411-2. Opening, closing and locking the doors
1
Before driving
LX570_OM_OM60L96U_(U) ■
Switching the door unlock function
It is possible to set which doors the entr y function unlocks using the wireless remote
control.
Turn the “ENGINE START STOP” switch OFF.
When the indicator on the key surface is turned off, press and hold
for approximately 5 seconds wh ile pressing on the key.
The setting changes each time an operation is performed, as shown below. (When
changing the setting continuously, release the buttons, wait for at least 5 seconds,
and repeat .)
To prevent unintended triggering of the alarm, unlock the doors using the wireless
remote control and open and close a door once after the settings have been
changed. (If a door is not opened with in 60 seconds after is pressed, the
doors will be locked again and the alarm will automatically be set.)
In case that the alarm is triggere d, immediately stop the alarm. (  P. 121)STEP 1
STEP 2
STEP 2
Multi-information
display Unlocking function Beep
Hold the driver’s door handle
to unlock only the driver’s
door. Exterior: Beeps three
times
Interior: Rings once
Hold either door handle to
unlock all doors. Exterior: Beeps twice
Interior: Rings once

421-2. Opening, closing and locking the doors
LX570_OM_OM60L96U_(U) ■
Battery-saving function
In the following circumstances, the entry func tion is disabled in order to prevent the
vehicle and electronic key batteries from discharging. ●
When the entry function has not been used for 2 weeks or more ●
When the electronic key has been left within approxim ately 3 ft. (1 m) of the
vehicle for 10 minutes or more
The system will resume operation when... ●
The vehicle is locked using th e door handle lock switch.●
The vehicle is locked/unlocked using the wireless remote control function
(  P. 49) or the mechanical key. (  P. 872)■
Electronic key battery depletion ●
The standard battery life is 1 to 2 years.
(The card key battery life is about a year and a half.) ●
If the battery becomes low, an alarm will sound in the cabin when the engine
stops. (  P. 44)●
The battery becomes depleted even if the electronic key is not used because
the key always receives radio waves. If the smart access system with push-but-
ton start or the wireless remote control fu nction does not operate, or the detec-
tion area becomes smaller, the battery may be depleted. Replace the battery
when necessary. (  P. 784)●
To avoid serious deterioration, do not le ave the electronic key within 3 ft. (1 m)
of the following electrical appliances that produce a magnetic field:
•TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Induction cookers
•Table lamps

431-2. Opening, closing and locking the doors
1
Before driving
LX570_OM_OM60L96U_(U) ■
To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get the
electronic key too close to the vehicle when operating the system from the outside
of the vehicle.
Depending on the position and holding cond ition of the electronic key, the key may
not be detected correctly and the system may not oper ate properly. (The alarm
may go off accidentally, or the door lock prevention may not function.) ■
Note for the entry function ●
Even when the electronic key is within the effective range (detection areas), the
system may not operate properly in the following cases:
• The electronic key is too close to the window or outside door handle, near the
ground, or in a high place when the doors are locked or unlocked.
• The electronic key is near the ground or in a high place, or too close to the
rear bumper center when the back door is locked or unlocked.
• The electronic key is on the instrument panel, floor or in the glove box when
the engine is started or “ENGINE ST ART STOP” switch modes are changed.●
Do not leave the electronic key on top of the instrument panel or near the door
pockets when exiting the vehicle. Depending on the radio wave reception con-
ditions, it may be detected by the antenna outside the cabin and the door will
become lockable from the outside, possibly trapping the electronic key inside
the vehicle. ●
As long as the electronic key is within the effective range, the doors may be
locked or unlocked by anyone. ●
Even if the electronic key is not inside the vehicle, it may be possible to start the
engine if the electronic key is near the window. ●
The doors may unlock if a large amount of water splashes on the door handle,
such as in the rain or in a car wash. (T he doors will automatically be locked after
approximately 60 seconds if the doors are not open ed and closed.)●
Gripping the door handle when wear ing a glove may not unlock the door.●
If the wireless remote control is used to lock the doors when the electronic key
is near the vehicle, there is a possibility that the door may not be unlocked by the
entry function. (Use the wireless remote control to unlock the doors.) ●
A sudden approach to the effective ra nge or door handle operation may pre-
vent the doors from being unlocked. In th is case, return the door handle to the
original position and check that the do ors unlock before pulling the door han-
dle.

441-2. Opening, closing and locking the doors
LX570_OM_OM60L96U_(U) ■
When the vehicle is not driven for extended periods
To prevent theft of the vehicle, do not leav e the electronic key within 6 ft. (2 m) of
the vehicle. ■
Security feature
If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature auto matically locks the vehicle again.■
Alarms and warning indicators
A combination of exterior and interior alarms as well as warnings displayed on the
multi-information display are used to prevent theft of the vehicle and unforeseeable
accidents resulting from erroneous operat ion. Perform the appropriate correction
procedure described in the following table.
Alarm Situation Correction procedure
Exterior alarm
sounds once for
2 seconds An attempt was made to lock
the doors using the entry
function while the electronic
key was still inside the pas-
senger compartment Retrieve the electronic
key from the passenger
compartment and lock
the doors again
Exterior alarm
sounds once for
60 seconds An attempt was made to exit
the vehicle and lock the
doors without first turning the
“ENGINE START STOP”
switch OFF Turn the “ENGINE
START STOP” switch
OFF and lock the doors
again
Exterior alarm
sounds once for
5 seconds An attempt was made to lock
the vehicle while a door is
open Close all of the doors
and lock the doors again

451-2. Opening, closing and locking the doors
1
Before driving
LX570_OM_OM60L96U_(U) Alarm Situation Correction procedure
Interior alarm pings
continuously The “ENGINE START
STOP” switch was turned to
ACCESSORY mode while
the driver’s door was open
(or the driver’s door was
opened while the “ENGINE
START STOP” switch was in
ACCESSORY mode) Turn the “ENGINE
START STOP” switch
OFF and close the
driver’s door
The “ENGINE START
STOP” switch was turned
OFF while the driver’s door
was open Close the driver’s door
Interior alarm
sounds continu-
ously
* 1
When the “ENGINE START
STOP” switch is in IGNI-
TION ON or ACCESSORY
mode, an attempt was made
to open the door and exit the
vehicle, and the shift lever
was not in “P” Shift the shift lever to “P”
and turn the “ENGINE
START STOP” switch
OFF
Interior and exte-
rior alarms sound
continuously
* 1
When the “ENGINE START
STOP” switch is in IGNI-
TION ON or ACCESSORY
mode, the driver’s door was
closed after the key was car-
ried outside the vehicle, and
the shift lever not in “P” Shift the shift lever to
“P”, turn the “ENGINE
START STOP” switch
OFF and close the
driver’s door again

461-2. Opening, closing and locking the doors
LX570_OM_OM60L96U_(U) * 1
: A warning message will be shown on the multi-information display in the instru-
ment cluster.
* 2
: If the engine does not start when the electronic key is inside the vehicle, the
electronic key battery may be depleted or there may be difficulties receiving
signal from the key. (  P. 40)Alarm Situation Correction procedure
Interior alarm pings
once
* 1
The electronic key has a low
battery Replace the electronic
key battery
An attempt was made to start
the engine without the elec-
tronic key being present, or
the electronic key was not
functioning normally Start the engine with the
electronic key
present
* 2
Interior alarm pings
once and exterior
alarm sounds 3
times
* 1
The driver’s door was closed
after the key was carried out-
side the vehicle, and the
“ENGINE START STOP”
switch was not turned OFF Turn the “ENGINE
START STOP” switch
OFF and close the
driver’s door again
An occupant carried the
electronic key outside the
vehicle and closed the door
while the “ENGINE START
STOP” switch was not OFF Bring the electronic key
back into the vehicle

471-2. Opening, closing and locking the doors
1
Before driving
LX570_OM_OM60L96U_(U) ■
If the smart access system with push-button start does not operate properly ●
Locking and unlocking the doors: Use the mechanical key. (  P. 872)●
Starting the engine:  P. 873■
When the electronic key battery is fully depleted
 P. 784■
Customization
Settings (e.g. smart access system with push-button start) can be changed.
(Customizable features  P. 912)■
Certification for the smart access system with push-button start
For vehicles sold in the U.S.A ., Hawaii, Guam and Puerto Rico
For vehicles sold in Canada

481-2. Opening, closing and locking the doors
LX570_OM_OM60L96U_(U) CAUTION■
Caution regarding interference with electronic devices ●
People with implantable cardiac pacemakers, cardiac resynchronization ther-
apy-pacemakers or implantable cardiove rter defibrillators should keep away
from the smart access system antennas. (  P. 39)
The radio waves may affect the operation of such devices. If necessary, the entry
function can be disabled. Ask your Lexus de aler for details, such as the frequency
of radio waves and timing of the emitte d radio waves. Then, consult your doctor
to see if you should disable the entry function. ●
Users of any electrical medical device other than implantable cardiac pacemak-
ers, cardiac resynchronization therapy- pacemakers or implantable cardioverter
defibrillators should consult the manufacturer of the device for information about
its operation under the influence of radio waves.
Radio waves could have unexpected effects on the operation of such medical
devices.
Ask your Lexus dealer for details on disabling the entry function.■
When using the smart access system with push-button start and operating the
power windows and moon roof
Operate the power window or moon roof af ter checking to make sure that there is
no possibility of any passenger having any of their body parts caught in the window
or moon roof. Also, do not allow children to operate the wireless remote control. It
is possible for children and other passengers to get caught in power window and
moon roof.

4911-2. Opening, closing and locking the doors
Before driving
LX570_OM_OM60L96U_(U) Wireless remote control The wireless remote control can be us ed to lock and unlock the vehicle
from outside the vehicle.
Locks all doors Check that the door is securely
locked.
Unlocks all doors Pressing the button unlocks the
driver’s door. Pressing the but-
ton again within 3 seconds
unlocks the other doors.
Opens the windows and
moon roof (press and hold)
*Opens/closes the back door
(press and hold)
Sounds alarm (press and
hold) (  P. 123)
* : This setting must be customized
at your Lexus dealer.

501-2. Opening, closing and locking the doors
LX570_OM_OM60L96U_(U) ■
Operation signals ●
Doors: A buzzer sounds and the emergenc y flashers flash to indicate that the
doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ●
Windows and moon roof: A buzzer sounds to indicate that the windows and
moon roof are opening.■
Operating conditions
The wireless remote control will not operate when the “ENGINE START STOP”
switch is in any position other than OFF. ■
Door lock buzzer
If a door is not fully closed, a buzzer soun ds continuously for 5 seconds if an attempt
to lock the door is made. Fully close the d oor to stop the buzzer, and lock the vehi-
cle once more. ■
Power back door operation
The power back door can be opened while the vehicle is locked. (one motion) ■
Alarm
Using the wireless remote control to lock the door will set the alarm system. ■
Electronic key battery depletion
 P. 42■
Security feature
 P. 44■
If the wireless remote control does not operate properly ●
Locking and unlocking the doors: Use the mechanical key. (  P. 872)●
Starting the engine:  P. 873■
When the electronic key battery is fully depleted
 P. 784■
Conditions affecting operation
 P. 40■
Customization
Settings (e.g. unlocking fu nction) can be changed.
(Customizable features  P. 912)
