Lexus IS F 2011 Owner's Manual

113
1-7. Safety information
1
Before driving
IS F_EE
CAUTION
SRS airbag precautions
Do not lean against the door, the roof
side rail or the front, side and rear pil-
lars.
Do not allow anyone to kneel on the
passenger seat toward the door or put
their head or hands outside the vehicle.
Do not attach anything to or lean any-
thing against areas such as the dash-
board, steering wheel pad or lower
portion of the instrument panel.
These items can become projectiles
when SRS driver, front passenger and
knee airbags deploy.
Do not attach anything to areas such as
the door, windshield glass, side door
glass, front and rear pillars, roof side
rail or assist grip.
Do not hang coat hangers or other hard
objects on the coat hooks. All of these
items could become projectiles and
seriously injure or kill you, should the
SRS curtain shield airbag deploy.

114
1-7. Safety information
IS F_EE
CAUTION
SRS airbag precautions
If a vinyl cover is put on the area where the SRS knee airbag will deploy,
be sure to remove it.
Do not use seat accessories which cover the parts where the SRS side air-
bags inflate as they may interfere with inflation of the airbags.
Do not strike or apply significant levels of force to the area of the SRS air-
bag components shown on P. 106.
Doing so can cause the SRS airbags to malfunction.
Do not touch any of the component parts immediately after the SRS air-
bags have deployed (inflated) as they may be hot.
If breathing becomes difficult after the SRS airbag has deployed, open a
door or window to allow fresh air in, or leave the vehicle if it is safe to do
so. Wash off any residue as soon as possible to prevent skin irritation.
If the areas where the SRS airbags are stored, such as the steering wheel
pad and front pillar garnish, are damaged or cracked, have them replaced
by any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.

115
1-7. Safety information
1
Before driving
IS F_EE
CAUTION
Modification and disposal of SRS airbag system components
Do not dispose of your vehicle or perform any of the following modifica-
tions without consulting any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional.
The SRS airbags may malfunction or deploy (inflate) accidentally, causing
death or serious injury.
Installation, removal, disassembly and repair of the SRS airbags
Repairs, modifications, removal or replacement of the steering wheel,
instrument panel, dashboard, seats or seat upholstery, front, side and rear
pillars or roof side rails.
Repairs or modifications of the front fender, front bumper, or side of the
occupant compartment
Installation of snow plows, winches, etc. to the front grille (bull bars, kan-
garoo bar etc.)
Modifications to the vehicle's suspension system
Installation of electronic devices such as an RF-transmitter system or CD
players
Modifications to your vehicle for a person with a physical disability

116
1-7. Safety information
IS F_EE
Child restraint systems
Points to remember
Studies have shown that installing a child restraint on a rear seat is
much safer than installing one to the front passenger seat.
Choose a child restraint system appropriate to the age and size of
the child.
For installation details, follow the instructions provided with the
child restraint system.
General installation instructions are provided in this manual.
(P. 124)
Lexus recommends that you use a child restraint system which
conforms to the regulation “ECE No.44”.
Types of child restraints
Child restraint systems are classified into the following 5 groups
according to the regulation ECE No.44.
Group 0: Up to 10 kg (22 lb.) (0 - 9 months)
Group 0
+: Up to 13 kg (28 lb.) (0 - 2 years)
Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years)
Group II: 15 to 25 kg (34 to 55 lb.) (4 years - 7 years)
Group III: 22 to 36 kg (49 to 79 lb.) (6 years - 12 years)
In this owner's manual, the following popular 3 types of child
restraint systems that can be secured with the seat belts are
explained.
Lexus strongly urges the use of child restraint systems.

117
1-7. Safety information
1
Before driving
IS F_EEBaby seat
Equal to Group 0 and 0
+ of
ECE No.44
Child seat
Equal to Group 0
+ and I of ECE
No.44
Junior seat
Equal to Group II and III of
ECE No.44

118
1-7. Safety information
IS F_EE
Child restraint system suitability for various seating positions
Provided information in the table shows your child restraint system
suitability for various seating positions.
Front passenger seat
Rear seat Airbag manual on-off
switch
On
Off
0
Up to 10 kg (22 lb.)
(0 - 9 months)X
Never putL1 L1
0
+
Up to 13 kg (28 lb.)
(0 - 2 years)X
Never putL1 L1
I
9 to 18 kg
(20 to 39 lb.)
(9 months - 4 years)L2 L2
II, III
15 to 36 kg
(34 to 79 lb.)
(4 - 12 years)L3 L3
Mass groupsSeating posi-

119
1-7. Safety information
1
Before driving
IS F_EEKey of letters inserted in the above table:
L1: Suitable for “LEXUS BABY-SAFE (0 to 13 kg [0 to 28 lb.])”
approved for the use in this mass group.
L2: Suitable for “LEXUS DUO+ (without ISOFIX, 9 to 18 kg [20
to 39 lb.])” approved for the use in this mass group.
L3: Suitable for “LEXUS KID (15 to 36 kg [34 to 79 lb.])”
approved for the use in this mass group.
X: Not suitable seat position for children in this mass group.
The child restraint systems mentioned in the table may not be
available outside of the EU area.
Other child restraint systems different from the systems mentioned
in the table can be used, but the suitability of the systems must be
carefully checked with the child restraint system manufacturer and
retailer.

120
1-7. Safety information
IS F_EE
Child restraint system suitability for various seating positions
(with ISOFIX rigid anchor)
Provided information in the table shows your child restraint system
suitability for various seating positions.
Mass groups Size class FixtureVehicle ISOFIX
positions
CarrycotF
ISO/L1X
G
ISO/L2X
(1) X
0
Up to 10 kg (22
lb.)
(0 - 9 months)E
ISO/R1X
(1) X
0
+
Up to 13 kg (28
lb.)
(0 - 2 years)E
ISO/R1X
D
ISO/R2X
C
ISO/R3X
(1) X
I
9 to 18 kg
(20 to 39 lb.)
(9 months - 4
years)D
ISO/R2X
C
ISO/R3X
B
ISO/F2IUF
B1
ISO/F2XX
A
ISO/F3X
(1) X
II, III
15 to 36 kg
(34 to 79 lb.)
(4 12 years)(1) X

121
1-7. Safety information
1
Before driving
IS F_EE(1) For CRS which do not carry the ISO/XX size class identifica-
tion (A to G), for the applicable mass group, the car manufac-
turer shall indicate the vehicle specific ISOFIX child restraint
system(s) recommended for each position.
Key of letters inserted in the above table:
IUF:Suitable for ISOFIX forward child restraints systems of uni-
versal category approved for use in this mass group.
X: ISOFIX position not suitable for ISOFIX child restraint sys-
tems in this mass group and/or this size class.
The child restraint systems mentioned in the table may not be
available outside of the EU area.
Other child restraint systems different from the systems mentioned
in the table can be used, but the suitability of the systems must be
carefully checked with the child restraint system manufacturer and
retailer.

122
1-7. Safety information
IS F_EE
When installing the child restraint system on the front passenger seat
Selecting an appropriate child restraint system
Get an appropriate child restraint system for the child. If a child is too large
for a child restraint system, sit the child on a rear seat and use the vehicle's
seat belt.
(P. 7 0 )
CAUTION
Using a child restraint system
The use of a child restraint system not suitable for the vehicle may not prop-
erly secure the infant or child, resulting in serious injury or even death.
Child restraint precautions
For effective protection in automobile accidents and sudden stops, a child
must be properly restrained, using a seat belt or child restraint system
depending on the age and size of the child. Holding a child in your arms is
not a substitute for a child restraint system. In an accident, the child can be
crushed against the windshield, or between you and the vehicle's interior.
Lexus strongly urges the use of a proper child restraint system that con-
forms to the size of the child, installed on the rear seat. According to acci-
dent statistics, the child is safer when properly restrained in the rear seat
than in the front seat.
When you have to use a child restraint
system in the front passenger seat, adjust
the seatback to the most upright position
and adjust the seat cushion to the upper-
most position.
