LEXUS LS500 2019 Owners Manual

3315-4. Using the interior lights
LS500_OM_(U)_1810 5
Interior features 5-4.Using the interior lights
Rear personal lights (  P.333)
Inside door handle lights
Instrument panel orname nt lights (if equipped)
Front personal lights (  P.333)
Front interi or lights (  P.332)
Clock light
Footwell lights
Engine switch light
Door trim ornament lights
Door courtesy lights
Seat belt buckle lights
Outer foot lights
Rear interior light (  P.332)
Shift lever lightsInterior lights list
Location of the interior lights
A
B
C
D
E
F
G
H
I
J
K
L
M
N

332 5-4. Using the interior lights
LS500_OM_(U)_1810 ■
Turning the door position on
Press the door-linked interior light
switch The lights are turned on and off according
to whether the doors are opened/closed.
When the door position is on, the indicator
illuminates.
■
Turning the lights on/off 
Front
Turns the lights on/off (touch the light) When a door is opened while the door
position is on, the lights turn on.

Rear (vehicles without a panoramic
moon roof)
On/off The rear interior light turns on/off together
the front interior lights.
When a door is opened while the door
position is on, the lights turn on. 
Rear (vehicles with a panoramic
moon roof)
On/off The rear interior light turns on/off together
the front interior lights.
When a door is opened while the door
position is on, the lights turn on.
■
Using the Rear Multi Operation
Panel (if equipped)
1 Display the home screen and then
touch “Rear Shade/Lamp”.
(  P.308)Operating the interior lights A

3335-4. Using the interior lights
LS500_OM_(U)_1810 5
Interior features 2 To turn on/off the rear interior
lights, touch the respective button.
■
Turning the lights on/off 
Front
Turns the lights on/off (touch the light) When a door is opened while the door
position is on, the lights turn on.

Rear (vehicles without a panoramic
moon roof)
On/dimmed/off When a door is opened while the door
position is on, the lights turn on. 
Rear (vehicles with a panoramic
moon roof)
On/dimmed/off When a door is opened while the door
position is on, the lights turn on.
■
Using the Rear Multi Operation
Panel (if equipped)
1 Display the home screen and then
touch “Rear Shade/Lamp”.
(  P.308)
2 To turn on/dimmed/off the rear per-
sonal lights, touch the respective
button.Operating the personal lights

334 5-4. Using the interior lights
LS500_OM_(U)_1810 ■
Illuminated entry system
The lights automatically turn on/off accord-
ing to the engine switch mode, the pres-
ence of the electronic key, whether the
doors are locked/unlocked, and whether
the doors are opened/closed. ■
To prevent the battery from being dis-
charged
If the interior lights remain on when the
engine switch is turned off, the lights will go
off automatically after 20 minutes. ■
When front interior light or front per-
sonal lights do not respond as normal●
When water, dirt, et c., have adhered to
the lens surface●
When operated with a wet hand●
When wearing gloves, etc.■
The interior lights may turn on automati-
cally when
If any of the SRS airbags deploy (inflate) or
in the event of a strong rear impact, the inte-
rior lights will turn on automatically.
The interior lights will turn off automatically
after approximately 20minutes.
The interior lights can be turned off manu-
ally. However, in order to help prevent fur-
ther collisions, it is recommended that they
be left on until sa fety can be ensured.
(The interior lights may not turn on auto-
matically depending on the force of the
impact and conditions of the collision.) ■
Customization
Some functions can be customized.
(  P.466)
NOTICE
■
To prevent battery discharge
Do not leave the lights on longer than
necessary when the engine is not run-
ning. ■
Removing light lenses
Never remove th e lens for the front inte-
rior light and front personal lights. Other-
wise, the lights will be damaged. If a lens
needs to be removed, contact your Lexus
dealer.

3355-5. Using the storage features
LS500_OM_(U)_1810 5
Interior features 5-5.Using the storage features

Vehicles without power rear seat
Glove box (  P.336)
Auxiliary boxes (  P.339)
Cup holders (  P.337)
Console box (  P.338)
Coin holder (  P.337)List of storage features
Location of the storage features
A
B
C
D
E

336 5-5. Using the storage features
LS500_OM_(U)_1810 
Vehicles with power rear seat
Glove box (  P.336)
Auxiliary boxes (  P.339)
Cup holders (  P.337)
Console box (  P.338)
Coin holder (  P.337)
1 Open (push button)
2 Unlock with the mechanical key
3 Lock with the mechanical keyA
B
C
D
E
WARNING■
Items that should not be left in the
storage spaces
Do not leave glasses, lighters or spray
cans in the storage spaces, as this may
cause the following when cabin tempera-
ture becomes high:
●
Glasses may be deformed by heat or
cracked if they come into contact with
other stored items.
●
Lighters or spray cans may explode. If
they come into contact with other
stored items, the lighter may catch fire
or the spray can may release gas,
causing a fire hazard. Glove box

3375-5. Using the storage features
LS500_OM_(U)_1810 5
Interior features ■
Glove box light
The glove box light turns on when the tail
lights are on. ■
Trunk opener main switch
The trunk opener main switch is located in
the glove box. (  P.110)■
Removing the partition
The partition inside the glove box can be
removed by pulling it.
Push the button. 
Front
Press in and release the button. 
Rear (vehicles without power rear
seat)
Pull the armrest down then push in the
cup holder trim to extend the cup hold-
ers.

Rear (vehicles with power rear seat)
Press in and release the button.WARNING■
Caution while driving
Keep the glove box closed. In the event
of sudden braking or sudden swerving,
an accident may occur due to an occu-
pant being struck by the open glove box
or the items stored inside.
Coin holder WARNING■
Caution while driving
Keep the coin holder closed.
Injuries may result in the event of an acci-
dent or sudden braking.
Cup holders

338 5-5. Using the storage features
LS500_OM_(U)_1810 ■
When stowing the rear cup holders
(vehicles without power rear seat)
Stow the cup holder with the armrest down.
The cup holder cannot be stowed if the
armrest is not down. Press a button to open the console box.
The console box can be opened from
either side.
■
Tray in the console box
The tray can be slid and removed. ■
Console box light
The console box light turns on when the tail
lights are on.WARNING■
Items unsuitable for the cup holder
Do not place anything other than cups or
beverage cans in the cup holders.
Inappropriate items must not be stored in
the cup holders even if the lid is closed.
Other items may be thrown out of the
holders in the event of an accident or
sudden braking and cause injury. If possi-
ble, cover hot drinks to prevent burns. ■
When not in use
Keep the cup holders closed.
Injuries may result in the event of an acci-
dent or sudden braking.
NOTICE
■
To prevent damage to the rear cup
holder (vehicles without power rear
seat)
Stow the cup holder before stowing the
armrest.
■
To avoid damaging the power outlet
Close the lid of the power outlet in the
front cup holder when the power outlet is
not in use. Foreign ob jects or liquids that
enter the power outlet may cause a short
circuit. Console box
WARNING
■
Caution while driving
Keep the console box closed.
Injuries may result in the event of an acci-
dent or sudden braking.
NOTICE
■
Tray
Do not insert items exceeding the height
of the tray. Doing so may prevent open-
ing and closing of the lid.

3395-5. Using the storage features
LS500_OM_(U)_1810 5
Interior features 
Overhead
Press in the button. This box is useful for temporarily storing
sunglasses and similar small items.

Rear seat (vehicles without power
rear seat)
Pull the armrest down then push the
knob and lift the lid to open it.

Rear seat (vehicles with power rear
seat)
Pull the armrest down then press the
button to open the lid.Auxiliary boxes WARNING■
Caution while driving
Do not leave the aux iliary box open while
driving.
Items may fall out and cause death or
serious injury in case of an accident or
sudden stop. ■
Items unsuitable for storing (over-
head)
Do not store items heavier than 0.4 lb.
(0.2 kg).
Doing so may cause the auxiliary box to
open and the items inside may fall out,
resulting in an accident.

340 5-5. Using the storage features
LS500_OM_(U)_1810 The cargo net is provided for securing
loose items on the floor or items inside
the trunk. Raise the cargo hooks on the floor.
Hook the net on the cargo hooks.

Side
Pull the strap upwards to lift the lug-
gage mat and remove it.Trunk features
Cargo net (if equipped)
WARNING
■
When the cargo net is not in use
To avoid injury, always return the cargo
hooks on the floor to their stowed posi-
tions. Shopping bag hooks
NOTICE■
To prevent damage to the grocery
bag hooks
Do not hang any object heavier than 11 lb.
(5 kg) on the grocery bag hooks.
Luggage mats
