Lexus CT200h 2011 Owner's Manual (in English)

411
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_EE (OM76041E)
Using the hands-free system (for cellular phone)
Audio unit
Type A
Display
A message, name, phone
number, etc. is displayed.
Lower-case characters
and special characters
cannot be displayed.
Displays information that
is too long to be displayed
at one time on the display
(press and hold)
Selects speed dials
Selects items such as menu
and number
Turn: Selects an item
Press: Inputs the selected
item
Bluetooth
® connection
condition
If “BT” is not displayed,
the hands-free system
cannot be used.
Reception level Type B

412
3-4. Using the hands-free phone system (for cellular phones)
CT200h_EE (OM76041E)
Steering wheel switches
Vo l u m e
The voice guidance volume
cannot be adjusted using this
button.
Off-hook switch
Turns the hands-free sys-
tem on/starts a call
On-hook switch
Turns the hands-free sys-
tem off/ends a call/refuses
a call
Ta l k s w i t c h
Turns the voice command
system on (press)/turns the
voice command system off
(press and hold)
Microphone

413
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_EE (OM76041E)
Using the hands-free phone system for the first time
Before using the hands-free phone system, it is necessary to regis-
ter a cellular phone in the system. The system will enter phone reg-
istration mode automatically when starting the system with no
cellular phone registered. Follow the procedure below to register
(pair) a cellular phone:
Press the off-hook switch and select “Pair phone” using
.
Select “Record Name” using , and say the name to
be registered after the beep.
The name to be registered will be repeated aloud.
Select “Confirm” using .
A passkey will be displayed.
Input the passkey into the cellular phone.
Refer to the manual that comes with the cellular phone for the
operation of the phone.
If the cellular phone has a Bluetooth® audio player, the audio
player can be registered at the same time.
When “Pair Audio?” is displayed, select “Yes” or “No”
using . (Bluetooth
® audio player P. 382)
STEP1
STEP2
STEP3
STEP4
STEP5

414
3-4. Using the hands-free phone system (for cellular phones)
CT200h_EE (OM76041E)
Menu list of the hands-free phone system
First menuSecond
menuThird menuOperation detail
“Callback”--
Dialing a number stored in
the incoming call history
memory
“Redial”--
Dialing a number stored in
the outgoing call history
memory
“Phone-
book”
“Add
Entry”-Adding a new phone num-
ber
“Change
Name”-Changing the registered
name in the phone book
“Delete
Entry”-Deleting the registered data
“Del Spd
Dial”-Deleting speed dials
“List
Names”-Listing the registered data
“Speed
Dial”-Setting speed dials

415
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_EE (OM76041E)
First menuSecond
menuThird menuOperation detail
“Setup”
“Security”
“Set PIN”Setting a PIN code
“Phbk Lock”Locking the phone book
“Phbk Unlock”Unlocking the phone book
“Phone
Setup”
“Pair Phone”Registering a cellular phone
“Select Phone”Selecting a cellular phone to
be used
“Change Name”Changing the registered
name of a cellular phone
“List Phones”Listing the registered cellu-
lar phones
“Set Passkey”Changing the passkey
“Delete Phone”Deleting a registered cellu-
lar phone
“System
Setup”
“Guidance Vol”Setting voice guidance vol-
ume
“Device Name”Displaying the Bluetooth®
device address and name
“Initialize”Initializing the system

416
3-4. Using the hands-free phone system (for cellular phones)
CT200h_EE (OM76041E)
Automatic volume adjustment
When vehicle speed reaches 80 km/h (50 mph) or more, the volume auto-
matically increases. The volume returns to the previous volume setting
when vehicle speed drops to 70 km/h (43 mph) or less.
Operations that cannot be performed while driving
Operating the system with
Registering a cellular phone to the system
Changing the passkey
P. 4 2 4

417
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_EE (OM76041E)
Making a phone call
Making a phone call
Dialing by inputting a name
“Dial by name”
Speed dialing
Dialing a number stored in the outgoing history memory
“Redial”
Dialing a number stored in the incoming history memory
“Call back”
Receiving a phone call
Answering the phone
Refusing the call
Transferring a call
Using the call history memory
Dialing
Storing data in the phone book
Deleting

418
3-4. Using the hands-free phone system (for cellular phones)
CT200h_EE (OM76041E)
Dialing by inputting a name
Press the talk switch and say a registered name.
The desired name or number is displayed.
Dial by one of the following methods:
a.Press the off-hook switch.
b.Select “Dial” using .
In , if the pronounced name cannot be recognized, select
the desired name using .
Speed dialing
Press the off-hook switch.
Press the preset button in which the desired number is regis-
tered.
Press the off-hook switch.
When receiving a phone call
Answering the phone
Press the off-hook switch.
Refusing the call
Press the on-hook switch.
STEP1
STEP2
STEP1
STEP1
STEP2
STEP3

419
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_EE (OM76041E)
Transferring a call
A call can be transferred between the cellular phone and system
while dialing, receiving a call, or during a call. Use one of the fol-
lowing methods:
a. Operate the cellular phone.
Refer to the manual that comes with the cellular phone for the oper-
ation of the phone.
b. Press the off-hook switch*.
*: This operation can be performed only when transferring a call
from the cellular phone to the system during a call.

420
3-4. Using the hands-free phone system (for cellular phones)
CT200h_EE (OM76041E)
Using a call history memory
Follow the procedure below to use number stored in call history
memory:
Press the off-hook switch and select “Redial” (when using a
number stored in the outgoing call history memory) or
“Call back” (when using a number stored in the incoming
call history memory) using .
Select the desired number using .
The following operations can be performed:
Dialing: Press the off-hook switch or select “Dial” using
.
Storing the number in the phone book: Select “Store” and then
“Confirm” using .
Deleting: Select “Delete” and then “Confirm” using .
STEP1
STEP2
STEP3
