CHASSIS
560
REPLACING WHEELS
As you might have difficulty in identifying a flat or deflated
tire, a tire pressure warning system is provided on this
vehicle.
When replacing the wheels, be sure to install tire pressure
sensors on the wheels.
There are 2 ways to set up the tire pressure sensors.
a. Remove the sensor from the old wheel and install it to the
new wheel.
b. Use a new wheel and sensor.You have to register an ID code for a new sensor. Up to 2
sets of codes can be registered. As one ID for the originally
installed sensor is registered at “MAIN” of the selector
switch, use the “2nd” position to register an ID for the new
sensor.
You do not need to re −register the ID code for any other
replacements. For the use of the originally installed tires,
put the selector switch at “MAIN” and for the use of tires
purchased later, put the switch at “2nd”. For the sensor
selector switch, see page 442.
CAUTION
 Have the tires, wheels or sensors replaced and ID
codes registered by Lexus dealer. If you need
sensors, purchase from Lexus dealer.
 The sensor nuts should always be tightened to a
torque of 4 N·m (0.4 kgf·m, 2.9 ft·lbf).
 The use of nongenuine wheels will cause the tire
pressure sensor to transmit the electronic code in
different manner, resulting in the failure of the
system.
When to replace your wheels
If you have wheel damage such as bending, cracks or
heavy corrosion, the wheel should be replaced.
If you fail to replace a damaged wheel, the tire may slip off the
wheel or cause loss of handling control.
Replacement with used wheels is not recommended as they
may have been subjected to rough treatment or high mileage
and could fail without warning. Also, bent wheels which have
been straightened may have hidden structural damage and
therefore should not be used. Never use an inner tube in a
leaking wheel which is designed for a tubeless tire.

CHASSIS
561
Wheel selection
When replacing wheels, care should be taken to ensure
that they are equivalent to those removed in load capacity,
diameter, rim width, and offset.
Correct replacement wheels are available at your Lexus
dealer.
A wheel of a different size or type may adversely affect
handling, wheel and bearing life, brake cooling,
speedometer/odometer calibration, stopping ability, headlight
aim, bumper height, vehicle ground clearance, and tire or snow
chain clearance to the body and chassis.
CAUTION
Observe the following instruction. Otherwise, an
accident may occur resulting in death or serious
injuries.
 Do not use wheels other than the manufacturer’s
recommended size, as this may cause dangerous
handling characteristics resulting in loss of control.
ALUMINUM WHEEL PRECAUTIONS
When installing aluminum wheels, check that the wheel
nuts are tight after driving your vehicle the first 1600 km
(1000 miles).
 If you have rotated, repaired, or changed your tires, check
that the wheel nuts are still tight after driving 1600 km (1000
miles).
 When using tire chains, be careful not to damage the
aluminum wheels.
 Use only Lexus wheel nuts and wrench designed for your
aluminum wheels.
 When balancing your wheels, use only Lexus balance
weights or equivalent and a plastic or rubber hammer.
 As with any wheel, periodically check your aluminum
wheels for damage. If damaged, replace immediately.

CHASSIS
562
SUSPENSION AND CHASSIS
CAUTION
Do not modify the suspension/chassis with lift kits,
spacers, springs, etc. It can cause dangerous handling
characteristics, resulting in loss of control.

SECTION 6 – 4
563
SERVICE PROCEDURES AND
SPECIFICATIONS
Electrical components
Specifications564
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Checking battery condition 571
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery recharging precautions 574
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking and replacing the blade type fuses 574
. . . . . . . . . . . . . . . .
Checking the cartridge type fuses 577
. . . . . . . . . . . . . . . . . . . . . . . . . .
Adding washer fluid 579
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Checking the headlight aim 579
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing light bulbs 584
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

ELECTRICAL COMPONENTS
564
SPECIFICATIONS
FUSE LOCATION
G64001
 1Engine compartment
2Left side kick panel
3Right side kick panel
4Engine compartment 5Trunk FUSES
G64002

Right side kick panel
G64003
Left side kick panel

ELECTRICAL COMPONENTS
565
g64004
Engine compartment
G64005
Engine compartment (GS430)
G64006
Engine compartment (GS300)
G64007
Trunk

ELECTRICAL COMPONENTS
566
No.FUSEAMPERECIRCUIT
1 STR LOCK25Steering lock system
2 SECURITY7.5Smart access system with
push−button start
3 TI &TE20Power tilt and telescopic
steering wheel, Multiplex
communication system
4 AM17.5Starting system
5 STOP SW7.5
Stop/tail lights, Multi− port fuel
injection system/sequential
multiport fuel injection system,
Starting system, Electronic
control brake system, Vehicle
stability control system, Shift
lock system
6 OBD7.5On− board diagnosis system
7 FR P/SEAT
RH30Power seat system
8 AIR SUS20Electronic modulated
suspension
9 PWR
OUTLET15Power outlet
10 CIG15Cigarette lighter
11 ACC7.5
Multiplex communication
system, Smart access system
with push− button start, Rear
view monitor system, Audio
system, Air conditioning system
No.FUSEAMPERECIRCUIT
12 IGN10
Multi− port fuel injection
system/sequential multiport fuel
injection system, SRS airbag
system, Stop/tail lights,
Steering lock system, Electronic
control brake system
13 GAUGE7.5Gauges and meters
14 ECUIG
RH10
Power tilt and telescopic
steering wheel, Multiplex
communication system, Smart
access system with
push −button start, Audio
system, Air conditioning
system, Shift lock system, Tire
pressure warning system,
Combination switch
15 FR S/HTR
RH15Seat heater, Heated and
ventilated seats
16 RHIG7.5
Seat heater switches, Front
right door control system, Rear
right door control system,
Capacitor, Combination switch,
Seat belt pretensioners,
Intuitive parking assist
17 AM215Starting system

ELECTRICAL COMPONENTS
567
No.FUSEAMPERECIRCUIT
18 FR DOORRH20
Front right door control system
(Power door lock system,
Power rear view mirror control
system, Door courtesy light,
Outside rear view mirror heater,
Power window), Multiplex
communication system
19 RR DOOR RH20Rear right door control system
(Power door lock system, Door
courtesy light, Power window)
20 RR DOOR LH20Rear left door control system
(Power door lock system, Door
courtesy light, Power window)
21 FR DOORLH20
Front left door control system
(Power door lock system,
Power rear view mirror control
system, Door courtesy light,
Outside rear view mirror heater,
Power window)
22 RAD NO.310Audio system
23 HLP LVL7.5Adaptive front lighting system
(AFS), Automatic headlight
leveling control system
No.FUSEAMPERECIRCUIT
24 LHIG10
Charging system, Headlight
cleaners, Exhaust gas sensor,
Rear window defogger, Electric
cooling fans, Rear left door
control system, Front left door
control system, Emergency
flashers, Automatic
transmission, Seat belt
pretensioners, Intuitive parking
assist
25 FR WIP30Windshield wipers and washer
26 PANEL7.5
Steering switch illumination,
Audio system, Glove box light,
Automatic transmission selector
lever illumination, Console box
light, Adaptive variable
suspension switch illumination,
Cigarette lighter illumination, Air
conditioning system, Traction
control off switch illumination,
Driving pattern selector switch,
Seat heater or Heated and
ventilated seat switches,
Register ILL RH, Register ILL
LH, Register ILL CTR
27 FUEL
OPEN10Fuel filler door opener, Trunk lid
opener

ELECTRICAL COMPONENTS
568
No.FUSEAMPERECIRCUIT
28 ECUIG LH10
Vehicle stability control system,
Electronic control brake system,
Yaw rate and G sensor,
Steering sensor, Cruise control
system, Dynamic radar cruise
control system, Electronic
power steering system, Variable
gear ratio steering system,
Rear view monitor system,
Four−wheel drive system, Front
controller, Moon roof, Rain
sensor
29 FR S/HTR
LH15Seat heater, Heated and
ventilated seats
30 FR P/SEAT LH30Power seat system
31 A/C7.5Air conditioning system
32 TV7.5Audio system, Air conditioning
system, Rear view monitor
system
33 TRK OPN10Trunk lid opener
34 LHB10Theft deterrent system
35 S/ROOF25Moon roof
36 ECUB10
Variable gear ratio steering
system, Electronic power
steering system, Driver’s seat
switch module
37 ABS
MAIN310Electronic control brake system
No.FUSEAMPERECIRCUIT
38 TURNHAZ15Turn signal lights, Emergency
flashers
39 IG2 MAIN20“IG2”, “GAUGE” and “IGN”
40 RAD NO.230Audio system
41 D/C CUT20“DOME “ and “MPX− B”
42 RAD NO.130Audio system
43 MPXB10
Multiplex communication
system, Front controller, Door
control system (Power door
lock system, Door courtesy
lights, Power windows, Power
rear view mirror control system,
Outside rear view mirror
heaters), Power seat system,
Steering sensors, Electronic
control brake system, Power tilt
and telescopic steering system,
Gauges and meters,
Combination switch
44 DOME10
Foot lights, Vanity lights,
Gauges and meters, Steering
spot light, Steering switch
illumination, Rear personal
lights, Automatic transmission
selector lever spot light, Front
personal lights
45 ABS
MAIN210Electronic control brake system
46 ABS
MOTOR30Anti− lock brake system

ELECTRICAL COMPONENTS
569
No.FUSEAMPERECIRCUIT
47 ABS
MAIN110Capacitor
48 E/GB60“FR CTRL BATT”, “ETCS” and
“ALT−S”
49 ABS150Vehicle stability control system,
“ABS MAIN1”, “ABS MAIN2”
and “ABS MTR”
50 RH J/BB30“AM2”, “DOOR FR” and “DOOR
RR”
51 VGRS40Variable gear ratio steering
system
52 MAIN30“H− LP R LWR” and “H −LP L
LWR”
53 STARTER30Starting system
54 LH J/BB30“FL DOOR”, “RL DOOR” and
“RAD No.3”
55 P/IB60Multi− port fuel injection
system/sequential multiport fuel
injection system
56 EPS80Electronic power steering
system
57 ALT150
“RH J/B− AM”, “LH J/B −AM”,
“E/G− AM”, “RR JB”, “HEATER”,
“DEFOG”, “FAN1”, “FAN2”,
“ABS2”, “ABS MOTOR”, “ABS
MAIN1”, and “ABS MAIN2”
No.FUSEAMPERECIRCUIT
58 RR J/B80
“STOP LP R”, “STOP LP L”,
“RR− B”, “RR TAIL”, “RR FOG”,
“RR− IG1”, “PSB”, and “RR
S/SHADE”
59 GLW PLG150Glow plug heater
60 RH J/BAM80
“AM1”, “OBD”, “STOP SW”, “TI
&TE”, “PWR OUTLET”, “FR
P/SEAT RH”, “STR LOCK”,
“ECU− IG RH”, “RH− IG”, “ACC”,
“CIG”, “SECURITY”, “FR
S/HTR RH”, and “AIR SUS”
61 ABS230Vehicle stability control system,
Anti− lock brake system
62 DEFOG50Rear window defogger, Noise
filter
63 FAN140Electric cooling fans
64 HEATER50Air conditioning system
65 GLW PLG250Glow plug heater
66 E/GAM60“H−LMP CLN”, “FR CTRL −AM”
and “A/C COMP”
67 LH J/
BAM80
“S/ROOF”, “FR P/SEAT LH”,
“TV”, “FR S/HTR LH”, “ECU− IG
LH”, “FR WIP”, “H −LP LVL”,
“LH− IG”, “FUEL OPEN”, “A/C”,
“PANEL”, and “LH− B”
68 FAN260No circuit
69 FR
CTRLB25“H− LP UPR” and “HORN”
