CONTROL UNITS
REPAIRS 86-3-1
CONTROL UNITS REPAIRS
Control unit - window lift
$% 86.25.39
Remove
1.Remove driver's side fuse box.

+ HARNESSES, REPAIRS, Fuse box -
passenger compartment.
2.Remove 2 nuts securing window lift control unit
and release unit from studs.
3.Disconnect multiplug from window lift control
unit and remove unit from vehicle.
Refit
1.Connect multiplug to window lift control unit.
2.Position unit and secure with 2 nuts.
3.Fit fuse box.

+ HARNESSES, REPAIRS, Fuse box -
passenger compartment.
Relay - power folding mirrors - from
02MY
$% 86.55.13
CAUTION: If the power fold mirrors are operated
consecutively more than three times, then they
will cease to function for a period of one minute.
This is to prevent damage to the power fold
mirror motors.
Remove
1.Remove passenger side tread strip.
2.Release power fold mirror relay from 'A' post.
3.Remove relay from harness block connector.
Refit
1.Fit relay to harness block connector.
2.Fit relay to securing clip.
3.Fit tread strip.

CONTROL UNITS
86-3-2 REPAIRS
Central Control Unit (CCU)
$% 86.55.75
Remove
1.Disconnect battery earth lead.
2.Open drivers glove box lid and remove fuse box
cover.
3.Remove bolt securing fuse box mounting plate
to steering column bracket.
4.Remove 2 bolts securing mounting plate to
body.
5.Remove 2 bolts securing fuse box to mounting
plate.
6.Disconnect 3 multiplugs from CCU in rear of
fuse box.

CONTROL UNITS
REPAIRS 86-3-3
7.Manoeuvre fuse box to gain access to CCU.
8.Release retaining clips and remove CCU.
Refit
1.Position CCU and secure in clips.
2.Align fuse box to mounting plate.
3.Connect multiplugs to CCU.
4.Fit bolts securing fuse box to mounting bracket
and tighten to 8 Nm (6 lbf.ft).
5.Position mounting plate and tighten bolts to 8
Nm (6 lbf.ft).
6.Fit fuse box cover.
7.Close glove box.
8.Connect battery earth lead.
Control Unit - power fold mirrors - up to
02MY
$% 86.54.30
CAUTION: If the power fold mirrors are operated
consecutively more than three times, then they
will cease to function for a period of one minute.
This is to prevent damage to the power fold
mirror motors.
Remove
1.Remove the front console.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Console - front - up to 04MY.
2.Release the two clips securing the power fold
mirror control unit.
3.Release the control unit from its mounting and
disconnect the multiplug.
4.Remove the control unit.
Refit
1.Locate the control unit in its mounting and
ensure the clips are fully engaged.
2.Connect the multiplug to the control unit.
3.Fit the front console.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Console - front - up to 04MY.
M86 5689

WINDOWS
REPAIRS 86-5-5
Relay - heated front screen
$% 86.55.18
Remove
1.Release heated front screen fuse holder from
heated front screen relay holder.
2.Release heated front screen relay holder from
'E' box bracket.3.Remove cover from heated front screen relay.
4.Remove heated front screen relay.
Refit
1.Fit heated front screen relay.
2.Ensure cover seal is fitted correctly and fit
heated front screen relay cover.
3.Fit heated front screen relay holder to 'E' box
bracket.
4.Fit heated front screen fuse holder to heated
front screen relay holder.

IN CAR ENTERTAINMENT
86-6-6 REPAIRS
Coaxial lead - front aerial - 3 door
$% 86.50.24
Remove
1.Remove aerial.

+ IN CAR ENTERTAINMENT,
REPAIRS, Aerial - manual - 3 door.
NOTE: Original coaxial lead cannot be
removed as it is part of the body harness.
2.Disconnect coaxial lead from link lead behind
fuse box.Refit
1.Position new coaxial lead to roof panel.
2.Align coaxial lead behind fascia and connect to
link lead.
3.Secure coaxial lead to harness with cable ties.
4.Fit aerial.

+ IN CAR ENTERTAINMENT,
REPAIRS, Aerial - manual - 3 door.

IN CAR ENTERTAINMENT
REPAIRS 86-6-7
Coaxial lead - front aerial - 5 door
$% 86.50.24
Remove
1.Remove aerial.

+ IN CAR ENTERTAINMENT,
REPAIRS, Aerial - manual - 5 door.
2.Remove 'A' post upper trim finisher.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim finisher - 'A' post - upper -
renew.
3.Remove sun visor.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Sun visor.
NOTE: Original coaxial lead cannot be
removed as it is part of the body harness.
4.Remove stud securing front edge of headlining.
5.Remove grab handle blanking plugs.6.Disconnect coaxial lead from link lead behind
fuse box.
Refit
1.Position new coaxial lead to roof panel.
2.Align coaxial lead behind fascia and connect to
link lead.
3.Secure coaxial lead to harness with cable ties.
4.Fit stud and grab handle blanking plugs to
headlining.
5.Fit 'A' post upper trim finisher.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim finisher - 'A' post - upper -
renew.
6.Fit sun visor.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Sun visor.
7.Fit aerial.

+ IN CAR ENTERTAINMENT,
REPAIRS, Aerial - manual - 5 door.

HARNESSES
REPAIRS 86-7-1
HARNESSES REPAIRS
Fuse box - passenger compartment
$% 86.70.01
Remove
1.Disconnect battery earth lead.
2.Open glove box.
3.Remove hinge pins and lid.
4.Remove fuse box cover.
5.Remove relays from fuse box mounting plate.
6.Remove bolt securing fuse box mounting plate
to steering column bracket.
7.Remove 2 bolts securing mounting plate to
body.
8.Remove 2 bolts securing fuse box to mounting
plate.
9.Disconnect 3 multiplugs from CCU in rear of
fuse box.
10.Release fusebox and disconnect 8 multiplugs.
11.Remove fusebox.
12.Remove fuses and relays from fuse box.Refit
1.Identify and fit fuses.
2.Fit relays.
3.Fit fuse box.
4.Connect multiplugs to fusebox.
5.Connect multiplugs to CCU.
6.Fit bolts securing fuse box to mounting plate
and tighten to 8 Nm (6 lbf.ft).
7.Fit bolts securing fuse box mounting plate to
body and tighten to 8 Nm (6 lbf.ft).
8.Fit relays to mounting plate.
9.Fit fuse box cover.
10.Fit glove box lid and hinge pins.
11.Close lid.
12.Connect battery earth lead.

HARNESSES
86-7-4 REPAIRS
33. Automatic gearbox only: Disconnect
multiplug from automatic gearbox ECU.
34.Disconnect 2 engine harness to main harness
multiplugs.
35.Disconnect 'E' box temperature sensor
multiplug.
36.Disconnect 'E' box cooling fan multiplug.
37.Remove fuse box cover.
38.Remove 2 bolts securing battery connections to
fuse box and disconnect multiplug from fuse
box.
39.Remove 3 nuts securing fuse box to brackets.40.Disconnect 6 multiplugs from the underside of
fusebox.
41.Disconnect multiplug from inertia switch.
42.Release 2 fixings securing harness to LH side
of engine bay.
43.Remove air intake plenum.

+ HEATING AND VENTILATION,
REPAIRS, Plenum - air intake.

HARNESSES
REPAIRS 86-7-5
44.Disconnect multiplug from wiper motor and pull
into engine bay.
45.With assistance pull main harness into vehicle
interior.
46.Remove 6 screws securing front mud flaps and
remove mud flaps.
47.Release rear edges of front wheel arch liners.48.Release side repeater lamps, disconnect
multiplugs and remove lamps.
49.Remove 3 bolts from passenger compartment
fuse box and pull fuse box forward.
50.Release and disconnect multiplug from RH 'A'
post.
51.Disconnect coaxial cable.
52.Release relays from fuse box bracket.

HARNESSES
86-7-6 REPAIRS
53.Release fuse box, disconnect 11 multiplugs
and remove fuse box.
54.Disconnect multiplug from steering column
switch.
55.Release harness clip from steering column.
56.Disconnect multiplug from throttle position
sensor.
57.Disconnect multiplugs from brake light switch
and brake pedal position switch.58.Disconnect multiplug from airbag ECU.
59.Remove airbag ECU securing bolt and release
earth lead.
60.Remove nut from earth header and release
header from floor tunnel.
