Lexus CT200h 2012 Owner's Manual (in English)
Manufacturer: LEXUS, Model Year: 2012, Model line: CT200h, Model: Lexus CT200h 2012Pages: 710
Page 661 of 710
659
6-1. Specifications
6
Vehicle specifica-
CT200h_OM_OM76067E_(EE)
Transmission
*: The fluid capacity is the quantity of reference.
If replacement is necessary, contact any authorized any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional.
Fluid capacity*3.4L (3.6 qt., 3.0 Imp.qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
Transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of your transmission accompanied
by vibration, and ultimately damage the transmission of your vehicle.
Page 662 of 710
660
6-1. Specifications
CT200h_OM_OM76067E_(EE)
Brakes
*1:Minimum pedal clearance when depressed with a force of 196 N
(20.0 kgf, 44.1 lbf) while the hybrid system is operating.
*2:Parking brake pedal travel when depressed with a force of 300 N (30.6
kgf, 67.5 lbf).
Steering
Pedal
clear-
ance
*1
Left-hand
drive vehicles
With an aluminum pedal
79 mm (3.11 in.) Min.
Without an aluminum pedal
77 mm (3.03 in.) Min.
Right-hand
drive vehicles
With an aluminum pedal
82 mm (3.23 in.) Min.
Without an aluminum pedal
80 mm (3.15 in.) Min.
Pedal free play1.0 6.0 mm (0.04 0.24 in.)
Parking brake pedal travel*28 11 clicks
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3
Free playLess than 30 mm (1.2 in.)
Page 663 of 710
661
6-1. Specifications
6
Vehicle specifica-
CT200h_OM_OM76067E_(EE)
Tires and wheels
Ty p e A
Ty p e B
Tire size215/45R17 87W
Tire inflation pressure
(Recommended cold tire
inflation pressure)Front tire
230 kPa (2.3 kgf/cm2 or bar, 33 psi)
Rear tire
220 kPa (2.2 kgf/cm2 or bar, 32 psi)
Wheel size17 7 J
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)
Tire size205/55R16 91V
Tire inflation pressure
(Recommended cold tire
inflation pressure)
More than
160 km/h
(100 mph)240 kPa (2.4 kgf/cm2 or bar,
35 psi)
160 km/h
(100 mph)
or less220 kPa (2.2 kgf/cm2 or bar,
32 psi)
Wheel size16 6J
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)
Page 664 of 710
662
6-1. Specifications
CT200h_OM_OM76067E_(EE)Ty p e C
Compact spare tire
Tire size195/65R15 91H
Tire inflation pressure
(Recommended cold tire
inflation pressure)
More than
160 km/h
(100 mph)250 kPa (2.5 kgf/cm2 or bar,
36 psi)
160 km/h
(100 mph) or
less
Normal pressure
230 kPa (2.3 kgf/cm2 or
bar, 33 psi)
ECO pressure
270 kPa (2.7 kgf/cm
2 or
bar, 39 psi)
Wheel size15 5 1/2J
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)
Tire sizeT125/70D17 98M
Spare tire inflation pressure
(Recommended cold tire infla-
tion pressure)
420 kPa (4.2 kgf/cm2 or bar, 60 psi)
Wheel size17 4 T
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)
Page 665 of 710
663
6-1. Specifications
6
Vehicle specifica-
CT200h_OM_OM76067E_(EE)
NOTICE
ECO pressure
For optimizing fuel economy, ECO tire pressure is recommended. Tire pres-
sure affects traveling comfort, road noise and steering characteristics.
Page 666 of 710
664
6-1. Specifications
CT200h_OM_OM76067E_(EE)
Light bulbs
A: H11 halogen bulbs
B: H9 halogen bulbs
C: Wedge base bulbs (clear)
D: Wedge base bulbs (amber)
E: Double end bulbs
*: If equipped
Light BulbsWTy p e
Exterior
Headlights
Low beam (halogen bulbs)
*
High beam
55
65A
B
Front fog lights*55A
Front turn signal lights21D
Rear turn signal lights21D
Back-up lights16C
Rear fog light21C
License plate lights5C
Interior
Front interior/personal lights5C
Rear interior light8E
Vanity lights8C
Luggage compartment light5E
Page 667 of 710
665
6-1. Specifications
6
Vehicle specifica-
CT200h_OM_OM76067E_(EE)
Fuel information
Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your Lexus has a fuel tank opening that
only accommodates the special nozzle on unleaded fuel pumps.
If your engine knocks
Consult any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
You may occasionally notice light knocking for a short time while
accelerating or driving uphill. This is normal and there is no need for
concern.
EU area:
Your vehicle must use only unleaded gasoline conforming to Euro-
pean standard EN228.
For optimum engine performance, select unleaded gasoline with a
Research Octane Number of 95 or higher.
Except EU area:
Your vehicle must use only unleaded gasoline.
For optimum engine performance, select unleaded gasoline with a
Research Octane Number of 95 or higher.
Page 668 of 710
666
6-1. Specifications
CT200h_OM_OM76067E_(EE)
NOTICE
Notice on fuel quality
Do not use improper fuels. If improper fuels are used the engine will be
damaged.
Do not use leaded gasoline.
Leaded gasoline will cause the three-way catalytic converter to lose its
effectiveness and emission control system to function improperly.
Gasoline engine (EU area): Bioethanol fuel sold under names such as
“E50” or “E85” and fuel containing a large amount of ethanol should not
be used. The use of these fuels will damage the vehicle’s fuel system. In
case of any doubt, ask any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional.
Gasoline engine (except EU area): Bioethanol fuel sold under names such
as “E50” or “E85” and fuel containing a large amount of ethanol should
not be used. Your vehicle can use gasoline mixed with 10% max ethanol.
The use of fuel with more than 10% ethanol content (E10) will damage
the vehicle’s fuel system. You must ensure that refueling is carried out
only from a source where fuel specification and quality can be guaranteed.
In case of any doubt, ask any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
Page 669 of 710
667
6
Vehicle specifica-
CT200h_OM_OM76067E_(EE)
6-2. Customization
Customizable features
Customizing vehicle features
It is possible to customize certain vehicle features using the
“DISP” switch.
When customizing vehicle features, ensure that the vehicle is
parked in a safe place with the shift position in P and the parking
brake set.
Press the “DISP” switch to dis-
play the “SETTINGS” screen
while the vehicle is stopped,
and then press and hold the
“DISP” switch to display the
customize mode screen.
Your vehicle includes a variety of electronic features that can be per-
sonalized to suit your preferences. Programming these preferences
requires specialized equipment and may be performed by any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped
professional.
It is also possible to customize certain vehicle features yourself using
the “DISP” switch and the navigation system screen.
For instructions on customizing vehicle features using the navigation
system screen, refer to the “Navigation System Owner’s Manual”.
Some function settings are changed simultaneously with other func-
tions being customized. Contact any authorized Lexus dealer or
STEP1
Page 670 of 710
668
6-2. Customization
CT200h_OM_OM76067E_(EE)Press the “DISP” switch and
select the “METER” or “VEHI-
CLE” and press and hold the
“DISP” switch.
Press the “DISP” switch and
select the item, and then press
and hold the “DISP” switch.
Press the “DISP” switch and
select the desired setting, and
then press and hold the “DISP”
switch.
To go back to the previous screen or exit the customize mode,
press the “DISP” switch to select the “EXIT”, and then press and
hold the “DISP” switch.
STEP2
STEP3
STEP4
