankshaft pulley bolt 460 Nm (340 lbf.ft)
Crankshaft pulley TV damper bolts 80 Nm (59 lbf.ft)
Crankshaft rear oil seal housing bolts 10 Nm (7 lbf.ft)
Cylinder head bolts initial tighten 30 Nm (22 lbf.ft)
Cylinder head bolts final tighten, then a further 90°, then a further 180° and finally a
further 45°65 Nm (48 lbf.ft)
Dipstick tube to camshaft carrier bolt 10 Nm (7 lbf.ft)
Drive plate (automatic transmission) to crankshaft bolts 115 Nm (85 lbf.ft)
EGR pipe clamp to cylinder head bolt - if fitted 25 Nm (18 lbf.ft)
EGR pipe Allen screws 10 Nm (7 lbf.ft)
Engine mounting (front) to cylinder block bolts 48 Nm (35 lbf.ft)
Engine mounting (front) to chassis nuts 85 Nm (63 lbf.ft)
Engine mounting bracket (rear, LH & RH) to gearbox bolts 85 Nm (63 lbf.ft)
Engine mounting bracket (rear, LH & RH) nuts 45 Nm (33 lbf.ft)
Flywheel to crankshaft (manual transmission) bolts, then a further 90°40 Nm (30 lbf.ft)
Front crossmember bolts 26 Nm (20 lbf.ft)
Fuel connector block bolts 25 Nm (18 lbf.ft)
Fuel cooler to inlet manifold bolts 25 Nm (18 lbf.ft)
Gearbox housing to engine bolts 50 Nm (37 lbf.ft)
Heater pipe to cylinder head bolts 25 Nm (18 lbf.ft)
Main bearing cap bolts then a further 90°33 Nm (24 lbf.ft)
Oil cooler housing to cylinder block bolts 25 Nm (18 lbf.ft)
Oil cooler pipe clip bolts 10 Nm (7 lbf.ft)
Oil filter adaptor housing to oil cooler housing bolts 25 Nm (18 lbf.ft)
Oil pick-up strainer screws 10 Nm (7 lbf.ft)
Oil pressure switch 15 Nm (11 lbf.ft)
Oil pump drive sprocket bolt 25 Nm (18 lbf.ft)
Oil pump pressure relief valve plug 25 Nm (18 lbf.ft)
Oil pump and stiffener assembly to cylinder block bolts 13 Nm (10 lbf.ft)
Oil sump to cylinder block bolts 25 Nm (18 lbf.ft)
Oil sump to gearbox bell housing bolts 13 Nm (10 lbf.ft)
PAS pump bracket bolts 27 Nm (20 lbf.ft)
PAS pump pulley bolts 27 Nm (20 lbf.ft)
Rocker arm adjusting screw locknuts 16 Nm (12 lbf.ft)

TORQUE WRENCH SETTINGS
06-4
Engine V8
TORQUE DESCRIPTION METRIC IMPERIAL
Engine mounting bolts (rear, LH & RH) to gearbox bolts 85 Nm (63 lbf.ft)
Engine mounting (rear, LH & RH) nuts 45 Nm (33 lbf.ft)
Cylinder head bolts tighten, then 90°, then a further 90°20 Nm (15 lbf.ft)
Rocker shaft bolts 40 Nm (30 lbf.ft)
Alternator mounting bracket 40 Nm (30 lbf.ft)
Auxiliary drive belt tensioner 45 Nm (33 lbf.ft)
Engine earth lead 22 Nm (16 lbf.ft)
Rocker cover bolts 8 Nm (6 lbf.ft)
Torque converter to drive plate 50 Nm (37 lbf.ft)
A/C compressor 22 Nm (16 lbf.ft)
ACE pump 22 Nm (16 lbf.ft)
Flywheel to crankshaft 78 Nm (58 lbf.ft)
Crankshaft sensor 6 Nm (5 lbf.ft)
Crankshaft sensor cover 6 Nm (5 lbf.ft)
Spacer and hub to crankshaft 85 Nm (63 lbf.ft)
Drive plate and clamp ring 45 Nm (33 lbf.ft)
Oil pick up strainer 10 Nm (7 lbf.ft)
Filter head adaptor 13 Nm (10 lbf.ft)
Filter head 8 Nm (6 lbf.ft)
Sump bolts 22 Nm (16 lbf.ft)
Oil pressure switch 15 Nm (11 lbf.ft)
Timing gear cover to cylinder block 22 Nm (16 lbf.ft)
Oil cooler pipe to timing gear cover 15 Nm (11 lbf.ft)
Crankshaft pulley bolt 270 Nm (200 lbf.ft)
Coolant outlet elbow 22 Nm (16 lbf.ft)
Auxiliary housing 40 Nm (30 lbf.ft)
Jockey pulley 50 Nm (37 lbf.ft)
Camshaft gear 50 Nm (37 lbf.ft)
Rocker shaft bolts 40 Nm (30 lbf.ft)
Connecting rod bolts
Final torque - turn through 80 °20 Nm (15 lbf.ft)
Initial torque - all main bearing cap bolts and side bolts 13.5 Nm (10 lbf.ft)
Final torque - main bearing cap side bolts 11 to 15 45 Nm (33 lbf.ft)
Final torque - main bearing cap bolts 1 to 8 72 Nm (53 lbf.ft)
Final torque - main bearing cap bolts 9 and 10 92 Nm (68 lbf.ft)
Final torque - main bearing cap side bolts 16 to 20 45 Nm (33 lbf.ft)
Viscous fan nut 45 Nm (33 lbf.ft)
Camshaft thrust plate bolts 22 Nm (16 lbf.ft)
Secondary Air Injection adapters 33 Nm (24 lbf.ft)

TORQUE WRENCH SETTINGS
06-10
Steering
TORQUE DESCRIPTION METRIC IMPERIAL
Drag link to drop arm 80 Nm (59 lbf.ft)
Track rod to steering knuckle 125 Nm (92 lbf.ft)
Tension collet to steering knuckle 5 Nm (3.7 lbf.ft)
Steering damper125 Nm (92 lbf.ft)
Steering knuckle to axle yoke upper ball joint 110 Nm (81 lbf.ft)
High pressure pipe union 20 Nm (15 lbf.ft)
Drag link/track rod M8 bolts 22 Nm (16 lbf.ft)
Drag link/track rod M10 bolts 33 Nm (24 lbf.ft)
Steering box90 Nm (66 lbf.ft)
Universal joint to intermediate shaft 25 Nm (18 lbf.ft)
Panhard rod230 Nm (170 lbf.ft)
Steering box output shaft 88 Nm (65 lbf.ft)
Drop arm240 Nm (177 lbf.ft)
Auxiliary housing bolts 40 Nm (30 lbf.ft)
Auxiliary housing nut 10 Nm (7 lbf.ft)
PAS pump - V822 Nm (16 lbf.ft)
PAS pump pipe bracket bolt 22 Nm (16 lbf.ft)
Jockey pulley bolt 50 Nm (37 lbf.ft)
PAS pump adaptor pipe 10 Nm (7 lbf.ft)
PAS pump to coolant pump bolts - Td5 25 Nm (18 lbf.ft)
Steering column to fascia 25 Nm (18 lbf.ft)
Universal joint to steering box 25 Nm (18 lbf.ft)
Ball joint to swivel hub 77 Nm (57 lbf.ft)
PAS pump pulley22 Nm (16 lbf.ft)
Steering wheel nut 43 Nm (32 lbf.ft)

TORQUE WRENCH SETTINGS
06-11
Front suspension
TORQUE DESCRIPTION METRIC IMPERIAL
Wheel nuts140 Nm (103 lbf.ft)
Panhard rod230 Nm (170 lbf.ft)
Lower ball joint nut 135 Nm (100 lbf.ft)
Track rod and drag link 80 Nm (59 lbf.ft)
Damper to front axle 55 Nm (40 lbf.ft)
Anti-roll bar link - upper 100 Nm (74 lbf.ft)
Anti-roll bar link - lower 100 Nm (74 lbf.ft)
Turret to chassis23 Nm (17 lbf.ft)
Radius arm230 Nm (170 lbf.ft)
ACE pump pulley 25 Nm (18 lbf.ft)
ACE pump banjo bolt 28 Nm (21 lbf.ft)
Valve block to chassis 18 Nm (13 lbf.ft)
Valve block clamping plate 21 Nm (15 lbf.ft)
ACE valve block pipe clip 6 Nm (4.4 lbf.ft)
ACE valve block filter cap 35 Nm (26 lbf.ft)
Pressure transducer 20 Nm (15 lbf.ft)
Fluid pipes to actuator cap 29 Nm (21 lbf.ft)
Banjo to pump bolt 28 Nm (21 lbf.ft)
Actuator to long arm 48 Nm (35 lbf.ft)
Actuator to short arm 180 Nm (133 lbf.ft)
Torsion bar clamp plate bolts 45 Nm (33 lbf.ft)
Long arm to torsion bar bolt 185 Nm (136 lbf.ft)

TORQUE WRENCH SETTINGS
06-12
Rear suspension
Brakes
TORQUE DESCRIPTION METRIC IMPERIAL
Wheel nuts140 Nm (103 lbf.ft)
Wheel hub to axle 100 Nm (74 lbf.ft)
Damper to axle125 Nm (92 lbf.ft)
SLS height sensor link to radius arm 25 Nm (18 lbf.ft)
Radius arm230 Nm (170 lbf.ft)
Transverse links to pivot housing 155 Nm (114 lbf.ft)
Pivot housing to axle bolts 230 Nm (170 lbf.ft)
Transverse link to chassis 140 Nm (103 lbf.ft)
SLS height sensor 6 Nm (4.4 lbf.ft)
SLS compressor25 Nm (18 lbf.ft)
ACE actuator to short arm 185 Nm (136 lbf.ft)
ACE actuator to long arm 48 Nm (35 lbf.ft)
ACE actuator pipe cap nuts 29 Nm (21 lbf.ft)
Anti-roll bar link - upper 50 Nm (37 lbf.ft)
Anti-roll bar link - lower 100 Nm (74 lbf.ft)
ACE long arm to torsion bar 180 Nm (133 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Brake caliper bleed screw 10 Nm (7 lbf.ft)
Brake disc to drive flange 13 Nm (10 lbf.ft)
Caliper bolts - Front 175 Nm (129 lbf.ft)
Caliper bolts - Rear 95 Nm (70 lbf.ft)
Master cylinder to servo 25 Nm (18 lbf.ft)
Master cylinder brake pipe, unions 25 Nm (18 lbf.ft)
Brake caliper pivot bolt 30 Nm (22 lbf.ft)
Vacuum pump8 Nm (6 lbf.ft)
Vacuum pump lubrication pipe union 10 Nm (7 lbf.ft)
Brake caliper guide pin bolts 30 Nm (22 lbf.ft)
Brake caliper banjo bolt 32 Nm (24 lbf.ft)
ABS modulator to mounting bracket nuts 9 Nm (7 lbf.ft)
ABS modulator - 13 mm unions 22 Nm (16 lbf.ft)
ABS modulator - 11 mm union 14 Nm (10 lbf.ft)
Handbrake lever to floor bolts 22 Nm (16 lbf.ft)

MAINTENANCE
10-28 PROCEDURES
4.Check condition of Engine - RH mounting
rubber
5.Check tightness of all mounting bolts.

+ TORQUE WRENCH SETTINGS,
Engine V8.
Road/roller test
WARNING: Roller test must be restricted to 3
mph (5 km/h). If 2 wheel rolling road is to be used,
disconnect propeller shaft from the transfer box
output shaft driving the axle which is NOT on the
rolling road.Testing
1. 2 wheel rolling road: Engage differential lock
using a 10 mm open ended spanner on flats
machined on differential lock selector
shaft.Switch on ignition and check that the
differential lock, electronic brake
distribution and hill descent warning lamps
are illuminated.
2.Check for correct operation of starter switch,
ensure engine starts correctly; leave the engine
running.
3.Check for correct operation of starter switch,
ensure engine starts correctly; leave the engine
running.
4.With vehicle stationary, turn steering from lock
to lock. Check for smooth operation and ensure
there is no undue noise from power steering
pump or drive belt.
5.Depress clutch and select all gears in turn,
check for smooth, notch free engagement.
6. Check all vehicle systems for correct
operation.
7.Check for unusual engine, gearbox and
suspension noises.
8.Check braking system operation.
9.Check for smooth gear engagement.
10.Check engine performance.
11.Check operation of all instruments and warning
devices where practicable.

ENGINE - TD5
DESCRIPTION AND OPERATION 12-1-5
1Crankshaft pulley bolt
2TV Damper to crankshaft pulley bolts (3 off)
3TV Damper
4Crankshaft pulley
5Woodruff key
6Crankshaft
7Crankshaft to flywheel dowel
8Spigot bush
9Flywheel to crankshaft bolts (8 off)
10Flywheel assembly (Manual shown)
11Main bearing shells (6 pairs)
12Main bearing caps (6 off)
13Main bearing cap bolts (12 off)
14Thrust washer (2 off at No. 3 Main bearing)
15Piston lubrication jets (5 off)
16Piston lubrication jet cap head screw (5 off)
17Stiffener plate (oil pump integral)18Stiffener plate / oil pump assembly to cylinder
block bolts (22 off)
19Oil pick-up pipe O-ring
20Oil pick-up pipe inserts (2 x 6mm; 1 x 10mm)
21Upper oil pick-up pipe
22Oil pick-up pipe gauze
23Lower oil pick-up pipe
24Sump
25Oil drain plug seal
26Oil drain plug
27Sump to cylinder block bolts (20 off)
28Sump gasket
29Oil pick-up pipe bolts (3 off)
30Oil pump
31Chain lubrication jet
32Chain lubrication jet screw
33Stiffener to cylinder block dowel (2 off)

ENGINE - TD5
12-1-12 DESCRIPTION AND OPERATION
Description
General
The Td5 diesel engine is a 2.5 litre, 5 cylinder, in-line direct injection unit having 2 valves per cylinder, operated by a
single overhead camshaft. The engine emissions, on pre EU3 models, comply with ECD2 (European Commission
Directive) and on EU3 models, comply with ECD3 legislative requirements. Both models employ electronic engine
management control, positive crankcase ventilation and exhaust gas recirculation to limit the emission of pollutants.
The unit is water cooled and turbo-charged and is controlled by an electronic engine management system.
The engine is a monobloc cast iron construction with an aluminium stiffening plate fitted to the bottom of the cylinder
block to improve lower structure rigidity. The cylinder head and sump are cast aluminium. An acoustic cover is fitted
over the upper engine to reduce engine generated noise.
The engine utilises the following features:
lElectronic Unit Injectors (EUI's) controlled by an Engine Management System for precise fuel delivery under
all prevailing operating conditions.
lTurbocharging which delivers compressed air to the combustion chambers via an intercooler for improved
power output.
lFuel Cooler
lOil Cooler
lCentrifuge Oil Filter
lHydraulic Lash Adjusters with independent finger followers
Cylinder block components
The cylinder block components are described below:
Cylinder Block
The cylinders and crankcase are contained in a single cast iron construction. The cylinders are direct bored and
plateau honed with lubrication oil supplied via lubrication jets for piston and gudgeon pin lubrication and cooling. It is
not possible to rebore the cylinder block if the cylinders become worn or damaged. Three metal core plugs are fitted
to the three centre cylinders on the right hand side of the cylinder block.
Lubrication oil is distributed throughout the block via the main oil gallery to critical moving parts through channels
bored in the block which divert oil to the main and big-end bearings via oil holes machined into the crankshaft. Oil is
also supplied from the cylinder block main gallery to the five lubrication jets which cool and lubricate the piston and
gudgeon pins. Plugs are used to seal both ends of the main oil gallery at front and rear of the engine block. An oil
cooler is fitted to the LH side of the engine block; ports in the oil cooler assembly mate with ports in the cylinder block
to facilitate coolant flow. Oil is diverted through the oil cooler, centrifuge filter and full-flow filter before supplying the
main oil gallery. A tapping in the oil filter housing provides a lubrication source for the turbocharger bearings and an
oil pressure switch is included in a tapping in the oil cooler housing which determines whether sufficient oil pressure
is available to provide engine lubrication and cooling.
Cylinder cooling is achieved by water circulating through chambers in the engine block casting. A threaded coolant
jacket plug is located at the front RH side of the cylinder block.
Cast mounting brackets are bolted to both sides of the engine block for mounting the engine to the chassis on the LH
and RH hydramount studs.
The gearbox bolts directly to the engine block; a gearbox shim plate is located between the adjoining faces of the
gearbox and the flywheel side of the engine block and is fixed to the rear of the engine block by two bolts. Two hollow
metal dowels locate the rear of the cylinder block to the gearbox shim plate. The gearbox casing provides the
mounting for the starter motor.
A port is included at the rear left hand side of the cylinder block which connects to the turbocharger oil drain pipe to
return lubrication oil to the sump.
A plug sealing the lubrication cross-drilling gallery is located at the front right hand side of the cylinder block and plugs
for the main lubrication gallery is included at the front and rear of the cylinder block.

ENGINE - TD5
DESCRIPTION AND OPERATION 12-1-21
Crankshaft
1Front end to crankshaft sprocket
2Oil supply cross-drillings
3Main journals
4Big-end journals
5Rear end to flywheel
The crankshaft is constructed from cast iron and is surface-hardened. The areas between the crankshaft journals and
the adjoining webs and balance weights are compressed using the cold roll process to form journal fillets.
Cross-drillings in the crankshaft between adjoining main and big-end bearings are used to divert lubrication oil to the
big-end bearings.
A torsional vibration damper is attached to the crankshaft pulley by three bolts.
The crankshaft is carried in six main bearings, with end-float being controlled by thrust washers positioned on both
sides of No. 3 main bearing.
Main bearings
There are six main bearings used to carry the crankshaft. Each of the bearing caps are of cast iron construction and
are attached to the cylinder block by two bolts.
The bearing shells are of the split cylindrical type. The upper half bearing shells are grooved to facilitate the supply of
lubrication oil to the bearings and fit into a recess in the underside of the cylinder block. The lower half bearing shells
are smooth and fit into the bearing caps.
Steel-backed thrust washers are included at each side of No. 3 main bearing to control crankshaft end-float. One side
of each of the thrust washers is grooved, the grooved side of each of the thrust washers is fitted facing outward from
No. 3 main bearing.
Cylinder head components
The cylinder head components are described below:
Cylinder head
The cylinder head is of aluminium construction. It is not possible to reface the cylinder head if it becomes worn or
damaged. An alloy camshaft carrier is bolted directly to the upper surface of the cylinder head. Two dowels are
included in the cylinder head upper face for correct location of the camshaft carrier.
The EU3 cylinder head has a single internal fuel rail for delivering fuel to the injectors and an external fuel pipe for
returning spill fuel back to the fuel connector block. Therefore, pre EU3 and EU3 model cylinder heads are not
interchangeable.
CAUTION: The cylinder head incorporates drillings for the fuel injection system, any contamination which
enters these drillings could cause engine running problems or injector failure. It is therefore, essential that
absolute cleanliness is maintained when carrying out work on the cylinder head.
