service indicator Lexus GX460 2021 Owner's Manual /

711-2. LEXUS Enform
GX460_OM_OM60T19U_(U)
1
For safety and security
LEXUS Enform Safety Connect
Microphone
LED light indicators
“SOS” button
: If equipped
Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embe dded cellular technology to provide
safety and security features to subscribers. Safety Connect is supported by
Lexus’ designated response center, wh ich operates 24 hours per day, 7 days
per week.
Safety Connect service is available by su bscription on select, telematics hard-
ware-equipped vehicles.
By using the Safety Connect service, you are agreeing to be bound by the
Telematics Subscription Service Agre ement and its Terms and Conditions, as
in effect and amended from time to time, a current copy of which is available
at Lexus.com. All use of the Safety Co nnect service is subject to such then-
applicable Terms and Conditions.
System components
1
2
3

731-2. LEXUS Enform
GX460_OM_OM60T19U_(U)
1
For safety and security
■Safety Connect Serv ices Information
●Phone calls using the vehicle’s Bluetooth® technology will not be possible during
Safety Connect.
●Safety Connect is available be ginning Fall 2009 on select Lexus models (in the contig-
uous United States only). Contact with th e Safety Connect response center is depen-
dent upon the telematics device being in operative condition, cellular connection
availability, and GPS sa tellite signal reception, which can limit the ability to reach the
response center or receive emergency se rvice support. Enrollment and Telematics
Subscription Service Agreement required. A variety of subscription terms is available;
charges vary by subscription term selected and location.
●Automatic Collision Notification, Emergenc y Assistance and Stolen Vehicle Location
will function in the United States, includin g Hawaii and Alaska, Puerto Rico and in Can-
ada, and Enhanced Roadside Assistance will function in the United States, Puerto Rico
and in Canada.
●Automatic Collision Notification, Emergenc y Assistance, Stolen Vehicle and Enhanced
Road Assistance will not function in the United States Virgin Islands.
For vehicles first sold in the USVI, no Safety Connect services will function in and out-
side the United States Virgin Islands.
●Safety Connect services are not subject to section 255 of the Telecommunications Act
and the device is not TTY compatible.
■Languages
The Safety Connect response ce nter will offer support in multiple languages. The Safety
Connect system will offer voice prompts in En glish, Spanish, and French. Please indicate
your language of ch oice when enrolling.
■When contacting the response center
You may be unable to contact the resp onse center if the network is busy.
When the engine switch is turned to IGNITION ON mode, the red indicator
light comes on for 2 seconds then turns off. Afterward, the green indicator light
comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage conditions:
●Green indicator light on = Active service
●Green indicator light flashing = Safety Connect call in process
●Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)
●No indicator light (off) = Safety Connect service not active
Safety Connect LED light Indicators

454
GX460_OM_OM60T19U_(U)6-2. Maintenance
Emission inspection and maintenance (I/M) programs
The OBD system determines that a problem exists somewhere in the emission
control system. Your vehicle may not pass the I/M test and may need to be
repaired. Contact your Lexus dealer to service the vehicle.
●When the battery is disconnected or discharged
Readiness codes that are set duri
ng ordinary driving are erased.
Also, depending on your driving habits , the readiness codes may not be com-
pletely set.
●When the fuel tank cap is loose
The malfunction indicator lamp comes on indicating a temporary malfunction
and your vehicle may not pass the I/M test.
The error code in the OBD system will not be cleared unless the vehicle \
is driven
40 or more times.
Contact your Lexus dealer to pr epare the vehicle for re-testing.
Some states have vehicle emission inspection programs which include OBD
(On Board Diagnostics) checks. The OBD system monitors the operation of
the emission control system.
If the malfunction indicator lamp comes on
Your vehicle may not pass the I/M te st in the following situations:
When the malfunction indicator lamp still remains on after several driv-
ing trips
If your vehicle does not pass the I/M test

GX460_OM_OM60T19U_(U)
5718-1. Specifications
8
Vehicle specifications
■Non-recommendation of the use of blended gasoline
●If you use gasohol in your vehicle, be sure that it has an octane rating no lower than 91.
●Lexus does not recommend the use of gasoline containing methanol.
■Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancing additive called MMT (Methylcy clopenta-
dienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasoline that contains MMT. If fuel containing
MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instru ment cluster may come on. If this happens,
contact your Lexus dealer for service.
■If your engine knocks
●Consult your Lexus dealer.
●You may occasionally notice light knocking for a short time while accelerating or driv-
ing uphill. This is normal and there is no need for concern.
●Use only gasoline containing up to 15% etha-
nol.
DO NOT use any flex-fuel or gasoline that
could contain more than 15% ethanol, includ-
ing from any pump labeled E30, E50, E85
(which are only some examples of fuel con-
taining more than 15% ethanol).DO NOT use gasoline con-
taining more than 15% ethanol.
(30% ethanol)
(50% ethanol)
(85% ethanol)

622Alphabetical index
GX460_OM_OM60T19U_(U)
Seat heaters ............................................ 398
Seat ventilators ...................................... 399
Seat position memory...........................145
Seats...................................................132, 134Adjustment ................................... 132, 134
Adjustment precautions ........ 133, 144
Child seats/child restraint system installation............................. 58
Cleaning .................................................445
Driving position memory ................ 145
Head restraint ....................................... 150
Properly sitting in the seat ................ 28
Seat position memory....................... 145
Ventilators ............................................ 399
Sensor Automatic headlight system ...........214
Automatic High Beam system ..... 216
Inside rear view mirror ..................... 156
Intuitive parking assist-sensor .....270
LDA (Lane Departure Alert) ...... 250
Radar sensor ........................................ 234
Rain-sensing windshield wipers ................................................... 224
Service reminder indicators ............... 84
Shift lever Automatic transmission ................. 206
If the shift lever cannot be shifted from P .................................. 209
Shift lock system....................................208
Side airbags ............................................... 36
Side mirrors .............................................. 157 Adjusting and folding........................ 157
Blind Spot Monitor............................. 361 Side turn signal lights ..............................211
Replacing light bulbs ...................... 505
Turn signal lever .....................................211
Smart access system with push-button start................................. 125 Antenna location.................................. 125
Starting the engine ............................200
Snow tires .................................................376
Spare tire ................................................... 531 Inflation pressure............................... 568
Storage location ................................. 532
Spark plug ............................................... 564
Specifications......................................... 560
Speedometer ............................................ 90
Steering lock Column lock release ....................... 203
Steering wheel ........................................ 153 Adjustment..............................................153
Audio switches
*
Heated steering wheel ................... 397
Steering wheel position memory.................................................145
Stop/tail lights Replacing light bulbs ...................... 505
Storage feature ..................................... 403
Stuck If the vehicle becomes stuck........556
Sunshade Roof ............................................................164
Sun visors................................................... 419
Switch Automatic High Beam switch ....... 216
AVS switch ........................................... 343
BSM (Blind Spot Monitor) switch ................................................... 362
Center differential lock/ unlock switch.................................... 345
