Lexus CT200h 2013 Owner's Manual (in English)

4576-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
6
Interior features
When the outside temperature is low
The dehumidification function may not operate even when “A/C” is pressed.
Operation of the air conditioning system in Eco drive mode
In the Eco drive mode, the air conditioning system is controlled as follows to
prioritize fuel efficiency
• Engine speed and compressor operation controlled to restrict heating/cooling
capacity
• Fan speed restricted when automatic mode is selected
To improve air conditioning performance, perform the following operations
• Adjust the fan speed
• Turn off Eco drive mode
• Customize the air conditioning control of Eco drive mode. (P. 658)
Ventilation and air conditioning odors
To let fresh air in, set the air conditioning system to the outside air mode.
During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to be
emitted from the vents.
To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode
prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic mode.
Air conditioning filter
P. 527
Customization
Settings (e.g. A/C automatic mode switch operation) can be changed.
(Customizable features: P. 650)

4586-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
WA R N I N G
To prevent the windshield from fogging up
Do not use during cool air operation in extremely humid weather. The
difference between the temperature of the outside air and that of the wind-
shield can cause the outer surface of the windshield to fog up, blocking your
vision.
To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on. (vehicles with wind-
shield wiper de-icer)
NOTICE
Humidity sensor (if equipped)
To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.
Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers from
defogging.
In order to detect fog on the windshield, a
sensor which monitors the temperature of
the windshield, the surround humidity, etc.
is installed. (P. 456)
Follow these points to avoid damaging the
sensor:
Do not disassemble the sensor
Do not spray the glass cleaner on the sen-
sor or subject it to strong impacts
Do not stick anything on the sensor

459
6 6-1. Using the air conditioning system and defogger
Interior features
CT200h_OM_OM76102E_(EE)
Heated steering wheel/seat heaters

: If equipped
Heated steering wheel and seat heaters heat the side grips of the steering
wheel and seats, respectively.
WA R N I N G
Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically challenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs,
cold remedies, etc.)
Observe the following precautions to prevent minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat heater.
• Do not use seat heater more than necessary.
NOTICE
Do not put heavy objects that have an uneven surface on the seat and do not
stick sharp objects (needles, nails, etc.) into the seat.
To prevent 12-volt battery discharge, do not use the functions when the hybrid
system is off.

4606-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
Turns the heated steering wheel on/
off
The indicator light comes on when
the heated steering wheel is operat-
ing.
The heated steering wheel can be used when the power switch is in ON mode.
The heated steering wheel will automatically turn off after about 30 minutes.
Pops the knob out
Turns the seat heater on
The indicator light comes on.
Adjusts the seat temperature
The further you turn the knob clock-
wise, the warmer the seat becomes.
The seat heaters can be used when the power switch is in ON mode.
When not in use, turn the knob fully counterclockwise. The indicator light goes
off. Press the knob into the recessed position.
Heated steering wheel
Seat heaters
1
2
3

4616-2. Using the interior lights
CT200h_OM_OM76102E_(EE)
6
Interior features
Interior lights list
Outer foot lights
Cup holder light (when the power switch is in ACCESSORY or ON
mode)
Front personal/interior lights (P. 462)
Rear interior light (P. 462)
Footwell lights
When the instrument panel light control dial is turned fully down, the cup
holder light and the footwell lights will turn off. (P. 106)
1
2
3
4
5

4626-2. Using the interior lights
CT200h_OM_OM76102E_(EE)
Turns the lights off
Turns the door position on
Turns the lights on
Turns the lights on/off
Turns the light on
Turns the door position on
*
*
: When the personal/interior light
main switch is in the off position, the
rear interior light will not turn on
even if the door is opened with the
rear interior light switch in door
position.
Personal/interior light main switch
1
2
3
Front personal/interior lights
Rear interior light
1
2

4636-2. Using the interior lights
CT200h_OM_OM76102E_(EE)
6
Interior features
Illuminated entry system: The lights automatically turn on/off according to
power switch mode, the presence of the electronic key, whether the doors are
locked/unlocked, and whether the doors are opened/closed.
If the interior lights remain on when the power switch is turned off, the lights
will go off automatically after 20 minutes.
Settings (e.g. the time elapsed before the lights turn off) can be changed.
(Customizable features: P. 655)
NOTICE
To prevent 12-volt battery discharge, do not leave the lights on longer than nec-
essary when the hybrid system is off.

4646-3. Using the storage features
CT200h_OM_OM76102E_(EE)
List of storage features
Auxiliary boxes (P. 468)
Glove box (P. 465)
Bottle holders/door pockets
(P. 466)Console box (P. 465)
Cup holders (P. 466)1
2
3
4
5
WA R N I N G
Do not leave glasses, lighters or spray cans in the storage spaces, as this may
cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact with
other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
When driving or when the storage compartments are not in use, keep the lids
closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.

4656-3. Using the storage features
CT200h_OM_OM76102E_(EE)
6
Interior features
Open (press the button)
Lock with the mechanical key
Unlock with the mechanical key
Lift the lid while pushing the knob
to release the lock.
Glove box
1
2
3
Console box
The tray slides forward/backward and can
be removed.

4666-3. Using the storage features
CT200h_OM_OM76102E_(EE)
Cup holders
Bottle holders/door pockets
Cup holders/bottle holders/door pockets
