5417-2. Steps to take in an emergency
GX460_OM_OM60R27U_(U)
7
When trouble arises
Ensure that the shift lever is in P and depress the brake pedal.
Touch the Lexus emblem side of the
electronic key to the engine switch.
When the electronic key is detected, a
buzzer sounds and the engine switch
will turn to IGNITION ON mode.
When the smart access system with
push-button start is deactivated in cus-
tomization setting, the engine switch will
turn to ACCESSORY mode.
Firmly depress the brake pedal and check that is shown on the multi-
information display.
Press the engine switch shortly and firmly.
In the event that the engine still cannot be started, contact your Lexus dealer.
■Stopping the engine
Shift the shift lever to P and press the engine switch as you normally do when stopping
the engine.
■Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the electronic
key battery be replaced immediately when the battery is depleted. ( P. 484)
■Changing engine switch modes
Within 10 seconds of the buzzer sounding, release the brake pedal and press the engine
switch.
The engine does not start and modes will be changed each time the switch is pressed.
(  P. 197)
■When the electronic key does not work properly
●Make sure that the smart access system wi th push-button start has not been deacti-
vated in the customization setting. If it is off, turn the function on.
(Customizable features:  P. 576)
●Check if battery-saving mode is set. If it is set, cancel the function. (P. 123)
Starting the engine
1
2
3
4

576
GX460_OM_OM60R27U_(U)8-2. Customization
Customizable features
■Changing by using the multi-information display
Press or of the meter control switches, select .
Press or of the meter control switches, select the item or the
desired setting, and then press .
To go back to the previous screen, press .
■Changing by using the multimedia system or navigation system Press the “SETUP” button on the multim edia system or navigation system.
Select “Vehicle” on the “Setup” screen and select “Vehicle Customization”.
Various setting can be changed. Refer to the list of settings that can be
changed for details.
Your vehicle includes a variety of elec tronic features that can be personalized
to suit your preferences. The settings of these features can be changed by
using the multi-information display, the multimedia system or navigation sys-
tem or at your Lexus dealer.
Customizing vehicle features
1
2
1
2

GX460_OM_OM60R27U_(U)
5778-2. Customization
8
Vehicle specifications
Some function settings are changed simultaneously with other functions being
customized. Contact your Lexus dealer for further details.
Settings that can be changed us ing the multi-information display
Settings that can be changed using the multimedia system or navigation sys-
tem
Settings that can be changed by your Lexus dealer
Definition of symbols: O = Available, – =Not available
■Multi-information display ( P. 91)
*1: The customized setting varies according to country.
*2: The default setting varies according to countries.
*3: Some status screens cannot be registered (indicated on the multi-information display)
■LDA (Lane Departure Alert) ( P. 246)
Customizable features
1
2
3
FunctionDefault settingCustomized
setting
LanguageEnglishFrench*1
O—OSpanish
Units*2miles (MPG US)km (km/L)O—Okm (L/100km)
Eco Driving Indicator LightOnOffO—O
switch settingsDrive information 1Desired status screen
*3O——
123
FunctionDefault
settingCustomized setting
Adjust alert type(Steering
vibration)(Buzzer)O——
Alert sensitivityStandardHighO——
Vehicle sway warning func-
tionOnOffO——
Vehicle sway warning sensi-
tivityStandardLowO——High
123

584
GX460_OM_OM60R27U_(U)8-2. Customization
■Intuitive parking assist* (P. 266)
*: If equipped
■In the following situations, customize mode will automatically be turned off.
●A warning message appears after the cu
stomize mode screen is displayed.
●The engine switch is turned to OFF.
●The vehicle begins to move while the customize mode screen is displayed.
FunctionDefault settingCustomized
setting
Intuitive parking assistOnOffO——
Buzzer volumeLevel 3Level 1 to 5—OO
Display settingAll sensors displayedDisplay off—OO
Detection distance of the
front center sensorFarNear—OO
Detection distance of the
rear center sensorFarNear—OO
123
WARNING
■During customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures.

605What to do if... (Troubleshooting)
GX460_OM_OM60R27U_(U)
●Is the electronic key left inside the vehicle or the moon roof opened?
Check the message on the multi-information display. (P. 520)
●When a warning light turns on or a warning message is displayed, refer to
P. 511, 520.
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
( P. 524)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
(P. 549)
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

608Alphabetical index
GX460_OM_OM60R27U_(U)
Console box ........................................... 396
Cool box .................................................. 409
Cooling system ..................................... 455Engine overheating.......................... 546
Conversation mirror ............................. 412
Crawl Control ....................................... 344
Cruise control Dynamic radar cruise control......254
Cup holders ............................................ 398
Curtain shield airbags ........................... 36
Current fuel consumption ................... 93
Customizable features ....................... 576
DAC (Downhill Assist Control system)................................................... 348
Daytime running light system ........... 210
Defogger Front windshield ................................ 380
Outside rear view mirrors .............. 381
Rear window ......................................... 381
Differential ............................................... 557
Dimension ............................................... 552
Display Drive information .................................. 93
Multi-information display ....................91
Warning message ............................ 520
Do-it-yourself maintenance ............. 447
Doors.......................................................... 104 Back door ................................................... 111
Door glasses ......................................... 156
Door lock ................................................ 104
Open door warning light................ 513
Outside rear view mirrors .............. 153
Rear door child-protector.............. 107
Drive information .................................... 93
Drive-Start Control ...............................166 Driver’s seat position memory............141
Driving ........................................................ 164
AVS switch ........................................... 339
Break-in tips ...........................................166
Correct posture .................................... 28
Procedures .............................................164
Winter drive tips ................................ 367
Dynamic radar cruise control ..........254
Eco Driving Indicator .............................96
EDR (Event data recorder)................... 10
Electronic key ......................................... 100 Battery-saving function .................... 123
If the electronic key does not operate properly ............................540
Replacing the battery ...................... 484
Emergency, in case of If the electronic key does not operate properly ............................540
If the engine will not start ...............538
If the vehicle has discharged battery ........................ 543
If the vehicle is trapped in rising water.....................................................502
If the warning buzzer sounds ......... 511
If the warning light turns on ............. 511
If you have a flat tire .......................... 524
If you lose your keys................. 101, 103
If you think something is wrong.................................................. 509
If your vehicle becomes stuck...................................................... 549
If your vehicle needs to be towed ...................................................503
If your vehicle overheats ................ 546
D
E

612Alphabetical index
GX460_OM_OM60R27U_(U)
MaintenanceDo-it-yourself maintenance.......... 447
Maintenance data ............................. 552
Maintenance requirements.......... 440
Resetting the message indicating maintenance is
required................................................ 441
Malfunction indicator lamp ................. 511
Meter Indicators................................................... 82
Instrument panel light control .........89
Meters........................................................ 88
Multi-information display ....................91
Warning lights ........................................ 82
Micro dust and pollen filter ............... 381
Mirrors Inside rear view mirror ....................... 151
Outside rear view mirror defoggers ............................................ 381
Outside rear view mirrors .............. 153
Vanity mirrors ......................................... 411
Moon roof................................................. 159 Jam protection function ................... 160
Operation ............................................... 159
MP3 disc
*
Multi-information display .......................91 BSM (Blind Spot Monitor)............357
Crawl Control .....................................344
Display contents ......................................91
Drive information .................................. 93
Dynamic radar cruise control......254
Intuitive parking assist ...................... 267
Language ............................................... 577
LDA (Lane Departure Alert) .......249
Multi-terrain Select............................284
Warning message ............................ 520 Multi-terrain Monitor ......................... 288
Multi-terrain Select ............................. 284
Navigation system
*
Odometer .................................................. 88
Off-road precautions ......................... 370
Oil
Engine oil ...............................................554
Front differential oil ........................... 557
Rear differential oil ............................ 557
Transfer.................................................. 558
Opener Back door..................................................112
Fuel filler door.......................................227
Hood........................................................450
Outside rear view mirrors .................. 153 Adjusting and folding ........................153
Blind Spot Monitor ........................... 357
Outside rear view mirror defoggers............................................ 381
Outside temperature display ............. 88
Overheating, Engine .......................... 546
Parking assist sensors (intuitive parking assist)...................266
Parking brake ........................................ 208 Operation..............................................208
Parking brake engaged warning buzzer ...............................208
Parking lights Light switch........................................... 209
Replacing light bulbs ....................... 497
M
N
O
P
