Lexus GX460 2013 Owner's Manual

710
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
*: The graphic is shown on the Rear height control air suspension display.
Indicates that the glass
hatch is not fully closed
*
If the vehicle reaches a
speed of 3 mph
(5 km/h),
flashes and a buzzer
sounds to indicate that
the glass hatch is not yet
fully closed.
Close the glass hatch.
(Flashes)
(If equipped)
Indicates that the moon
roof is not fully closed
(with the “ENGINE
START STOP” switch off,
and the driver’s door
open)
Close the moon roof.
Indicates that the parking
brake is still engaged If the vehicle reaches a
speed of 3 mph
(5 km/h),
flashes and a buzzer
sounds to in dicate that
the parking brake is still
engaged.
Release the parking
brake.
Wa r n i n g m e s s a g eDetailsCorrection procedure
GX460_OM_OM60J63U_(U).book Page 710 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
711
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
*: Refer to the separate “Scheduled maintenance” or “Owner’s Manual Supple-ment” for the maintenance interval applicable to your vehicle.
Wa r n i n g m e s s a g eDetailsCorrection procedure
Indicates that the washer
fluid level is lowAdd washer fluid.
(U.S.A. only)
Indicates that all mainte-
nance according to the
driven distance on the
maintenance schedule
*
should be performed
soon
If necessary, perform
maintenance.
Comes on approximately
4500 miles (7200 km)
after the maintenance
data has been reset.
(U.S.A. only)
Indicates that all mainte-
nance is required to cor-
respond to the driven
distance on the mainte-
nance schedule
*.Perform the necessary
maintenance. Please reset
the maintenance data
after the maintenance is
performed (→ P. 6 0 5 )
Comes on approximately
5000 miles (8000 km)
after the maintenance
data has been reset. (The
indicator will not work
properly unless the main-
tenance data has been
reset.)
GX460_OM_OM60J63U_(U).book Page 711 Thursday, March 29, 2012 9:10 AM

712
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Wa r n i n g m e s s a g eDetailsCorrection procedure
(If equipped)
Indicates that the pre-
collision system is not
currently functional
• Clean the grill and the sensor if they are dirty.
• In case of overheating, the system will become
functional once the sys-
tem cools down.
(If equipped)
Indicates that intuitive
parking assist is dirty or
covered with ice
A buzzer also sounds.
Clean the sensor.
(Flashes)
(If equipped)
Indicates that the radar
cruise control sensor is
dirty or covered with ice A buzzer also sounds.
Clean the sensor.
GX460_OM_OM60J63U_(U).book Page 712 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
713
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
(Flashes)
(If equipped)
Indicates that the radar
cruise control system is
unable to judge vehicle-
to-vehicle distance A buzzer also sounds.If the windshield wipers
are on, turn them off or set
them to a mode other than
“A U T O ” o r h i g h s p e e d
wiper operation.
(Flashes)
(If equipped)
Indicates that your vehi-
cle is nearing the vehicle
ahead (in radar cruise
mode)
A buzzer also sounds.
Slow the vehicle by apply-
ing the brakes.
Wa r n i n g m e s s a g eDetailsCorrection procedure
GX460_OM_OM60J63U_(U).book Page 713 Thursday, March 29, 2012 9:10 AM

714
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
(Flashes)
(If equipped)
Indicates that there is a
high possibility of a fron-
tal collision, or that the
pre-collision braking
function is operating A buzzer also sounds.
Slow the vehicle by apply-
ing the brakes.
(If equipped)
Indicates that the LDA is
suspendedThe camera sensor tem-
perature is higher than
the operation tempera-
ture range.
Reactivate the lane depar-
ture alert system.
(If equipped)
Alerts the driver that the
vehicle may deviate from
its lane (while the LDA
system is operating).The lane markings flash.
Check the road condi-
tions and correct the driv-
ing path appropriately.
Wa r n i n g m e s s a g eDetailsCorrection procedure
GX460_OM_OM60J63U_(U).book Page 714 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
715
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Have the malfunction repaired immediately.After taking the specified steps to co rrect the suspected problem, check
that the warning message and light go off.
Interior
buzzerExterior buzzerWa r n i n g m e s s a g eDetailsCorrection
procedure
Sounds
once
(Flashes)
The electronic key
is not detected
when an attempt
is made to start
the engine.
Confirm the loca-
tion of the elec-
tronic key.
GX460_OM_OM60J63U_(U).book Page 715 Thursday, March 29, 2012 9:10 AM

716
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Sounds
onceSounds
3 times
(Flashes)
The electronic key
was carried out-
side the vehicle
and a door other
than the driver’s
door was opened
and closed while
the “ENGINE
START STOP”
switch was in a
mode other than
off.
Bring the elec-
tronic key back
into the vehicle.
The driver’s door
was opened and
closed while the
electronic key was
not in the vehicle,
the shift lever was
in P and the
“ENGINE START
STOP” switch was
not turned off.
Tu r n t h e
“ENGINE START
STOP” switch off
or bring the elec-
tronic key back
into the vehicle.
InteriorbuzzerExterior buzzerWarning messageDetailsCorrection
procedure
GX460_OM_OM60J63U_(U).book Page 716 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
717
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Sounds
onceSounds
once
(Displayed alternately)(Flashes)
An attempt was
made to exit the
vehicle with the
electronic key and
lock the doors
without first turn-
ing the “ENGINE
START STOP”
switch off.
Tu r n t h e
“ENGINE START
STOP” switch off
and lock the
doors again.
Sounds
once
(Flashes)
An attempt was
made to start the
engine without
the electronic key
being present, or
the electronic key
was not function-
ing normally.
An attempt was
made to drive
when the regular
key was not inside
the vehicle.
Confirm that the
electronic key is
inside the vehicle.
InteriorbuzzerExterior buzzerWa r n i n g m e s s a g eDetailsCorrection
procedure
GX460_OM_OM60J63U_(U).book Page 717 Thursday, March 29, 2012 9:10 AM

718
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Con-
tinuous
(Flashes)
The driver’s door
was opened when
the shift lever was
not in P and the
“ENGINE START
STOP” switch was
not turned off.
Shift the shift lever
to P.
Con-
tinuousCon-
tinuous
(Displayed alternately)(Flashes)
The driver’s door
was opened and
closed while the
electronic key was
not in the vehicle,
the shift lever was
not in P and the
“ENGINE START
STOP” switch was
not turned off.
• Shift the shift lever to P.
• Bring the elec- tronic key back
into the vehicle.
InteriorbuzzerExterior buzzerWarning messageDetailsCorrection
procedure
GX460_OM_OM60J63U_(U).book Page 718 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
719
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Sounds
onceCon-
tinuous
(Flashes)
An attempt was
made to lock the
doors using the
smart access sys-
tem with push-
button start while
the electronic key
was still inside the
vehicle.
Retrieve the elec-
tronic key from
the vehicle and
lock the doors
again.
An attempt was
made to lock
either front door
by opening a door
and putting the
inside lock button
into the lock posi-
tion, then closing
the door with the
electronic key still
inside the vehicle.
InteriorbuzzerExterior buzzerWa r n i n g m e s s a g eDetailsCorrection
procedure
GX460_OM_OM60J63U_(U).book Page 719 Thursday, March 29, 2012 9:10 AM
