STARTING AND DRIVING
134
To allow proper operation of your vehicle's ventilation system, keep
the inlet grilles in front of the windshield clear of snow, leaves, or
other obstructions.
 If you smell exhaust fumes in the vehicle, drive with the windows
open and the trunk lid closed. Have the cause immediately located
and corrected.
BEFORE STARTING THE ENGINE
1. Check the area around the vehicle before entering it.
2. Adjust seat position, seatback angle, head restraint height and steering
wheel angle.
3. Adjust inside and outside rear view mirrors.
4. Lock all doors.
5. Fasten seat belts.
Remember to check that the service reminder indicators function when
turning the key to ºONº, and check the fuel gauge to see that you \
have
sufficient fuel.
IGNITION SWITCH WITH STEERING
LOCK
31E036
ºSTARTº ± Starter motor on. The key will return to the ºONº position
when released.
For starting tips, see page 136.
ºONº ± Engine on and all accessories on.
This is the normal driving position.
NOTICE
Do not leave the key in the ºONº position if the engine is not runni\
ng.
The battery will discharge and the electronic ignition system/distributo\
r
ignition system could be damaged.
ºACCº ± Accessories such as the radio operate, but the engine i\
s off.

MAINTENANCE
182
Tire rotation
Rotate the tires every 12000 km (7500 miles). See page 208 for additional
information.
Fluid leaks
Check underneath for leaking fuel, oil, water or other fluid after the vehicl\
e
has been parked for a while. If you smell fuel fumes or notice any leak, h\
ave
the cause found and corrected immediately.
Doors and engine hood
Check
that all doors, including trunk lid, operate smoothly and all latches lo\
ck
securely. Make sure the engine hood secondary latch secures the hood when
the primary latch is released.
Vehicle interior
Items listed below should be checked regularly, e.g. while performing
periodic services, cleaning the vehicle, etc.
Lights
Make sure the headlight, stop lights, tail lights, turn signal lights, and o\
ther
lights are working. Check headlight aim.
Service reminder indicators and warning buzzers
Check that all service reminder indicators and warning buzzers function
properly.
Steering wheel
Check that it has the specified freeplay. Be alert for changes in steering
condition, such as hard steering, excessive freeplay or strange noise.
Seats
Check that all front seat controls such as seat adjusters, seatback recliner, etc.
operate smoothly. Check that the head restraints move up and down smoothly
and that the locks hold securely in any latched position.
Seat belts
Check that the seat belt system such as buckles, retractors and anchors operat\
e
properly and smoothly. Make sure the belt webbing is not cut, frayed, worn
or damaged.

ENGINE
196
Gasolines containing MTBE
Gasolines that contain MTBE (Methyl Tertiary±Butyl Ether) are
available in the market. If you use a gasoline mixed with MTBE, make
certain that it does not contain more than 15% of MTBE.
If the use of gasolines containing MTBE causes poor drivability and/or p\
oor
fuel economy, you should stop using them.
Gasolines containing MMT
Some gasolines contain an octane±enhancing additive called MMT
(methylcyclopentadienyl manganese tricarbonyl).
Lexus does not recommend the use of gasolines that contain MMT. If fuels
containing MMT are used, your emission control system may be adversely
affected. The Malfunction Indicator Lamp on the instrument cluster may
come on. If this happens, contact your Lexus dealer for service.
Gasolines containing alcohol
Gasohol is a mixture of gasoline and ethanol. If you use gasohol in your
Lexus, be sure that it is unleaded, has an octane rating no lower than 87
and does not contain more than 10% ethanol. Lexus does not recommend
the use of gasolines containing methanol.
If you use gasoline containing methanol, use only gasoline meeting the
requirements above and also containing less than 5% methanol with
cosolvents and corrosion inhibitors for methanol.
NOTICE
 Do not use gasohol other than stated above. It will cause fuel system
damage or vehicle performance problems.
 If drivability problems are encountered (poor hot starting, vaporizing,
engine knock, etc.), discontinue its use.
 Take care not to spill gasohol during refueling. Gasohol may cause
paint damage.
Fuel tank capacity
70 L (18.5 gal., 15.4 lmp.gal.)
FACTS ABOUT ENGINE OIL
CONSUMPTION
Functions of engine oil
Engine oil has the primary function of lubricating and cooling the inside of th\
e
engine, and plays a major role in maintaining the engine in proper working
order.

ELECTRICAL COMPONENTS217
No.FUSEAMPERECIRCUIT
1 ABS60Anti±lock brake system
2 DRL NO.25Vehicles sold in Canada
Daytime Running Light System
3 H±LP
LH (LO)10Vehicles sold in Canada
Left±hand headlight (low beam)
4
H±LP
RH(LO)10Vehicles sold in Canada
Right±hand headlight (low beam)
4
A/F HTR25Vehicles sold in California
Air fuel ratio sensor
5 ALT100Charging system
6 CDS NO.230No circuit
7 HTR50Air conditioning system, Seat
heater
8 MAIN40Headlight, Starting system
9 DOME7.5
Theft deterrent system, Clock,
Door courtesy light, Interior light,
Ignition switch light, Vanity light,
Wireless remote control system
10 ECU±B10Cruise control system, Air
conditioning system, Power seat
system
11 RAD NO.120Audio system
12 HAZ10Emergency flashers, Turn signal
lights
13 AM230Starting system
No.FUSEAMPERECIRCUIT
14 TEL5Telephone
15
H±LP LH15Vehicles sold in the U.S.A.
Left±hand headlight (high beam)
15 H±LP
LH HI15Vehicles sold in Canada
Left±hand headlight (high beam)
16 ALT±S5Charging system
17
H±LP RH15Vehicles sold in the U.S.A.
Right±hand headlight (high beam)
17 H±LP RH HI15Vehicles sold in Canada
Right±hand headlight (high beam)
18 EFI15Multiport fuel injection
19 HORN10Theft deterrent system
20 RDI FAN30Electronic cooling fan system
21 CDS30Air conditioning system
22 A/C10No circuit
23 S±HTR20Seat heater system
24 HTR10Air conditioning system
25 GAUGE10
Gauges and meters, service reminder
indicators and warning buzzers, Back±up
light, Door courtesy light, Seat heater, Power
window system
26 WIP20Windshield wipers and washer
