4476-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
6
Interior features
Switching between outside air and recirculated air modes
Press .
The mode switches between (recirculated air mode) and (out-
side air mode) modes each time the button is pressed.
Defogging the windshield
Defoggers are used to defog the windshield and front side windows.
Press .
Set to outside air mode if the recirculated air mode is used.
(It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.
To return to the previous mode, press again when the windshield is
defogged.
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window and to remove raindrops,
dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.
Pollen removal mode
Pollen is removed from the air and the air flows to the upper part of the
body.
Press or select on the operation screen.
When the pollen removal mode is on, is displayed on the air condi-
tioning control screen.
In order to prevent the windshield from fogging up when the outside air is
cold, the dehumidification function may operate.
The pollens are filtered out even if the pollen removal mode is turned off.
Other functions

4486-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the windshield
and wiper blades.
Select on the option control screen.
When the windshield wiper de-icer is on, is displayed on the air con-
ditioning control screen.
The windshield wiper de-icer will automatically turn off after a period of
time.
Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.
Adjusting the position of and opening and closing the air outlets
Direct air flow to the left or
right, up or down.
Turn the knob to open or close
the vent.
Air outlets
1
2

4496-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
6
Interior features
Registering air conditioning settings to electronic keys (vehicles with a smart
entry & start system)
Unlocking the vehicle using an electronic key and turning the power switch to
ON mode will recall that key’s registered air conditioning settings.
When the power switch is turned off, the current air conditioning settings will
automatically be registered to the electronic key that was used to unlock the
vehicle.
The system may not operate correctly if more than one electronic key is in the
vicinity or if the smart entry & start system is used to unlock a passenger door.
Settings for the electronic key and the corresponding door can be changed.
Contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and the
ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after the “AUTO” button is pressed or “AUTO” is selected.
Fogging up of the windows
The windows will easily fog up when the humidity in the vehicle is high. Press-
ing “A/C” button or selecting “A/C” will dehumidify the air from the outlets
and defog the windshield effectively.
If you turn “A/C” off, the windows may fog up more easily.
The windows may fog up if the recirculated air mode is used.
Windshield fog detection function (if equipped)
When automatic mode is set, the humidity sensor (P. 451) detects fog on the
windshield and controls the air conditioning system to prevent fog.
Outside/recirculated air mode
When driving on dusty roads such as tunnels or in heavy traffic, set
to the recirculated air mode. This is effective in preventing out-
side air from entering the vehicle interior. During cooling operation, setting the
recirculated air mode will also cool the vehicle interior effectively.
Outside/recirculated air mode may automatically switch depending on the tem-
perature setting or the inside temperature.

4506-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
When the outside temperature is low
The dehumidification function may not operate even when “A/C” is pressed or
“A/C” is selected.
Operation of the air conditioning system in Eco drive mode
In the Eco drive mode, the air conditioning system is controlled as follows to
prioritize fuel efficiency
• Engine speed and compressor operation controlled to restrict heating/cooling
capacity
• Fan speed restricted when automatic mode is selected
To improve air conditioning performance, perform the following operations
• Adjust the fan speed
• Turn off Eco drive mode
• Customize the air conditioning control of Eco drive mode. (P. 658)
Ventilation and air conditioning odors
To let fresh air in, set the air conditioning system to the outside air mode.
During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to be
emitted from the vents.
To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode
prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic mode.
Air conditioning filter
P. 527
Customization
Settings (e.g. A/C automatic mode switch operation) can be changed.
(Customizable features: P. 650)

4516-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
6
Interior features
WA R N I N G
To prevent the windshield from fogging up
Do not use during cool air operation in extremely humid weather. The
difference between the temperature of the outside air and that of the wind-
shield can cause the outer surface of the windshield to fog up, blocking your
vision.
To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on. (vehicles with wind-
shield wiper de-icer)
NOTICE
Humidity sensor (if equipped)
To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.
Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers from
defogging.
In order to detect fog on the windshield, a
sensor which monitors the temperature of
the windshield, the surround humidity, etc.
is installed. (P. 449)
Follow these points to avoid damaging the
sensor:
Do not disassemble the sensor
Do not spray the glass cleaner on the sen-
sor or subject it to strong impacts
Do not stick anything on the sensor

4526-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
Automatic air conditioning system (Vehicles without
a navigation system or Lexus Display Audio System)
Adjusting the temperature setting
Press to increase the temperature and to decrease the
temperature.
Adjusting the fan speed setting
Press to increase the fan speed and to decrease the
fan speed.
Press the “OFF” button to turn the fan off.
Air outlets and fan speed are automatically adjusted according to the
temperature setting.
The illustrations below are for left-hand drive vehicles.
The button positions and shapes will differ for right-hand drive vehicles.
Control panel

4536-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
6
Interior features
Change the airflow mode
To change the air outlets, press
.
The air outlets used are switched
each time the button is pressed.
Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and the
windshield defogger oper-
ates.
Using the automatic mode
Press the “AUTO” button.
Adjust the temperature setting.
To stop the operation, press the “OFF” button.
Automatic mode indicator
If the fan speed setting or air flow modes are operated, the automatic
mode indicator goes off. However, automatic mode for functions other
than that operated are maintained.
Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)
To turn on the “DUAL” mode, perform any of the following proce-
dures:
Press the “DUAL” button.
Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL” mode is on.
1
2
3
4
Air conditioning controls
1
2
3

4546-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
Switching between outside air and recirculated air modes
Press .
The mode switches between (recirculated air mode) and (out-
side air mode) modes each time the button is pressed.
Defogging the windshield
Defoggers are used to defog the windshield and front side windows.
Press .
Set to outside air mode if the recirculated air mode is used.
(It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.
To return to the previous mode, press again when the windshield is
defogged.
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window and to remove raindrops,
dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.
Pollen removal mode
Pollen is removed from the air and the air flows to the upper part of the
body.
Press .
In order to prevent the windshield from fogging up when the outside air is
cold, the dehumidification function may operate.
The pollens are filtered out even if the pollen removal mode is turned off.
Other functions

4556-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
6
Interior features
Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the windshield
and wiper blades.
Turns on/off.
The indicator comes on when the
windshield wiper de-icer is on.
The windshield wiper de-icer will
automatically turn off after a
period of time.
Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.
Adjusting the position of and opening and closing the air outlets
Direct air flow to the left or
right, up or down.
Turn the knob to open or close
the vent.
Air outlets
1
2

4566-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
Registering air conditioning settings to electronic keys (vehicles with a smart
entry & start system)
Unlocking the vehicle using an electronic key and turning the power switch to
ON mode will recall that key’s registered air conditioning settings.
When the power switch is turned off, the current air conditioning settings will
automatically be registered to the electronic key that was used to unlock the
vehicle.
The system may not operate correctly if more than one electronic key is in the
vicinity or if the smart entry & start system is used to unlock a passenger door.
Settings for the electronic key and the corresponding door can be changed.
Contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and the
ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after the “AUTO” button is pressed.
Fogging up of the windows
The windows will easily fog up when the humidity in the vehicle is high. Press-
ing “A/C” button on will dehumidify the air from the outlets and defog the
windshield effectively.
If you turn “A/C” off, the windows may fog up more easily.
The windows may fog up if the recirculated air mode is used.
Windshield fog detection function (if equipped)
When automatic mode is set, the humidity sensor (P. 458) detects fog on the
windshield and controls the air conditioning system to prevent fog.
Outside/recirculated air mode
When driving on dusty roads such as tunnels or in heavy traffic, set
to the recirculated air mode. This is effective in preventing out-
side air from entering the vehicle interior. During cooling operation, setting the
recirculated air mode will also cool the vehicle interior effectively.
Outside/recirculated air mode may automatically switch depending on the tem-
perature setting or the inside temperature.
