Lexus GX460 2012 Owner's Manual

229
2-3. Operating the lights and windshield wipers
2
When driving
GX460_U.S.A. (OM60J00U)
■Limitations of the Automatic High Beam
Do not rely on the Automatic High Beam. Always drive safely, taking care to
observe your surroundings and turning high beam on or off manually if necessary.
■Camera sensor detection information
●High beam may not be automatically turned off in the following situations:
• When oncoming vehicles suddenly appear from a curve.
• When another vehicle cuts across in front of you.
●High beam may be turned off if an oncoming vehicle that is using fog lights with-
out using the headlights is detected.
●Houselights, streetlights, red traffic signals, and illuminated billboards or signs
may cause the high beam to turn off.
●The following factors may affect the amount of time taken to turn high beam on
or off:
• The brightness of headlights, fog lights, and tail lights of oncoming and pre-ceding vehicles
• Road conditions (wetness, ice, snow etc.)
• The number of passengers and amount of baggage
●High beam may be turned on or off when unexpected by the driver.

230
2-3. Operating the lights and windshield wipers
GX460_U.S.A. (OM60J00U)
●In the situations below, the system may not be able to correctly detect the sur-
rounding brightness levels, and may flash or expose nearby pedestrians to the
high beam. Therefore, you should consider turning the high beam on or off
manually rather than relying on the Automatic High Beam system.
• In bad weather (rain, snow, fog, sandstorms etc.)
• The windshield is obscured by fog, mist, ice, dirt etc.
• The windshield is cracked or damaged.
• The inside rear view mirror or camera sensor is deformed or dirty.
• Surrounding brightness levels are equal to those of headlights, tail lights orfog lights.
• Vehicles ahead have headlights that are either switched off, dirty, are chang-
ing color, or are not aimed properly.
• When driving through an area of intermittently changing brightness and darkness
• When frequently and repeatedly driving ascending/descending roads, or roads with rough, bumpy or uneven surfaces (such as stone-paved roads,
gravel tracks etc.)
• When frequently and repeatedly taking curves or driving on a winding road
• There is a highly reflective object ahead of the vehicle, such as a sign or a mir- ror.
• The vehicle’s headlights are damaged or dirty.
• The vehicle is listing or tilting, due to a flat tire, a trailer being towed etc.
• The Automatic High Beam indicator is flashing.
• The high beam and low beam are repeatedly being switched between in an abnormal manner.
• The driver believes that the high beam may be causing problems or distress to other drivers or pedestrians nearby.

231
2-3. Operating the lights and windshield wipers
2
When driving
GX460_U.S.A. (OM60J00U)
■If the Automatic High Beam indicator flashes...
It may indicate a malfunction in the system. Contact your Lexus dealer.
■Temporary lowering sensor sensitivity
The sensitivity of the sensor can be temporarily lowered.
To lower the sensitivity, push and hold the “AUTO” button on the inside rear view
mirror for 15 to 20 seconds, and release. The indicator light on the inside rear view
mirror will flash to indicate that the sensitivity has been lowered.
When the “ENGINE START STOP” switch is turned off, the sensitivity will be
returned to its normal level.
■Customization that can be configured at your Lexus dealer
The Automatic High Beam can be turned off.

232
2-3. Operating the lights and windshield wipers
GX460_U.S.A. (OM60J00U)
NOTICE
■Camera sensor
●Do not touch the camera sensor.
●Do not subject the inside rear view mirror or the camera sensor to a strong
impact.
●Do not disassemble the camera sensor.
●Do not spill liquid onto the inside rear view mirror or the camera sensor.
●Do not apply window tinting or stickers to the camera sensor or the area of wind-
shield near the camera sensor.
●Do not place items on the dashboard. There is a possibility that the camera sensor
will mistake items reflected in the windshield for streetlights, the headlights of
other vehicles, etc.
●Do not install a parking tag or any other accessories near or around the inside
rear view mirror and the camera sensor.
●Do not overload the vehicle.
●Do not modify the vehicle.
●Do not replace windshield with a non-genuine windshield.
Contact your Lexus dealer.
Observe the following to ensure that the
Automatic High Beam functions correctly.

233
2-3. Operating the lights and windshield wipers
2
When driving
GX460_U.S.A. (OM60J00U)
Fog light switch
The fog lights secure excellent visibility in difficult driving conditions, such
as in rain or fog.
Ty p e ATurns the fog lights off
Turns the fog lights on

234
2-3. Operating the lights and windshield wipers
GX460_U.S.A. (OM60J00U)
Ty p e BTurns the fog lights off
Turns the fog lights on
Ty p e C Turns the fog lights off
Turns the fog lights on

235
2-3. Operating the lights and windshield wipers
2
When driving
GX460_U.S.A. (OM60J00U)
■Fog lights can be used when
The head lights are on in low beam.
NOTICE
■To prevent battery discharge
Do not leave the lights on longer than necessary when the engine is not running.

236
2-3. Operating the lights and windshield wipers
GX460_U.S.A. (OM60J00U)
Windshield wipers and washer
When “AUTO” is selected, the wipers will operate automatically when the
sensor detects falling rain. The system automatically adjusts wiper timing
according to rain volume and vehicle speed.
When “AUTO” is selected, the sensor sensitivity can be adjusted as fol-
lows by turning the switch ring:
Ty p e AOff
Rain-sensing wiper
operation
Low speed wiper
operation
High speed wiper
operation
Temporary operation

237
2-3. Operating the lights and windshield wipers
2
When driving
GX460_U.S.A. (OM60J00U)
Increases the sensitivity
Decreases the sensitivity
Washer/wiper dual operation
The wipers operate automati-
cally. (After operating several
times, the wipers operate one
more time after a short delay to
prevent dripping.)
Vehicles with the headlight
cleaners: If the headlights are
on, the headlight cleaners will
operate once.

238
2-3. Operating the lights and windshield wipers
GX460_U.S.A. (OM60J00U)
Ty p e BOff
Rain-sensing wiper
operation
Low speed wiper
operation
High speed wiper
operation
Temporary operation
Increases the sensitivity
Decreases the sensitivity
