2-4. Using other driving systems
2
When driving
CT200h_EE (OM76041E)
Lexus parking assist-sensor

: If equipped
The distance from your vehicle to nearby obstacles when parallel
parking or maneuvering into a garage is measured by the sensors and
communicated via the multi-information display, touch screen and a
buzzer. Always check the surrounding area when using this system.
Types of sensors
Front corner sensors
Rear corner sensors
Rear center sensors
Lexus parking assist-sensor switch
Turns the Lexus parking
assist-sensor on/off
When on, the indicator light
comes on to inform the driver
that the system is operational.

270
2-4. Using other driving systems
CT200h_EE (OM76041E)
Display
When the sensors detect an obstacle, a graphic is shown on the
multi information display depending on the position and distance
to the obstacle.
Multi-information display
Front corner sensor operation
Rear corner sensor operation
Rear center sensor operation
Touch screen
When the vehicle is moving
forward
A graphic is automatically dis-
played when an obstacle is
detected. The screen can be set
so that the graphic is not dis-
played. Refer to the “Naviga-
tion System Owner’s Manual”.
When the vehicle is moving
backward
A simplified image is displayed
on the right upper corner of the
touch screen when an obstacle
is detected.

271
2-4. Using other driving systems
2
When driving
CT200h_EE (OM76041E)
The distance display and buzzer
When a sensor detects an obstacle, the direction of and the approx-
imate distance to the obstacle are displayed and the buzzer sounds.
Distance display
Corner sensors
The system operates when the vehicle approaches within
approximately 50 cm (1.6 ft.) of an obstacle.
Approximately 37.5 cm (1.2
ft.) to 50 cm (1.6 ft.) from the
obstacle
Approximately 25 cm (0.8
ft.) to 37.5 cm (1.2 ft.) from
the obstacle
Flashing: Within 25 cm (0.8
ft.) of the obstacle
Rear center sensors
The system operates when the vehicle approaches within
approximately 150 cm (4.9 ft.) of an obstacle.
Approximately 60 cm (2.0
ft.) to 150 cm (4.9 ft.) from
the obstacle
Approximately 45 cm (1.5
ft.) to 60 cm (2.0 ft.) from the
obstacle
Approximately 35 cm (1.1
ft.) to 45 cm (1.5 ft.) from the
obstacle
Flashing: Within 35 cm (1.1
ft.) of the obstacle

274
2-4. Using other driving systems
CT200h_EE (OM76041E)
If the display flashes and a message is displayed
P. 5 6 5
Customization
Settings (e.g. buzzer volume) can be changed. (Customizable features P.
655)
CAUTION
Caution when using the Lexus parking assist-sensor
Observe the following precautions.
Failure to do so may result in the vehicle being unable to be driven safely
and possibly cause an accident.
Do not use the sensor at speeds in excess of 10 km/h (6 mph).
Do not attach any accessories within the sensor range.
NOTICE
Notes when washing the vehicle
Do not apply intensive bursts of water or steam to the sensor area.
Doing so may result in the sensor malfunctioning.

275
2-4. Using other driving systems
2
When driving
CT200h_EE (OM76041E)
Rear view monitor system
: If equipped
The rear view monitor system assists the driver by displaying an
image of the view behind the vehicle while reversing. The image is
displayed in reverse on the screen. This allows the image to appear in
the same manner as that of the rear view mirror.
The rear view image is dis-
played when the shift posi-
tion is in R and the
“POWER” switch is in ON
mode.
This reversed image is a sim-
ilar image to the one on the
inside rear view mirror.
If you shift the shift position
to any positions other than R,

276
2-4. Using other driving systems
CT200h_EE (OM76041E)
Switching the screen
When using the rear view monitor system
The anti-glare function of the inside rear view mirror will be canceled.
Automatic shut off
The display will be turned off automatically after 5 minutes.
Display mode
The rear view monitor display mode can be adjusted when the “POWER”
switch is in ON mode and the shift position is in R.
To permanently disable the monitor.
Push and hold the “AUTO” button for 12 to 15 seconds.
The monitor will turn off and on after 6 seconds. Continue holding the
button down until the display turns back off.
The indicator should flash orange.
The monitor will not automatically turn on again after the “POWER”
switch is turned OFF and ON.
To manually turn on the monitor when it is turned off.
Push the “AUTO” button. The indicator should turn green.
To temporarily turn off the monitor
when it is on.
Push the “AUTO” button. The indica-
tor should turn orange.
The monitor will automatically turn on
again after the “POWER” switch is
turned OFF and ON.
To manually turn on the monitor when
it is turned off.
Push the “AUTO” button. The indica-
tor should turn green.

277
2-4. Using other driving systems
2
When driving
CT200h_EE (OM76041E)
Displayed area
The area covered by the camera is lim-
ited. Objects which are close to either
corner of the bumper or under the bumper
cannot be seen on the screen.
The area displayed on the screen may
vary according to vehicle orientation or
road conditions.
Corners of

278
2-4. Using other driving systems
CT200h_EE (OM76041E)
Rear view monitor guide lines
Guide lines are displayed on the screen.
Guide lines shown differ from those shown on the actual screen.
Vehicle width extension guide lines (blue)
These lines indicate the estimated vehicle width extension.
Distance guide line (blue)
This line indicates a position on the ground about 1 m (3 ft.) behind on
the ground of the rear bumper of your vehicle.
Distance guide line (red)
This line indicates a position on the ground about 0.5 m (1.5 ft.) behind
on the ground of the rear bumper of your vehicle.
Vehicle center guide lines (blue)
These lines indicate the estimated vehicle center on the ground.

284
2-4. Using other driving systems
CT200h_EE (OM76041E)
CAUTION
Conditions which may affect the rear view monitor system
If the back of the vehicle has been hit, the camera’s position and mounting
angle may have been changed. Have the vehicle inspected by any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional.
Rapid temperature changes, such as when hot water is poured on the vehi-
cle in cold weather, may cause the system to function abnormally.
If the camera lens is dirty, it cannot transmit a clear image. Rinse with
water and wipe with a soft cloth. If the camera lens is extremely dirty,
wash with a mild cleanser and rinse.
The displayed image may be darker and moving images may be slightly
distorted when the system is cold.
When washing the vehicle, do not apply intensive bursts of water to the
camera or camera area. Doing so may result in the camera malfunctioning.
Do not allow organic solvent, car wax, window cleaner or glass coat to
adhere to the camera. If this happens, wipe it off as soon as possible.
As the camera has a water proof construction, do not detach, disassemble
or modify it. This may cause incorrect operation.
Do not hit the camera or subject it to strong impacts as this may cause its
position and mounting angle to change.
Do not scrub the camera lens roughly or clean it with a hard brush or abra-
sive cleaner. Doing so may damage the lens and adversely affect the
image.

292
2-4. Using other driving systems
CT200h_EE (OM76041E)
PCS (Pre-Crash Safety system)

: If equipped
When the radar sensor detects possibility of a frontal collision, the pre-
crash safety system such as the brakes and seat belts are automatically
engaged to lessen impact to occupants as well as vehicle damage.
Pre-crash seat belts (front seat belts only)
If the pre-crash sensor detects that a collision is unavoidable, the
pre-crash safety system will retract the seat belt before the collision
occurs.
The same will happen if the driver makes an emergency braking or
loses control of the vehicle. (P. 106)
However, when the VSC system is disabled, the system will not
operate in the event of skidding.
Pre-crash brake assist
When there is a high possibility of a frontal collision, the system
applies greater braking force in relation to how strongly the brake
pedal is depressed.
Pre-crash braking
When there is a high possibility of a frontal collision, the system
warns the driver using a warning light, warning display and buzzer.
If the system determines that a collision is unavoidable, the brakes
are automatically applied to reduce the collision speed. Pre-crash
b ki b di bl d i h h b ki ff i h
