steering Lexus CT200h 2012 Navigation Manual (in English)

1
2
3
4
5
6
7
9
CT200h_Navi_OM76078E_(EE)
14.02.06 12:29
8
9
10
1. TELEPHONE OPERATION ............. 170
QUICK REFERENCE ......................... 170
TELEPHONE (HANDS-FREE SYSTEM
FOR CELLULAR PHONE) ............. 172
REGISTER A Bluetooth
® PHONE ..... 176
CALL ON THE Bluetooth® PHONE .. 181
RECEIVE ON THE Bluetooth®
PHONE ............................................. 188
TALK ON THE Bluetooth
® PHONE.. 189
Bluetooth® PHONE MESSAGE
FUNCTION....................................... 192
2. SETUP ............................................... 195
TELEPHONE SETTINGS .................. 195
Bluetooth® SETTINGS ....................... 218
1. AUDIO/VIDEO SYSTEM
OPERATION ................................... 232
QUICK REFERENCE ......................... 232
SOME BASICS ................................... 234
RADIO OPERATION ......................... 240
DVD PLAYER OPERATION ............ 246
USB MEMORY OPERATION ........... 268
iPod OPERATION .............................. 274
Bluetooth
® AUDIO OPERATION...... 279
AUDIO/VIDEO REMOTE
CONTROLS
(STEERING SWITCHES) ................ 288
AUDIO/VIDEO SYSTEM
OPERATING HINTS ....................... 290
2. SETUP ............................................... 299
AUDIO SETTINGS ............................ 299
1. AIR CONDITIONING SYSTEM
OPERATION .................................. 306
QUICK REFERENCE .........................306
SOME BASICS ...................................308
AUTOMATIC AIR CONDITIONING
SYSTEM ...........................................309
1. SPEECH COMMAND SYSTEM
OPERATION .................................. 322
SPEECH COMMAND SYSTEM........322
COMMAND LIST ...............................328
1. INFORMATION DISPLAY ............. 332
TRAFFIC .............................................332
2. SETUP ............................................... 338
TRAFFIC AND PARKING
SETTINGS ........................................338
1. CONNECTED SERVICES ............... 344
CONNECTED SERVICES
OVERVIEW......................................344
SETTINGS REQUIRED FOR USING
THE SERVICE..................................347
USING CONNECTED SERVICES ....353
2. SETUP ............................................... 363
ONLINE SEARCH SETTINGS ..........363
4TELEPHONE
5AUDIO/VIDEO SYSTEM
6AIR CONDITIONING
7SPEECH COMMAND
8INFORMATION
9CONNECTED SERVICES

169
1
2
3
4
5
6
7
4
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
8
9
10
1. QUICK REFERENCE ..................... 170
2. TELEPHONE (HANDS-FREE
SYSTEM FOR CELLULAR
PHONE)......................................... 172
USING THE TELEPHONE SWITCH .. 174
USING THE STEERING SWITCHES . 175
ABOUT THE PHONEBOOK IN THIS
SYSTEM ............................................. 175
WHEN SELLING OR DISPOSING OF
THE VEHICLE ................................... 175
3. REGISTER A Bluetooth® PHONE . 176
CONNECTING A Bluetooth®
PHONE ................................................ 178
RECONNECTING THE Bluetooth
®
PHONE ................................................ 180
4. CALL ON THE Bluetooth®
PHONE .......................................... 181
BY DIAL ................................................ 181
BY PHONEBOOK................................. 181
BY SPEED DIAL .................................. 183
BY CALL HISTORY ............................ 184
BY VOICE RECOGNITION................. 185
CALLING USING AN SMS/MMS
MESSAGE .......................................... 187
BY POI* CALL ..................................... 187
5. RECEIVE ON THE Bluetooth®
PHONE ......................................... 188
6. TALK ON THE Bluetooth
®
PHONE ......................................... 189
WHEN YOU SELECT “0-9” ................. 189
INCOMING CALL WAITING .............. 191
7. Bluetooth® PHONE MESSAGE
FUNCTION................................... 192
CHECKING MESSAGES ...................... 192
REPLYING (QUICK REPLY)............... 193
NEW MESSAGE NOTIFICATION ...... 194
1. TELEPHONE SETTINGS .............. 195
TELEPHONE SOUND SETTINGS....... 195
PHONEBOOK ........................................ 197
MESSAGE SETTINGS .......................... 211
TELEPHONE DISPLAY SETTINGS.... 215
2. Bluetooth® SETTINGS ................... 218
REGISTERED DEVICES ...................... 219
SELECTING A Bluetooth® PHONE ..... 223
SELECTING PORTABLE PLAYER .... 224
DETAILED Bluetooth
® SETTINGS...... 226
1TELEPHONE OPERATION
2SETUP
TELEPHONE
For vehicles sold outside Europe, some of the functions cannot be operated while
driving.

170
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
1. TELEPHONE OPERATION
1. QUICK REFERENCE
Bluetooth® phones can be operated via the navigation system’s screen. To dis-
play the hands-free operation screen, press the “MENU” button on the Remote
Touch and then select “Telephone”, or the switch on the steering wheel.

172
1. TELEPHONE OPERATION
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
2. TELEPHONE (HANDS-FREE SYSTEM FOR CELLULAR PHONE)
The hands-free system enables calls
to be made and received without
having to take your hands off the
steering wheel.
This system supports Bluetooth
®.
Bluetooth® is a wireless data system
that enables cellular phones to be
used without being connected by a
cable or placed in a cradle.
The operating procedure of the tele-
phone is explained here.
For registering and setting of the tele-
phone, see “TELEPHONE SET-
TINGS” on page 195 and
“Bluetooth
® SETTINGS” on page
218.
CAUTION
Use a cellular phone or connect the
Bluetooth® phone only when safe and
legal to do so.
An antenna for the Bluetooth® con-
nection is built in the instrument
panel. People with implanted pace-
makers or cardiac defibrillators
should maintain a reasonable distance
between themselves and the
Bluetooth
® antennas. The radio
waves may affect the operation of
such devices.
Before using cellular phones, users of
any electrical medical device other
than implanted pacemakers and
implanted cardiac defibrillators
should consult the manufacturer of
the device for information about its
operation under the influence of radio
waves. Radio waves could have unex-
pected effects on the operation of
such medical devices.
NOTICE
Do not leave your cellular phone in
the vehicle. The temperature inside
may rise to a level that could damage
the telephone.

174
1. TELEPHONE OPERATION
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
The microphone can be used when
talking on the telephone.
USING THE TELEPHONE
SWITCH
By pressing the telephone switch, a
call can be received or ended without
taking your hands off the steering
wheel.
INFORMATION
The other party’s voice will be heard
from the front speakers. The audio/
video system will be muted during
telephone calls or when hands-free
speech commands are used.
Talk alternately with the other party
on the telephone. If both parties speak
at the same time, the other party may
not hear what has been said. (This is
not a malfunction.)
Keep call volume down. Otherwise,
the other party’s voice may be audible
outside the vehicle and voice echo
may increase. When talking on the
telephone, speak clearly towards the
microphone.
The other party may not hear you
clearly when:
• Driving on an unpaved road. (Mak-
ing excessive traffic noise.)
• Driving at high speeds.
• The roof or windows are open.
• The air conditioning vents are
pointed towards the microphone.
• The sound of the air-conditioning
fan is loud.
• There is a negative effect on sound
quality due to the telephone and/or
network being used.

175
1. TELEPHONE OPERATION
4
TELEPHONE
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
Volume control switch
Press the “+” side to increase the vol-
ume.
Press the “-” side to decrease the vol-
ume.
The following data is stored for every
registered telephone. When another
telephone is connected, the following
registered data cannot be read:
• Phonebook data
• Call history data
• Speed dial data
• Image data
• All telephone settings
• Message settingsThe following data in the system can be
initialized:
• Phonebook data
• Call history data
• Speed dial data
• Image data
• All telephone settings
• Message settings
USING THE STEERING
SWITCHES
ABOUT THE PHONEBOOK
IN THIS SYSTEM
INFORMATION
When a telephone’s registration is
deleted, the above-mentioned data is
also deleted.
WHEN SELLING OR
DISPOSING OF THE
VEHICLE
A lot of personal data is registered
when the hands-free system is used.
When selling or disposing of the ve-
hicle, initialize the data. (See “DE-
LETING PERSONAL DATA” on
page 72.)
INFORMATION
Once initialized, the data and settings
will be erased. Pay much attention
when initializing the data.

176
1. TELEPHONE OPERATION
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
3. REGISTER A Bluetooth® PHONE
1Press the “MENU” button on the
Remote Touch.
2Select “Telephone”.
The “Telephone” screen can be dis-
played by pressing
on the steering
wheel.
3Select “Yes” to register a telephone.
If 5 Bluetooth® devices have already
been registered, a registered device
needs to be deleted. See “When 5
Bluetooth
® devices have already been
registered” on page 178.
4When this screen is displayed, oper-
ate the Bluetooth
® device.
Search for the navigation system dis-
played on the system’s screen using
your Bluetooth
® device, and register
the Bluetooth® device.
For details about operating the
Bluetooth
® device, see the manual that
comes with it.
To use the hands-free system, it is
necessary to register a telephone
with the system. Once the telephone
has been registered, it is possible to
make a hands-free call.
If a Bluetooth
® phone has not been
registered yet, it is necessary to reg-
ister it first according to the follow-
ing procedure.
See “REGISTERING A Bluetooth®
DEVICE” on page 219 of additional
registration when registering.

179
1. TELEPHONE OPERATION
4
TELEPHONE
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
When the “POWER” switch is in
ACCESSORY or ON mode, the system
searches for a nearby registered cellular
phone.
The system will connect with the tele-
phone that was last connected, if it is
nearby.
When “Display telephone status” is set
to “On”, the connection status is dis-
played. (See “Bluetooth
® DEVICE
CONNECTION STATUS DISPLAY
SETTINGS” on page 229.)
This screen appears when the
Bluetooth
® phone is first connected
after the “POWER” switch is in
ACCESSORY or ON mode.
1Press the “MENU” button on the
Remote Touch, then select
“Telephone”.
The “Telephone” screen can be dis-
played by pressing
on the steering
wheel.
2Select “Connect telephone”.
3Select the screen button correspond-
ing to the desired telephone connec-
tion.
When the cellular phone’s device name
has not been able to be obtained,
“Device 1” to “Device 5” will be dis-
played in the order the telephones were
registered.
*:Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
INFORMATION
It may take time if the telephone con-
nection is carried out during
Bluetooth
® device playback.
Depending on the type of Bluetooth®
phone being connected, it may be
necessary to perform additional steps
on the telephone.
MANUALLY
When the auto connection has failed
or “Bluetooth* power” is turned off,
it is necessary to connect Bluetooth
®
manually.

181
1. TELEPHONE OPERATION
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
4
TELEPHONE
4. CALL ON THE Bluetooth® PHONE
1Press the “MENU” button on the
Remote Touch. (See “Remote
Touch” on page 12.)
2Select “Telephone” on the “Menu”
screen.
The “Telephone” screen can be dis-
played by pressing
on the steering
wheel.
3Select the desired keys to input the
telephone number.
Each time is selected, an input
digit is deleted.
4Select or press the switch
on the steering wheel.
Depending on the type of Bluetooth®
phone being connected, it may be nec-
essary to perform additional steps on
the telephone.
1Select “Contacts”.
2Select the desired data from the list.
“1/3”, “2/3”, “3/3”: Select this
screen button to change between Latin,
Cyrillic and Greek characters.
After a Bluetooth® phone has been
registered, a call can be made using
the hands-free system. There are 7
methods by which a call can be
made. These are described below.
BY DIAL
A call can be made by inputting the
telephone number.
BY PHONEBOOK
Calls can be made by using the
phonebook data which is transferred
from the registered cellular phone.
The phonebook changes depending
on the telephone connected. Up to
1000 contacts (maximum of 3 num-
bers per contact) can be registered in
each phonebook.

182
1. TELEPHONE OPERATION
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
3Select the desired number from the
list.
4Select or press the switch
on the steering wheel.
1Select “Contacts”.
2Select “Yes” or “Transfer” to auto-
matically transfer the phonebook
from the connected telephone.
Select “Manual” to transfer the phone-
book manually. (See “TRANSFER-
RING A TELEPHONE NUMBER” on
page 198.)
Select “No” or “Cancel” to cancel
transferring.
If your cellular phone is neither PBAP
nor OPP compatible, the phonebook
cannot be transferred.
PBAP compatible models
PBAP incompatible but OPP compat-
ible models
3Transfer the phonebook data to the
system using a Bluetooth® phone.
Depending on the type of cellular
phone, OBEX authentication may be
required when transferring phonebook
data. Enter “1234” into the Bluetooth
®
phone.
This screen appears while transferring.
To cancel this function, select “Can-
cel”.
WHEN THE PHONEBOOK IS
EMPTY
