Lexus CT200h 2011 Owner's Manual (in English)

101
1
1-4. Adjustable components (seats, mirrors, steering wheel)
Before driving
CT200h_EE (OM76041E)
Head restraints
Head restraints are provided for all seats.
Front seats
Up
Pull the head restraints up.
Down
Push the head restraint down
while pushing the lock
release button.
Rear center seat
Up
Pull the head restraints up.
Down
Push the head restraint down
while pushing the lock
release button.
Rear outboard seats
Up
Pull the head restraints up.
Down
Push the head restraint down
while pushing the lock
release button.
Lock release
button
Lock release but-
Lock release but-

102
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_EE (OM76041E)
Removing the head restraints
Installing the head restraints
Adjusting the height of the head restraints (front seats)
Adjusting the rear seat head restraint
Always raise the head restraint one level from the stowed position when
using.
Pull the head restraint up while pressing
the lock release button.
Lock
release
button
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Lock
release
button
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.

103
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_EE (OM76041E)
CAUTION
Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
Use the head restraints designed for each respective seat.
Adjust the head restraints to the correct position at all times.
After adjusting the head restraints, push down on them and make sure
they are locked in position.
Do not drive with the head restraints removed.

104
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_EE (OM76041E)
Seat belts
Make sure that all occupants are wearing their seat belts before driving
the vehicle.
Correct use of the seat belts
Extend the shoulder belt so
that it comes fully over the
shoulder, but does not
come into contact with the
neck or slide off the shoul-
der.
Position the lap belt as low
as possible over the hips.
Adjust the position of the
seatback. Sit up straight
and well back in the seat.
Do not twist the seat belt.
Fastening and releasing the seat belt
To fasten the seat belt,
push the plate into the
buckle until a click sound
is heard.
To release the seat belt,
press the release button.
Rl b tt

105
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_EE (OM76041E)
Seat belt pretensioners (front seats)
The pretensioner helps the seat
belt to quickly restrain the
occupant by retracting the seat
belt when the vehicle is sub-
jected to certain types of severe
frontal collision.
The pretensioner may not acti-
vate in the event of a minor
frontal impact, a side impact, a
rear impact or a vehicle roll-
over.
Adjusting the seat belt shoulder anchor height (front seats)
Push the seat belt shoulder
anchor down while press-
ing the release button.
Push the seat belt shoulder
anchor up.
Move the height adjuster up
and down as needed until you
hear a click.

106
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_EE (OM76041E)
Pre-crash seat belts (front seats of vehicles with pre-crash safety
system)
If the pre-crash sensor detects that a collision is unavoidable, the
pre-crash safety system will retract the seat belt, thus enhancing
the effectiveness of the seat belt pretensioner in a crash.
The same will happen if the driver makes an emergency braking or
loses control of the vehicle. (P. 292)
After using the rear center seat belt
Store the buckle into the stor-
age location in the seat cushion.

107
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_EE (OM76041E)
Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may
also lock if you lean forward too quickly. A slow, easy motion will allow the
belt to extend so that you can move around fully.
Pregnant women
People suffering illness
Obtain medical advice and wear the seat belt in the proper way. (P. 104)
Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult
size.
Use a child restraint system appropriate for the child, until the child
becomes large enough to properly wear the vehicle’s seat belt. (P. 163)
When the child becomes large enough to properly wear the vehicle’s seat
belt, follow the instructions on P. 104 regarding seat belt usage.
Obtain medical advice and wear the seat
belt in the proper way. (P. 104)
Women who are pregnant should position
the lap belt as low as possible over the
hips in the same manner as other occu-
pants. Extend the shoulder belt com-
pletely over the shoulder and position the
belt across the chest. Avoid belt contact
over the rounding of the abdominal area.
If the seat belt is not worn properly, not
only the pregnant woman, but also the
fetus could suffer death or serious injury
as a result of sudden braking or a colli-
sion.

108
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_EE (OM76041E)
Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will acti-
vate for the first collision, but will not activate for the second or subsequent
collisions.
Seat belt regulations
If seat belt regulations exist in the country where you reside, please contact
any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional for seat belt replacement or installation.

109
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_EE (OM76041E)
CAUTION
Observe the following precautions to reduce the risk of injury in the event of
sudden braking, sudden swerving or an accident.
Failing to do so may cause death or serious injury.
Wearing a seat belt
Ensure that all passengers wear a seat belt.
Always wear a seat belt properly.
Each seat belt should be used by one person only. Do not use a seat belt
for more than one person at once, including children.
Lexus recommends that children be seated in the rear seat and always use
a seat belt and/or an appropriate child restraint system.
To achieve a proper seating position, do not recline the seat more than
necessary. The seat belt is most effective when the occupants are sitting up
straight and well back in the seats.
Do not wear the shoulder belt under your arm.
Always wear your seat belt low and snug across your hips.
When children are in the vehicle
Do not allow children to play with the seat belt. If the seat belt becomes
twisted around a child’s neck, it may lead to choking or other serious inju-
ries that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used
to cut the belt.
Seat belt pretensioners
If the pretensioner has activated, the SRS warning light will come on. In that
case, the seat belt cannot be used again and must be replaced at any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional.

110
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_EE (OM76041E)
CAUTION
Seat belt damage and wear
Do not damage the seat belts by allowing the belt, plate, or buckle to be
jammed in the door.
Inspect the seat belt system periodically. Check for cuts, fraying, and
loose parts. Do not use a damaged seat belt until it is replaced. Damaged
seat belts cannot protect an occupant from death or serious injury.
Ensure that the belt and plate are locked and the belt is not twisted.
If the seat belt does not function correctly, immediately contact any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional.
Replace the seat assembly, including the belts, if your vehicle has been
involved in a serious accident, even if there’s no obvious damage.
Do not attempt to install, remove, modify, disassemble or dispose of the
seat belts. Have any necessary repairs carried out by any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional.
Inappropriate handling of the pretensioner may prevent it from operating
properly, resulting in death or serious injury.
