Lexus IS F 2011 Owner's Manual

343
3-7. Other interior features
3
Interior features
IS F_EE
CAUTION
When not in use
Ensure that the inside trunk door is closed.
In the event of sudden braking, items stored in the trunk may be thrown for-
ward into the cabin, resulting in injury.

344
3-7. Other interior features
IS F_EE
Coat hooks
CAUTION
Items that must not be hung on the hook
Do not hang a coat hanger or other hard or sharp object on the hook. If the
SRS curtain shield airbags deploy, these items may become projectiles that
cause death or serious injury.
To use the coat hook, push it
in.

345
3-7. Other interior features
3
Interior features
IS F_EE
Floor mat
Use only floor mats designed specifically for vehicles of the same
model and model year as your vehicle. Fix them securely in place onto
the carpet.
Fix the floor mat in place
using the retaining hooks
(clips) provided.
The shape of the retaining
hooks (clips) and the fixing
procedure of the floor mat for
your vehicle may differ from
those shown in the illustra-
tion. For details, refer to the
floor mat retention clip

346
3-7. Other interior features
IS F_EE
CAUTION
Observe the following precautions.
Failure to do so may cause the driver's floor mat to slip, possibly interfering
with the pedals while driving. An unexpectedly high speed may result or it
may become difficult to stop the vehicle, leading to a serious accident.
When installing the driver's floor mat
Do not use floor mats designed for other models or different model year
vehicles, even if they are Lexus Genuine floor mats.
Only use floor mats designed for the driver's seat.
Always install the floor mat securely using the retaining hooks (clips) pro-
vided.
Do not use two or more floor mats on top of each other.
Do not place the floor mat bottom-side up or upside-down.
Before driving
Check that the floor mat is securely
fixed in the correct place with all the
provided retaining hooks (clips). Be
especially careful to perform this check
after cleaning the floor.
With the engine stopped and the shift
lever in P, fully depress each pedal to
the floor to make sure it does not inter-
fere with the floor mat.

347
3-7. Other interior features
3
Interior features
IS F_EE
Trunk features
Cargo hooks
Cargo hooks are provided for
securing loose items.
Shopping bag hooks
First-aid kit storage belt
Loosen
Tighten

348
3-7. Other interior features
IS F_EE
CAUTION
When the cargo hooks are not in use
To avoid injury, always return the cargo hooks to their positions when they
are not in use.
Warning triangle storage belt
Loosen
Tighten
Luggage mat
Pull the lever upwards when
lifting the luggage mat up.
The lever can be hooked on
the edge of the trunk.

349
3-7. Other interior features
3
Interior features
IS F_EE
NOTICE
When closing the trunk
Do not leave the luggage mat lever hooked on the edge of the trunk.
The luggage mat may get damaged.

4Maintenance and care
349
IS F_EE
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ........ 350
Cleaning and protecting
the vehicle interior ......... 353
4-2. Maintenance
Maintenance
requirements .................. 3564-3. Do-it-yourself
maintenance
Do-it-yourself service
precautions..................... 359
Hood ................................ 362
Positioning a floor jack .... 363
Engine compartment ........ 365
Tires ................................. 378
Tire inflation pressure ...... 381
Wheels ............................. 383
Air conditioning filter ...... 385
Electronic key battery ...... 388
Checking and replacing
fuses ............................... 390
Light bulbs ....................... 404

350
IS F_EE
4-1. Maintenance and care
Cleaning and protecting the vehicle exterior
Automatic car washes
Fold the mirrors back before washing the vehicle.
Brushes used in automatic car washes may scratch the vehicle surface
and harm your vehicle’s paint.
Turn the wipers off before washing the vehicle.
High pressure car washes
Do not allow the nozzles of the car wash to come within close proximity
of the windows.
Before car wash, check that the fuel filler door on your vehicle is closed
properly.
Touch-up paint (if equipped)
Touch-up paint may be used to cover small chips or scratches.
Apply the paint soon after the damage occurs or corrosion may set in. To
apply the touch-up paint so it is hardly noticeable the trick is to apply it only
to the bare spots. Apply only the smallest amount possible and do not paint
the surface around the scratch or chip.
Perform the following to protect the vehicle and maintain it in prime
condition.
Working from top to bottom, liberally apply water to the
vehicle body, wheel wells and underside of the vehicle to
remove any dirt and dust.
Wash the vehicle body using a sponge or soft cloth, such as
a chamois.
For hard-to-remove marks, use car wash soap and rinse
thoroughly with water.
Wipe away any water.
Wax the vehicle when the waterproof coating deteriorates.
If water does not bead on a clean surface, apply wax when the vehi-
cle body is cool.

351
4-1. Maintenance and care
4
Maintenance and care
IS F_EE
Aluminum wheels
Remove any dirt immediately by using a neutral detergent. Do not use
hard brushes or abrasive cleaners. Do not use strong or harsh chemical
cleaners.
Use the same mild detergent and wax as used on the paint.
Do not use detergent on the wheels when they are hot, for example after
driving for long distance in the hot weather.
Wash detergent from the wheels immediately after use.
Bumpers
Do not scrub with abrasive cleaners.
CAUTION
When cleaning the windshield
When the upper part of the windshield where the raindrop sensor is
located is touched by hand
When a wet rag or similar is held close to the raindrop sensor
If something bumps against the windshield
If you directly touch the raindrop sensor body or if something bumps into
the raindrop sensor
Exhaust pipes and rear bumper exhaust diffusers
Exhaust gasses cause the exhaust pipes and rear bumper exhaust diffusers to
become quite hot. Therefore, do not touch them while the engine is running
or immediately after turning the engine off.
When washing the vehicle, be careful not to touch the exhaust pipes and rear
bumper exhaust diffusers until they have cooled sufficiently, as touching hot
exhaust pipes and diffusers can cause burns.
Set the wiper switch to off.
If the wiper switch is in “AUTO”, the
wipers may operate unexpectedly in the
following situations, and may result in
hands being caught or other serious inju-
ries and cause damage to the wiper
blades.
Off
