1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
IS F_EE
Outside rear view mirrors
Folding back the mirrors
Press the button to fold back the
mirrors
Push once more to return to the
original position.
Mirror angle can be adjusted using the switch when the “ENGINE
START STOP” switch is in ACCESSORY or IGNITION ON mode.
Select a mirror to adjust
(“L”: left or “R”: right)
Adjust the mirror up,
down, in, or out using the
switch

82
1-3. Adjustable components (seats, mirrors, steering wheel)
IS F_EE
The mirrors can be operated when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION
ON mode.
When the mirrors are fogged up
Turn on the mirror defoggers to defog the mirrors. (P. 236)
One-touch adjustment of the mirror angle
A desired mirror face angle can be entered to memory and adjusted with the
touch of a button. (P. 6 2 )
Linked mirror function when reversing
The outside rear view mirrors will automatically angle downwards when the
vehicle is reversing in order to give a better view of the ground. However,
this function will not operate when the mirror select switch is in the neutral
position (between “L” and “R”).
Auto anti-glare function
When the anti-glare inside rear view mirror is set to automatic mode, the
outside rear view mirrors will activate in conjunction with the anti-glare
inside rear view mirror to reduce reflected light. (P. 7 9 )

82
IS F_EE
1-4. Opening and closing the windows and moon roof
Power windows
Lock switch
Press the switch down to lock
the passenger window switches.
Use this switch to prevent chil-
dren from accidentally opening
or closing a passenger window.
The passenger windows can still
be opened and closed using the
driver’s switch even if the lock
switch is on.
The power windows can be opened and closed using the following
switches.
Closing
One-touch closing
*
Opening
One-touch opening
*
*:Pushing the switch in the
opposite direction will stop
window travel partway.
The power windows can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
Door lock linked window operation
The power windows can be opened and closed using the mechanical key.
(P. 458)
The power windows can be closed using the entry function. (P. 3 7 )

83
1-4. Opening and closing the windows and moon roof
1
Before driving
IS F_EE
Operating the power windows after turning the “ENGINE START STOP”
switch OFF
The power windows can be operated for approximately 45 seconds even
after the “ENGINE START STOP” switch is switched to ACCESSORY
mode or turned OFF. They cannot, however, be operated once either front
door is opened.
Jam protection function
If an object becomes caught between the window and the window frame,
window travel is stopped and the window is opened slightly.
When the power window does not close normally
If the jam protection function is operating abnormally and a window cannot
be closed, perform the following operations using the power window switch
on the relevant door.
After stopping the vehicle, the window can be closed by holding the
power window switch in the one-touch closing position while the
“ENGINE START STOP” switch is turned to IGNITION ON mode.
If the window still cannot be closed even by carrying out the operation
explained above, initialize the function by performing the following pro-
cedure.
Hold the power window switch in the one-touch closing position.
Continue holding the switch for a further 6 seconds after the win-
dow has closed.
Hold the power window switch in the one-touch opening position.
Continue holding the switch for a further 2 seconds after the win-
dow has opened completely.
Hold the power window switch in the one-touch closing position
once again. Continue holding the switch for a further 2 seconds
after the window has closed.
If you release the switch while the window is moving, start again from the
beginning. If the window continues to close but then re-open slightly even
after performing the above procedure correctly, have the vehicle inspected
by any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Customization that can be configured at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional
Settings (e.g. linked door lock operation) can be changed.
(Customizable features P. 484)
STEP1
STEP2
STEP3

86
1-4. Opening and closing the windows and moon roof
IS F_EE
The moon roof can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
Door lock linked moon roof operation
The moon roof can be opened and closed using the mechanical key.
( P. 458)
The moon roof can be closed using the entry function. (P. 3 7 )
Operating the moon roof after turning the “ENGINE START STOP” switch
OFF
The moon roof can be operated for approximately 45 seconds even after the
“ENGINE START STOP” switch is switched to ACCESSORY mode or
turned OFF. It cannot, however, be operated once either front door is
opened.
Jam protection function
If an object is detected between the moon roof and the frame while closing
or tilting down, travel is stopped and the moon roof opens slightly.
To reduce moon roof wind noise
Drive with the moon roof opened to slightly before the fully open position
as driving with the moon roof opened fully will cause wind noise.
Sunshade
The sunshade can be opened and closed manually. However, the sunshade
will open automatically when the moon roof is opened.

92
IS F_EE
1-6. Theft deterrent system
Engine immobilizer system
System maintenance
The vehicle has a maintenance-free type engine immobilizer system.
Conditions that may cause the system to malfunction
If the key is in contact with a metallic object
If the key is in close proximity to or touching a key to the security sys-
tem (key with a built-in transponder chip) of another vehicle
The vehicle's keys have built-in transponder chips that prevent the
engine from starting if the key has not been previously registered in
the vehicle's on-board computer.
Never leave the keys inside the vehicle when you leave the vehicle.
The indicator light flashes
after the “ENGINE START
STOP” switch has been
turned OFF to indicate that
the system is operating.
The indicator light stops
flashing after the “ENGINE
START STOP” switch has
been turned to ACCESSORY
or IGNITION ON mode to
indicate that the system has

135
1-7. Safety information
1
Before driving
IS F_EE
Airbag manual on/off system
Deactivating the front passenger airbags
This system deactivates the front passenger airbag, front passenger
knee airbag and front passenger side airbag.
Only deactivate the airbags when using a child restraint system on the
front passenger seat.
“PASSENGER AIRBAG”
indicator
This indicator turns on when
the airbag system is on.
(Only when the “ENGINE
START STOP” switch is in
IGNITION ON mode.)
Airbag manual on-off
switch

136
1-7. Safety information
IS F_EEInsert the mechanical key into
the cylinder and rotate to the
“OFF” position.
The “OFF” indicator turns on.
(Only when the “ENGINE
START STOP” switch is in
IGNITION ON mode.)
“PASSENGER AIRBAG” indicator information
If any of the following problems occurs, it is possible that there is a mal-
function in the system. Have the vehicle inspected by any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional.
Neither “ON” nor “OFF” comes on.
The indicator does not change when the airbag manual on-off switch is
switched to “ON” or “OFF”.
CAUTION
When installing a child restraint system
For safety reasons, always install the child restraint system in a rear seat. In
the event that the rear seat cannot be used, the front seat can be used as long
as the airbag manual on-off system is set to off.
If the airbag manual on-off system is left on, the strong impact of the airbag
deployment (inflation) may cause serious injury or even death.
When a child restraint system is not installed on the front passenger seat
Ensure that the airbag manual on-off system is set to on.
If it is left off, the airbag may not deploy in the event of an accident, which
may result in serious injury or even death.

2When driving
135
IS F_EE
2-1. Driving procedures
Driving the vehicle........... 136
Engine (ignition) switch... 145
Automatic transmission ... 149
Turn signal lever .............. 158
Parking brake ................... 159
Horn ................................. 160
2-2. Instrument cluster
Gauges and meters ........... 161
Indicators and warning
lights .............................. 164
Multi-information display 167
2-3. Operating the lights and
windshield wipers
Headlight switch.............. 172
Fog light switch ............... 175
Windshield wipers and
washer ............................ 176
Headlight cleaner switch .. 1792-4. Using other driving
systems
Cruise control .................. 180
Dynamic radar cruise
control ............................ 184
Lexus parking
assist-sensor ................... 199
Driving assist systems ..... 205
PCS (Pre-Crash Safety
system)............................ 211
2-5. Driving information
Cargo and luggage ........... 220
Winter driving tips ........... 222
Trailer towing .................. 225

146
2-1. Driving procedures
IS F_EE
Engine (ignition) switch
Performing the following operations when carrying the electronic key
on your person starts the engine or changes “ENGINE START STOP”
switch modes.
Starting the engine
Check that the parking brake is set.
Check that the shift lever is set in P.
Sit in the driver’s seat and firmly depress the brake pedal.
The “ENGINE START STOP” switch indicator turns green.
Press the “ENGINE START
STOP” switch.
The engine can be started
from any “ENGINE START
STOP” switch mode.
STEP1
STEP2
STEP3
STEP4
