Lexus CT200h 2013 Owner's Manual (in English)

4676-3. Using the storage features
CT200h_OM_OM76102E_(EE)
6
Interior features
When storing a bottle, close the cap.
The bottle may not be stored depending on its size or shape.
The partition in the cup holder can also be
used to store a small cup or can.
WA R N I N G
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent burns.
NOTICE
Put the cap on before stowing a bottle. Do not place open bottles or glass and
paper cups containing liquid in the bottle holders.
The contents may spill and glasses may break.

4686-3. Using the storage features
CT200h_OM_OM76102E_(EE)
Auxiliary boxes
Ty p e ATy p e B
Press in the lid.
This box is useful for temporarily
storing sunglasses and similar small
items.
Type C (if equipped)Type D (if equipped)

4696-3. Using the storage features
CT200h_OM_OM76102E_(EE)
6
Interior features
Auxiliary box (type D)
If an object has fallen down the back of the
lid, the fallen object can be retrieved by
removing the cover inside the auxiliary box.
Remove the mat.
Remove the cover using a flathead screw-
driver protected with tape etc.
WA R N I N G
Do not store items heavier than 200 g (0.44 lb.).
Doing so may cause the auxiliary box to open and the items inside may fall out,
resulting in an accident. (type A)
NOTICE
Do not leave items in the auxiliary box or on the dashboard for long periods of
time when the vehicle is in the sun.
The inside of the auxiliary box and the dashboard will become extremely hot
compared to other parts of the vehicle, and the items could be deformed or
damaged. (type D)
1
2

4706-3. Using the storage features
CT200h_OM_OM76102E_(EE)
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
Secure the first-aid kit.
To loosen
To t i g h t e n
Cargo hooks
First-aid kit storage belt
1
2
Auxiliary boxes
Center Right side
Lift the center deck board. Lift the right side deck board.

4716-3. Using the storage features
CT200h_OM_OM76102E_(EE)
6
Interior features
Using the luggage cover
Pull out the luggage cover and
secure it to the hook brackets.
Removing the luggage cover
Retract the cover and release
both ends, then lift it out.
Left side (if equipped)
Lift the left side deck board.
Luggage cover (if equipped)

4726-3. Using the storage features
CT200h_OM_OM76102E_(EE)
Stowing the luggage cover
Remove the side deck boards
and open the center auxiliary
box.
Adjust the cover so that the
information label is facing up.
Fold the rear edge of the cover
over, replace the side deck
boards and close the center
auxiliary box.
1
2
3
WA R N I N G
To avoid injury, always return the cargo hooks to their stowed positions when
not in use.
If the deck boards are removed, return them to their original positions before
driving. In the event of sudden braking, an accident may occur due to an
occupant being struck by the deck boards or the items stored in the auxiliary
box.
Do not allow children to climb on the luggage cover. Climbing on the luggage
cover could result in damage to the luggage cover, possibly causing death or
serious injury to the child.

4736-4. Other interior features
CT200h_OM_OM76102E_(EE)
6
Interior features
Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
Slide the cover to open.
The light turns on when the cover is
opened.
If the vanity lights remain on when the power switch is turned off, the light will
go off automatically after 20 minutes.
Sun visors
1
2
Vanity mirrors
NOTICE
To prevent 12-volt battery discharge, do not leave the vanity lights on for
extended periods while the hybrid system is off.

474
CT200h_OM_OM76102E_(EE)6-4. Other interior features
Vehicles with a navigation system
Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
Vehicles without navigation system
The clock can be adjusted by pressing the buttons.
Adjusts the hours
Adjusts the minutes
Rounds to the nearest hour
*
*
: e.g. 1:00 to 1:291:00
1:30 to 1:592:00
The clock is displayed when the power switch is in ACCESSORY or ON mode.
Clock
1
2
3

4756-4. Other interior features
CT200h_OM_OM76102E_(EE)
6
Interior features
Please use a power supply for electronic goods that use less than 12 VDC
/10 A (power consumption of 120 W).
When using electronic goods, make sure that the power consumption of
all the connected power outlets is less than 120 W.
Center console
Press down and release the lid.
Open the cover.
Auxiliary box (if equipped)
Press the button.
Power outlet
1
2
1

476
CT200h_OM_OM76102E_(EE)6-4. Other interior features
Open the cover.
The power outlet can be used when the power switch is in ACCESSORY or ON
mode.
2
The gap in the lid allows power cables to
be passed through even when the lid is
closed. (auxiliary box)
NOTICE
To avoid damaging the power outlet, close the power outlet lid when the
power outlet is not in use.
Foreign objects or liquids that enter the power outlet may cause a short cir-
cuit.
To prevent 12-volt battery discharge, do not use the power outlet longer than
necessary when the hybrid system is off.
