LEXUS LX570 2014 Owners Manual

6113-4. Using the rear se at entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) ■
A/V input port
The rear seat entertainment system plays videos and sound when audio-video
equipment is connected to the A/V input port. For details, refer to the manufac-
turer’s instructions. ■
Powe r o u t l e t
The power outlet is used to connect the audio-video equipment. (  P. 7 0 1 )■
To turn off the display
■
LC D AI
The image quality is automatically adjust ed when the “LCD AI” indicator is on,
brightness and contrast adjustment becomes less effective.
NOTICE■
When the A/V input port is not in use
Keep the A/V input port cover closed.
Inserting anything other than an appropriat e plug may cause electrical failure or a
short circuit. Select “Screen off” on the screen.
To turn the display back on, press the
“SOURCE”, “DISC”, “VIDEO” or
“SETTING” button on the controller.

612
LX570_OM_OM60L21U_(U) 3-5. Using the hands-free system (for cellular phone)
Hands-free system (for cellular phone) The hands-free system is a function th at allows you to use your cellular
phone without touching it.
This system supports Bluetooth ®
cellular phones. Bluetooth ®
is a wireless
data system that allows a cellular phon e to wirelessly connect to the hands-
free system and outgoing/incoming calls.
The illustrations of the hands-free system screens shown here may slightly
vary depending on the type of the system.
■ Telephone switch
Off hook switch
• Sending
• Receiving
• “Phone” screen display
On hook switch
• End call
• Refuse call

6133-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L21U_(U) ■ Microphone
You can use the microphone
when talking on the phone.
The person you are speaking to
can be heard from the front
speakers.
To use the hands-free system, yo u must register your Bluetooth ®
phone in the system. (  P. 621)
■ Steering switch
Adjusting the volume Press “+” to increase the volume
and “-” to decrease the volume.

6143-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L21U_(U) Status display
You can check indicators such as signal strength an d battery charge on
the “Phone” screen.
Connection status
Battery charge
Call area
Signal strength
Indicators Conditions
Connection status Good No
connection
Battery charge Full Empty
Call area “Rm”: Roaming area
Signal strength Excellent Poor

6153-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L21U_(U) ■
When using the hands-free system ●
The audio system is muted when making a call. ●
If both parties speak at the same time, it may be difficult to hear.●
If the incoming call volume is overly loud, an echo may be heard. ●
Try to face toward the microphone as much as possible when speaking. ●
In the following circumstances, it may be difficult to hear the other party:
• When driving on unpaved roads
• When driving at high speeds
• If a window is open
• If the air conditioning is blowing directly on the microphone
• If the air conditioning is set to high
• There is an effect from the network of the cellular phone■
Conditions under which the system will not operate ●
If using a cellular phone that does not support Bluetooth ®
●
If the cellular phone is turned off ●
If you are outside service range ●
If the cellular phone is not connected ●
If the cellular phone’s battery is low■
When using the touch screen
Dimmed screen buttons cannot be operated.

6163-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L21U_(U) ■
Bluetooth ®
antenna
The antenna is built into the audio unit. If the cellular phone is behind the seat or in
the console box, or touching or covered by metal objects, connection status may
deteriorate. ■
Battery charge/Signal status ●
This display may not correspond exac tly with the cellular phone itself.●
When the cellular phone is not conn ected, “No connect” is displayed.●
When the cellular phone is out of the se rvice area or in a place inaccessible by
radio waves, “No Service” is displayed.■
When using Bluetooth ®
audio and hands-free system at the same time
The following problems may occur. ●
The Bluetooth ®
connection may be cut.●
Noise may be heard on the Bluetooth ®
audio playback.■
About the phonebook in this system
The following data is stored for every registered phone. When another phone is
connecting, you cannot read the registered data. ●
Phonebook date ●
Call history data ●
Speed dial data ●
Image data ●
Messages ●
Quick reply messages ●
All phone settings
When you delete the phone, the above-mentioned data is also deleted. ■
When you release your car
Be sure to initialize your data. (  P. 4 2 2 )

6173-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L21U_(U) ■
About Bluetooth ®
■
Compatible models
This system supports the following service. ●
Bluetooth ®
Specification Ver. 1.1 or higher (Recommended: Ver. 2.1+EDR or
higher) ●
Profiles
• HFP (Hands Free Profile) Ver. 1.0 or higher (Recommended: Ver. 1.5 or
higher)
• OPP (Object Push Profile) Ver. 1.1 or higher
• PBAP (Phone Book Access Profile) Ver. 1.0 or higher
• MAP (Message Access Profile) Ver. 1.0 or higher
• SPP (Serial Port Profile) Ver. 1.1 or higher*
*: This profile is necessary when using Apps.
(  Navigation System Owner’s Manual)
If your cellular phone does not supp ort HFP, you cannot enter the Bluetooth ®
phone, and take OPP, PBAP, MAP or SPP service individually.
If the connected Bluetooth ®
phone version is older than recommended or incom-
patible, this function may not be used.
Please go to http:// www.lexus.com/MobileLink to find approved Bluetooth ®
phones for this system. Bluetooth is a registered trademark of
Bluetooth SIG, Inc.

6183-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L21U_(U) ■
Certification
FCC ID: AJDK041
IC: 775E-K041
This device complies with Part 15 of FCC Rules and Industry Canada licence-
exempt RSS standard(s). Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must accept any inter-
ference, including interference that may cause undesired operation of this device.
Le présent appareil est conforme aux la partie 15 des règles de la FCC et CNR
d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas
produire de brouillage, et (2 ) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouilla ge est susceptible d’en compromettre le
fonctionnement.
For vehicles sold in Canada
This device complies with RSS-310 of Indu stry Canada. Operation is subject to the
condition that this device does not cause harmful interference.
Cet appareil est conforme au CNR-310 d’Industrie Canada. Son exploitation est
autorisée sous réserve que l’appareil ne cause pas de brouillage préjudiciable.

6193-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L21U_(U) CAUTION■
FCC WARNING
This equipment complies with FCC/IC radiation exposure limits set forth for
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency
(RF) Exposure rules. This equipment has very low levels of RF energy that it
deemed to comply without maximum permis sive exposure evaluation (MPE). But it
is desirable that it should be installed and operated keeping the radiator at least 7.9
in. (20 cm) or more away from person’s body (excluding extremities: hands, wrists,
feet and ankles).
Cet équipement est conforme aux limites d’exposition aux rayonnements énon-
cées pour un environnement non contrôlé et respecte les règles les radioélectri-
ques (RF) de la FCC lignes directrices d’exposition dans le Supplément C à
OET65 et d’exposition aux fréquences ra dioélectriques (RF) CNR-102 de l’IC.
Cet équipement émet une énergie RF très faible qui est considérée conforme sans
évaluation de l’exposition maximale autorisée. Cependant, cet équipement doit
être installé et utilisé en gardant une distan ce de 7.9 in. (20 cm) ou plus entre le dis-
positif rayonnant et le corps (à l’exceptio n des extrémités: mains, poignets, pieds et
chevilles).
For vehicles sold in the USA
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.

6203-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L21U_(U) CAUTION For vehicles sold in Canada
Under Industry Canada regulations, this radio transmitter may only operate using
an antenna of a type and maximum (or lesser) gain approved for the transmitter by
Industry Canada. To reduce potential radio interference to other users, the antenna
type and its gain should be so chosen that the equivalent isotropically radiated
power (e.i.r.p.) is not more than that necessary for successful communication.
Conformément à la réglementation d’Indu strie Canada, le présent émetteur radio
peut fonctionner avec une an tenne d’un type et d’un gain maximal (ou inférieur)
approuvé pour l’émetteur par Industrie Ca nada. Dans le but de réduire les risques
de brouillage radioélectrique à l’intention des autres utilisateurs, il faut choisir le
type d’antenne et son gain de sorte que la puissance isotrope rayonnée équivalente
(p.i.r.e.) ne dépasse pas l’intensit é nécessaire à l’établissement d’une
communication satisfaisante.■
Caution while driving
Do not use the cellular phone or connect the Bluetooth ®
system.■
Caution regarding interference with electronic devices ●
Your audio unit is fi tted with Bluetooth ®
antennas. People with implantable car-
diac pacemakers, cardiac resynchronization therapy-pacemakers or implantable
cardioverter defibrillators should maintain a reasonable distance between them-
selves and the Bluetooth ®
antennas. The radio waves may affect the operation of
such devices. ●
Before using Bluetooth ®
devices, users of any electrical medical device other
than implantable cardiac pacemakers, cardiac resynchronization therapy-pace-
makers or implantable cardioverter defibrillators should consult the manufac-
turer of the device for information about its operation under the influence of radio
waves. Radio waves could have unexpected effects on the operation of such
medical devices.
NOTICE■
When leaving the vehicle
Do not leave your cellular phone in the vehicle. The inside of the vehicle may
become hot, causing da mage to the phone.
