- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-45
2137 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(c) Using several steps, loosen and remove the 10 bearing
cap bolts uniformly in the sequence shown in the illustra-
tion. Remove the 5 bearing caps and No. 3 camshaft.
NOTICE:
Do not pry out the camshaft.
Be careful not to damage the contact surface of the
cylinder head that receives the shaft thrust.
30. REMOVE NO.4 CAMSHAFT SUB-ASSY
(a) Using several steps, loosen and remove the 10 bearing
cap bolts uniformly in the sequence shown in the illustra-
tion. Remove the 5 bearing caps and No. 4 camshaft.
NOTICE:
Do not pry out the camshaft.
Be careful not to damage the contact surface of the
cylinder head that receives the shaft thrust.
(b) Remove the oil seal from the No. 4 camshaft.
31. INSPECT CAMSHAFT TIMING GEAR ASSY
(a) Clamp the camshaft in a vise on the hexagonal lobe.
(b) Check that the VVT-i will not turn.
(c) Cover all the oil ports with vinyl tape except the port on the
advance angle side (nearest to the convex portion)
shown in the illustration.
(d) Using the air gun, apply about 100 kPa (1 kgf/cm
2, 14 psi)
of air pressure to the port on the advance angle side.
NOTICE:
Some oil spraying will occur. Be prepared to catch the
spray with a shop rag.
HINT:
This operation releases the lock pin for the most retard angle
lock.
(e) Under the condition above, turn the VVT-i to the advance
angle side (the direction of the white arrow in the illustra-
tion) by hand.
Standard: Must turn
HINT:
Depending on the air pressure, the VVT-i will turn to the ad-
vance angle side without applying force by hand. Also, if the
pressure can be hardly applied because of the air leakage from
the port, the lock pin might not be released easily.
Page 422 of 969
A05739
A05740
P12596
14-46
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2138 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(f) Check that the VVT-i moves freely within about 30
range. Avoid moving the VVT-i unit to the most retard
angle position as the lock pin will engage again.
Standard: Smooth movable range is about 30
(g) Turn the VVT-i by hand, then lock it at the most retard
angle position.
32. REMOVE CAMSHAFT TIMING GEAR ASSY
NOTICE:
Do not remove or install the camshaft timing gear (VVT-i)
unless you are replacing the VVT-i or camshaft.
(a) Clamp the camshaft in a vise on the hexagonal lobe.
NOTICE:
Be careful not to damage the camshaft.
(b) Using a 46 mm socket wrench, remove the lock nut by
turning it clockwise.
NOTICE:
Remove it with the lock pin engaged and locked at the
most retard angle position.
The lock nut has LH threads.
Never use any tools other than the socket wrench.
Other tools will deform the cam angle rotor.
(c) Remove the camshaft VVT-i.
NOTICE:
Never remove the 3 bolts on the gear.
If it is difficult to remove VVT-i, tap it lightly using a plastic-faced
hammer, then remove it.
33. REMOVE CAMSHAFT SUB GEAR
(a) Clamp the camshaft in a vise on the hexagonal lobe.
NOTICE:
Be careful not to damage the camshaft.
Page 423 of 969
A78715
SST
A52353
A05275
A78716
Front
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-47
2139 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) Using SST, turn the sub gear counterclockwise, then re-
move the service bolt.
SST 09960-10010 (09962-01000, 09963-00500)
(c) Using snap ring pliers, remove the snap ring.
(d) Remove the wave washer, camshaft sub gear and cam-
shaft gear bolt washer.
HINT:
Arrange the camshaft sub gears and gear bolt washers (RH and
LH sides) so that they can be returned to the original locations
when reassembling.
34. REMOVE ENGINE HANGER NO.2
35. REMOVE CYLINDER HEAD COVER REAR
36. REMOVE OIL CONTROL VALVE FILTER
(a) Remove the plug, gasket and valve filter.
37. REMOVE CYLINDER HEAD SUB-ASSY
(a) Using a socket hexagon wrench 8, remove the hexagon
bolt.
Page 424 of 969
A78717
Front
1
23
8
7
6
5
4
A78718
Front
A78719
Front
1
23
8
7
6
5
4
A78314
1
2
3
8
7
6
5
4
9
10 14-48
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2140 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) Using several steps, loosen the 8 cylinder head bolts uni-
formly in the sequence shown in the illustration. Remove
the 8 cylinder head bolts and plate washers.
NOTICE:
Be careful not to drop the washers into the cylinder
head.
Head warpage or cracking could result from remov-
ing the bolts in an incorrect order.
38. REMOVE CYLINDER HEAD GASKET
39. REMOVE CYLINDER HEAD LH
(a) Using a socket hexagon wrench 8, remove the hexagon
bolt.
(b) Using several steps, loosen the 8 cylinder head bolts uni-
formly in the sequence shown in the illustration. Remove
the 8 cylinder head bolts and plate washers.
NOTICE:
Be careful not to drop the washers into the cylinder
head.
Head warpage or cracking could result from remov-
ing the bolts in an incorrect order.
40. REMOVE CYLINDER HEAD GASKET NO.2
41. REMOVE WATER INLET HOUSING
(a) Remove the 8 bolts and 2 nuts, then remove the water in-
let housing.
Page 425 of 969
A78720
SST
A36750
A00019
SST
SST
B04136
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-49
2141 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
42. REMOVE OIL FILTER SUB-ASSY
(a) Using SST, remove the oil filter.
SST 09228-07501
(b) Using a socket hexagon wrench 12, remove the oil filter
union.
43. REMOVE OIL PAN DRAIN PLUG
44. REMOVE OIL PAN SUB-ASSY NO.2
(a) Remove the 10 bolts and 2 nuts.
(b) Insert the blade of SST between the oil pan No. 1 and oil
pan No. 2, then cut off the sealer and remove the oil pan
No. 2.
SST 09032-00100
NOTICE:
Be careful not to damage the contact surface of the oil
pan No. 1 where the oil pan No. 2 is mounted.
Do not damage the flange portion of the oil pan No. 2
when removing.
45. REMOVE OIL STRAINER SUB-ASSY
(a) Remove the bolt and 2 nuts, then remove the oil strainer and gasket.
46. REMOVE OIL PAN SUB-ASSY
(a) Loosen and remove the 15 bolts and 2 nuts uniformly.
Page 426 of 969
B04137
P12508
P12589
A51990
14-50
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2142 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) Using a screwdriver, remove the oil pan by prying be-
tween the cylinder block and oil pan.
NOTICE:
Be careful not to damage the contact surfaces of the oil pan
and cylinder block.
47. REMOVE OIL PAN BAFFLE PLATE
48. REMOVE ENGINE REAR OIL SEAL RETAINER
(a) Remove the 6 bolts.
(b) Using a screwdriver, remove the oil seal retainer by prying
between the oil seal retainer and bearing cap.
49. REMOVE ENGINE REAR OIL SEAL
(a) Using a screwdriver and hammer, tap out the oil seal.
50. REMOVE OIL PUMP ASSY
(a) Remove the 9 bolts.
(b) Using a screwdriver, remove the oil pump by prying be-
tween the oil pump and bearing cap.
(c) Remove the O-ring.
Page 427 of 969
A62375
A05245
A05243
EM3336
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-51
2143 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
51. REMOVE OIL PUMP SEAL
(a) Using a screwdriver, pry out the oil seal.
52. REMOVE SPARK PLUG TUBE GASKET
(a) Bend up the tab on the ventilation baffle plate which pre-
vents the gasket from slipping out.
NOTICE:
Be careful not to damage the baffle plate of the cylinder
head cover.
(b) Using a screwdriver and hammer, tap out the gasket.
(c) Using needle-nose pliers, pry out the gasket.
NOTICE:
Be careful not to damage the cylinder head cover.
53. INSPECT TIMING BELT
NOTICE:
Do not bend, twist or turn the timing belt inside out.
Do not allow contact of the timing belt with oil, water
or steam.
Do not use the timing belt tension when installing or
removing the mounting bolt of the camshaft timing
pulley.
Check the belt for any defects as shown in the illustrations.
Also, check these points below.
(a) If the belt tears in a short time:
Check if the belt is installed properly.
Check if the timing cover gasket is damaged and if
it is installed properly.
(b) If the belt teeth are cracked or damaged, check if either
camshaft is locked.
(c) If there is noticeable wear or cracks on the belt face,
check if there are nicks on the side of the idler pulley lock
and water pump.
Page 428 of 969
EM1628
A51428
A51429
A78721
Tension Portion 14-52
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2144 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(d) If there is wear or damage on only one side of the belt,
check the belt guide and alignment of each pulley.
(e) If there is noticeable wear on the belt teeth:
Check the timing cover for damage.
Check that the gasket has been installed correctly.
Check for foreign objects on the pulley teeth.
If there is any doubt about the belt condition, replace the timing
belt.
54. INSPECT CAMSHAFT
(a) Inspect the camshaft for runout.
(1) Place the camshaft on V-blocks.
(2) Using a dial indicator, measure the runout at the
center journal.
Maximum circle runout: 0.06 mm (0.0024 in.)
If the runout is greater than maximum, replace the camshaft.
(b) Inspect the cam lobes.
(1) Using a micrometer, measure the cam lobe height.
Standard cam lobe height:
43.132 to 43.232 mm (1.6981 to 1.7020 in.) for intake
43.010 to 43.110 mm (1.6933 to 1.6972 in.) for exhaust
Minimum cam lobe height:
42.98 mm (1.6921 in.) for intake
42.86 mm (1.6874 in.) for exhaust
If the cam lobe height is less than minimum, replace the cam-
shaft.
(c) Inspect the camshaft journals.
(1) Using a micrometer, measure the journal diameter.
Journal diameter:
26.959 to 26.975 mm (1.0614 to 1.0620 in.)
If the journal diameter is not as specified, check the oil clear-
ance.
55. INSPECT CYLINDER HEAD SET BOLT
(a) Using vernier calipers, measure the tension portion diam-
eter of the bolt.
Standard outside diameter:
8.95 to 9.05 mm (0.3524 to 0.3563 in.)
Minimum outside diameter: 8.75 mm (0.3445 in.)
If the diameter is less than minimum, replace the bolt.
Page 429 of 969
A78722
SST
A78723
SST
A78724
Seal Width 2 to 3 mm (0.08 to 0.12 in.)
A
A
B
B
A78754
SST
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-53
2145 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
56. INSTALL SPARK PLUG TUBE GASKET
(a) Using SST and a hammer, tap in the new gasket until its
surface is flush with the upper edge of the cylinder head
cover.
SST 09950- 60010 (09951- 00430), 09950- 70010
(09951-07100)
(b) Return the ventilation plate tab to its original position.
(c) Apply a light coat of multi-purpose grease to the gasket
lip.
57. INSTALL ENGINE REAR OIL SEAL
(a) Using SST and a hammer, tap in the new oil seal until its
surface is flush with the rear oil seal retainer edge.
SST 09223-15030, 09950-70010 (09951-07100)
NOTICE:
Be careful not to tap the oil seal at an angle.
Keep the lip free of foreign objects.
(b) Apply multi-purpose grease to the oil seal lip.
58. INSTALL ENGINE REAR OIL SEAL RETAINER
(a) Remove any old packing material from the contact sur-
face.
(b) Apply a continuous bead of seal packing (Diameter 2 to
3 mm (0.08 to 0.12 in.)) as shown in the illustration.
Seal packing: Part No. 08826-00080 or equivalent
NOTICE:
Remove any oil from the contact surface.
Install the oil seal retainer within 3 minutes after ap-
plying seal packing.
Do not expose the seal packing to engine oil within 2
hours after installing.
(c) Install the oil seal retainer with the 6 bolts. Tighten the
bolts uniformly in several steps.
Torque: 8.0 NVm (82 kgfVcm, 71 in.Vlbf)
59. INSTALL OIL PUMP SEAL
(a) Using SST and a hammer, tap in the new oil seal until its
surface is flush with the oil pump body edge.
SST 09223-00010
NOTICE:
Be careful not to tap the oil seal at an angle.
Keep the lip free of foreign objects.
(b) Apply multi-purpose grease to the oil seal lip.
Page 430 of 969
A36784
A78725
Seal Packing
Seal Width
2 to 3 mm
(0.08 to 0.12 in.) A
A
BB
C
C
A36785
14-54
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2146 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
60. INSTALL OIL PUMP ASSY
(a) Remove any old packing material from the contact sur-
face.
(b) Apply a light coat of engine oil to a new O-ring, then place
it on the cylinder block.
(c) Apply a continuous bead of seal packing (Diameter 2 to
3 mm (0.08 to 0.12 in.)) as shown in the illustration.
Seal packing: Part No. 08826-00080 or equivalent
NOTICE:
Remove any oil from contact surface.
Apply seal packing to the inner side of the bolt holes.
Install the oil pump within 3 minutes after applying
seal packing.
Do not expose the seal packing to engine oil within 2
hours after installing.
(d) Align the key of the oil pump drive gear with the keyway
located on the crankshaft, then slide the oil pump into
place.
