INTERIOR TRIM COMPONENTS
76-3-20 REPAIRS
10.Disconnect 2 multiplugs from fuse box.
11.Close glove box.
12.Remove clock.

+ INSTRUMENTS, REPAIRS, Clock.
13.Remove hazard warning switch.

+ DRIVER CONTROLS, REPAIRS,
Switch - hazard warning - from 04MY.
14.Remove both 'A' post upper trim finishers.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim finisher - 'A' post - upper -
renew.
15.Remove passenger airbag.

+ RESTRAINT SYSTEMS, REPAIRS,
Air bag - fascia - passenger - from 04MY.
16.Disconnect 2 multiplugs from fascia harness.17.Remove 14 bolts securing fascia.
18.With assistance remove fascia.
NOTE: Do not carry out further dismantling if
component is removed for access only.
19.Disconnect 4 multiplugs from fascia switch
assembly.
20.Remove 4 switches from fascia switch carrier.
M76 4722
M76 4714

INTERIOR TRIM COMPONENTS
76-3-22 REPAIRS
29.Noting fitted position remove fascia harness
assembly.Refit
1.Fit and secure fascia harness.
2.Fit striker plate, secure with screws and adjust
if necessary.
3.Fit passenger side glove box assembly.
4.Fit face level air vents.
5.Fit and secure cruise switch carrier assembly to
fascia.

+ FUEL DELIVERY SYSTEM -
PETROL, REPAIRS, Switch - engagement
(on/off) - from 04MY.
6.Fit glove box lids and secure hinge pins.
7.Connect mirror switch multiplug and fit switch
assembly to fascia.
8.Fit switches to fascia carrier and connect
multiplugs.
9.With assistance fit fascia to vehicle and secure
bolts to 10 Nm (7 lbf.ft).
10.Connect fascia harness multiplugs to main
harness.
11.Fit passenger airbag.

+ RESTRAINT SYSTEMS, REPAIRS,
Air bag - fascia - passenger - from 04MY.
12.Fit 'A' post upper trim finishers.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim finisher - 'A' post - upper -
renew.
13.Fit hazard warning switch.

+ DRIVER CONTROLS, REPAIRS,
Switch - hazard warning - from 04MY.
14.Fit clock.

+ INSTRUMENTS, REPAIRS, Clock.
15.Open drivers side glove box.
16.Fit Radio/CD module.

+ IN CAR ENTERTAINMENT,
REPAIRS, Radio/CD - from 04MY.
17.Fit fuse box cover and close glove box lid.
18.Fit steering column lower cover and secure with
screws.
19.Fit wiper/indicator switch and tighten clamping
screw.
20.Connect multiplugs to wiper/indicator switch.
21.Fit rotary coupler.

+ RESTRAINT SYSTEMS, REPAIRS,
Rotary coupler - (SRS) air bag system.
22.Fit heater control to fascia and secure with
screws.
23.Fit instrument pack.

+ INSTRUMENTS, REPAIRS,
Instrument panel - from 04MY.
M76 4721

PANEL REPAIRS
WELDING PROCEDURES 77-2-15
WE LDING PROCEDURE S
ECU locations (3 door model shown, 5
door model similar)
1Central control unit (on forward side of
passenger compartment fusebox, behind
driver's glove box)
2RF Receiver (on top of instrument pack)
3Immobiliser ECU (rear of fascia)
4DCU (SRS on transmission tunnel below
heater)
5EAT ECU (inside Environmental 'E' box)
6ECM (inside 'E' box)
7Fuel Burning Heater (behind wheelarch liner)
'Diesel only'8Cooling Fan Ecu (rear of radiator housing) all
models except 1.8
9ABS ECU (RH side front of engine
compartment)
10Folding door mirror ECU (on transmission
tunnel under centre console)
11Window lift ECU (on driver `A` post)
12Cruise Control Interface ECU (under R/H seat)
13Cruise control ECU (under R/H seat)

PANEL REPAIRS
77-2-30 REPAIRS
Front sidemember (complete)
In this procedure, the front sidemember closing
panel and the related crossmember to sidemember
gusset plate are replaced in conjunction with the front
sidemember.
Remove
1.Disconnect battery earth lead.
2.Disconnect alternator.
3.Disconnect all ECUs.
4.Remove road wheel(s).
5.Remove underbelly panel.

+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
6.Remove front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
7.Remove front bumper armature.
8.Remove radiator.

+ COOLING SYSTEM - K SERIES KV6,
REPAIRS, Radiator assembly.
9.Remove PAS fluid cooler.

+ STEERING, REPAIRS, Oil cooler -
Td4 & K1.8 models.
10.Remove headlamp.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
11.Release wiring to headlamp and position aside.
12.Remove engine bay shield.
13.Remove front wheel arch liner.

+ EXTERIOR FITTINGS, REPAIRS,
Liner - front wheel arch.
14.Remove front suspension rear beam.
15.Remove engine and gearbox.

+ ENGINE - K SERIES KV6, REPAIRS,
Engine and automatic gearbox - up to 03MY.
16.Remove PAS rack.

+ STEERING, REPAIRS, Power
steering rack.
17.Remove fascia.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Fascia - up to 04MY.
18. LH side: Remove front bumper LH support
bracket.
19. LH side: Remove LH engine mounting from
body.
20. LH side: Remove battery.

+ CHARGING AND STARTING,
REPAIRS, Battery.
21. LH side: Remove air intake hose.
22. LH side: Remove horn.

+ SECURITY, REPAIRS, Horn.
23. RH side: Remove front bumper RH support
bracket.24. RH side: Remove RH engine mounting from
body.
25. RH side: Remove windscreen washer
reservoir.

+ WIPERS AND WASHERS, REPAIRS,
Reservoir - washer.
26. Driver's side: Remove passenger
compartment fuse box.
27. Driver's side: Remove brake pedal box and
brake servo.
28. Driver's side: Remove clutch pedal box.
29.Remove treadplate from front door aperture.
Release front carpet and position aside.
30.Remove insulation pads from engine bulkhead.

PANEL REPAIRS
REPAIRS 77-2-31
Repair
1.Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.
Refit
1.Fit insulation pads to engine bulkhead.
2.Position front carpet and fit treadplate to front
door aperture. 3. Driver's side: Fit clutch pedal box.
4. Driver's side: Fit brake pedal box and brake
servo.
5. Driver's side: Fit passenger compartment fuse
box.
6. LH side: Fit horn.

+ SECURITY, REPAIRS, Horn.
7. LH side: Fit air intake hose.
8. LH side: Fit battery. Do not connect battery
earth lead.

+ CHARGING AND STARTING,
REPAIRS, Battery.
9. LH side: Fit LH engine mounting to body.
10. LH side: Fit front bumper LH support bracket.
11. RH side: Fit windscreen washer reservoir.

+ WIPERS AND WASHERS, REPAIRS,
Reservoir - washer.
12. RH side: Fit RH engine mounting to body.
13. RH side: Fit front bumper RH support bracket.
14.Fit fascia.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Fascia - up to 04MY.
15.Fit PAS rack.

+ STEERING, REPAIRS, Power
steering rack.
16.Fit engine and gearbox.

+ ENGINE - K SERIES KV6, REPAIRS,
Engine and automatic gearbox - up to 03MY.
17.Fit front suspension rear beam.
18.Fit front wheel arch liner.

+ EXTERIOR FITTINGS, REPAIRS,
Liner - front wheel arch.
19.Fit engine bay shield.
20.Fit headlamp.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
21.Secure headlamp wiring.
22.Fit PAS fluid cooler.

+ STEERING, REPAIRS, Oil cooler -
Td4 & K1.8 models.
23.Fit radiator.

+ COOLING SYSTEM - K SERIES KV6,
REPAIRS, Radiator assembly.
24.Fit front bumper armature.
25.Fit front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
26.Fit underbelly panel.

+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
27.Fit road wheel(s) and tighten nuts to 115 Nm
(85 lbf.ft).
28.Connect all ECUs.
29.Connect alternator.
30.Connect battery earth lead.

PANEL REPAIRS
REPAIRS 77-2-33
Refit
1. LH side: Fit horn.

+ SECURITY, REPAIRS, Horn.
2. LH side: Fit air intake hose.
3. LH side: Fit air cleaner.
4. LH side: Fit battery carrier. Do not connect
battery earth lead.

+ CHARGING AND STARTING,
REPAIRS, Carrier - battery.
5. LH side: Fit ECM.
6. LH side: Fit front bumper LH support bracket.
7. RH side: Fit PAS pump.

+ STEERING, REPAIRS, Pump -
steering - KV6.
8. RH side: Fit alternator.

+ CHARGING AND STARTING,
REPAIRS, Alternator - KV6.
9. RH side: Fit windscreen washer reservoir.

+ WIPERS AND WASHERS, REPAIRS,
Reservoir - washer.
10. RH side: Fit front bumper RH support bracket.
11.Fit front wheel arch liner.

+ EXTERIOR FITTINGS, REPAIRS,
Liner - front wheel arch.
12.Fit engine bay shield.
13.Fit headlamp.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
14. Secure headlamp wiring.
15.Fit PAS fluid cooler.

+ STEERING, REPAIRS, Oil cooler -
Td4 & K1.8 models.
16.Fit radiator.

+ COOLING SYSTEM - K SERIES KV6,
REPAIRS, Radiator assembly.
17.Fit front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
18.Fit underbelly panel.

+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
19.Connect all ECUs.
20.Connect battery earth lead.
Front valance assembly
Remove
1.Disconnect battery earth lead.
2.Disconnect all ECUs.
3.Remove road wheel(s).
4.Remove underbelly panel.

+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
5.Remove front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
6.Remove front bumper armature.
7.Remove radiator.

+ COOLING SYSTEM - K SERIES KV6,
REPAIRS, Radiator assembly.
8.Remove PAS fluid cooler.

+ STEERING, REPAIRS, Oil cooler -
Td4 & K1.8 models.
9.Remove headlamp.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
10.Release wiring to headlamp and position aside.
11.Remove engine bay shield.
12.Remove front wheel arch liner.

+ EXTERIOR FITTINGS, REPAIRS,
Liner - front wheel arch.
13.Remove front wing.

+ EXTERIOR FITTINGS, REPAIRS,
Wing - front.
14.Remove front suspension rear beam.
15.Remove engine and gearbox.

+ ENGINE - K SERIES KV6, REPAIRS,
Engine and automatic gearbox - up to 03MY.
16.Remove front damper.

+ FRONT SUSPENSION, REPAIRS,
Damper.
17.Remove PAS rack.

+ STEERING, REPAIRS, Power
steering rack.
18.Remove fascia.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Fascia - up to 04MY.
19. LH side: Remove front bumper LH support
bracket.
20. LH side: Remove air cleaner.
21. LH side: Remove air intake hose.
22. LH side: Remove ECM.
23. LH side: Remove engine compartment
fusebox.
24. LH side: Remove battery carrier.

+ CHARGING AND STARTING,
REPAIRS, Carrier - battery.
25. LH side: Remove engine compartment fuse
box and related wiring.

PANEL REPAIRS
77-2-34 REPAIRS
26. LH side: Remove LH engine mounting from
body.
27. LH side: On models with Diesel engines,
remove fuel filter.

+ FUEL DELIVERY SYSTEM - DIESEL,
REPAIRS, Filter - main - up to 03MY.
28. LH side: Remove LH front brake pipe.
29. RH side: Remove front bumper RH support
bracket.
30. RH side: Remove windscreen washer
reservoir.

+ WIPERS AND WASHERS, REPAIRS,
Reservoir - washer.
31. RH side: Remove coolant expansion tank.
32. RH side: Remove RH engine mounting from
body.
33. RH side: Remove PAS fluid reservoir.
34. RH side: Remove RH front brake pipe.
35. Driver's side: Remove passenger
compartment fuse box.
36.Remove brake pedal box and brake servo.
37.Remove clutch pedal box.
38.Release vehicle harness from valance and
position aside.
39.Remove treadplate from front door aperture.
Release front carpet and position aside.
40.Remove insulation pads from engine bulkhead.
Repair
1.Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown. Refit
1.Fit insulation pads to front and rear sides of
engine bulkhead.
2.Position front carpet and fit treadplate to front
door aperture.
3.Secure vehicle harness to valance.
4. Driver's side: Fit clutch pedal box.
5.Fit brake pedal box and brake servo.
6.Fit passenger compartment fuse box.
7. LH side: Fit LH front brake pipe. Bleed brake
system.
+ BRAKES, ADJUSTMENTS, Brake
bleed.
8. LH side: On models with Diesel engines, fit fuel
filter.

+ FUEL DELIVERY SYSTEM - DIESEL,
REPAIRS, Filter - main - up to 03MY.
9. LH side: Fit LH engine mounting to body.
10. LH side: Fit engine compartment fuse box and
related wiring.
11. LH side: Fit battery carrier. Do not connect
battery earth lead.

+ CHARGING AND STARTING,
REPAIRS, Carrier - battery.
12. LH side: Fit engine compartment fusebox.
13. LH side: Fit ECM.
14. LH side: Fit air intake hose.
15. LH side: Fit air cleaner.
16. LH side: Fit front bumper LH support bracket.
17. RH side: Fit RH front brake pipe. Bleed brake
system.

+ BRAKES, ADJUSTMENTS, Brake
bleed.
18. RH side: Fit PAS fluid reservoir.
19. RH side: Fit RH engine mounting to body.
20. RH side: Fit coolant expansion tank.
21. RH side: Fit windscreen washer reservoir.

+ WIPERS AND WASHERS, REPAIRS,
Reservoir - washer.
22. RH side: Fit front bumper RH support bracket.
23.Fit fascia.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Fascia - up to 04MY.
24.Fit PAS rack.

+ STEERING, REPAIRS, Power
steering rack.
25.Fit front damper.

+ FRONT SUSPENSION, REPAIRS,
Damper.
26.Fit engine and gearbox.

+ ENGINE - K SERIES KV6, REPAIRS,
Engine and automatic gearbox - up to 03MY.
27.Fit front suspension rear beam.
28.Fit front wing.

+ EXTERIOR FITTINGS, REPAIRS,
Wing - front.

PANEL REPAIRS
REPAIRS 77-2-37
Valance front
Remove
1.Disconnect battery earth lead.
2.Disconnect alternator.
3.Disconnect all ECUs.
4.Remove road wheel(s).
5.Remove front wheel arch liner.

+ EXTERIOR FITTINGS, REPAIRS,
Liner - front wheel arch.
6.Remove engine bay shield.
7.Remove front wing.

+ EXTERIOR FITTINGS, REPAIRS,
Wing - front.
8.Remove front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
9.Remove front bumper support bracket.
10.Remove radiator.

+ COOLING SYSTEM - K SERIES KV6,
REPAIRS, Radiator assembly.
11.Remove headlamp.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
12.Release wiring to headlamp and position aside.
13. LH side: Remove air cleaner.
14. LH side: Remove air intake hose.
15. LH side: Remove ECM.
16. LH side: Remove battery carrier.

+ CHARGING AND STARTING,
REPAIRS, Carrier - battery.
17. LH side: Remove engine compartment fuse
box and related wiring.
18. LH side: Remove LH front brake pipe.
19. RH side: Remove PAS fluid reservoir.
20. RH side: Remove RH front brake pipe.
21. RH side: Remove windscreen washer
reservoir.

+ WIPERS AND WASHERS, REPAIRS,
Reservoir - washer.
22. RH side: Remove PAS fluid cooler.

+ STEERING, REPAIRS, Oil cooler -
Td4 & K1.8 models.Repair
1.Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.

PANEL REPAIRS
77-2-38 REPAIRS
Refit
1. LH side: Fit LH front brake pipe. Bleed brake
system.

+ BRAKES, ADJUSTMENTS, Brake
bleed.
2. LH side: Fit engine compartment fuse box and
related wiring.
3. LH side: Fit battery carrier. Do not connect
battery earth lead.

+ CHARGING AND STARTING,
REPAIRS, Carrier - battery.
4. LH side: Fit ECM.
5. LH side: Fit air intake hose.
6. LH side: Fit air cleaner.
7. RH side: Fit PAS fluid cooler.

+ STEERING, REPAIRS, Oil cooler -
Td4 & K1.8 models.
8. RH side: Fit windscreen washer reservoir.

+ WIPERS AND WASHERS, REPAIRS,
Reservoir - washer.
9. RH side: Fit RH front brake pipe. Bleed brake
system.

+ BRAKES, ADJUSTMENTS, Brake
bleed.
10. RH side: Fit PAS fluid reservoir.
11.Fit headlamp.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
12.Secure headlamp wiring.
13.Fit PAS fluid cooler.

+ STEERING, REPAIRS, Oil cooler -
Td4 & K1.8 models.
14.Fit radiator.

+ COOLING SYSTEM - K SERIES KV6,
REPAIRS, Radiator assembly.
15.Fit front bumper support bracket.
16.Fit front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
17.Fit front wing.

+ EXTERIOR FITTINGS, REPAIRS,
Wing - front.
18.Fit front wheel arch liner.

+ EXTERIOR FITTINGS, REPAIRS,
Liner - front wheel arch.
19.Fit road wheel(s) and tighten nuts to 115 Nm
(85 lbf.ft).
20.Connect all ECUs.
21.Connect alternator.
22.Connect battery earth lead.

PANEL REPAIRS
REPAIRS 77-2-39
Valance outer reinforcement
Remove
1.Disconnect battery earth lead.
2.Disconnect alternator.
3.Disconnect all ECUs.
4.Remove road wheel(s).
5.Remove front wheel arch liner.

+ EXTERIOR FITTINGS, REPAIRS,
Liner - front wheel arch.
6.Remove front wing.

+ EXTERIOR FITTINGS, REPAIRS,
Wing - front.
7.Remove front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
8.Remove headlamp.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
9.Release wiring from valance and position
aside.
10. LH side: Remove battery.

+ CHARGING AND STARTING,
REPAIRS, Battery.
11. LH side: Remove ECM.
12. LH side: Remove relay module.
13. LH side: Remove battery carrier.

+ CHARGING AND STARTING,
REPAIRS, Carrier - battery.
14. LH side: Remove engine compartment fuse
box and related wiring.
15. RH side: Remove PAS fluid reservoir.
16. RH side: Remove brake pipes from valance. Repair
1.Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.
Refit
1. LH side: Fit engine compartment fuse box and
related wiring.
2. LH side: Fit battery carrier.

+ CHARGING AND STARTING,
REPAIRS, Carrier - battery.
3. LH side: Fit relay module.
4. LH side: Fit ECM.
5. LH side: Fit battery. Do not connect earth lead.

+ CHARGING AND STARTING,
REPAIRS, Battery.
6. RH side: Fit PAS fluid reservoir.
7. RH side: Fit brake pipes to valance. Bleed
brakes.

+ BRAKES, ADJUSTMENTS, Brake
bleed.
8.Secure wiring to valance.
9.Fit headlamp.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
10.Fit front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
11.Fit front wing.

+ EXTERIOR FITTINGS, REPAIRS,
Wing - front.
12.Fit front wheel arch liner.

+ EXTERIOR FITTINGS, REPAIRS,
Liner - front wheel arch.
13.Fit road wheel(s) and tighten nuts to 115 Nm
(85 lbf.ft).
14.Connect all ECUs.
15.Connect alternator.
16.Connect battery earth lead.
