Lexus GX460 2013 Owner's Manual

720
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Sounds
once
(Flashes)
• When the doors were unlocked
with the
mechanical key
and then the
“ENGINE
START STOP”
switch was
pressed, the
electronic key
could not be
detected in the
vehicle.
• The electronic
key could not be
detected in the
vehicle even
after the
“ENGINE
START STOP”
switch was
pressed two
consecutive
times.
Touch the elec-
tronic key to the
“ENGINE START
STOP” switch
while depressing
the brake pedal.
InteriorbuzzerExterior buzzerWarning messageDetailsCorrection
procedure
GX460_OM_OM60J63U_(U).book Page 720 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
721
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Sounds
once
(Flashes)
An attempt was
made to start the
engine with the
shift lever in an
incorrect position.
Shift the shift lever
to P and start the
engine.
Sounds
once
(Flashes)
An attempt was
made to turn the
“ENGINE START
STOP” switch off
when the shift
lever was not in P.To turn off the
engine, first shift
the shift lever to P
and then turn the
“ENGINE START
STOP” switch off.
InteriorbuzzerExterior buzzerWa r n i n g m e s s a g eDetailsCorrection
procedure
GX460_OM_OM60J63U_(U).book Page 721 Thursday, March 29, 2012 9:10 AM

722
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)

Power was turned
off due to the
automatic power
off function.
Next time when
starting the
engine, increase
the engine speed
slightly and main-
tain that level for
approximately 5
minutes to
recharge the bat-
tery.
Sounds
onceThe electronic key
has a low battery.Replace the elec-
tronic key battery.
(→ P. 6 5 2 )
Interior
buzzerExterior buzzerWarning messageDetailsCorrection
procedure
GX460_OM_OM60J63U_(U).book Page 722 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
723
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Sounds
once
(Flashes)
The driver’s door
was opened and
closed with the
“ENGINE START
STOP” switch
turned off and
then the
“ENGINE START
STOP” switch was
put in ACCES-
SORY mode
twice without the
engine being
started.
Press the
“ENGINE START
STOP” switch
while depressing
the brake pedal.
During an engine
starting proce-
dure in the event
that the elec-
tronic key was not
functioning prop-
erly (→P. 744),
the “ENGINE
START STOP”
switch was
touched with the
electronic key.
Press the
“ENGINE START
STOP” switch
within 10 seconds
of the buzzer
sounding.
Interior
buzzerExterior buzzerWa r n i n g m e s s a g eDetailsCorrection
procedure
GX460_OM_OM60J63U_(U).book Page 723 Thursday, March 29, 2012 9:10 AM

724
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Sounds
once
(Flashes)
The steering lock
could not be
released within 3
seconds of the
“ENGINE START
STOP” switch
being pressed.
Press the
“ENGINE START
STOP” switch
while depressing
the brake pedal
and moving the
steering wheel left
and right.
InteriorbuzzerExterior buzzerWarning messageDetailsCorrection
procedure
GX460_OM_OM60J63U_(U).book Page 724 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
725
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Other messagesIf the following message is displayed, take appropriate action and confirm
that the message has disappeared. (→ P. 3 3 2 )
MessageCorrection procedure
(If equipped)
Select the four-wheel driving position switch in L4
and shift the shift lever to D or R.
(If equipped)
Confirm the operating conditions.
■Warning light display in radar cruise mode (if equipped)
In the following cases, the warning light may not be displayed even if vehicle-to-
vehicle distance decreases:
●When your vehicle and the vehicle ahead are traveling at the same speed or the
vehicle ahead is traveling more quickly than your vehicle
●When the vehicle ahead is traveling at a very low speed
●Immediately after cruise control speed is set
●At the instant the accelerator pedal is depressed
GX460_OM_OM60J63U_(U).book Page 725 Thursday, March 29, 2012 9:10 AM

726
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
If you have a flat tire
Remove the flat tire and replace it with the spare provided.
■Before jacking up the vehicle
●Stop the vehicle on a hard, flat surface.
● Set the parking brake.
● Shift the shift lever to P.
● Vehicles with rear height control air suspension: Turn off the
height control. ( →P. 320)
● Stop the engine.
● Turn on the emergency flashers. (→ P. 6 8 4 )
■ Location of the spare tire, jack and tools
Spare tire
Jack
Tool box
GX460_OM_OM60J63U_(U).book Page 726 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
727
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Taking out the jackRemove the cover.
Unhook the rubber band and take
out the jack.For loosening
For tightening
STEP1
STEP2
GX460_OM_OM60J63U_(U).book Page 727 Thursday, March 29, 2012 9:10 AM

728
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Taking out the tool boxRemove the cover.
Take out the tool box.
STEP1
STEP2
GX460_OM_OM60J63U_(U).book Page 728 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
729
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Taking out the spare tireAssembling the jack handle.
Remove the jack handle extension bar from the tool box and
assemble by following these steps. Loosen the bolt and the screw
using either the jack handle end
or a screwdriver.
Assemble the jack handle
extension bar and the jack han-
dle and tighten the bolt and the
screw.
Check that the bolt and screw are
firmly tightened.
Remove the spare tire carrier lid
using a flathead screwdriver.
STEP1
STEP2
GX460_OM_OM60J63U_(U).book Page 729 Thursday, March 29, 2012 9:10 AM
