LEXUS ES300 2005 Repair Manual
Manufacturer: LEXUS, Model Year: 2005, Model line: ES300, Model: LEXUS ES300 2005Pages: 969, PDF Size: 24.08 MB
Page 441 of 969
A78535
A78747
SST
Additional
3/4 Turn
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-65
2157 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
81. INSTALL WATER PUMP ASSY
(a) Install a new gasket and the water pump with the 3 bolts
and 3 nuts.
Torque: 8.0 NVm (82 kgfVcm, 71 in.Vlbf)
82. INSTALL OIL LEVEL GAGE GUIDE
(a) Apply a light coat of engine oil to a new O-ring, then install it to the level gage guide.
(b) Install the level gage guide.
Torque: 8.0 NVm (82 kgfVcm, 71 in.Vlbf)
83. INSTALL OIL FILTER SUB-ASSY
(a) Using a socket hexagon wrench 12, install the oil filter
union.
Torque: 30 NVm (306 kgfVcm, 22 ftVlbf)
(b) Check and clean the oil filter installation surface.
(c) Apply clean engine oil to the gasket of a new oil filter.
(d) Lightly screw the oil filter into place, then tighten it until the
gasket contacts the seat.
(e) Using SST, tighten it by an additional 3/4 turn.
SST 09228-07501
84. INSTALL TIMING BELT IDLER BRACKET
Torque: 28 NVm (286 kgfVcm, 21 ftVlbf)
85. INSTALL TIMING BELT NO.3 COVER
(a) Visually check for cracks and breaks on the gasket of the
timing belt cover.
HINT:
If there is a trace of water intrusion when checking visually, re-
pair the gasket with seal packing when the crack length is within
2 to 3 cm (0.79 to 1.18 in.). Replace the gasket when the crack
length is 3 to 4 cm (1.18 to 1.57 in.) or longer.
Page 442 of 969
A78748
Seal Packing
Gasket
A78749
E
F
Joining
Line D
G
Gasket Joining Portion:
Seal Packing E
Joining
Line
A78750
FrontFront
Belt
GuideBelt
Guide
14-66
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2158 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) If the timing belt cover gasket is needed to repair, follow
the procedure below.
(1) Repair the cracks and breaks by applying seal
packing to the damaged area.
Seal packing: Part No. 08826-00080 or equivalent
NOTICE:
When applying the seal packing, apply it as wide and high
as the gasket.
(c) If the timing belt cover gasket is needed to replace, follow
the procedure below.
(1) Using a screwdriver and gasket scraper, remove
the remaining gasket.
NOTICE:
Be careful not to damage the timing belt cover.
(2) Remove the backing paper from a new gasket, then
affix the gasket along the groove of the timing belt
cover as shown in the illustration.
NOTICE:
Affix the gasket in the center of the groove.
At the corners, try to keep the gasket thickness uni-
form.
HINT:
GasketDEFG
Length335 mm
(13.19 in.)180 mm
(7.09 in.)133 mm
(5.24 in.)72 mm
(2.83 in.)
(3) If there is a gap between the ends of the gasket, ap-
ply seal packing to close the gap.
Seal packing: Part No. 08826-00080 or equivalent
NOTICE:
When applying the seal packing, apply it as wide and high
as the gasket.
(d) Install the timing belt cover with the 6 bolts.
Torque: 8.5 NVm (87 kgfVcm, 75 in.Vlbf)
86. INSTALL CAMSHAFT TIMING PULLEY
(a) Pay attention to the orientation of the belt guide. Install
the camshaft timing pulley with the belt guide properly ori-
ented, then tighten the bolt temporarily.
HINT:
Align the belt guide of the RH timing pulley so it faces the
front of the engine as illustrated.
Align the belt guide of the LH timing pulley so it faces the
rear of the engine as illustrated.
Page 443 of 969
A78703
SST
A78704
SST
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-67
2159 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) Using SST, tighten the RH pulley bolt.
SST 09960-10010 (09962-01000, 09963-01000)
Torque: 125 NVm (1,275 kgfVcm, 92 ftVlbf)
(c) Using SST, tighten the LH pulley bolt.
SST 09960-10010 (09962-01000, 09963-01000)
Torque: 125 NVm (1,275 kgfVcm, 92 ftVlbf)
87. INSTALL TIMING BELT IDLER SUB-ASSY NO.2
Torque: 43 NVm (438 kgfVcm, 32 ftVlbf)
88. INSTALL TIMING BELT IDLER SUB-ASSY NO.1
(a) Using a socket hexagon wrench 10, install the plate washer and timing belt idler No. 1 with the pivot
bolt.
Torque: 34 NVm (347 kgfVcm, 25 ftVlbf)
89. INSTALL TIMING BELT
(a) Remove any oil or water on the pulleys, then keep them
clean.
NOTICE:
If there is a trace of water and/or oil on the timing belt,
repair the leakage and install a new timing belt.
Only wipe the pulleys; do not use any cleaning agent.
(b) Check the idler pulleys.
(1) Check that the idler pulley turns smoothly.
(2) Visually check the seal portion of the idler pulley for
oil leakage.
(c) Check the water pump.
(1) Turn the pulley, then check that water pump bearing
moves smoothly and does not make a noise.
(2) Visually check the drain hole for coolant leakage.
(d) Temporarily install the crankshaft pulley bolt and washer
to the crankshaft.
Page 444 of 969
A82349
Approximately 60
Turn
A78751
SST
A05062
A52840
A78702(1) (2)
(3) (4)
(5)
(6) 14-68
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2160 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(e) Turn the crankshaft counterclockwise by approximately
60.
NOTICE:
To prevent contact of the piston head with the valve head,
set the crankshaft pulley at the 60 BTDC/compression
position.
(f) Using SST, turn the crankshaft pulley, then align the tim-
ing marks of the timing pulley with the timing belt No. 3
cover.
SST 09960-10010 (09962-01000, 09963-01000)
(g) Turn the crankshaft, then align the timing mark of the
crankshaft timing pulley with the oil pump body.
(h) Align the front mark on the timing belt so it faces forward.
(i) Align the installation mark on the timing belt with the tim-
ing mark of the crankshaft timing pulley.
(j) Align the installation marks on the timing belt with the tim-
ing marks of the camshaft timing pulleys.
(k) Install the timing belt in this order.
1stCrankshaft timing pulley
2ndWater pump pulley
3rdLH camshaft timing pulley
4thNo. 2 idler pulley
5thRH camshaft timing pulley
6thNo. 1 idler pulley
Page 445 of 969
A36238
A78326
Turn
A05052
A36239
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-69
2161 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
90. INSTALL TIMING BELT TENSIONER ASSY
(a) Set the timing belt tensioner upright on the press.
(b) Slowly press in the push rod.
NOTICE:
Do not apply pressure more than 9.8 kN (1,000 kgf, 2,205
lbf) to the rod.
(c) Align the holes of the push rod and housing, then pass a
1.5 mm hexagon wrench through the holes to keep the
setting position of the push rod.
(d) Release the press.
(e) Temporarily install the tensioner with the 2 bolts. Alter-
nately tighten the 2 bolts.
Torque: 27 NVm (280 kgfVcm, 20 ftVlbf)
NOTICE:
Be sure to tighten the bolts uniformly. Installing the ten-
sioner at an angle may cause failure of its proper operation.
(f) Remove the 1.5 mm hexagon wrench from the tensioner.
(g) Turn the crankshaft 2 revolutions slowly, then align the
timing mark of the crankshaft timing pulley with the oil
pump body.
NOTICE:
Always turn the crankshaft clockwise.
(h) Check that the timing marks of the RH and LH timing pul-
leys are aligned with the timing marks of the timing belt
No. 3 cover as shown in the illustration.
If the marks are not aligned, remove the timing belt and reinstall
it.
(i) Remove the crankshaft pulley bolt.
91. INSTALL TIMING BELT GUIDE NO.2
(a) Install the timing belt guide with the cup side facing the en-
gine front.
Page 446 of 969
A78753
SST
A52345
14-70
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2162 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
92. INSTALL ENGINE MOUNTING BRACKET RH
Torque: 28 NVm (286 kgfVcm, 21 ftVlbf)
93. INSTALL TIMING BELT NO.2 COVER
(a) Visually check for cracks and breaks on the gasket of the timing belt cover.
If there is a trace of water intrusion when checking visually, replace the timing belt cover.
(b) Install the timing belt cover.
Torque: 8.5 NVm (87 kgfVcm, 75 in.Vlbf)
94. INSTALL TIMING BELT NO.1 COVER
(a) Visually check for cracks and breaks on the gasket of the timing belt cover.
If there is a trace of water intrusion when checking visually, replace the timing belt cover.
(b) Install the timing belt cover.
Torque: 8.5 NVm (87 kgfVcm, 75 in.Vlbf)
95. INSTALL CRANKSHAFT PULLEY
(a) Align the keyway of the pulley with the key located on the
crankshaft, then slide the pulley into place.
(b) Using SST, install the pulley bolt.
SST 09213-54015 (91651-60855), 09330-00021
Torque: 220 NVm (2,250 kgfVcm, 162 ftVlbf)
96. INSTALL VVT SENSOR
Torque: 8.0 NVm (82 kgfVcm, 71 in.Vlbf)
97. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSY
Torque: 8.0 NVm (82 kgfVcm, 71 in.Vlbf)
98. INSTALL ENGINE HANGER NO.2
Torque: 20 NVm (199 kgfVcm, 14 ftVlbf)
99. INSPECT VALVE CLEARANCE
(a) Turn the crankshaft pulley, then align the timing notch with
the timing mark º0º of the timing belt No. 1 cover.
(b) Check that the valve lifters on the intake side of the No.
1 cylinder are not pushed by the cam.
If the valve lifters are pushed, turn the crankshaft 1 revolution
(360) and align the marks as above.
Page 447 of 969
A78666
LH Bank:EX
IN
1
23
6 Front
13 RH Bank:
6
2
IN
EX
A78667
LH Bank:EX
IN
3
45
2Front
35 RH Bank:
2
4
IN
EX
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-71
2163 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(c) Inspect the valves indicated in the illustration on the left.
(1) Using a feeler gauge, measure the clearance be-
tween the valve lifter and camshaft.
Valve clearance (Cold):
0.15 to 0.25 mm (0.0059 to 0.0098 in.) for intake
0.25 to 0.35 mm (0.0098 to 0.0138 in.) for exhaust
(2) Record the out-of-specification valve clearance
measurements. They will be used later to select an
adjusting shim to replace.
(d) Turn the crankshaft by 2/3 of a revolution (240), then in-
spect the valves indicated in the illustration on the left.
(1) Using a feeler gauge, measure the clearance be-
tween the valve lifter and camshaft.
Valve clearance (Cold):
0.15 to 0.25 mm (0.0059 to 0.0098 in.) for intake
0.25 to 0.35 mm (0.0098 to 0.0138 in.) for exhaust
(2) Record the out-of-specification valve clearance
measurements. They will be used later to select an
adjusting shim to replace.
Page 448 of 969
A78668
LH Bank:EX
IN
5
6
1
4 Front
5
1 RH Bank:
4
6
IN
EX
A78669
Upward
Notch
A78670
Front of No. 1 and No. 2 Cylinders:
Others:
SST (A)
SST (B)
SST (B)
SST (A)
7
9 14-72
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2164 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(e) Turn the crankshaft by 2/3 of a revolution (240), then in-
spect the valves indicated in the illustration on the left.
(1) Using a feeler gauge, measure the clearance be-
tween the valve lifter and camshaft.
Valve clearance (Cold):
0.15 to 0.25 mm (0.0059 to 0.0098 in.) for intake
0.25 to 0.35 mm (0.0098 to 0.0138 in.) for exhaust
(2) Record the out-of-specification valve clearance
measurements. They will be used later to select an
adjusting shim to replace.
100. ADJUST VALVE CLEARANCE
(a) Turn the camshaft so that the cam lobe faces upward.
(b) Turn the valve lifter with a screwdriver so that the notches
are perpendicular to the camshaft.
(c) Using SST (A), press down the valve lifter and place SST
(B) between the camshaft and valve lifter. Remove SST
(A).
SST 09248-55040 (09248-05410, 09248-05420)
HINT:
Apply SST (B) at a slight angle on the side marked with
º9º or º7º at the position shown in the illustration.
When SST (B) is inserted too deeply, it will get pinched by
the shim. To prevent SST(B) from getting stuck, insert it
gently from the intake side at a slight angle.
SST (A)09248-05410
SST (B)09248-05420
Page 449 of 969
A78671
SST (B)
Magnetic Finger
EM0494
EXAMPLE (Intake):
Measured valve clearance = 0.45 mm (0.0177 in.)
0.45 mm (0.0177 in.) - 0.20 mm (0.0079 in.) = 0.25 mm (0.0098 in.)
(Measured - Specification = Excess clearance)
Used shim measurement = 2.80 mm (0.1102 in.)
0.25 mm (0.0098 in.) + 2.80 mm (0.1102 in.) = 3.05 mm (0.1201 in.)
(Excess clearance + Used shim = Ideal new shim)
Closest new shim = 3.05 mm (0.1201 in.)
Select No. 12 shim
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-73
2165 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(d) Using a small screwdriver and magnetic finger, remove
the adjusting shim.
(e) Using a micrometer, measure the thickness of the re-
moved shim.
(f) Calculate the thickness of a new shim so that the valve
clearance comes within the specified value.
AThickness of new shim
BThickness of used shim
CMeasured valve clearance
Specified value (Cold):
Intake A = B + (C - 0.20 mm (0.0079 in.))
Exhaust A = B + (C - 0.30 mm (0.0118 in.))
(g) Select a new shim with a thickness which is as close to the
calculated values as possible.
HINT:
Shims are available in 17 sizes in increments of 0.05 mm
(0.0020 in.), from 2.50 mm (0.0984 in.) to 3.30 mm
(0.1299 in.).
Refer to New Shim Thickness table on the next 2 pages.
Page 450 of 969
V00719
Adjusting Shim Selection Chart (Intake)
Intake valve clearance (Cold):
0.15 to 0.25 mm (0.0059 to 0.0098 in.)
EXAMPLE: The 2.800 mm (0.1102 in.) shim is installed, and
the measured clearance is 0.450 mm (0.0177 in.).
Replace the 2.800 mm (0.1102 in.) shim with a new No. 12
shim.New Shim Thickness mm (in.)
HINT: New shims have the thickness in millimeters
imprinted on the face.Thickness
Thickness Shim
No. Shim
No.
Installed Shim Thickness
Measured Clearance
mm (in.)mm (in.)
14-74
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2166 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
