LEXUS LX570 2014 Owners Manual

5
When trouble arises
8695-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) ■
Stopping the engine
Shift the shift lever to “P” and press th e “ENGINE START STOP” switch as you nor-
mally do when stopping the engine. ■
Replacing the key battery
As this above procedure is a temporary measure, it is recommended that the elec-
tronic key battery be replaced immediately when the battery depletes. (  P. 7 8 0 )■
Changing “ENGINE START STOP” switch modes
Within 10 seconds of the buzzer sounding, release the brake pedal and press the
“ENGINE START STOP” switch.
The engine does not start and modes will be changed each time the switch is
pressed. (  P. 1 76 )■
Alarm
Using the mechanical key to lock the doors will not set the alarm system.
If a door is unlocked using the mechanical key when the alarm system is set, the
alarm may be triggered. (  P. 1 1 9 )

8705-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) If the battery is discharged The following procedures may be used to start the engine if the vehicle’s
battery is discharged.
You can also call your Lexus dealer or qualified repair shop.
If you have a set of jumper (or booster) cables and a second vehicle
with a 12-volt battery, you can jump start your Lexus following the steps
below.
Remove the engine compartment cover.
 P. 74 8
Connect the jumper cables.
Positive (+) battery terminal on your vehicle
Positive (+) battery terminal on the second vehicle
Negative (-) battery terminal on the second vehicle
Connect the jumper cable to ground on your vehicle as shown in the
illustration. STEP 1
STEP 2

5
When trouble arises
8715-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) ■
Starting the engine when the battery is discharged
The engine cannot be started by push-starting. ■
Avoiding a discharged battery ●
Turn off the headlights and the audio system while the engine is off. ●
Turn off any unnecessary electrical compon ents when the vehicle is running at a
low speed for an extended period, such as in heavy traffic, etc.■
Charging the battery
The electricity stored in the battery will discharge gradually even when the vehicle
is not in use, due to natural discharge and the draining effects of certain electrical
appliances. If the vehicle is left for a long time, the battery may discharge, and the
engine may be unable to start. (The battery recharges automatically during driving.) ■
When the battery is removed or discharged ●
The power back door must be initialized. (  P. 6 0 )●
Make sure the key is not inside the vehicle when recharging or replacing the
battery. The key may be locked in the vehicle if the alarm is activated. (  P. 1 2 0 )Start the engine of the second vehicle. Increase the engine
speed slightly and maintain at that level for approximately 5
minutes to recharge the battery of your vehicle.
Open and close any of the do ors with the “ENGINE START
STOP” switch off.
Maintain the engine speed of th e second vehicle and turn the
“ENGINE START STOP” switch to IGNITION ON mode,
then start the vehicle’s engine.
Once the vehicle’s engine ha s started, remove the jumper
cables in the exact reverse ord er in which they were con-
nected.
Once the engine starts, have the vehicle checked at your Lexus dealer,
as soon as possible. STEP 3
STEP 4
STEP 5
STEP 6

8725-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) CAUTION■
Avoiding battery fires or explosions
Observe the following precautions to prevent accidentally igniting the flammable
gas that may be emitted from the battery. ●
Make sure the jumper cable is connected to the correct terminal and that it is not
unintentionally in contact with any pa rt other than the intended terminal.●
Do not allow the jumper cables to come into contact with the “+” and “-” termi-
nals. ●
Do not allow open flame or use matches, cigarette lighters or smoke near the
battery.■
Battery precautions
The battery contains poisonous and corrosive acidic electrolyte, while related parts
contain lead and lead compounds. Observe the following precautions when han-
dling the battery. ●
When working with the battery, always we ar safety glasses and take care not to
allow any battery fluids (acid) to come into contact with skin, clothing or the vehi-
cle body. ●
Do not lean over the battery. ●
In the event that battery fluid comes into contact with the skin or eyes, immedi-
ately wash the affected area with water and seek medical attention.
Place a wet sponge or cloth over the affected area until medical attention can be
received. ●
Always wash your hands after handling the battery support, terminals, and other
battery-related parts. ●
Do not allow children near the battery.
NOTICE■
When handling jumper cables
Be careful that the jumper cables do not become tangled in the cooling fan or any
of the belts when connectin g or disconnecting them.

5
When trouble arises
8735-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) If your vehicle overheats
Correction procedures
Stop the vehicle in a safe place and turn off the air conditioning
system, and then stop the engine.
If you see steam:
Carefully lift the hood after the steam subsides.
If you do not see steam:
Carefully lift the hood.
After the engine has cooled down
sufficiently, inspect the hoses and
radiator core (radiator) for any
leaks.
Radiator
Cooling fans If a large amount of coolant leaks,
immediately contact your Lexus
dealer.The following may indicate that your vehicle is overheating.
● The needle of the engine coolant temperature gauge (  P. 1 9 0 )
enters the red zone or a loss of engine power is experienced.
(For example, the vehicle speed does not increase.)
● Steam is coming from under the hood. STEP 1
STEP 2
STEP 3

8745-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) The coolant level is satisfactory if it
is between the “F” and “L” lines on
the reservoir.
Reservoir
“F”
“L”
Radiator cap
Add coolant if necessary.
(  P. 74 8 ) Water can be used in an emer-
gency if coolant is unavailable.
Start the engine and turn the air conditioning system on to check
that the radiator cooling fans op erate and to check for coolant
leaks from the radiator or hoses. The fans operate when the air conditio ning system is turned on immedi-
ately after a cold start. Confirm that the fans are operating by checking
the fan sound and air flow. If it is diff icult to check these, turn the air con-
ditioning system on and off repeatedly. (The fans may not operate in
freezing temperatures.)
If the fans are not operating:
Stop the engine immediately and contact your Lexus dealer.
If the fans are operating:
Have the vehicle inspected at the nearest Lexus dealer. STEP 4
STEP 5
STEP 6
STEP 7

5
When trouble arises
8755-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) CAUTION■
To prevent an accident or injury when in specting under the hood of your vehicle●
If steam is seen coming from under the hood, do not open the hood until the
steam has subsided. The engine compartm ent may be very hot, causing serious
injury such as burns. ●
Keep hands and clothing (especially a tie, a scarf or a muffler) away from the fans
and belts. Failure to do so may cause the hands or clothing to be caught, resulting
in serious injury. ●
Do not loosen the radiator cap or the c oolant reservoir cap while the engine and
radiator are hot.
Serious injury, such as burns, may resu lt from hot coolant and steam released
under pressure.
NOTICE■
When adding engine coolant
Wait until the engine has cooled do wn before adding engine coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly
can cause damage to the engine. ■
To prevent damage to the cooling system
Observe the following precautions: ●
Avoid contaminating the coolant with foreig n matter (such as sand or dust etc.).●
Do not use any coolant additives.

8765-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) If the vehicle becomes stuck
■
When it is difficult to free the vehicle
■
Extra high mode
 P. 3 2 3Carry out the following procedures if the tires spin or the vehicle becomes
stuck in mud, dirt, or snow.
Stop the engine. Set the parking brake and shift the shift lever
to “P”.
Remove the mud, snow, or sand from around the rear wheels.
Place wood, stones or some ot her material under the rear
wheels to help provide traction.
Restart the engine.
Shift the shift lever to the “D” or “R” position and release the
parking brake. Then, while exer cising caution, depress the
accelerator pedal. STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
Press to turn off Active TRAC.

5
When trouble arises
8775-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) CAUTION■
When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the surround-
ing area is clear, to avoid striking other vehicles, objects or people. The vehicle may
also lunge forward or lunge back sudden ly as it becomes free. Use extreme cau-
tion. ■
When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may cause an
accident resulting in death or serious injury.
NOTICE■
To avoid damaging the transmission and other components ●
Avoid spinning the rear wheels and depr essing the accelerator pedal more than
necessary. ●
If the vehicle remains stuck even after these procedures are performed, the vehi-
cle may require towing to be freed.

8785-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) If your vehicle has to be stopped in an emergency
CAUTION■
If the engine has to be turned off while driving
Power assist for the brakes and steering wh eel will be lost, making the brake pedal
harder to depress and the steering wheel heavier to turn. Decelerate as much as
possible before turning off the engine.Only in an emergency, such as if it becomes impossible to stop the vehicle
in the normal way, stop the vehicle using the following procedure:
Steadily step on the brake pe dal with both feet and firmly
depress it. Do not pump the brake pedal repeatedly as this will increase the
effort required to slow the vehicle.
Shift the shift lever to “N”.
If the shift lever is shifted to “N”
After slowing down, stop the vehicl e in a safe place by the road.
Stop the engine.
If the shift lever cannot be shifted to “N”
Keep depressing the brake pedal with both feet to reduce vehi-
cle speed as much as possible.
To stop the engine, press and
hold the “ENGINE START
STOP” switch for 2 consecutive
seconds or more, or press it
briefly 3 times or more in suc-
cession.
Stop the vehicle in a safe place by the road. STEP 1
STEP 2
STEP 3
STEP 4
STEP 3
STEP 4
Press and hold for 2 seconds or more,
or press briefly 3 times or more STEP 5
