INTERIOR EQUIPMENT
85
14L004a
Rear
14L044a
To turn on the personal light, push the switch. To
turn it off, push the switch again.

INTERIOR EQUIPMENT
86
IGNITION SWITCH LIGHT
14L006±1
For easy access to the ignition switch, the ignition
switch light comes on when any of the doors are
opened.
The light remains on for about 15 seconds and goes out
after all the doors are closed. However, the light goes
out immediately when all the doors are locked or the
ignition key is in the ºACCº or ºONº position.

INTERIOR EQUIPMENT
87
CLOCK
14L46
To reset the hour, press the ºHº button. To reset the
minutes, press the ºMº button. To adjust the time to
the nearest hour, press the º:00º button.
For example, if the º:00º button is pressed when the time
is between 9:30 ± 9:59 or between 10:01 ± 10:29, the
time will change to 10:00.
If the electrical power source has been disconnected
from the clock, the time display will automatically be set
to 1:00 (one o'clock).
For vehicles equipped with Navigation System, refer
to the separate ºOwner's Manual for Navigation
Systemº.

INTERIOR EQUIPMENT
88
OUTSIDE TEMPERATUREDISPLAY
14L026-4
This display shows the outside temperature when
the ignition switch is on.
The displayed temperature ranges from ±30 C (±22F)
up to 50C (122F). If the temperature does not appear
on the display or it shows º± ± ±º, take your vehicle to
your Lexus dealer.

INTERIOR EQUIPMENT
89
CIGARETTE LIGHTER ANDASHTRAY
14L010-2

Front cigarette lighter and ashtray
14L011-1

Rear cigarette lighter and ashtray

INTERIOR EQUIPMENT
90Open
the ashtray cover. To use the cigarette lighter,
press in the cigarette lighter. When it becomes
heated, it automatically pops out ready for use.
Do not hold the cigarette lighter pressed in.
If the engine is not running, the ignition key must be in
the ºACCº position.
When fini shed with your cigarette, thoroughly extinguish
it in the ashtray to prevent other cigarette butts from
catching fire. After using the ashtray, push it back in or
close the lid completely.
To remove the ashtray, just pull it up.
Use a Lexus genuine cigarette lighter or equivalent for
replacement.
CAUTION
To reduce the chance of injury in case of an accident or
sudden stop while driving, always close the ashtray
completely after using.

INTERIOR EQUIPMENT
91
POWER OUTLET
14L038±1
The power outlet is designed for power supply for
car accessories.
The ignition key must be in the ºACCº or ºONº position
for the power outlet to be used.NOTICE
To prevent the fuse from being blown, do notuse the electricity over the total vehiclecapacity of 3.5A/12V.
To prevent the battery from being discharged,do not use the power outlet longer thannecessary when the engine is not running.
Close the power outlet lid when the poweroutlet is not in use. Inserting a foreign objectother than the appropriate plug that fits theoutlet, or allowing any liquid into the outlet maycause electrical failure or short circuits.

INTERIOR EQUIPMENT
92
GLOVE BOX
14L037±1

1Unlock 2Open 3Lock
To open the glove box door, pull the lever. To lock
the glove box door, insert the master key and turn it
clockwise.
With the tail lights on, the glove box light will come on
when the glove box door is open.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the glove box door closed
while driving.

INTERIOR EQUIPMENT
93
GARAGE DOOR OPENER
The garage door opener is manufactured under
license from HomeLink and can be programmed
to operate garage doors, estate gates, security
lighting, etc.
(a) Programming HomeLink
14L040

INTERIOR EQUIPMENT
94

1Indicator light 2Buttons
The
HomeLink has 3 buttons and can be
programmed to operate 3 separate devices.
Prepare the HomeLink
 for programming by
erasing all codes or the memorized data
programmed by the former owner. Follow the
procedure in º(c) Erasing the garage door opener
memoryº.
1. Decide which one of the 3 buttons you want to
program. Push and hold down the button for about 20
seconds until the indicator light begins to flash. While
holding this button, follow steps º2º and º3º.
2. Bring the hand held garage door opener within about
25 mm (1 in.) of the button being programmed and push
the button on the hand held garage door opener. The
signal from the hand held garage door opener is sent to
the vehicle's opener.
3. When the frequency and code is registered, the
indicator light flashes rapidly. At this point, you can
release both buttons.
4. To program the remaining buttons, repeat steps º1º
through º3º.
If you want to replace an existing program with a new
program, select the button you want to program. Follow
the procedure from step 1.
If the transmitter has a ºrolling code featureº, it is
necessary to program the in±garage receiver after programming
HomeLink
.
1. Locate the ºtrainingº or ºlearningº button on the
in±garage receiver and push and release this
button. Location of the button may vary by the
garage door opener manufacturer.
2. Firmly push and release the trained HomeLink

button 2 times (some garage door manufacturer
may require you to push the HomeLink button up
to 3 times) to complete the process.
The garage door should now operate when the
HomeLink
 button is pushed.
