Lexus GS450h 2007 Hybrid system / LEXUS 2007 GS450H THROUGH JUNE 2006 PROD. QUICK REFERENCE MANUAL

Topic 5
Driving Comfort
31
Touch Screen
By touching the screen with your finger, you can control the audio system, air-conditioning
and adjust the screen display, etc. For details, see the Owner’s Manual.
*: See Navigation System Owner’s Manual
When you press this button...This display appears.
CLIMATEAir conditioning operation screen
AUDIOAudio control screen
INFOInformation screen
DISPDisplay screen
Trip informationTrip information screen
MaintenanceMaintenance screen*
Te l e p h o n eTelephone screen
Adjust ClockAdjust clock screen
CalenderCalender screen*
LEXUS Park AssistLEXUS Park Assist setting screen
LanguageSelect language screen
Screen SettingScreen setting screen
1
2
3
4
5
6
7
8
9
10
11
12

Topic 5
Driving Comfort
32
Entering and Exiting
When Driving
Rain and
Night Driving
Driving ComfortDriving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Before Driving
Air Conditioning System
Press to display the air conditioning operation screen. For details, refer to the Owner’s
Manual
Vehicles with navigation system
Vehicles without navigation system
Air conditioning operation screen display button
Driver’s side temperature control
Automatic mode
Dual operation switch
Passenger’s side temperature control
1
2
3
4
5

Topic 5
Driving Comfort
33
nUsing the automatic mode
Press .
Adjust the temperature using .
nAdjusting the temperature in DUAL mode
In DUAL mode, driver and passenger side tem-
perature settings can be adjusted separately.
Touch on the operation screen.
Adjust the driver side temperature using
, and the passenger side temperature
using .

Topic 5
Driving Comfort
34
Entering and Exiting
When Driving
Rain and
Night Driving
Driving ComfortDriving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Before Driving
Audio System
nBasic operation
*: Various adjustments can be made in each mode.
For details, refer to the Owner’s Manual.Audio control screen display button*
FM radio mode button
AM•SAT radio mode button
Power ON/OFF button, Volume adjustment knob
Disc eject button
Tape eject button
Disc slot
TAPE mode button
DISC mode button
DISC load button
Ta p e s l o t
1
2
3
4
5
6
7
8
9
10
11

Topic 5
Driving Comfort
35
nListening to the radio
Press or to choose an AM or
FM band.
Tune to your desired station.
For tuning adjustment and further information,
refer to the Owner’s Manual.
nPlaying the cassette player
You have 2 methods to play your cassette player.
lInsert a cassette tape into the tape slot.
lPress with the tape inserted.
For further information, refer to the Owner’s
Manual.
nPlaying the CD/DVD player
You have 2 methods to play your CD/DVD
player.
lPress and insert a disc into the disc slot.
lPress with the disc inserted.
For further information, refer to the Owner’s
Manual.

Topic 5
Driving Comfort
36
Entering and Exiting
When Driving
Rain and
Night Driving
Driving ComfortDriving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Before Driving
Hands-free System
To use the hands-free system, you must register your Bluetooth® phone in the system. For
details, see the Owner’s Manual.
nMaking a call
Press .
To u c h .
Inputting the phone number.
For another way of calling, see the Owner’s
Manual.
Touch or press on the steering
switch.

Topic 5
Driving Comfort
37
nHanging up the phone
Touch or press on the steering switch.
Ashtrays
Front
To remove the ashtray, push the release lever.
Rear
To remove the ashtray, press down on the plate
and lift the ashtray out.

Topic 5
Driving Comfort
38
Entering and Exiting
When Driving
Rain and
Night Driving
Driving ComfortDriving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Before Driving
Seat Heaters / Seat Heaters and
Ventilators (If Equipped)
Seat heaters
Turn the dial toward .
Seat heaters and ventilators
Seat heaters: turn the dial toward .
Ve n t i l a t o r s : turn the dial toward .
1
1
2

Topic 5
Driving Comfort
39
Console Box
Front console box
To open, slide and lift the armrest with the knob
pulled up.
Overhead console box
To open, press the lid.
There is a power outlet located in the front console box.

Topic 5
Driving Comfort
40
Entering and Exiting
When Driving
Rain and
Night Driving
Driving ComfortDriving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Before Driving
Glove Box
Open: press the button.
Lock
Unlock
The glove box can be locked and unlocked using
the mechanical key.
Cup Holders
Front
To open, press down on the front of the lid.
Rear
To open, press in and release the rear cup holder
on the rear center armrest.
1
2
3
